Dimplex EMC4240 Manuel utilisateur

Owner’s Manual

Model

EMC4240

DCH4831L

7208970100R04

IMPORTANT SAFETY INFORMATION: Always read this manual rst

before attempting to install or use this heater. For your safety, always

comply with all warnings and safety instructions contained in this manual

to prevent personal injury or property damage.

To view the full line of Dimplex products, please visit

www.dimplex.com

2 www.dimplex.com

Table of Contents

Always use a qualied technician

or service agency to repair

this heater.

!NOTE: Procedures and

techniques that are

considered important

enough to emphasize.

CAUTION: Procedures and

techniques which, if not

carefully followed, will result

in damage to the equipment.

WARNING: Procedures

and techniques which, if not

carefully followed, will expose

the user to the risk of re,

serious injury, or death.

Welcome & Congratulations ................3

IMPORTANT INSTRUCTIONS...............4

Heater Installation ........................6

Operation ...............................7

Maintenance and Cleaning . . . . . . . . . . . . . . . . .8

Warranty................................8

ReplacementParts ........................9

Welcome & Congratulations

Thank you and congratulations for choosing to purchase an electric

heater from Dimplex, the world leader in electric heaters.

Please carefully read and save these instructions.

CAUTION: Read all instructions and warnings carefully before

starting installation. Failure to follow these instructions may result

in a possible electric shock, re hazard and will void the warranty.

Please record your model and serial numbers below for future

reference: model and serial numbers can be found on the Model and

Serial Number Label of your heater.

Model Number

Label

Serial Number

NO NEED TO RETURN TO THE STORE

Questions with operation or assembly? Require Parts Information?

Product Under Manufacturer’s Warranty?

For Troubleshooting and Technical Support

OR Toll-Free 1-888-DIMPLEX (1-888-346-7539)

Monday to Friday 8:00 a.m. to 4:30 p.m. EST

Please have your model number and product serial

number ready. (See above)

4 www.dimplex.com

①Readallinstructionsbefore

using this appliance.

② The heater is hot when in use.

To avoid burns, do not let bare

skin touch hot surfaces. The trim

around the heater outlet becomes

hot during heater operation.

Keep combustible materials, such

as furniture, pillows, bedding,

papers, clothes, and curtains at

least 3 feet (0.9m) from the front

of the unit.

③ Extreme caution is necessary

when any heater is used by or

near children or invalids and

whenever the unit is left operating

and unattended.

④ Always unplug the heater

when not in use.

⑤ Do not operate any unit with

a damaged cord or plug, or if the

heater has malfunctioned, or if

the heater has been dropped or

damaged in any manner. Return

heater to authorized service

facility for examination, electrical

or mechanical adjustment or

IMPORTANT INSTRUCTIONS

repair.

⑥ Do not use outdoors.

⑦ The heater is not intended for

use in bathrooms, laundry areas

and similar indoor locations.

Never locate heater where it may

fall into a bathtub or other water

container.

⑧Do not run the cord under

carpeting. Do not cover cord with

throw rugs, runners or the like.

Arrange cord away from trafc

area and where it will not be

tripped over.

⑨To disconnect the unit, turn

the controls off, then remove the

plug from the outlet.

⑩ Connect to perperly grounded

outlets only.

⑪Do not insert or allow foreign

objects to enter any ventilation

or exhaust opening as this may

cause an electric shock or re, or

damage to the heater.

⑫ To prevent a possible re, do

SAVE THESE INSTRUCTIONS

not block air intake or exhaust

in any manner. Do not use on

soft surfaces, like a bed, where

openings may become blocked.

⑬ All electrical heaters have hot

and arching or sparking parts

inside. Do not use in areas where

gasoline, paint, or ammable

liquids are used or stored or

where the unit will be exposed to

ammable vapours.

⑭Do not modify the heater.

Use it only as described in

this manual. Any other use

not recommended by the

manufacturer may cause re,

electric shock or injury to persons.

⑮ To reduce the risk of electric

shock, this appliance has a

polarized plug (one blade is

wider than the other). This plug

will t in a polarized outlet only

one way. If the plug does not t

fully in the outlet, reverse the

plug. If it still does not t, contact

a qualied electrician to install

the proper outlet. Do not change

the plug in any way. This heater

is not intended for use with an

extension cord. Plug the unit

directly into a wall receptacle.

