Dimplex DCPF46 Manuel utilisateur

46cm HV PEDESTAL FAN

Model: DCPF46

INSTRUCTION MANUAL

PLEASE READ THE INSTRUCTION MANUAL CAREFULLY BEFORE USING THE UNIT

TABLE OF CONTENTS

IMPORTANT INFORMATION……………..………………………………………… 1

STRUCTURE….……………….…………………………………………………………. 3

ASSEMBLY & OPERATION………………………………………………………….. 4

CLEANING & MAINTENANCE..…………………………………………………….. 5

TECHNICAL SPECIFICATIONS.….…………………………………………………. 7

WARRANTY.............…..………..……………………………………………………. 7

IMPORTANT INFORMATION

Warnings

•Never place the unit near any gas appliances, fire or flammable

liquids.

•Never hit or shake the unit to prevent damage.

•Never cover or obstruct the air inlet or outlet to prevent overheating.

•Never spray water or place the unit near water to prevent electric

shock.

•Only ever have a professional technician, manufacturer or a service

agent to replace a damaged power cord.

•Never share the power outlet with other appliances.

•Never connect or disconnect the power plug with wet hands to avoid

electric shock.

•Never put rods or objects into the opening of the unit.

•Never use an extension cord with this unit.

Cautions

•Be sure the unit is placed on a stable surface when operating to

avoid overturning.

•The unit must not be used if the guards are not fastened according

to instructions.

•This appliance is for indoor use only.

•Do not plug the unit into a power socket before assembly is

complete.

•Never insert fingers, pencils, or any other object through the guard

when unit is running.

•Power plug must be removed from the power socket before cleaning,

servicing, maintenance or moving from one location to another.

•The unit should not be placed in a damp place or where humidity is

high (such as a bathroom).

•Electrical connections shall be in accordance with National or Local

Codes.

•Keep the unit at least 1 metre away from electric appliances such as

TV’s and radios, to avoid electromagnetic interference.

•Do not expose the unit under direct sunlight to avoid surface colour

fading.

•Do not tilt the unit more than 35 degrees or upside down while

transporting.

•Place the unit on a flat surface with less than 5 degree inclination.

•To avoid damaging the surface, do not use chemical solvents (i.e.

Benzene, alcohol-grazer) or harsh cleaners when cleaning the unit.

•Do not use your appliance with an extension cord unless it has been

checked and tested by a qualified electrician or electrical supplier.

•This appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person

responsible for their safety.

•Children should be supervised to ensure that they do not play with

the appliance.

•Do not leave the fan unattended.

•Do not use the fan near a window. Rain may create an electrical

hazard. Do not leave the fan operating adjacent to an area where

water has been collected to avoid the potential of electrical hazards.

•Power plug must be removed from the power socket before cleaning,

servicing, maintenance or moving from one location to another.

STRUCTURE

1. Front Guard 12. Washer

2. Screw 13. Inner Pillar

3. Blade 14. Long Screw

4. Rear Guard 15. Outer Connector

5. Motor 16. Outer Pillar

6. Switch Box 17. Base

7. Power Supply Cord 18. Basic Addition Part

8. Screw 19. Plane Washer

9. Nut 20. Orthogonal Screw

10. Nut 21. Piece

11. Spring Washer 22. Screw

ASSEMBLY & OPERATION

Assembly of your pedestal fan

1. Locate the pedestal base of the fan (item 17). Insert the outer pillar

(item 16) into the pedestal base, then fasten together with the

additional part (item 17 & 18) using the screws provided.

2. Undo the thumbscrew at the top of the stand and align the motor

unit complete with guards before fastening.

3. Put the motor head onto the pole (item 13) and fix with screws and

washers.

Operation of your pedestal fan

1. Adjust the desired speed by rotating the switch:

0 – Stop

1 – Low

2 – Medium

3 – High

2. Adjust the tilt angle by pushing the grill.

CLEANING AND MAINTENANCE

Cleaning

1. Always unplug the fan before cleaning.

2. To clean the blade and grille assembly, remove the safety grille,

unscrew the locknut and remove the blade from the unit.

3. Clean the unit with a soft cloth moistened with a mild soap solution.

Use dry cloth to wipe the unit after cleaning.

4. Never use strong or volatile chemicals to clean the unit as it will

damage the plastic parts.

5. Do not immerse in water for cleaning, never allow water to drip into

the motor housing.

6. In the off-season, it is important to keep your unit in a safe, dry

location. Please remember to protect the unit from dust or moisture.

Meaning of crossed-out wheeled dustbin

1. Do not dispose of electrical appliances as unsorted municipal waste,

use separate collection facilities.

2. Contact your local government for information regarding the

collection systems available.

3. If electrical appliances are disposed of in landfills or dumps,

hazardous substances can leak into the groundwater and get into

the food chain, damaging your health and well-being.

Maintenance

If the unit’s working efficiency decreases, the unit is broken or other

problems arise, please stop running the unit and unplug it. Ask for advice by

calling your local after sales service agent or the Customer Care Centre on

1300 556 816 (AU) / +64 9 274 8265 (NZ)

TECHNICAL REFERENCE DATA

Model DCPF46

Rated Power 70W

Voltage/Frequency 220V-240V/50Hz

Net Weight 8.76kg

Body (mm) 1390X570X400Dimensions

HxWxD Package (mm) 570X570X240

5336

Warranty:

The warranty is valid for 12 months from date of purchase. For service

advice, please contact the Customer Care Centre on 1300 556 816 (AU) /

+64 9 274 8265 (NZ)

Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd

Unit 1, 21 Lionel Road 38 Harris Road, East Tamaki,

Mount Waverley VIC 3149 Manukau, Auckland 2013

Australia New Zealand

Ph: 1300 556 816 Ph: (09) 274 8265

Fax: 1800 058 900 Fax: (09) 274 8472

Web: www.dimplex.com.au Web: www.dimplex.co.nz
