For domestic household use

only.

INSTRUCTION MANUAL

117cm Digital Tower Fan with Night

Light

Model: DCTF117NL

IMPORTANT

THESE INSTRUCTIONS SHOULD BE READ CAREFULLY

AND RETAINED FOR FUTURE REFERENCE.

Note also the information presented on the appliance

CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY

CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE

YOUR WARRANTY

Please read the operating instructions carefully before using your

fan for the rst time and keep them in a safe place.

WARNING – This appliance must not be used in a bathroom.

WARNING – Do not use this appliance in the immediate

surroundings of a bath, a shower or a swimming pool.

• If the mains lead is damaged it must only be replaced by the

manufacturers service agent or a similarly qualied person in

order to avoid a hazard.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

• Children should be supervised to ensure they do not play with

the appliance.

• Never immerse the appliance in water or other liquids.

• Operate this unit only on a rm, at surface.

• Do not place on soft, unstable or non-horizontal/angled

surfaces.

• Never operate the appliance if a cable or connector has been

damaged, after appliance malfunction or if the appliance was

dropped or is otherwise damaged.

• Please ask a professional service agent to repair the product.

Improper repair may cause danger to users.

• Disconnect the appliance from mains power whenever it is not

in use, before relocating it, and before cleaning.

• Operate the appliance only at the voltage specied on the

rating label.

• Only connect the unit to a properly installed and easily accessible

socket so that you can quickly disconnect the plug if necessary.

• Do not connect this product to the mains using an extension

lead.

• ThisfanisonlyintendedforINDOOR RESIDENTIALapplications.

This fan should not be used for commercial or industrial or

leisure applications or in small enclosed spaces.

• Never use the mains lead as a carrying strap or pulling lead.

• To avoid a re or electrocution hazard, NEVER put the cord

near heat registers, radiator, stoves or heaters.

• DO NOT cover cord with carpeting, throw rugs, runners, or

similar coverings.

• DO NOT route cord under furniture or appliances. Take care to

position the cord away from trafc areas and where it will not

be a tripping hazard.

• DO NOT use the unit near windows or where water collects.

Rain and water collection may lead to a risk of re or electric

shock.

• Only operate this appliance with a minimum of 50cm clearance

all around i.e. away from walls, furniture and overhanging

objects such as curtains or a shelf.

• WARNING: To avoid danger of suffocation please remove all

packaging materials particularly plastic and EPS and keep

these away from vulnerable people, children and babies.

• NEVER drop or insert any object or ngers into any openings.

• Do not use the appliance in locations where paint, petrol or

other ammable liquids are used or stored.

• Do not use bug sprays or other ammable cleansers/vapour

sprays on or around the unit.

• Always switch off the unit and take the plug out of the socket:

•

If you are not using the unit

•

Before you clean or carry out maintenance on the unit

•

If a fault occurs

•

In the event of an electrical storm.

• Avoid electromagnetic interference. Keep the unit at least 1

metre away from electrical appliances such as televisions &

radios.

• DO NOT use this appliance with an extension lead or power

board.

Exposed to the

weather outdoors

Near water If the power cable

wires are frayed or cut

Where small children

may be left unattended

No extension

leads or power

boards

Where there is risk

of re or close to

a naked ame

Where the power

cable may be

damaged

On a slope or

uneven surface

Where it may be

damaged by

chemicals

If there is a risk

of water falling on

the unit

Where there is a risk

of interference by

foreign objects

This product is not

made for DIY repair

Model no. DCTF117NL

Colour

White

Power supply

220-240V~ 50-60Hz

Rated power

45W

Speed settings

Modes 4

Timer 1-12hrs

Air speed 2.7m/s

Oscillating 75°

Controls Button & Remote

Noise level

53.8dB

Weight (net) 3.63kg

Dimensions (w x d x h) 315 x 315 x 1170mm

Specification

• For greater precision, please always refer to the rating label placed on the product.

Parts

Control panel Carry handle

LED display

Cable hook

Air outlet

Front cover Back cover

Base Night light

Assembly

1. Place the two parts of the base together.

2. Line up the Tower Fan with the base.

3. Use the xed knob to secure the base onto the Tower Fan.

4. Put wire in the recess, then x the base on the fan body with four

screws(included) and turn the screws clockwise.

Operation

This tower fan can be operated by the Button and remote control. Please refer to the

below diagrams and descriptions.

Remote Control

1. Install 2 x AAA batteries (not included) into the remote.

2. All remote control buttons are labeled as below and all the remote control functions

work identically as the manual controls.

Remote Control Top Control Panel

Power

Speed

Oscillation

Night light

Timer

Mode

LED

Manual Controls

Place the fan on a table or at surface. Plug the cord set into an appropriate electrical

outlet.

2. Turn the fan on by pressing the 'POWER' button. Turn the fan off by pressing the

'POWER' button again.

3. You can adjust the fan speed to the desired level: low, medium and high by pressing

the 'SPEED' button. The speed setting is displayed on the LED panel.

4. You can adjust the fan mode by pressing the 'MODE' button. The four modes are

'natural' 'normal' 'sleep' and 'child'.

To set the fans timer, press the 'TIMER' button. This allows you to set the fans length

of operation between 1-12 hours.

6. To make the fan oscillate, press the 'OSC' button. This allows the fan to oscillate up

to 75° .

7. Turn the LED display temporarily off by pressing the 'LED' button on the remote

or by pressing and holding the 'SPEED' button on the control panel for more than

3 seconds. The display will light up again once any control button is pressed.

Turn on the Nightlight by pressing the 'LIGHT' button on the remote or on the

control panel. Turn the Nightlight off by pressing the 'LIGHT' button on the remote

or on the control panel.

Operation

Cable Hook:

The cable hook is packed in the user manual,Take it out and install it on the backside

of the fan. The power cord can be hanged at the cable hook when the fan is not in

use.

Cleaning

Over time, dust can accumulate on the fan grille, which can affect the fans

performance. It is recommended to clean the fan at least once a month.

1. Turn the unit OFF and disconnect the appliance from the power supply.

2. Remove any dust build up with a soft brush.

3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used

for any stubborn marks.

Do not use abrasive sponges, scouring pads, or a stiff brush to clean the unit.

IMPORTANT

The control panel and other parts must not come into contact with water or any

other liquids.

Storage

If not using the unit for an extended period of time. After cleaning please:

• Turn the unit off, unplug and take care of the mains lead & plug.

•

Cover the unit and store it upright in a location where it will not receive direct

sunlight. NB- Prolonged exposure to direct sunlight will discolour the enclosure.
