Dixon 2004 Manuel utilisateur

Model Year 2004Model Year 2004

Model Year 2004

Zeeter SeriesZeeter Series

Zeeter Series

ZTR®

IMPORTANT - READ CAREFULLY

The Dixon®ZEETER®Mower is both easy and fun

to operate. However, any power mower must be

operated properly to be safe. It is not a toy or a

recreational vehicle. Before you start to use the

mower, read the operator’s manual carefully and

become completely familiar with the controls.

The information contained in this manual applies to

all Dixon®ZEETER®Mowers. Your Dixon dealer

will gladly answer any questions.

See your dealer for warranty service, parts and

repairs.

INDEX

Page

Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . .13

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 14-16

Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-19

Operation Instructions. . . . . . . . . . . . . . . . . . . 20-27

Care & Maintenance. . . . . . . . . . . . . . . . . . . . . .28-42

Standard Service Parts List. . . . . . . . . . . . . . . . . . . .43

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . .44-45

ZEETER®Series

Part No. 14251-0703

RIDING LAWN MOWERS,

IF IMPROPERLY OPERATED,

CAN CAUSE SERIOUS INJURY OR DEATH.

The most common causes of injury to the operator or bystander...

...read and understand this manual to prevent injuries.

BLADE CONTACT

TIP OVER

RUN OVER

BACK OVER

SAFETY

Safety Alert Symbol

When you see this symbol,

BE ALERT to the potential for injury.

DANGER

(highlighted in red)

indicates an imminently hazardous

situation which, if not avoided, will

result in death or serious injury.

WARNING

(highlighted in orange)

indicates a potentially

hazardous situation which, if not

avoided, could result in death or

serious injury.

CAUTION

(highlighted in yellow)

indicates a potentially

hazardous situation which, if not

avoided, may result in minor or

moderate injury. It may also be used

to alert against unsafe practices.

Follow recommended safety precautions

and safe operating practices.

SAFETY

Failure to observe the following safety

instructions could result in serious injury or death.

GENERAL OPERATION:

•Read, understand, and follow all instructions in the

manual and on the mower before starting.

•Only allow responsible adults, who are familiar with the

instructions, to operate the mower.

•Clear the area of objects such as rocks, toys, wire, etc.,

which could be picked up and thrown by the blade.

•Be sure the area is clear of other people before mowing.

Stop mower if anyone enters the area.

•NEVER carry passengers.

•Do not mow in reverse unless absolutely necessary.

Always look down and behind before and while backing.

•Be aware of the mower discharge direction and do not

point it at anyone.

•Do not operate the mower without either the entire

grass catcher or the deflector in place.

•Slow down before turning.

•Never leave a running mower unattended. Always turn off

blades, set parking brake, stop engine and remove key

before dismounting.

SAFETY

GENERAL OPERATION (continued):

•Turn off blades when not mowing.

•Stop engine before removing grass catcher or unclogging

chute.

•Mow only in daylight or good artificial light.

•Do not operate the mower while under the influence of

alcohol or drugs.

•Watch for traffic when operating near or crossing

roadways.

•Use extra care when loading or unloading the mower into

a trailer or truck. Do not ride the mower when loading

and unloading.

•Always wear safety goggles or safety glasses with side

shields when operating mower.

•Data indicates that operators, age 60 years and above,

are involved in a large percentage of riding mower-related

injuries. These operators should evaluate their ability to

operate the riding mower safely enough to protect them-

selves and others from serious injury.

•Follow the manufacturer’s recommendation for wheel

weights and counterweights.

•Maintain or replace safety & instruction labels as needed.

WARNING: The engine exhaust from this product contains chemicals

known to the State of California to cause cancer, birth

defects or other reproductive harm.

SAFETY

SLOPE OPERATION:

Slopes are a major factor related to loss-of-control

and tip-over accidents, which can result

in severe injury or death.

All slopes require extra caution.

If you cannot back up the slope or if you feel

uneasy on it, do not mow it!

•Mow across the slope with your Dixon ZTR - never up or

down.

•Remove obstacles such as rocks, tree limbs, etc.

•Watch for holes, ruts or bumps. Uneven terrain could

overturn the mower. Tall grass can hide obstacles.

•Use slow speed. Tires may lose traction on slopes even

though the brakes are functioning properly.

•Use extra care with grass catchers or other attach-

ments. These can change the stability of the mower.

•Keep all movement on the slopes slow and gradual. Do

not make sudden changes in speed or direction.

SAFETY

SLOPE OPERATION (continued):

DO (continued)

•Avoid starting or stopping on a slope. If tires lose traction,

disengage the blades and proceed slowly down the slope.

•If front wheels lift off the ground, pull the levers back to

stabilize the mower.

DO NOT

•Do not turn on slopes unless necessary, and then, turn

slowly and gradually downhill, if possible.

•Do not mow near drop-offs, ditches, or embankmnets.

The mower could suddently turn over if a wheel is over

the edge of a cliff or ditch or if an edge caves in.

•Do not mow on wet grass. Reduced traction could cause

sliding.

•Do not try to stabilize the mower by putting your foot on

the ground.

•Do not use grass catcher on steep slopes.

SAFETY

CHILDREN:

Tragic accidents can occur if the operator is

not alert to the presence of children.

Children are attracted to lawn mowers

and the mowing activity.

NEVER assume children will stay where they

were last seen.

Be alert to avoid accidents.

•Keep children out of the mowing area and under the

watchful care of another responsible adult.

•Be alert and turn mower off if a child enters the area.

•Before and during backing, look BEHIND and DOWN for

small children.

•Never carry children. They may fall off and be seriously

injured or interfere with safe mower operation.

•Never allow children to operate the mower.

•Use extra care when approaching blind corners, shrubs,

trees, or other objects that may obscure vision.
