Directed Electronics Python 500 Manuel utilisateur

550000MMooddeell

➤

OOwwnneerr’’ssGGuuiiddee

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy

Directed Electronics, Inc. ("Directed") promises to the original purchaser to repair or

replace with a comparable reconditioned model any Directed unit (hereafter the "unit"),

excluding without limitation the siren, the remote transmitters, the associated sensors and

accessories, which proves to be defective in workmanship or material under reasonable use

during the lifetime of the vehicle provided the following conditions are met: the unit was

professionally installed and serviced by an authorized Directed dealer; the unit will be pro-

fessionally reinstalled in the vehicle in which it was originally installed by an authorized

Directed dealer; and the unit is returned to Directed, shipping prepaid with a legible copy

of the bill of sale or other dated proof of purchase bearing the following information: con-

sumer's name, telephone number and address; the authorized dealers name, telephone

number and address; complete product description, including accessories; the year, make

and model of the vehicle; vehicle license number and vehicle identification number. All

components other than the unit, including without limitation the siren, the remote trans-

mitters and the associated sensors and accessories, carry a one-year warranty from the date

of purchase of the same. This warranty is non-transferable and is automatically void if: the

original purchaser has not completed the warranty card and mailed it within ten (10) days

of the date of purchase to the address listed on the card; the unit's date code or serial num-

ber is defaced, missing or altered; the unit has been modified or used in a manner con-

trary to its intended purpose; the unit has been damaged by accident, unreasonable use,

neglect, improper service, installation or other causes not arising out of defects in materi-

als or construction. The warranty does not cover damage to the unit caused by installa-

tion or removal of the unit. Directed, in its sole discretion, will determine what consti-

tutes excessive damage and may refuse the return of any unit with excessive damage. TO

THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUD-

ING BUT NOT LIMITED TO EXPRESS WARRANTY, IMPLIED WARRANTY,

WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE

AND WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY,

ARE EXPRESSLY EXCLUDED; AND DIRECTED NEITHER ASSUMES NOR

AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY,

OBLIGATION OR LIABILITY IN CONNECTION WITH ITS PRODUCTS.

DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY FOR ANY

AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-

ERS OR INSTALLERS. DIRECTED SECURITY SYSTEMS, INCLUDING THIS

UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT

OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAM-

AGE OR THEFT OF THE AUTOMOBILE, ITS PARTS OR CONTENTS; AND

HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUD-

ING WITHOUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR

VANDALISM. THIS WARRANTY DOES NOT COVER LABOR COSTS FOR

MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY

CONSEQUENTIAL DAMAGES OF ANY KIND. IN THE EVENT OF A CLAIM

OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE PROPER

VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA.

CALIFORNIA STATE LAWS AND APPLICABLE FEDERAL LAWS SHALL APPLY

AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY

CLAIM AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE

AUTHORIZED DIRECTED DEALER'S PURCHASE PRICE OF THE UNIT.

DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEV-

ER, INCLUDING BUT NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES,

INCIDENTAL DAMAGES, DAMAGES FOR THE LOSS OF TIME, LOSS OF

EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY

AND THE LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER

DOES OFFER A LIMITED WARRANTY TO REPLACE OR REPAIR THE CON-

TROL MODULE AS DESCRIBED ABOVE. Some states do not allow limitations on

how long an implied warranty will last or the exclusion or limitation of incidental or con-

sequential damages. This warranty gives you specific legal rights and you may also have

other rights that vary from State to State.

This product may be covered by a Guaranteed Protection Plan ("GPP"). See your autho-

rized Directed dealer for details of the plan or call Directed Customer Service at 1-800-

876-0800. Directed security systems, including this unit, are deterrents against possible

theft. Directed is not offering a guarantee or insurance against vandalism, damage or theft

of the automobile, its parts or contents; and hereby expressly disclaims any liability what-

soever, including without limitation, liability for theft, damage and/or vandalism.

Directed does not and has not authorized any person or entity to create for it any other

obligation, promise, duty or obligation in connection with this security system.

