Dodge 2009 Dakota Manuel utilisateur

2009

QUICK REFERENCE GUIDE

DAKOTA

175476_09a_Dakota_102408.indd 6 4/24/09 1:45:03 PM

MANUAL CLIMATE CONTROLS

AIR RECIRCULATION

 Use recirculation for maximum A/C operation.

 For window defogging, turn recirculation off.

 Recirculation is not allowed in defrost or defrost/ﬂoor

(mix) modes.

uconnect™phone

 uconnect™phone is a voice-activated, hands-free, in-vehicle,

communications system. uconnect™phone allows you to

dial a phone number with your cellular phone using

voice commands.

uconnect™phone requires a cellular phone equipped with

the Bluetooth®Hands-Free Proﬁle, Version 0.96 or higher.

See the www.dodge.com/uconnect website for supported

phones. Refer to your Owner’s Manual for further information.

REAR CARGO AREA UTILITY RAILS

 There are four adjustable cleats in the pick-up bed that can be

used to assist in securing cargo. Each cleat must be located

and tightened down in one of the detents along either rail, in

order to keep cargo properly secure.

 Refer to Owner’s Manual for further details.

Rotate

Blower

Control

Rotate

Temperature

Control

Rotate

Mode

Control

Push

A/C

Button

Air

Recirc.

Push Rear

Window

Defroster

Button

175476_09a_Dakota_102408.indd 2 4/24/09 1:44:37 PM

DRIVER’S SEAT ADJUSTMENT

SEAT ADJUSTMENT

 On manual seats, the adjusting lever controls forward

and rearward seat adjustment.

The recline lever controls the seatback adjustment.

Rotate the dial located on the outboard side of the seatback

to adjust lumbar “lower back” support.

 Up, down, forward, rearward, and tilt adjustment are power

seat adjustments.

REAR “CRATE ‘N GO” STORAGE

 The rear “Crate ‘n Go” storage, located under the rear

seat lower cushion, consists of two removable, collapsible

storage crates.

 To open the crates, lift upwards on the crate handles, and

engage the crate end ﬂaps.

 To remove the crate, press on the release lever, located on the

ends of the base, and lift up on the crate.

 To install the crate into the base, insert the crate into the

inboard slot and push down on the outboard side of the crate,

then snap into place.

 To collapse the crate, push the crate end ﬂaps inward to

disengage. Push the sides inward and snap into the base.

 Refer to Owner’s Manual for further details.

Recline

Up, Down, Forward,

and Rearward Lumbar Dial

175476_09a_Dakota_102408.indd 3 4/24/09 1:44:42 PM

VEHICLE FEATURES

Fuel cap

LOOSE GAS CAP MESSAGE



tighten the gas cap until a “clicking” sound is heard.

 

  

tightening the gas cap, see your dealer.

Tire pressure MoniToring sysTeM (TpMs)



Monitoring Light will illuminate and an audible chime will sound.

  Check the inﬂation pressure of each road tire on your vehicle and

inﬂate to the recommended cold pressure value, shown on the placard

located in the driver’s door opening. The TPMS display should not be

used as a tire pressure gauge when adjusting your tire pressure.

   

recognized. The vehicle may need to be driven for up to 10 minutes

above 15 mph (25 km/h) before the light will turn off.

  Temperature changes can affect tire pressures, causing the TPMS light

to turn on. Colder temperatures will decrease tire pressure and

warmer temperatures will increase tire pressure.

   

Refer to your Owner’s Manual.

oil change indicaTor

MESSAGE

 

single chime sounds, it is time for your next required oil change.

RESETTING LIGHT AFTER SERVICING

 

 

 

175476_09a_Dakota_102408.indd 4 4/24/09 1:44:44 PM

VEHICLE FEATURES

clock seTTing

NON-TOUCH-SCREEN RADIOS

 

SCROLL control knob to set the hours.

 

turn the TUNE/SCROLL control knob to set the minutes.

 

TOUCH-SCREEN RADIOS

  

  

 

Radio Only).

 

backward button.

 

minute backward button.

 

is displayed.

SPARE TIRE REMOVAL

 The scissor jack and tire changing tools on Extended Cab models are

located behind a panel on the outboard side of the right rear passenger

seat. On Crew®Cab models, the scissor jack and tire changing tools

are located below the right rear seat.

 Remove the jack from the stowage compartment.

 Assemble jacking tools.

 Locate the tire carrier access hole on the rear bumper.

 Place assembled jack tool extension rod into the access hole in the

direction of the arrow on the bumper trim.

 Rotate the tool counterclockwise to release and lower the spare tire to

the ground so that it can be pulled out from under the vehicle.

 Refer to Owner’s Manual for proper jacking and tire change procedures.

175476_09a_Dakota_102408.indd 5 4/24/09 1:44:45 PM

Headlight Switch

(Behind Steering Wheel)

Turn Signals/Wiper/

Washer/High Beams Lever

(Behind Steering Wheel)

Speed Control

Switches

Instrument

Cluster

INSTRUMENT PANEL

175476_09a_Dakota_102408.indd 7 4/24/09 1:45:08 PM

Instrument

Cluster

Column

Shift Lever

Audio System

(Non-Touch-Screen

Radio Shown)

Power Outlet

Climate

Controls

INSTRUMENT PANEL

175476_09a_Dakota_102408.indd 8 4/24/09 1:45:13 PM

Power Outlet

key Fob





 

twice within ﬁve seconds to unlock all the doors.

  

  

 

PANIC ALARM



 

time to turn the panic alarm off.

REMOTE START



Pressing the button a third time will shut the engine off.

 

ignition and turn to the ON/RUN position.

 

unless the ignition key is placed in the ON/RUN position.

 

consecutive timeouts.

VEHICLE FEATURES

Remote

Start

Lock

Unlock

175476_09a_Dakota_102408.indd 9 4/24/09 1:45:23 PM

headlighT swiTch





the second detent for headlights.

 

 

on or off based on ambient light levels.

DIMMER CONTROL

 

dim the instrument panel lights and prevent the interior lights from

illuminating when a door is opened.

  

instrument panel lights when the parking lights or headlights are on.

  

brighten the odometer and radio displays when the parking lights or

headlights are on. Refer to your multimedia or navigation user

manual for display dimming.

 

interior lighting.

FOG LIGHTS

 

once to turn the fog lights on. Push the switch a second time to turn the

fog lights off. Fog lights will not operate when the high beams are on.

 

fog lights are on.

VEHICLE FEATURES

Rotate

Headlight

Switch

AUTO

Push Fog

Lights

Rotate

Dimmer

Push

Cargo Light

175476_09a_Dakota_102408.indd 10 4/24/09 1:45:30 PM

speed conTrol

CRUISE ON/OFF

 

 

Speed Control is on.

 

SET



desired speed.

ACCEL/DECEL



hold the Decel switch to decelerate the vehicle, release the switch to

save the new set speed.

 

switch once will increase or decrease the set speed approximately

1 mph (2 km/h).

CANCEL



the set speed and maintain the set speed memory.

 

speed memory.

RESUME

 

Resume/Accel switch and release.

Push

ON/OFF Push

Resume - Accel

Push

Cancel

Push

Decel

Push

Set

175476_09a_Dakota_102408.indd 11 4/24/09 1:45:37 PM