⑯ This heater includes a visual

alarm (red light) to warn that parts

of the heater are over heating. If

the red light turns on, immediately

turn heater off and inspect for

any objects on or adjacent

to the heater that may cause

high temperatures. DO NOT

OPERATE WHEN RED LIGHT IS

ON.

⑰ Always use a certied

electrician should new circuits or

outlets be required.

⑱ Disconnect all power supply

before performing any cleaning,

maintenance or relocation of the

unit.

⑲ When transporting or storing

the unit and cord, keep in a

dry place, free from excessive

vibration and store so as to avoid

damage.

IMPORTANT INSTRUCTIONS

6 www.dimplex.com

Grounding Instructions

This heater is for use on 240

Volts. The cord has a plug as

shown on Figure 1. No adapter

should be used with this unit. The

type outlet is a 240 Volt grounding

outlet. When properly installed,

it provides a ground connection

through the cord to the heater to

protect the operation from

electric shock.

IMPORTANT INSTRUCTIONS

Figure 1:

Plug and outlet

conguration for 240

Volt, 30 Amp circuit

Ground

Plug Outlet

Heater Location And

Clearances

The heater is intended for use

located on a hard oor, table top,

desk or on shelf, and the like.

The discharge air should wipe the

walls without blowing directly on

them (Figure 2).

Ensure the air discharge is

parallel to or away from walls.

!NOTE: To prevent personal

injury always use a licensed

electrician to install new

outlets or circuits.

CAUTION: When turning and/

or tilting the heater do not block

the exhaust opening.

Outside Wall

Discharge

Figure 2

Heater Installation

Use Of Support Stand

(EMC4240 only)

The pre-installed support stand

can be swivelled out to allow an

upward angle for the air dis-

charge. When in down position,

the heater should be placed on

a at surface such that it will be

stable and not fall over (Figure 3).

Heater Installation

Figure 3

Down Position

Operation

Setting the Thermostat

Before connecting or discon-1.

necting plug, turn knob fully

counterclockwise (Figure 4).

Heater is equipped with a2.

thermostat. To adjust tem-

perature to your individual

requirements, turn thermostat

control knob clockwise all the

way to turn heater on, the

yellow power light will illumi-

nate (Figure 5). When room

reaches desired temperature,

turn thermostat knob coun-

terclockwise until you hear a

click. Leave in this position

to maintain room temperature

at this setting. For additional

heat, turn clockwise until you

hear a click again and heater

will turn on. To shut heater off

turn thermostat knob counter

clockwise all the way. The

yellow power indicator light

will turn off.

OFF

LOW

Thermostat control knob

Figure 4

Power ON

Over Temp

Surchauffe

Temperatura

Excesiva

Figure 5

Red Light

Yellow Light

8 www.dimplex.com

WARNING: Disconnect

power before attempting any

maintenance or cleaning to

reduce the risk of re, electric

shock or damage to persons.

CAUTION: Allow at least

30 minutes for the heater to

cool before attempting any

maintenance or cleaning.

To clean the exterior surface,

use a solution of water and mild

detergent, apply with damp

sponge. Wipe dry with a dry cloth.

DO NOT plug heater into outlet

until it has dried thoroughly.

Warranty

Dimplex Electric Heaters are tested

and inspected prior to shipment and

are guaranteed free from defect to the

purchaser of each new product. Any part

which proves to be defective in material

or workmanship under normal use within

one year will be repaired or replaced

without charge. The Company will not

be responsible for any expense incurred

for installation, removal from service, or

transportation costs. Any such defect

should be brought to the attention of the

Dealer where the product was purchased

and is authorized to repair or replace

within the terms of this warranty.

The Company’s only obligation under this

warranty will be at its sole option to repair

or replace any part proving defective or to

refund the purchase price thereof.

The owner/user assumes all other risks,

if any, including the risk of any direct,

indirect or consequential loss or damage

arising out of the use of or inability to use

the product.

The warranty will not apply if, in the

sole judgment of the Company, damage

or failure has resulted from accident,

alteration, misuse, abuse, incorrect

installation, or operation on an incorrect

power source.

The foregoing is in lieu of all other

warranties expressed, implied, or

statutory, and the Company neither

assumes, nor authorizes any person to

assume for it any other obligation, or

liability in connection with said product.