Make sure you have all of the following information from your dealer:

A clear copy of the sales receipt, showing the following:

➤Date of purchase

➤Your full name and address

➤Authorized dealer's company name and address

➤Type of alarm installed

➤Year, make, model and color of the automobile

➤Automobile license number

➤Vehicle identification number

➤All security options installed on automobile

➤Installation receipts

ttaabblleeooffccoonntteennttss

lliimmiitteeddlliiffeettiimmeeccoonnssuummeerrwwaarrrraannttyy..............................................................................33

ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn................................................................................77

wwhhaattiissiinncclluuddeedd............................................................................................................88

iimmppoorrttaannttiinnffoorrmmaattiioonn..................................................................................................88

system maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

your warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

fcc/id notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

ttrraannssmmiitttteerrffuunnccttiioonnss..................................................................................................1100

standard configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

uussiinnggyyoouurrssyysstteemm......................................................................................................1122

active arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

passive arming. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

multi-level security arming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

high security disarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

disarming without a transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

dome light control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

silent mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

panic mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

valet mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

one-time bypass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

nuisance prevention® circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

aauuxxiilliiaarryyoouuttppuuttss((ooppttiioonnss))..........................................................................................2222

ddiiaaggnnoossttiiccss..................................................................................................................2233

arming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

disarming diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

system status chirps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

table of zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

interpreting zone diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

ccooddeehhooppppiinngg..............................................................................................................2266

hhiigghhffrreeqquueennccyy............................................................................................................2277

oowwnneerrrreeccooggnniittiioonn......................................................................................................2277

rraappiiddrreessuummeellooggiicc......................................................................................................2288

ppoowweerrssaavveerrmmooddee......................................................................................................2288

pprrooggrraammmmiinngg..............................................................................................................2299

iinnssttaallllaattiioonnooppttiioonnss....................................................................................................3322

vveehhiicclleerreeccoovveerryyssyysstteemm((vvrrss®®))....................................................................................3333

arming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

vrs® triggered sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

disarming the vrs® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

pprrooggrraammmmiinnggooppttiioonnss..............................................................

..................................3366

sshhoocckksseennssoorraaddjjuussttmmeenntt............................................................................................3388

enter shock sensor adjustment mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

adjusting the shock sensor setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

exit shock sensor adjustment mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

reset shock sensor to default setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

sseeccuurriittyy&&ccoonnvveenniieenncceeeexxppaannssiioonnss..........

..................................................................4411

gglloossssaarryyoofftteerrmmss........................................................................................................4433

qquuiicckkrreeffeerreenncceegguuiiddee..................................................................................................4455

ssttaannddaarrddttrraannssmmiitttteerrccoonnffiigguurraattiioonn

controls the LLoocckk––AArrmm//PPaanniiccOOnn//PPaanniiccOOfffffunction.

controls the UUnnlloocckk––DDiissaarrmm//PPaanniiccOOfffffunction.

controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt((22)).

controls the PPaanniic

cOOnn//OOfffffunction.

and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((33)).

and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((44)).

and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((55)).

and pressed together control an AAuuxxiilliiaarryyOOuuttppuutt((66)).

wwhhaattiissiinncclluuddeedd

➤One control module

➤A pair of four-button transmitters

➤Wire harnesses

➤The 514N six-tone programmable siren

➤The status LED indicator light

➤A push-button Valet switch

➤Your warranty registration

➤Failsafe®Starter Kill ready circuitry

(may require additional labor)

➤XR external receiver/antenna

iimmppoorrttaannttiinnffoorrmmaattiioonn

Congratulations on the purchase of your state-of-the-art vehicle

security system. This system has been designed to provide years

of trouble-free operation. Due to the complexity of this system,

it must be installed by an authorized dealer only. Installation of

this product by anyone other than an authorized dealer voids the

warranty. All dealers are provided with preprinted dealer certifi-

cates to verify that they are authorized.

This owner’s guide should help you to get the most out of your

system. Please take the time to read it prior to using the system.

system maintenance

The system requires no specific maintenance. Your remote

control is powered by a small, lightweight 3 volt lithium battery

(CR2032) that will last approximately one year under normal

use. When the battery weakens, operating range will be reduced

and the LED on the remote will dim.

your warranty

Your warranty registration must be returned and the bar code

serial number must not be removed. If the warranty registration

is not returned, you do not have a warranty. It is also necessary to

keep your proof of purchase, which reflects that the product was

installed by an authorized dealer. Make sure that you receive the

warranty registration from your dealer.

fcc/id notice

This device complies with Part 15 of FCC rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) This device must accept any

interference received, including interference that may cause

undesirable operation.

