Vigor2135 Series

Gigabit Broadband Router

Quick Start Guide

(for RF Model)

Version: 1.2

Firmware Version: V4.4.2

(For future update, please visit DrayTek web site)

Date: October 26, 2022

iii

Intellectual Property Rights (IPR) Information

by copyright. No part may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language without written permission

from the copyright holders.

Trademarks The following trademarks are used in this document:

Microsoft is a registered trademark of Microsoft Corp.

Windows 8, 10, 11 and Explorer are trademarks of Microsoft Corp.

Apple and Mac OS are registered trademarks of Apple Inc.

Other products may be trademarks or registered trademarks of their

respective manufacturers.

Safety Instructions and Approval

Safety

Instructions

Read the installation guide thoroughly before you set up the router.

The router is a complicated electronic unit that may be repaired only be

authorized and qualified personnel. Do not try to open or repair the

router yourself.

Do not place the router in a damp or humid place, e.g. a bathroom.

Do not stack the routers.

The router should be used in a sheltered area, within a temperature

range of 0 to +45 Celsius.

Do not expose the router to direct sunlight or other heat sources. The

housing and electronic components may be damaged by direct sunlight

or heat sources.

Do not deploy the cable for LAN connection outdoor to prevent

electronic shock hazards.

Keep the package out of reach of children.

When you want to dispose of the router, please follow local regulations

on conservation of the environment.

Warranty

We warrant to the original end user (purchaser) that the router will be free

from any defects in workmanship or materials for a period of two (2) years

from the date of purchase from the dealer. Please keep your purchase receipt

in a safe place as it serves as proof of date of purchase. During the warranty

period, and upon proof of purchase, should the product have indications of

failure due to faulty workmanship and/or materials, we will, at our discretion,

repair or replace the defective products or components, without charge for

either parts or labor, to whatever extent we deem necessary tore-store the

product to proper operating condition. Any replacement will consist of a new

or re-manufactured functionally equivalent product of equal value, and will

be offered solely at our discretion. This warranty will not apply if the product

is modified, misused, tampered with, damaged by an act of God, or subjected

to abnormal working conditions. The warranty does not cover the bundled or

licensed software of other vendors. Defects which do not significantly affect

the usability of the product will not be covered by the warranty. We reserve

the right to revise the manual and online documentation and to make changes

from time to time in the contents hereof without obligation to notify any

person of such revision or changes.

Declaration of Conformity

Hereby, DrayTek Corporation declares that the radio equipment type Vigor2135 series router is in

compliance with Directive 2014/53/EU.

The full text of the EU Declaration of Conformity is available at the following internet address:

https://fw.draytek.com.tw/Vigor2135/Document/CE/

Manufacturer: DrayTek Corp.

Address: No.26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan

Product: Vigor2135 Wireless Series

Frequency Information for Europe area:

2.4GHz WLAN For ac model, 2400MHz - 2483MHz, max. TX power: 19.79dBm *1

For ax model, 2400MHz - 2483MHz, max. TX power: 19.81dBm *1

5GHz WLAN For ac model,

5150MHz - 5350MHz, max. TX power: 22.74dBm *2

5470MHz - 5725MHz, max. TX power: 29.88dBm *2

For ax model,

5150MHz - 5350MHz, max. TX power: 22.70dBm *2

5470MHz - 5725MHz, max. TX power: 29.47dBm *2

Requirements in AT/BE/BG/CZ/DZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/

CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/HR.

5150MHz~5350MHz is for indoor use only.

(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)

This product is designed for 2.4GHz /5GHz WLAN network throughout the EC region.

Declaration of Conformity

Hereby, DrayTek Corporation declares that the radio equipment type Vigor2135 series router is in

compliance with Regulation SI 2017 No. 1206.

Manufacturer: DrayTek Corp.

