Dixon ZTR RAM SERIES Mode d’emploi

Safety Instructions

Operator’s Manual

RAM SERIES

ZTR

IMPORTANT - READ CAREFULLY

The Dixon® ZTR® mower is both easy and

fun to operate. However, any power mower

must be operated properly to be safe. It is

not a toy or a recreational vehicle. Before

you start to use the mower, read this

Operator’s Manual carefully. It contains

valuable information that is necessary for

the safe operation of the machine. Observe

all safety rules and become completely

familiar with the controls.

The information contained in this manual

applies to all Dixon® ZTR® RAM Series

mowers.

See your authorized Dixon® dealer for

warranty service, parts and repairs or to

answer any questions you may have about

your new Dixon® ZTR®.

TABLE OF CONTENTS

Page

SAFETY & WARNING....................................4-15

WARRANTY...................................................16-17

SPECIFICATIONS........................................18-19

SEAT ADJUSTMENT.........................................20

CONTROLS..................................................21-24

OPERATION INSTRUCTIONS....................25-35

CARE & MAINTENANCE............................36-48

STANDARD SERVICE PARTS LIST.........49-50

TROUBLESHOOTING..................................51-52

RAM SERIES

Part Number 17823-106

SAFETY

Blade Contact

Tip Over

Run Over

Back Over

RIDING LAWN MOWERS,

IF IMPROPERLY OPERATED

CAN CAUSE SERIOUS INJURY OR DEATH

Pictured below are the most common causes of injury to

the operator or bystander. Please read and understand

this manual to prevent injuries.

SAFETY

Safety Alert Symbol

When you see this symbol, BE ALERT

to the potential for injury.

Follow the recommended safety precautions and

safe operating practices.

DANGER

(highlighted in red)

indicates an imminently hazardous

situation which, if not avoided, will result

in death or serious injury.

WARNING

(highlighted in orange)

indicates a potentially

hazardous situation which, if not

avoided, could result in death or

serious injury.

CAUTION

(highlighted in yellow)

indicates a potentially

hazardous situation which,

if not avoided, may result in minor

or moderate injury. It may also

be used to alert against

unsafe practices.

WARNING

Failure to observe the following safety instructions

could result in serious injury or death.

GENERAL OPERATION:

Read, understand, and follow all instructions in this

manual and on the mower before starting.

Only allow responsible adults, who are familiar with the

instructions, to operate the mower.

Clear the area of objects such as rocks, toys, wire, etc.,

which could be picked up and thrown by the blade.

Be sure the area is clear of other people before mowing.

Stop mower if anyone enters the area.

Be aware of the mower discharge direction and do not

point it at anyone. Mower blades can throw rocks or other

debris.

Do not operate the mower without either the entire grass

catcher or the deflector in place. This will decrease the

possibility of injury from objects being thrown by the

mower blades.

Never carry passengers. They may fall off and become

seriously injured or interfere with safe operation of the

mower.

Mowing in reverse is not recommended because it is

difficult to maintain a clear vision of the mowing path.

However, should it become necessary to back up,

remember to look down and behind before and while

backing.

WARNING

GENERAL OPERATION (continued):

Never leave a running mower unattended. Always turn off

blades, set parking brake, stop engine and remove key

before dismounting.

Turn off blades when not mowing. Injury could occur from

contact with moving parts.

Under no circumstances should you place hands or feet

under the mower deck or in the chute while blades or

impeller are still running.

To avoid personal injury from accidental clutch

engagement, stop engine before removing grass catcher

or unclogging chute.

Mow only in daylight or good artificial light.

Do not operate the mower while under the influence of

alcohol or drugs.

Slow down before turning to reduce the risk of tip-over.

Watch for traffic when operating near or crossing

roadways.

Use extra care when loading or unloading the mower into

a trailer or truck. Push, do not ride the mower when

loading and unloading.

Failure to observe the following safety instructions

could result in serious injury or death.

WARNING

Never dismount mower without applying parking brake

or stopping engine.

Protect your eyes. Always wear safety goggles or safety

glasses with side shields when operating mower.

Data indicates that operators, age 60 years and above,

are involved in a large percentage of riding mower-

related injuries. These operators should evaluate their

ability to operate the riding mower safely enough to

protect themselves and others from serious injury.

To protect against possible tip-over, follow the

manufacturer’s recommendation for wheel weights,

counterweights and R.O.P.S.

Maintain or replace safety & instruction labels as

needed.

GENERAL OPERATION (continued):

The engine exhaust from this product contains chemicals known to the State of

California to cause cancer, birth defects or other reproductive harm.

Failure to observe the following safety instructions

could result in serious injury or death.

WARNING

SLOPE OPERATION:

Slopes are a major factor related to loss-of-control

and tip-over accidents, which can result in

severe injury or death.

All slopes require extra caution. If you feel uneasy

on a slope, do not mow it!

Mow across the slope with your Dixon® ZTR® --

never up or down. This will decrease the risk of

tip-over.

Remove obstacles such as rocks, tree limbs, wires

and other foreign objects that can be thrown by

mower blades.

Watch for holes, ruts, roots and bumps. Uneven

terrain could overturn the mower. Tall grass can

hide such obstacles.

Use slow speed. Tires may lose traction on slopes

even though the brakes are functioning properly.

Avoid starting or stopping on a slope. If tires lose

traction, disengage the blades and proceed slowly

down the slope.

Failure to observe the following safety instructions

could result in serious injury or death.

WARNING

Keep all movement on the slopes slow and

gradual. Do not make sudden changes in speed

or direction.

Use extreme caution when operating the mower

with attachments to prevent tip-over or roll-over.

If front wheels lift off the ground, pull levers back to

stabilize the mower. Discontinue mowing the

slope!

SLOPE OPERATION (continued):

DO (continued):

Failure to observe the following safety instructions

could result in serious injury or death.