Changes or modifications not expressly approved by the party

responsible for compliance could void the user's authority to

operate this device.

➜

ttrraannssmmiitttteerrffuunnccttiioonnss

This system uses a computer-based learn routine to learn the

transmitter buttons. This makes it possible to assign any trans-

mitter button to any system function. The transmitter initially

comes programmed with Standard Configuration, but may also

be customized by an authorized dealer. The buttons described in

this manual correspond to a Standard Configuration transmitter.

standard configuration

Button

The arming function is controlled by pressing this button for

one second.

Button

The disarming function is controlled by pressing this button for

one second.

➜

3101 Series

Button

Silent Mode™ and an optional auxiliary function are controlled

by pressing this button. (Silent Mode works by pressing this

button for less than one second before arming or disarming. An

optional auxiliary function, such as trunk release, can be

controlled by pressing this button for 1.5 seconds.)

The auxiliary output controls __________________________.

Button

The panic feature is controlled by pressing this button for two

seconds.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls_________________________.

and Buttons

An optional auxiliary convenience or expansion function that

you have added to your system can be activated by pressing these

buttons simultaneously.

The auxiliary output controls_________________________.

Table des matières

Autres manuels Directed Electronics Alarme de voiture

Directed Electronics

Directed Electronics AVITAL 3001L Manuel utilisateur

Directed Electronics

Directed Electronics PYTHON 210P Manuel utilisateur

Directed Electronics

Directed Electronics 736T Manuel utilisateur

Directed Electronics

Directed Electronics Viper 5904 Manuel utilisateur

Directed Electronics

Directed Electronics 3000 Manuel utilisateur

Directed Electronics

Directed Electronics G436S 5220XS Manuel utilisateur

Directed Electronics

Directed Electronics Concept 550 Manuel utilisateur

Directed Electronics

Directed Electronics Viper 140 HF Manuel utilisateur

Directed Electronics

Directed Electronics 550ESP Manuel utilisateur

Directed Electronics

Directed Electronics 410S Manuel utilisateur

Directed Electronics

Directed Electronics Matrix RS 2 Manuel utilisateur

Directed Electronics

Directed Electronics Python 3000 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 100 ESP Manuel utilisateur

Directed Electronics

Directed Electronics 732T Manuel utilisateur

Directed Electronics

Directed Electronics G312R Guide de démarrage rapide

Directed Electronics

Directed Electronics 436 Series Manuel utilisateur

Directed Electronics

Directed Electronics 671XV Manuel utilisateur

Directed Electronics

Directed Electronics VIPER 5701 Manuel utilisateur

Directed Electronics

Directed Electronics AutoCommand 20095 Manuel utilisateur

Directed Electronics

Directed Electronics 460MAX Manuel utilisateur

Directed Electronics

Directed Electronics 429 Series Manuel utilisateur

Directed Electronics

Directed Electronics IntelliGuard 7000 Manuel utilisateur

Directed Electronics

Directed Electronics Rattler 250 Manuel utilisateur

Directed Electronics

Directed Electronics Security System and Convenience 125xv Manuel utilisateur

Manuels Alarme de voiture populaires d'autres marques

Clifford

Clifford 3606X Manuel utilisateur

Ultra Start

Ultra Start 2500M SERIES Manuel utilisateur

Ultra Start

Ultra Start 650 Series Manuel utilisateur

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuel utilisateur

Sparkrite

Sparkrite SRA8 Manuel utilisateur

Viper

Viper 4708V Manuel utilisateur

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuel

Falcon

Falcon Predator XL3 Guide de l'utilisateur

Audiovox

Audiovox Auto Security XR91 Mode d'emploi

Clifford

Clifford Sabre II Manuel utilisateur

CrimeStopper

CrimeStopper CS-8717 Guide de démarrage rapide

Ultra Start

Ultra Start 450 SERIES Manuel utilisateur

Scytek electronic

Scytek electronic Vectra X3 Manuel utilisateur

Excalibur

Excalibur AL-1860-EDPB Manuel utilisateur

Clifford

Clifford CYBER 2 Manuel utilisateur

Gemini

Gemini 7057 Manuel utilisateur

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuel utilisateur

Magicar

Magicar FAI-440 Manuel utilisateur