Address: No. 26, Fushing Rd., Hukou, Hsinchu Industrial Park, Hsinchu 303, Taiwan

Product: Vigor2135 Wireless Series

Importer: CMS Distribution Ltd: Bohola Road, Kiltimagh, Co Mayo, Ireland

Frequency Information for UK area:

2.4GHz WLAN For ac model, 2400MHz - 2483MHz, max. TX power: 19.79dBm *1

For ax model, 2400MHz - 2483MHz, max. TX power: 19.81dBm *1

5GHz WLAN For ac model,

5150MHz - 5350MHz, max. TX power: 22.74dBm *2

5470MHz - 5725MHz, max. TX power: 29.88dBm

For ax model,

5150MHz - 5350MHz, max. TX power: 22.70dBm *2

5470MHz - 5725MHz, max. TX power: 29.47dBm

Requirements in UK. 5150MHz~5350MHz is for indoor use only.

(*1: for 2.4GHz WLAN model; *2: for 5GHz WLAN model)

This product is designed for 2.4GHz /5GHz WLAN network use in the UK & Ireland.

External Power Supply ErP Information

*The external power supply used for each product will be model dependent.

1 2 3 4 5 6 7 8 9

A Manufacturer CWT CWT CWT CWT CWT APD APD APD APD

B Address No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No. 222, Sec.

2, Nankan Rd.,

Lujhu

Township,

Taoyuan

County 338,

Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

No.5, Lane 83,

Lung-Sou St.,

Taoyuan City

330, Taiwan

2ABB012F UK 2ABB018F UK 2ABL024F UK

2ABL030F UK

2ABN036F UK

WA-12M12FG

WB-18D12FG WA-24Q12FG WA-36A12FG

C Model identifier 2ABB012F EU 2ABB018F EU 2ABL024F EU

2ABL030F EU

2ABN036F EU

WA-12M12FK

WB-18D12FK WA-24Q12FK WA-36A12FK

D Input voltage 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V 100~240V

Input AC frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60HzE Output voltage DC 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V 12.0V

F Output current 1.0A 1.5A 2.0A 2.5A 3.0A 1.0A 1.5A 2.0A 3.0A

G Output power 12.0W 18.0W 24.0W 30.0W 36.0W 12.0W 18.0W 24.0W 36.0W

H Average active

efficiency 84.9% 86.2% 87.6% 87.8% 89.8% 83.7% 85.4% 88.6% 88.2%

I Efficiency at low load

10% 73.6% 78.0% 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4%

J No-load power

consumption 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W

For more update, please visit www.draytek.com.

Regulatory Information

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and

(2) This device may accept any interference received, including interference that may cause

undesired operation.

RF Exposure Warning

This equipment must be installed and operated in accordance with provided instructions and the

antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20

cm from all persons and must not be co-located or operating in conjunction with any other antenna or

transmitter. End-users and installers must be provided with antenna installation instructions and

transmitter operating conditions for satisfying RF exposure compliance.

Company name ABP International Inc.

Address 13988 Diplomat Drive Suite 180 Dallas TX 75234

ZIP Code 75234 E-mail rmesser@abptech.com

USA Local

Representative Contact Person Mr. Robert Messer

Tel. 19728311600

Caution

Any changes or modifications not expressly approved by the grantee of this device could void the

user's authority to operate the equipment.

The antenna/transmitter should be kept at least 20 cm away from human body.

vii

1. Package Content .................................................................................................. 1

2. Panel Explanation................................................................................................. 2

2.1 Vigor2135ac, Vigor2135Vac, Vigor2135FVac............................................................................ 2

2.2 Vigor2135ax............................................................................................................................... 5

3. Hardware Installation ........................................................................................... 7

3.1 Network Connection for ac series.............................................................................................. 7

3.2 Network Connection for ax series.............................................................................................. 8

3.3 Wall-Mounted Installation for ac series...................................................................................... 9

3.4 Wall-Mounted Installation for ax series ....................................................................................10

4. Software Configuration.......................................................................................11

5. Customer Service............................................................................................... 17

Take a look at the package content. If there is anything missed or damaged,

please contact DrayTek or dealer immediately.

