Dji Mavic 3 Manuel utilisateur

v1.0

Quick Start Guide

快速入门指南

快速入門指南

クイックスタートガイド

퀵 스타트 가이드

Kurzanleitung

Guía de inicio rápido

Guide de démarrage rapide

Guida di avvio rapido

Snelstartgids

Guia de início rápido

Guia de Início Rápido

Краткое руководство пользователя

CHS

CHT

PT-BR

Quick Start Guide 2

快速入门指南 11

快速入門指南 19

クイックスタートガイド27

퀵 스타트 가이드 36

Kurzanleitung 45

Guía de inicio rápido 54

Guide de démarrage rapide 63

Guida di avvio rapido 72

Snelstartgids 81

Guia de Início Rápido 99

Guia de início rápido 90

Краткое руководство пользователя 108

Contents

Aircraft

DJITM MAVICTM 3E/3T features both an infrared sensing system and

upward, downward, and horizontal omnidirectional vision systems*,

allowing for hovering and flying indoors as well as outdoors and for

automatic Return to Home while avoiding obstacles in all directions.

With a precise three-axis gimbal to stabilize the high-performance

multi-camera payload, the DJI PILOTTM 2 app can be used to view

in real-time from the cameras and take photos and videos. Built-in

DJI AirSense detects nearby aircraft in the surrounding airspace to

ensure safety, and the beacon helps identify the aircraft during flight.

The aircraft is equipped with a PSDK port to connect compatible

accessories that are used to adapt to different security, patrol

inspection, and mapping scenarios.

Mavic 3T

Mavic 3E

1. Gimbal and Camera**

2. Horizontal Omnidirectional

Vision System

3. Auxiliary Bottom Light

4. Downward Vision System

5. Infrared Sensing System

6. Front LEDs

7. Motors

8. Propellers

9. Aircraft Status Indicators

10. Landing Gears (built-in

antennas)

11. Upward Vision System

12. USB-C Port

13. microSD Card Slot

14. Battery Level LEDs

15. Intelligent Flight Battery

16. Power Button

17. Battery Buckles

18. Beacon

19. PSDK Port

* The vision and infrared sensing systems are affected by the surrounding conditions.

Read the User Manual for more information.

** The Mavic 3E and Mavic 3T are equipped with different cameras. Refer to the actual

product purchased.

Remote Controller

The DJI RC Pro Enterprise remote controller features O3 Enterprise,

the latest version of DJI’s signature OCUSYNCTM image transmission

technology, and can transmit a live HD view from the camera of the

aircraft at a distance of up to 15 km*. The remote controller has a

wide range of aircraft and gimbal controls as well as customizable

buttons. The built-in microphone allows recording voice and the 5.5-in

high brightness 1000 cd/m2screen boasts a resolution of 1920×1080

pixels. Users can connect to the internet via Wi-Fi and the Android

operating system comes with a variety of functions such as Bluetooth

and GNSS.

ENTERPRISE

10 11 12 13 14

18 19

242526

ENTERPRISE

10 11 12 13 14

18 19

242526

ENTERPRISE

10 11 12 13 14

18 19

242526

1. Control Sticks

2. Back/Function Button

3. RTH Button

4. Flight Pause Button

5. Flight Mode Switch

6. 5D Button

7. Power Button

8. Confirm Button

9. Touchscreen

10. M4 Screw Hole

11. microSD Card Slot

12. USB-C Port

13. Mini HDMI Port

14. Microphone

15. Gimbal Dial

16. Record Button

17. Antennas

18. Status LED

19. Battery Level LEDs

20. Focus/Shutter Button

21. Camera Settings Dial

22. Air Vent

23. Control Sticks Storage Slot

24. Customizable C1 Button

25. Speaker

26. Customizable C2 Button

27. Air Intake

* The remote controller can reach its maximum transmission distance (FCC) in a wide-

open area with no electromagnetic interference at an altitude of about 120 m (400 ft).

1. Watching the Tutorials

Scan the QR code or visit DJI official website to watch the tutorial

videos.

2. Charging the Battery

Charge to activate the Intelligent Flight Battery and the internal

battery of the Remote Controller before using it for the first time.

Check battery level: press once.

Power on/off: press, then press and hold.

https://www.dji.com/mavic-3-enterprise/video

B A

A B

3. Preparing the Aircraft

Unfold the front arms Unfold the rear arms

Remove the gimbal protector from the camera

Match the propellers to motors

Press the

propellers down

and rotate until

they click in place

Unfolded

• Unfold the front arms before the rear arms. All arms and propellers must be

unfolded before takeoff.

4. Preparing the Remote Controller

Attach the control sticks and

twist to secure

Unfold the antennasRemove the control

sticks from the

storage slots

• DO NOT operate other wireless devices at the same frequency as the

remote controller, to avoid signal interference.

• A warning prompt appears in DJI Pilot 2 if the transmission signal is weak.

