IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this

Opti-V

. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this Opti-V.

!NOTE: Procedures and

techniques that are considered

important enough to emphasize.

CAUTION: Procedures and

techniques which, if not carefully

followed, will result in damage to

the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations ..................3

IMPORTANT SAFETY INSTRUCTIONS.........4

Opti-V Installation ..........................6

Locating the Opti-V .........................6

Hardwire Installation ........................6

Operation ................................10

Maintenance .............................12

Warranty................................13

Technical Support .........................15

MADEIN IRELAND

FAITEN IRLANDE

HECHOEN IRLANDA

MODEL

MODELE

MODELO

CAT.#

No.de Cat.

PROTECTEDBY THE FOLLOWING PATENTS / PROTEGE PAR LES BREVETS SUIVANTS/PROTEGIDO POR LAS SIGUIENTES

PATENTES: US PATENTS / BREVETS DE ETATS UNIS / PATENTES DE ESTADOS UNIDOS : 8,361,367

OTHERPATENTS PENDING / AUTRES BREVETS EN INSTANCE / OTRAS PATENTES PENDIENTES

DIMPLEXNORTH AMERICA

1367INDUSTRIAL ROAD

CAMBRIDGE,ON, N1R 7G8

CANADA

6909410100

VF2927L

100-240V ~, 50/60HZ, 35W

Intertek

North America Limited

xxxxxxx

SERIAL No./No DE SERIE/No DE SERIE

DDDYYSLF - XXX

Welcome & Congratulations

Model Number

Serial Number

Thank you and congratulations for purchasing an Opti-V from Dimplex.

Please use our convenient online registration page to record your

model and serial numbers for future reference at

www.dimplex.com/register

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

In order to better serve you, please have your model and serial number

ready or register your product online before calling (See above)

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result in

a possible electric shock, re hazard and will void the warranty.

4 www.dimplex.com

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliances,

basic precautions should always be

followed to reduce the risk of fire,

electric shock, and injury to persons,

including the following:

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near

water.

6. The appliance shall not be

exposed to dripping or splash-

ing and that no objects lled with

liquid, such as vases, shall be

placed on the apparatus.

WARNING: To reduce the risk of

re or electric shock, do not expose

this apparatus to rain or moisture.

7. Clean only with dry cloth.

8. Do not block any ventilation open-

ings. Install in accordance with the

manufacturer’s instructions.

9. Do not install near any heat

sources such as radiators, heat

registers, stoves, or other ap-

paratus (including ampliers) that

produce heat.

10. No naked ame sources, such as

candles should be placed on this

apparatus.

11. Only use attachments/accessories

specied by the manufacturer.

12. Use only with the cart, stand, tri-

pod, bracket, or table specied by

the manufacturer, or sold with the

apparatus. When a cart is used,

use caution when moving the cart/

apparatus combination to avoid

injury from tip-over.

13. Disconnect power at the service

panel during lightning storms or

when unused for long periods of

time.

14. Refer all servicing to qualied

service personnel. Servicing is

required when the apparatus has

been damaged in any way, such

as power-supply cord or plug is

damaged, liquid has been spilled

or objects have fallen into the ap-

paratus, the apparatus has been

exposed to rain or moisture, does

not operate normally, or has been

dropped.

15. If the appliance is damaged,

check immediately with the

supplier before installation and

operation.

16. Do not operate any unit with a

damaged cord, or if the Opti-V

has been dropped or damaged

in any manner, contact Dimplex

Technical Service at

1-888-346-7539.

17. Do not modify the Opti-V. Use it

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

NO USER-SERVICEABLE PARTS INSIDE

only as described in this manual.

Any other use not recommended

by the manufacturer may cause

re, electric shock or injury to

persons.

18. When transporting or storing the

unit and cord, keep in a dry place,

free from excessive vibration and

store so as to avoid damage.

19. Do not install the remote control

battery backwards; charge; put

in excessive heat such as re,

sunshine or the like; or mix with

used or other battery types - may

explode or leak causing injury.

20. When replacing the battery

ensure that it is replaced with

alkaline 1.5 Volt (AAA) batter-

ies. Battery must be recycled or

disposed of properly. Check with

your Local Authority or Retailer for

recycling advice in your area.

!NOTE: To disconnect from mains

- set the mains switch to 'O'. The

mains (power) switch is located at

the top left hand side of the appliance

above the manual controls - see 'O/I'

Figure 2. Mains switch shall remain

readily operable.

WARNING: To prevent injury, this

apparatus must be securely attached

to the oor/wall in accordance with

the installation instructions.

WARNING: Remote control con-

tains small batteries. Keep away from

children. If swallowed, seek medical

attention immediately.

!NOTE: Changes or modications

not expressly approved by the party

responsible for compliance could void

user's authority to operate the equip-

ment.