Maintenance and Cleaning

Dimplex North America Limited

1367 Industrial Road

Cambridge ON

Canada N1R 7G8

In keeping with our policy of continuous product improvement, we reserve the right to

make changes without notice.

DCH4831A

Fan Blade . . . . . . . . 1900010022RP

Motor Kit . . . . . . . . . 2000020022RP

Element . . . . . . . . . . 2200070122RP

Thermostat . . . . . . . 09635002RP

Cutout . . . . . . . . . . . 00009113RP

Knob - Clear . . . . . . 02210011RP

Cordset . . . . . . . . . . 4100000001RP

DCH4831L

Fan Blade . . . . . . . . 5300220200RP

Motor Kit . . . . . . . . . 2000020022RP

Element . . . . . . . . . . 2200070122RP

Thermostat . . . . . . . 2600070100RP

Cutout . . . . . . . . . . . 00009112RP

Knob - Clear . . . . . . 02210011RP

Cordset . . . . . . . . . . 4100000004RP

Replacement Parts

DCH4831L

Fan Blade . . . . . . . . 5300220100RP

Motor Kit . . . . . . . . . 2000260300RP

Element . . . . . . . . . . 2200070122RP

Thermostat . . . . . . . 2600070100RP

Cutout . . . . . . . . . . . 00009112RP

Knob - Clear . . . . . . 02210011RP

Cordset . . . . . . . . . . 4100000004RP

Autres manuels pour EMC4240

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dimplex Chauffage électrique

Dimplex

Dimplex CDFI-TMHEAT Manuel utilisateur

Dimplex

Dimplex Quantum Classic VFR 20 Manuel utilisateur

Dimplex

Dimplex Apollo APL100 Manuel utilisateur

Dimplex

Dimplex ML2TA Manuel utilisateur

Dimplex

Dimplex GDH-RD24C Manuel utilisateur

Dimplex

Dimplex PPC series Manuel utilisateur

Dimplex

Dimplex DLG1106 Manuel utilisateur

Dimplex

Dimplex DGWH4031 Manuel utilisateur

Dimplex

Dimplex DLGM29 Manuel utilisateur

Dimplex

Dimplex BUH19BWS Manuel utilisateur

Dimplex

Dimplex QSH-70 Manuel utilisateur

Dimplex

Dimplex BN Series Manuel utilisateur

Dimplex

Dimplex DLGM29 Manuel utilisateur

Dimplex

Dimplex Danube DNB20 Manuel utilisateur

Dimplex

Dimplex QRAD050 Mode d’emploi

Dimplex

Dimplex CKHA Series Manuel utilisateur

Dimplex

Dimplex DLG1058 Manuel utilisateur

Dimplex

Dimplex DGWH4031 Manuel utilisateur

Dimplex

Dimplex Optiflame DF2608-LED Manuel utilisateur

Dimplex

Dimplex Chalbury Fire CHB20BR Manuel utilisateur

Dimplex

Dimplex Alta Series Manuel utilisateur

Dimplex

Dimplex Cheriton Fire CHT20 Manuel utilisateur

Dimplex

Dimplex VR15 Manuel utilisateur

Dimplex

Dimplex RT 204 U Manuel utilisateur

Manuels Chauffage électrique populaires d'autres marques

Heatscope

Heatscope PURE Guide rapide

Sunbeam

Sunbeam Calentador SFH457A Manuel utilisateur

Dura Heat

Dura Heat DH2000C Manuel utilisateur

Harvia

Harvia K10.5GS Manuel utilisateur

Harvia

Harvia GL70 Manuel utilisateur

Heylo

Heylo DE 2 XL Manuel utilisateur

Heylo

Heylo DE 20 SH Manuel utilisateur

Harvia

Harvia PP70SP Manuel utilisateur

Tylo

Tylo SENSE SPORT Manuel utilisateur

Dirna

Dirna ecodirna SUN Mode d’emploi

Creda

Creda Heating Solution Manuel utilisateur

THERMEx

THERMEx Frame E Wi-Fi Series Manuel utilisateur

SHUFT

SHUFT UniMAX-R 1400VE EC Manuel utilisateur

HUUM

HUUM CLIFF Series Manuel utilisateur

Harvia

Harvia HL70S Manuel utilisateur

Radialight

Radialight SIRIO Manuel utilisateur

Polaris

Polaris PRE E 0715 H Manuel utilisateur

HeatQ

HeatQ HTL Manuel utilisateur