Adjust the antennas to make sure that the aircraft is within the optimal

transmission range.

The optimal transmission range is where the antennas face the

aircraft, with the angle between the antennas and the back of the

remote controller being 180° or 270°.

DJI Pilot 2

App

5.GettingReadyforTakeo

Power on the remote

controller

Power on the aircraft Launch DJI Pilot 2

A DJI account and internet connection are required to activate the aircraft

and the remote controller. Before activating the aircraft in DJI Pilot 2, power

on the remote controller and follow the prompts to activate.

Internet

6. Flight

• Manual Takeoff/Landing

Start/Stop Motors:

perform Combination

Stick Command and

hold for two seconds.

Takeoff:

slowly push the

left control stick

(mode 2) up to

take off.

Landing:

slowly push the left

control stick (mode 2)

down until the aircraft

lands. Hold for three

seconds to stop the

motors.

• Control Stick Mode

The default control stick mode is mode 2. The left control stick

controls the altitude and heading of the aircraft, while the right

control stick controls the forward, backward, and sideward

movements.

• Always set an appropriate RTH mode and RTH altitude before takeoff.

• Press the Flight Pause button for emergency braking during flight.

Up Forward

Down

Backward

Turn Left LeftTurn Right Right

Specications

Aircraft (Model: M3E/M3T)

Takeoff Weight

(with propellers) 915 g (Mavic 3E), 920 g (Mavic 3T)

Max Takeoff Weight 1050 g

Max Ascent Speed 8 m/s (Sport mode)

6 m/s (Normal mode)

Max Descent Speed 6 m/s (Sport mode)

6 m/s (Normal mode)

Max Horizontal Speed

(near sea level, no wind)

21 m/s (Sport mode), 19 m/s (Sport mode, EU)

15 m/s (Normal mode)

Max Service Ceiling Above

Sea Level (without payload) 6,000 m

Max Flight Time

(without wind) 45 mins

Max Hover Time

(without wind) 38 mins

Max Wind Speed

Resistance 12 m/s

Operating Temperature -10° to 40° C (14° to 104° F)

GNSS GPS + Galileo + BeiDou + GLONASS (GLONASS is

supported only when RTK module is enabled)

Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz*

Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)

5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)

Interface USB-C, microSD card slot, PSDK port

Gimbal

Angular vibration range ±0.007°

Controllable Rotating

Range Tilt: -90° to +35°

Wide Camera (Mavic 3E)

Sensor 4/3 CMOS; Effective pixels: 20 MP

Lens

FOV: 84°

Format Equivalent: 24 mm

Aperture: f/2.8-f/11

Focus: 1 m to ∞(with autofocus)

Tele Camera (Mavic 3E/3T)

Sensor 1/2" CMOS; Effective pixels: 12 MP

Lens

FOV: 15°

Format Equivalent: 162 mm

Aperture: f/4.4

Focus: 3 m to ∞

Wide Camera (Mavic 3T)

Sensor 1/2" CMOS; Effective pixels: 48 MP

Lens

FOV: 84°

Format Equivalent: 24 mm

Aperture: f/2.8

Focus: 1 m to ∞

Thermal Camera (Mavic 3T)

Thermal Imager Uncooled VOx Microbolometer

Lens

DFOV: 61°

Focal Length: 9.1 mm (equivalent: 40 mm)

Aperture: f/1.0

Focus: 5 m to ∞

Infrared Temperature

Measurement Accuracy ±2° C or ±2% (using the larger value)

Intelligent Flight Battery

Capacity 5000 mAh

Standard Voltage 15.4 V

Max Charging Voltage 17.6 V

Battery Type LiPo 4S

Energy 77 Wh

Weight 335.5 g

Charging Temperature 5° to 40° C (41° to 104° F)

Battery Charger

Input 100-240 V AC, 50-60 Hz, 2.5 A

Output

Max. 100 W (Total)

When both ports are in use, the maximum output of

one of the ports is 82 W. The charger will dynamically

allocate the output of the two ports accordingly to

the power load.

Remote Controller (Model: RM510B)

Weight Approx. 680 g

Battery Li-ion (5000 mAh @ 7.2 V)

Storage Capacity ROM 64GB + expandable storage via microSD card

Operating Time 3 hrs

Operating Temperature -10° to 40° C (14° to 104° F)

Charging Temperature 5° to 40° C (41° to 104° F)

GNSS GPS + Galileo + GLONASS

O3 Enterprise

Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz*

Max Transmission

Distance

(Unobstructed, free of

interference)

15 km (FCC), 8 km (CE/SRRC/MIC)

Max Transmission

Distance**

(with interference)

Strong Interference (urban landscape, limited line of

sight, many competing signals):

1.5-3 km (FCC/CE/SRRC/MIC)

Medium Interference (suburban landscape, open line

of sight, some competing signals):

3-9 km (FCC), 3-6 km (CE/SRRC/MIC)

Weak Interference (open landscape, abundant line of

sight, few competing signals):

9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