6 www.dimplex.com

Opti-V Installation

WARNING: ANY INSTAL-

LATION AND SERVICE WORK

CAN ONLY BE PERFORMED BY

QUALIFIED AND AUTHORIZED

PERSONNEL. ALL INSTALLA-

TIONS MUST COMPLY WITH

ALL LOCAL CODES AND BY-

LAWS, AND INSPECTED AND

APPROVED FOR OPERATION

BY LOCAL GOVERNING AU-

THORITY PRIOR TO USE.

WARNING: Construction

and electrical outlet wiring must

comply with local building codes

and other applicable regulations

to reduce the risk of re, electric

shock and injury to persons.

Locating the Opti-V

The Opti-V uses an illusory reec-

tion technique and is designed

to work best when ambient light

levels are low. If the Opti-V is

installed in brightly lit areas, the

strong reections may diminish

the ame.

Depending on your specic ap-

plication, installation of the unit

at a height appropriate for the

viewers enjoyment is important. It

is recommended that the follow-

ing guidelines be used for locating

the unit.

!NOTE: Measurements are to

the bottom of the viewing area of

the ame.

For standing applications:

Maximum - 51 in. (129.5 cm)

Minimum - 26 in. (66.0 cm)

For sitting applications:

Maximum - 36 in. (91.4 cm)

Minimum - 26 in. (66.0 cm)

Hardwire Installation

The Opti-V is supplied in an as-

sembled state and is designed to

be permanently installed. The unit

comes ready for hardwire instal-

lation.

WARNING: Do not attempt

to wire your own new outlets or

circuits. To reduce the risk of re,

electric shock or injury to persons,

always use a licensed electrician.

WARNING: Ensure that the

On/Off switch is set to the Off po-

sition (refer to Operation section)

and that the circuit on which the

Opti-V is to be installed has the

power cut off at the service panel

until installation is complete.

!NOTE: Please read all instruc-

tions before installing.

1. For rough in framing, the

opening should follow the

Opti-V Installation

recommended dimensions

located in Figure 1.

!NOTE: Dimensions provided

are minimum clearances and will

vary depending on type of support

framing and nishing options.

!NOTE: Framing should be

constructed to support:

VF2927L / VFA2927 - 63 lbs (29 kg)

VF5452L - 116 lbs (52 kg)

2. Allow up to 4 ft. (121.9 cm) of

service cable for connecting

a power supply wire to the

cable clamp on the Opti-V

when installing before nish-

ing wall.

!NOTE: A 15 amp, 120 volt

alternating current (VAC) circuit

is recommended, but the unit is

constructed that it can operate

using voltages from 120-240VAC.

!NOTE: Use minimum 14 AWG

supply cable with two insulated

copper conductors (white and

black) and one bare ground wire.

A B C D E F G

VF5452L 54.5 in

(1380 mm)

17.7 in

(450 mm)

13.6 in

(345 mm)

2.9 in

(74 mm)

5.3 in

(135 mm)

18.6 in

(474 mm)

55.3 in

(1404 mm)

VF2927L 30.0 in

(762 mm)

17.7 in

(450 mm)

13.6 in

(345 mm)

2.9 in

(74 mm)

5.3 in

(135 mm)

18.6 in

(474 mm)

30.5 in

(775 mm)

VFA2927 30.0 in

(762 mm)

17.7 in

(450 mm)

13.6 in

(345 mm)

2.9 in

(74 mm)

5.3 in

(135 mm)

18.6 in

(474 mm)

30.5 in

(775 mm)

Figure 1

8 www.dimplex.com

Opti-V Installation

Do not use cable with alumi-

num conductors.

!NOTE: It is recommended that

all drywall installation and nish-

ing be completed after unit is fully

installed.

3. In the upper left hand corner

of the unit, loosen the two

securing screws and remove

the electrical cover panel.

(Figure 2)

4. Install a ⅜ in. (10 mm) or ½

in. (13 mm) cable connec-

tor, not included, suitable for

mounting in a ⅞ in. (22 mm)

hole, to the cable plate and

feed the supply cable through

the connector and secure.

5. Place the unit in the framed

opening, level with shims if

necessary and attach unit to

frame using mounting anges

provided (Figure 3).

CAUTION: When inserting

the unit take care not to damage

or pinch any of the power cables

that are concealed in the wall.

6. Remove the outer jacket and

strip the individual conductors

½ in. (1.3 cm) from the end.

7. Connect the black wire from

the unit to the Live (120V) or

Line 1 (240V) wire from the

power supply using a wire

connector (included).

8. Connect the white wire from

the unit to the Neutral (120V)

or Line 2 (240V) from the

power supply using a wire

connector (included).

Figure 2

Electrical

Cover Panel

Cable Clamp

Hole

Figure 3

Mounting

Flanges

Cable Plate

Grounding

Screw

Opti-V Installation

!NOTE: Cap any additional

wires from the power supply not

used in the installation.

9. Ensure that the green ground-

ing wire is securely attached

to the back plate.

CAUTION: Ensure the

wire connectors are securely

tightened, so no bare wires (live

or neutral) are exposed.

10. Ensure the grounding wire of

the supply cable is securely

attached to the grounding

screw.

