Digitus DA-70855 Manuel utilisateur

USB3.0 Type-C™Multiport HDMI

Adapter

Manual

DA-70855

Introduction

The USB Type-C™ HDMI multiport adapter, 3-port extends your USB-C™ device with

three additional ports. Use the HDMI port to connect an additional TV set or monitor

to your laptop or hold a presentation with a projector. The highest possible

resolution is UHD (4K/30Hz). In addition, the adapter has a USB 3.0 port to connect

external USB devices. It also complies with USB-BC specification 1.2 (USB Battery

Charging) and is thus suitable for charging mobile devices (max. 5V/1.5A). Moreover,

it features a USB-C™ port with Power Delivery (PD) 2.0 functionality to power your

laptop while using the adapter. The multiport adapter is suitable for all operating

systems: Windows®, Mac®, Google Chrome®.

Features

Chipset: AG6310 + LDR6023SD

Support USB-C input, USB 3.0 and HDMI output

Support HDMI 4Kx2K@30Hz, 9Gbps Bandwidth

Support USB 3.0 super speed (5Gbps) transmission, downward compatible

USB 2.0

Support BC1.2, the power of USB-A port can be up to 7.5W (5V/1.5A)

USB 3.0 port supports to charge and transmit data for the USB device

simultaneously

Support to charge for USB-C supported devices and supply power for the

adapter at the same time

USB-C female port supplies power up to 60W(20V/3A)

Multiple USB-C interfaces support plug and play, hot swap, and easy to

use and carry

Package Content

1 x Main unit: USB Type-C™ HDMI multiport adapter, 3-port

1 x Manual

Specifications

Input/Output Connector

Input USB-C Male x1/USB-C Female x1

Output HDMI Female x1/USB-A Female x1

Resolutions

Resolutions Up to 4KX2K@30HZ

Physical

Weight 39g

Size L-W-H Main Unit: 75x47x15mm

Cable: 150mm

Environmental

Operating Temperature 0°C to +45°C

Operating Humidity 10% to 85% RH (no condensation)

Storage Temperature -10°C to +70°C

Storage Humidity 5% to 90% RH (no condensation)

Power Supply

USB3.0 Port UP to 7.5W (5V/1.5A)

USB-C Female Charging Port Up to 60W (20/3A)

Operation

1. Connect the USB-C male port of this product to Macbook®or Chromebook®

2. Connect HDMI output of this product to HDTV with one HDMI cable

3. Connect the USB 3.0 output of this product to a USB 3.0/2.0 device with a USB

cable

4. Connect the USB-C charging port, it can charge for the host computer and support

this product to work simultaneously

Note:

1. When connecting the USB-C male port of the adapter to Chromebook®, the

mouse to be connected to the USB 3.0 port will not work immediately, it will

have seconds’ delay. This problem also occurs in other similar type-c adapter

(including Apple original 3 in 1 Adapter) when connected to Chromebook®.

2. When plugging in and out the PD Adapter, the connected USB devices will get

disconnected flashily and then reconnect in a few seconds, so to prevent

possible data loss or corruption, avoid disconnecting the PD Adapter from AC

power while transferring data

Hereby Assmann Electronic GmbH, declares that the Declaration of Conformity is part of the

shipping content. If the Declaration of Conformity is missing, you can request it by post under the

below mentioned manufacturer address.

www.assmann.com

Assmann Electronic GmbH

Auf dem Schüffel 3

58513 Lüdenscheid

Germany