Vigor2135ac series Vigor2135ax

RJ-45 Cat-5 Ethernet Cable Antenna (for Vigor2135ac series)

& Quick Start Guide

The type of the power adapter depends on the country that the router will be

installed. * The maximum power consumption is 18 Watts.

UK-type Power Adapter EU-type Power Adapter

USA/Taiwan-type Power Adapter AU/NZ-type Power Adapter

Note

Remove the protective film from the router before use to

ensure ventilation.

LED Status Explanation

Blinking The router is powered on and running normally.

Blinking

(quickly) When both ACT and WLAN LEDs blink quickly, it

means the WPS function is enabled and active. The

system is waiting for a wireless station of

connection.

(Activity)

Off The router is powered off.

On Internet connection is ready.

Blinking The data is transmitting.

WAN Off Internet connection is not ready.

On The phone connected to this port is off-hook.

Off The phone connected to this port is on-hook.

1, 2

(for “V” model) Blinking A phone call comes.

On Wireless access point is ready.

Blinking Ethernet packets are transmitting over wireless LAN.

Blinking

(quickly) When both ACT and WLAN LEDs blink quickly, it

means the WPS function is enabled and active. The

system is waiting for a wireless station of

connection.

WLAN

Off The WLAN function is inactive.

On The LAN port is connected.

Blinking The data is transmitting.

LAN1/2/3/4 Off The LAN port is disconnected.

On A USB device is connected and active.

USB Blinking The data is transmitting.

Interface Description

Wireless LAN

ON/OFF/WPS WLAN On - Press the button and release it within 2 seconds. When

the wireless function is ready, the green LED will be on.

WLAN Off - Press the button and release it within 2 seconds to turn

off the WLAN function. When the wireless function is not ready, the

LED will be off.

WPS - When WPS function is enabled by web user interface, press

this button for morethan 2 seconds to wait for client’s device making

network connection through WPS.

Factory Reset Restore the default settings.

Usage: Turn on the router (ACT LED is blinking). Press the hole and

keep for more than 5 seconds. When you see the ACT LED begins to

blink rapidly than usual, release the button. Then the router will

restart with the factory default configuration.

USB1~USB2 Connector for a USB device (USB Modem or printer).

P4~P1 Connectors for local networked devices.

Autres manuels pour Vigor2135 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Draytek Routeur réseau

Draytek

Draytek Vigor2500 series Manuel utilisateur

Draytek

Draytek Vigor2710 Series Manuel utilisateur

Draytek

Draytek VigorPro 5510 Series Manuel utilisateur

Draytek

Draytek Vigor 2820 Series Guide de référence

Draytek

Draytek Vigor2910 Series Manuel utilisateur

Draytek

Draytek Vigor2760 Manuel utilisateur

Draytek

Draytek Vigor2122 Series Manuel utilisateur

Draytek

Draytek Vigor 2800 Manuel utilisateur

Draytek

Draytek Vigor2910 Series Manuel utilisateur

Draytek

Draytek Vigor 2800G Guide de référence

Draytek

Draytek Vigor2760 Manuel utilisateur

Draytek

Draytek Vigor2600VG Manuel utilisateur

Draytek

Draytek Vigor2110 Series Manuel utilisateur

Draytek

Draytek Vigor Router 11ax Series Manuel utilisateur

Draytek

Draytek Vigor2920 Series Manuel utilisateur

Draytek

Draytek Vigor 2620 Series Manuel utilisateur

Draytek

Draytek Vigor3300V+ Manuel utilisateur

Draytek

Draytek Vigor2927 Series Manuel utilisateur

Draytek

Draytek Vigor2765 Series Manuel utilisateur

Draytek

Draytek Vigor 2800Gi Guide de référence

Draytek

Draytek VigorAP 1060C Manuel utilisateur

Draytek

Draytek Vigor 3100 Series Manuel utilisateur

Draytek

Draytek Vigor2500V Manuel utilisateur

Draytek

Draytek VigorPro 5300 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