!NOTE: The wire connections

on the Opti-V feed into a 3-prong

plug just below the electrical cav-

ity opening, before closing the

electrical cover ensure that the

plug is fully installed.

11. Reinstall the electrical cover

panel.

12. Reinstall the protector sheet

to prevent dust from entering

the unit while nishing the

surround.

13. Finish surrounding wall.

There are 3 different options

for nishing the wall:

• Permanent - install drywall

right up to the ange that sur-

rounds the opening.

• Semi Permanent - nish

around edge using ashing

material (not included)

• Flexible - create opening big

enough to access mounting

anges and a false front that

can be removed.

10 www.dimplex.com

Operation

WARNING: This Opti-V must

be properly installed before it is

used.

The power switch (Figure 2A) must

rst be switched "I" to operate the

appliance.

An ‘Opti-V’ logo will appear on

the screen for about 3 seconds

before the ame picture starts .

!NOTE: The user may notice a

blank screen for approximately 5

seconds, every 30 minutes. This

is normal and should not be a

cause for concern.

Manual Operation

The manual controls for the

screen are located at the inner

top left hand side of the appliance

above the glass.(Figure 2).

The mains (power) switch (Figure

Figure 2

IR Remote Sensor

2A) may be used to switch the

appliance Off ("O") when it is not

required, for example, overnight

or for long periods, to avoid un-

necessary energy use.

!NOTE: Ensure that the mains

(power) switch shall remain read-

ily operable.

The standby button " " (Figure

2B) is located just below the pow-

er switch. A red light will indicate

when the unit is in standby mode.

(Figure 2)

The volume of the sound effects

may be adjusted up or down by

pressing the volume control but-

tons (Figure 2C & 2D).

The screen brightness can be ad-

justed using the (Figure 2E) and

(Figure 2F) buttons. The but-

ton darkens the screen and the

EB DC

Autres manuels pour VF5452L

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dimplex Cheminée intérieure

Dimplex

Dimplex OLF46-AM Manuel utilisateur

Dimplex

Dimplex Mini Mozart Manuel utilisateur

Dimplex

Dimplex WESTBROOK Manuel utilisateur

Dimplex

Dimplex DF2600CG Manuel utilisateur

Dimplex

Dimplex BF33ST Manuel utilisateur

Dimplex

Dimplex BAR20-AU Manuel utilisateur

Dimplex

Dimplex Navara Nav15 Log Manuel utilisateur

Dimplex

Dimplex DFG3033 Manuel utilisateur

Dimplex

Dimplex VCX1525 Manuel utilisateur

Dimplex

Dimplex Chadwick Suite CDW15WW Manuel utilisateur

Dimplex

Dimplex SCANDIC DELUXE SDC20RC Manuel utilisateur

Dimplex

Dimplex Optiflame BF3600 Manuel utilisateur

Dimplex

Dimplex DFI2310 Manuel utilisateur

Dimplex

Dimplex DF2690 Manuel utilisateur

Dimplex

Dimplex BF392SD Manuel utilisateur

Dimplex

Dimplex contempra ef KDS6401E Guide de démarrage rapide

Dimplex

Dimplex purifire DF3220 Sseries Manuel utilisateur

Dimplex

Dimplex SCANDIC Manuel utilisateur

Dimplex

Dimplex Optiflame MiniMozart FGA15E Mode d’emploi

Dimplex

Dimplex ROTHESAY RSY20 Manuel utilisateur

Dimplex

Dimplex 6911540100 Manuel utilisateur

Dimplex

Dimplex VFA2927 Manuel utilisateur

Dimplex

Dimplex Optiflame Toluca Deluxe TLC20LX Mode d’emploi

Dimplex

Dimplex Opti-V Manuel utilisateur

Manuels Cheminée intérieure populaires d'autres marques

Brigantia

Brigantia 35-DVRS31N-2 Manuel du propriétaire

Nordpeis

Nordpeis Bergen Manuel utilisateur

Superior

Superior BCT2536TMN Manuel utilisateur

Quadra-Fire

Quadra-Fire 5100I-GD-B Manuel utilisateur

Renaissance

Renaissance RUMFORD 1000 Manuel utilisateur

Lacunza

Lacunza IV-800 Manuel utilisateur

Baxi

Baxi 940 Instructions d'utilisation

Dru

Dru Maestro 60/2 Tall RCH Manuel utilisateur

Diamond Fireglass

Diamond Fireglass SS-O22 Manuel utilisateur

HearthStone

HearthStone Windsor Bay 8830 Manuel de programmation

Napoleon

Napoleon ASCENT B42 Manuel utilisateur

Enviro

Enviro E33GI Manuel utilisateur

Smeg

Smeg L30 FABE Instructions de montage

KEDDY

KEDDY K700 Manuel utilisateur

Godin

Godin 3451 Manuel utilisateur

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manuel utilisateur

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manuel utilisateur

Desa

Desa CCFPDFT Manuel d'utilisation
