CDF18, CDF26, CDF36, CDF46

Compressor Cooler

Operating manual . . . . . . . . . . . . . . . . . . . . .4

COOLING BOXES

COOLFREEZE

CDF18-26-36-46--O-16s.book Seite 1 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze

12/24V DC

COLD FREEZE

ERROR

POWER

HIGH

LOW

TEMPERATURE BATTERY MONITOR

CDF18

2 3 4

12/24V DC

CDF26, CDF36, CDF46

ERROR

POWER

CDF26

134 5 6 7

CDF18-26-36-46--O-16s.book Seite 2 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze

ERROR

POWER

CDF36, CDF46

134 5 6

1 2 3

CDF26, CDF36, CDF46

1 2

CDF18-26-36-46--O-16s.book Seite 3 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is passed on to

another person, this operating manual must be handed over to the user

along with it.

The manufacturer cannot be held liable for damage resulting from improper usage

or incorrect operation.

Contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Function description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

8 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

11 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

CDF18-26-36-46--O-16s.book Seite 4 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze Explanation of symbols

1 Explanation of symbols

2 Safety instructions

2.1 General safety

!WARNING!

•Do not operate the device if it is visibly damaged.

•If this device's power cable is damaged, it must be replaced by the

manufacturer, customer service or a similarly qualified person in order

to prevent safety hazards.

•This device may only be repaired by qualified personnel. Improper

repairs can lead to considerable hazards.

•This device can be used by childrenaged 8 years or over, as well as by

persons with diminished physical, sensory or mental capacities or a

lack of experience and/or knowledge, providing they are supervised

or have been taught how to use the device safely and are aware of the

resulting risks.

•Cleaning and user maintenance must not be carried out by children

without supervision.

•Children must not play with the device.

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

CDF18-26-36-46--O-16s.book Seite 5 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

Safety instructions CoolFreeze

•Children must be supervised to ensure that they do not play with the

device.

•Always keep and use the device out of the reach of children under the

age of 8 years.

•Do not store any explosive substances such as spray cans with a

flammable propellant in the device.

!CAUTION!

•Disconnect the device from the power supply

– before each cleaning and maintenance

– after every use

•Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

•Check that the voltage specification on the type plate corresponds to

that of the energy supply.

•Only connect the device to a DC plug socket in the vehicle (e. g.

cigarette lighter) with the DC cable.

•Never pull the plug out of the socket by the cable.

•Disconnect the cooler and other power consuming devices from the

battery before connecting the quick charging device.

•Disconnect the cooler or switch it off when you turn off the engine.

Otherwise you may discharge the battery.

•The cooling device is not suitable for transporting caustic materials or

materials containing solvents.

•The cooling device contains inflammable cyclopentane in the

insulation. The gases in the insulation material require special disposal

procedures. Deliver the device at the end of its life-cycle to an appro-

priate recycling.

2.2 Operating the device safely

!CAUTION!

•Before starting the device, ensure that the power supply line and the

plug are dry.

ANOTICE!

•Do not use electrical devices inside the cooler unless they are

recommended by the manufacturer for the purpose.

CDF18-26-36-46--O-16s.book Seite 6 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze Scope of delivery

•Do not place the device near naked flames or other heat sources

(heaters, direct sunlight, gas ovens etc.).

•Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the heat that

arises during operation does not build up. Make sure that the device

is sufficiently far away from walls and other objects so that the air can

circulate.

•Ensure that the ventilation openings are not covered.

•Do not fill the inner container with ice or fluid.

•Never immerse the device in water.

•Protect the device and the cable against heat and moisture.

3Scopeofdelivery

fig. 1, page 2, shows the scope of delivery.

4Accessories

To operate the cooler using an AC power supply, we recommend using the

following mains adapter.

Available as accessory (not included in scope of delivery):

•220–240 V: CoolPower EPS100

•110–240 V: CoolPower MPS35

Item Quantity Description

1 1 Compressor cooler

2 1 Connection cable for DC connection

– 1 Operating manual

CDF18-26-36-46--O-16s.book Seite 7 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

Intended use CoolFreeze

5 Intended use

The compressor cooler is suitable for cooling and freezing foodstuffs. The compres-

sor cooler is also suitable for use on boats.

The compressor cooler is designed to be operated from a 12 Vgor 24 Vgon-

board socket of a vehicle (e.g. DC socket), boat or mobile home.

6 Function description

The cooler can chill products, keep them cool as well as freeze them. A mainte-

nance-free, CFC-free refrigerant circuit with compressor provides the cooling. The

extra strong CFC-free insulation and powerful compressor ensure especially fast

cooling.

The cooler is designed for mobile use.

When used on boats, the cooler can be withstand a constant heel (inclination) of 30°.

An integrated dual-stage (CDF18) / three-stage (CDF26, CDF36, CDF46) battery

monitor prevents your vehicle battery from excessive discharging.

NOTE

To operate the device at the AC mains supply, we recommend using

one of the following rectifiers:

•220–240 V: CoolPower EPS100

•110–240 V: CoolPower MPS35

CAUTION! Health hazard!

Please check if the cooling capacity of the device is suitable for storing

the food or medicine you wish to cool.

CDF18-26-36-46--O-16s.book Seite 8 Montag, 7. November 2016 2:13 14

Autogoods “130”

130.com.ua

CoolFreeze Function description

6.1 Operating and display elements

CDF18

Operating panel and connection socket (fig. 2, page 2):

Item Description Explanation

1 TEMPERATURE Temperature controller,

cooling temperature at the end positions:

COLD: +10 °C

FREEZE: –18 °C

2 POWER Operating display

LED is lit green: Device is switched on and ready for

operation

LED is lit yellow: Set temperature has been reached

3 ERROR LED flashes red: Switched on device is not ready for

operation

4 BATTERY MONITOR Switch-on device/battery monitor:

0: Device is switched off

HIGH: Device is switched on, battery

monitor is in HIGH mode

LOW: Device is switched on, battery

monitor is in LOW mode

5 12/24V DC Connection socket DC voltage supply
