KVM SWITCH

DUAL DISPLAY, 4K

Quick Installation Guide

DS-12860, DS-12883

DS-12862, DS-12882

User consideration

The manufacturer has the right to modify and change the information, documents

and specifications contained in the QIG without prior notice. If the software program

is found to be defective after purchase, the purchaser will be responsible for all

necessary services, repairs and any accidental or consequential damages caused by

the software.

The manufacturer is not responsible for any unauthorized adjustments to the radio

and / or television interference caused by this equipment, and the user must correct

the interference. If the operating voltage setting is not correctly selected before

operation, the manufacturer will not be liable for any damage caused.

Be sure to confirm that the voltage is set correctly before use. This product does

not have a power supply. If the power supply is required in a special environment,

the customer can configure it according to the product power interface (power

supply socket specification 5.5mm*2.1mm) and the power socket printing

parameters.

Package Contents

The multi-computer KVM switch package includes the following:

DS-12860

1 x KVM Switch, 2-Port, Dual Display, 4K, HDMI®

2 x HMDI® cable

2 x KVM cable (HDMI, USB, Audio)

1 x QIG

DS-12883

1 x KVM Switch, 4-Port, Dual Display, 4K, HDMI®

4 x HMDI® cable

4 x KVM cable (HDMI, USB, Audio)

1 x QIG

DS-12862

1 x KVM Switch, 2-Port, Dual Display, 4K, DisplayPort®

2 x DisplayPort® cable

2 x KVM cable (DisplayPort, USB, Audio)

1 x QIG

DS-12882

1 x KVM Switch, 4-Port, Dual Display, 4K, DisplayPort®

4 x DisplayPort® cable

4 x KVM cable (DisplayPort, USB, Audio)

1 x QIG

Check that all parts are in place and that they are not damaged in transit.

If you encounter problems, please contact your dealer.

To prevent damage to the machine or equipment connected to the machine, please

read this QIG carefully and follow the instructions for installation and operation.

* Since the publication of this QIG, there may be new product features. Please visit

our website to download the latest version of the QIG.

Table of contents

About QIG ................................................................................................................5

Product information .................................................................................................5

Chapter 1.................................................................................................................. 6

Introduction ...................................................................................................................5

Product description ...............................................................................................5

Product features....................................................................................................5

Operating system ..................................................................................................7

Components ..........................................................................................................8

Chapter 2 .....................................................................................................................12

Hardware installation ..................................................................................................12

Cable connection and installation .......................................................................12

Chapter 3 .....................................................................................................................13

Basic operation ............................................................................................................13

Overview .............................................................................................................13

Manual switching method...................................................................................13

Hotkey switching method....................................................................................13

Power off and restart ..........................................................................................13

Chapter 4 .....................................................................................................................14

Overview ......................................................................................................................14

Hotkey setting .....................................................................................................14

Appendix ......................................................................................................................17

Safety instructions...............................................................................................17

Product specification...........................................................................................19

About QIG

This QIG will assist you in the effective use of product features, including the

installation, setup, and operation of your equipment. You can find out what is

included in the following:

Chapter 1 Introduction - This chapter describes the rack-mounted KVM device

system, including its functions, features, and benefits, and describes and describes its

front and rear panel components.

Chapter 2 Hardware installation - This section explains how to install this product.

Chapter 3 Basic operation - Explain the basic operational concept of the KVM switch.

Chapter 4 Hotkey Operation - Describes the keyboard's hotkey combination

operations and settings.

Appendix - Mainly provide specifications and other technical information about

the relevant KVM switch.

Common terms:

Following symbols indicate the text information that should be entered:

Symbols

Text information that should be entered

[ ] The brackets indicate the key you want to enter. For

example, “Enter” means that the Enter key is pressed. For keys

that need to be entered at the same time, they are placed in the

same brackets and the keys are connected by a plus signs. For

example: [ CTRL ]

Indicates the serial number of the operation step

◆Indicate that information is provided for reference, but is

independent from the operation steps

• The origin symbol represents the classification sub-item

information and is independent of the operation steps

Product information

To find out more about our KVM product information and how to use it more

efficiently, you can go to our website or contact an authorized reseller for more

contact information.

Chapter 1

Introduction

Product description

As a KVM switch, Dual display desktop KVM Series Switches allows users to access

from a single USB keyboard, mouse and Dual display console accesses 2 to

4 computers.

As per built in USB hub, it allows each computer (one computer at a time) to access

the connected peripherals.

Switch installation is quick and easy, just plug the cable into the correct port. No

software settings are required, no installation procedures and no compatibility

issues. Desktop compact design, metal casing, easy to install and place to provide

a variety of video interface options, to provide users with a variety of fast switching

options for audio, video, USB devices, saving desktop space, is a multimedia

application such as SOHO office Ideal.

Product features

Dual Video Display series KVM switch

Single USB Console controls 2 to 4 of computers and peripherals USB (low speed)

Built-in USB2.0 hub, compatible with USB2.0 protocol specification

HDMI video maximum support resolution is 4K@30fp (DS-12860, DS-12883)

DisplayPort video maximum support resolution 4K@60fp (DS-12862, DS-12882)

Support Dual Monitor display

Provide keyboard hotkey switching shortcut function and device panel button two

switching function selection

Support multiple platforms for various operating systems

BIOS level hardware connection, no need to install drivers and control software

The front panel of the device is extended with a USB interface, which is convenient

for users to connect peripheral devices such as a USB keyboard, a mouse, or

a USB flash drive or a USB printer

Provide a variety of hotkey selection and setting functions, so that users can set

their own hotkeys according to the situation

Automatically scans the connected computer ω

Operating system

Operating systems supported by remote users' computers include: Windows

XP and above

The operating systems supported by the server connected to the switch are shown

in the following table:

operating system

version

Windows

Windows 2000 / XP / 2003 / 2008 / Vista

7 / 10 / 11

Linux

RedHat

9.0 or higher

SuSE

10/11.1 or higher

Debian

3.1/4.0

Ubuntu

7.04/7.10

UNIX

AIX

4.3 or higher

FreeBSD

5.5 or higher

Sun Solaris

8 or higher

Mac

OS 9.0 to 10.6 (Snow Leopard)

Novell

Netware

6.0 or higher

Components DS-12860

Front view Rear view

1. Power Indicator

2. Power Button

3. Front USB interface, you can

connect mouse and keyboard,

U disk storage device and printer.

4. Power 9V DC=, optional

5. For HDMI video interface

6. For the integrated audio

and MIC interface,

connect to KVM cable

7. For the computerside B type

USB connection interface

8. Local audio output interface

9. Output interface for local MIC

10. Local USB keyboard and

mouse input interface

Components DS-12862

Front view Rear view

1. Reset Button

4. Power 9V DC=, optional

2. Power Indicator Switch Button

5. For DisplayPort video interface

3. Front USB 2.0 Type A interface, you

can connect mouse and keyboard,

U disk storage device and printer.

6. For the integrated audio

and MIC interface,

connect to KVM cable

7. For the computerside B type

USB connection interface

8. Local audio output interface

9. Output interface for local MIC

10. Local USB keyboard and

mouse input interface

Components DS-12882

Front view Rear view

1. Reset Button

4. Power 9V DC=, optional

2. Power Indicator Switch Button

5. For DisplayPort video interface

3. Front USB 2.0 Type A interface,

you can connect mouse and

keyboard, U disk storage device

and printer.

6. For the integrated audio

and MIC interface,

connect to KVM cable

7. For the computerside B type

USB connection interface

8. Local audio output interface

9. Output interface for local MIC

10. Local USB keyboard and

mouse input interface
