Dometic CDF-11 Manuel utilisateur

CDF11

Compressor Cooler

Operating manual

PORTABLE REFRIGERATION

CDF SERIES

CDF11-O-AU.book Seite 1 Donnerstag, 19. Oktober 2017 2:51 14

CDF11-O-AU.book Seite 2 Donnerstag, 19. Oktober 2017 2:51 14

CoolFreeze CDF11

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is passed on to

another person, this operating manual must be handed over to the user

along with it.

The manufacturer cannot be held liable for damage resulting from improper usage

or incorrect operation.

Contents

1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

4 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

7 Cleaning and maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

8 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

10 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

CDF11-O-AU.book Seite 3 Donnerstag, 19. Oktober 2017 2:51 14

Explanation of symbols CoolFreeze CDF11

1 Explanation of symbols

WARNING!

Safety instruction: Failure to observe this instruction can cause fatal or

serious injury.

CAUTION!

Safety instruction: Failure to observe this instruction can lead to injury.

NOTICE!

Failure to observe this instruction can cause material damage and impair

the function of the product.

NOTE

Supplementary information for operating the product.

CDF11-O-AU.book Seite 4 Donnerstag, 19. Oktober 2017 2:51 14

CoolFreeze CDF11 Safety instructions

2 Safety instructions

2.1 General safety

!WARNING!

•Do not operate the cooling device if it is visibly damaged.

•If this cooling device's power cable is damaged, it must be replaced

by the manufacturer, customer service or a similarly qualified person in

order to prevent safety hazards.

•This cooling device may only be repaired by qualified personnel.

Improper repairs can lead to considerable hazards.

•This cooling device can be used by children aged 8 years or over, as

well as by persons with diminished physical, sensory or mental capac-

ities or a lack of experience and/or knowledge, providing they are

supervised or have been taught how to use the cooling device safely

and are aware of the resulting risks.

•Cleaning and user maintenance must not be carried out by children

without supervision.

•Children must not play with the cooling device.

•Children must be supervised to ensure that they do not play with the

cooling device.

•Always keep and use the cooling device out of the reach of children

under the age of 8 years.

•Do not store any explosive substances such as spray cans with a

flammable propellant in the cooling device.

!CAUTION!

•Disconnect the cooling device from the power supply

– before each cleaning and maintenance

– after every use

•Food may only be stored in its original packaging or in suitable

containers.

ANOTICE!

•Check that the voltage specification on the type plate corresponds to

that of the energy supply.

•Only connect the cooling device to a DC power supply in the vehicle

with the DC cable.

CDF11-O-AU.book Seite 5 Donnerstag, 19. Oktober 2017 2:51 14

Safety instructions CoolFreeze CDF11

•Never pull the plug out of the socket by the cable.

•Disconnect the cooling device and other power consuming devices

from the battery before connecting a quick charging device.

•Disconnect the cooling device or switch it off when you turn off the

engine. Otherwise you may discharge the battery.

•The cooling device is not suitable for transporting caustic materials or

materials containing solvents.

•The insulation of the cooling device contains flammable cyclopentane

and requires special disposal procedures. Deliver the cooling device

at the end of its life-cycle to an appropriate recycling.

2.2 Operating the cooling device safely

!CAUTION!

•Before starting the cooling device, ensure that the power supply line

and the plug are dry.

ANOTICE!

•Do not use electrical devices inside the cooling device unless they are

recommended by the manufacturer for the purpose.

•Do not place the cooling device near naked flames or other heat

sources (heaters, direct sunlight, gas ovens etc.).

•Danger of overheating!

Ensure at all times that there is sufficient ventilation so that the heat that

arises during operation does not build up. Make sure that the cooling

device is sufficiently far away from walls and other objects so that the

air can circulate.

•Ensure that the ventilation openings are not covered.

•Do not fill the inner container with ice or fluid.

•Never immerse the cooling device in water.

•Protect the cooling device and the cable against heat and moisture.

CDF11-O-AU.book Seite 6 Donnerstag, 19. Oktober 2017 2:51 14

CoolFreeze CDF11 Scope of delivery

3Scopeofdelivery

•Cooling device

•Connection cable for 12/24 Vgconnection

•Carry strap

4Intendeduse

The cooler CDF11 is suitable for cooling and freezing foodstuffs.

The cooler is designed to be operated from:

•a DC on-board power supply of a vehicle, boat or caravan

•a DC auxiliary battery

The appliance may also be used for camping use. The appliance shall not be

exposed to rain.

CAUTION! Health hazard!

Please check if the cooling capacity of the device is suitable for storing

the food or medicine you wish to cool.

NOTE

To operate the device using a 220 – 240 Vwmains supply, we

recommend using a rectifier (accessory).

CDF11-O-AU.book Seite 7 Donnerstag, 19. Oktober 2017 2:51 14

Technical description CoolFreeze CDF11

5 Technical description

The cooler can chill products, keep them cool as well as freeze them. A

maintenance-free refrigerant circuit with compressor provides the cooling.

The cooler is suitable for mobile use.

When used in vehicles the cooler can be secured with the seat belt.

If an error occurs within the interior electronics, the cooling can be kept by using an

emergency switch.

5.1 Description of the device

EMERGENCY OVERRIDE

NORMAL USE

10 9

23 4567

CDF11-O-AU.book Seite 8 Donnerstag, 19. Oktober 2017 2:51 14

CoolFreeze CDF11 Technical description

Item Description

1 Control panel

2Cupholder

3 Fixing position for seat belt

4 Interior LED light

5 Cooling compartment

6 Freezer compartment

7 Lock

8 Skid proof pad

9Handles

10 Carry strap

11 Connection socket

12 Emergency switch

CDF11-O-AU.book Seite 9 Donnerstag, 19. Oktober 2017 2:51 14

Technical description CoolFreeze CDF11

5.2 Control panel

Item Description Explanation

1 On/Off button Switches the cooler on or off when the button is pressed for

between one and two seconds

2 POWER Status indication

LED lights up green Compressor is on; preset

temperature isn’t reached

yet

LED lights up orange Preset temperature is

reached

LED flashes orange Insufficient voltage

3 ERROR LED flashes red Device is switched on but

not ready for operation

4 SET Selects the input mode

•Set Temperature

•Set temperature unit (Celsius or Fahrenheit)

•Set battery monitor

5 Display Shows the temperature inside the cooling compartment

The first three digits of the four-digit display show the

temperature, the fourth digit shows the temperature unit

(°C or °F).

In case of an error the display shows the error message

“Err1” or “Err2”.

6 + Press once to increase the value

7 – Press once to decrease the value

POWER

FRIDGE FREEZER

ERROR

12 34 5 6 7

CDF11-O-AU.book Seite 10 Donnerstag, 19. Oktober 2017 2:51 14
