Digital Watchdog V1362DIR Manuel utilisateur

5436 W Crenshaw St. Tampa, FL 33634

Tel: 866-446-3595 / 813-888-9555

Fax: 813-888-9262

www.Digital-Watchdog.com

[email protected]

Technical Support Hours: Monday-Friday

8:30am to 8:00pm Eastern Time

Before installing and using the camera, please read this manual carefully.

Be sure to keep it handy for future reference.

ABOUT MANUAL

01302012

User Manual

V1362DIR / V1363TIR /

V1382TIR / V1382TIRH / V1365T

Vandal Dome Camera

■ Do not open or modify.

■Do not open the case except during maintenance and installation,

for it may be dangerous and can cause damages.

■Do not put objects into the unit.

■Keep metal objects and ammable substances from entering the camera. It can cause re, short- circuits,

or other damages.

■Be careful when handling the unit.

■To prevent damages, do not drop the camera or subject it to shock or vibration.

■Do not install near electric or magnetic elds.

■Protect from humidity and dust.

■Protect from high temperature.

■Be careful when installing near the ceiling of a kitchen or a boiler room, as the temperature may rise to

high levels.

■ Cleaning

To remove dirt from the case, moisten a soft cloth with a soft detergent solution and wipe.

■Mounting Surface

The material of the mounting surface must be strong enough to support the camera.

PRECAUTIONS

Before sending your camera out for repair, check the items below.

If the problem persists after checking these items, contact your service

center.

■No Video

Check the coaxial cable and make sure it is connected securely.

Check the lens’iris adjustment at the menu setup of the camera.

Check the power supply and make sure the camera has the proper voltage and current.

■Out-of-Focus Video

Check the clear dome cover and the lens for dirt or ngerprints. Use a soft cloth and gently clean.

Check the lens manual focal and zoom adjustment. Field test monitor is recommended.

TROUBSHOOTING

■1/3" Sony Super HAD II CCD

■540 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■100ft Range IR with Intelligent Camera Sync

■Electronic Day and Night

■DRC (Dynamic Range Compressor)

■HME (Highlight Masking Exposure)

■SLC (Side Light Compensation)

■AGC / BLC / AWB

■Negative Imaging

■Mirror Image Control

■RS485 Built-In

■Programmable Privacy Zone (4) & Motion Detection

■Easy Icon Driven OSD Menu with Built-In Joystick

■Secondary Video-BNC Output

■1/3”High Resolution CCD

■High Resolution 560 TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■Electronic Day and Night

■100ft Range IR with Intelligent Camera Sync

■True Day and Night / TDN5

■Star-Light (Super Low LightTechnology)

■DRC (Dynamic Range Compressor)

■3D-DNR (3D Digital Noise Reduction)

■HME (Highlight Masking Exposure)

■Negative Imaging

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■Secondary Video-BNC Output

FEATURES*-

V1362DIR

FEATURES*-

V1363TIR

■1/3”Sony Super HAD ⅡCCD

■High Resolution 560 TV Lines

■OMNI-Focus 2.9~8.5mm 3X Motorized Zoom, Auto Iris 70ft Range IR with Intelligent Camera Sync

■True Day & Night / TDN5 (Electro Magnetic Mechanism)

■Max-DR (Electronic Wide Dynamic Range)

Enables the camera to capture perfect images in both bright and dark environments simultaneously.

■3D-DNR (3D Digital Noise Reduction)

Produces less noise and more color during low-light application.

■HME (Highlight Mask Exposure)

Masks overly exposed light to produce a true video image of any environment.

■SLC (Side Light Compensation)

■DIS (Digital Image Stabilizer)

■RS485 Built-In

■Programmable Privacy Zone (6) & Motion Detection Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■No Fog or Condensation under AnyWeather Condition

FEATURES*-

V1382TIR

FEATURES*-

V1382TIRH

■1/3”Sony Super HAD ⅡCCD

■High Resolution 560 TV Lines

■OMNI-Focus 2.9~8.5mm 3X Motorized Zoom, Auto Iris 70ft Range IR with Intelligent Camera Sync

■True Day & Night / TDN5 (Electro Magnetic Mechanism)

■Max-DR (Electronic Wide Dynamic Range)

Enables the camera to capture perfect images in both bright and dark environments simultaneously.

■3D-DNR (3D Digital Noise Reduction)

Produces less noise and more color during low-light application.

■HME (Highlight Mask Exposure)

Masks overly exposed light to produce a true video image of any environment.

■SLC (Side Light Compensation)

■DIS (Digital Image Stabilizer)

■RS485 Built-In

■Programmable Privacy Zone (6) & Motion Detection Easy Icon Driven OSD Menu with Built-In Joystick

■Auto Sensing 12VDC or 24VAC with Line Lock

■Built-in Heater , WithstandTemperatures as Low as -40°F

■No Fog or Condensation under AnyWeather Condition

FEATURES*-

V1365T

■1/3" Pixim Seawolf CMOS Sensor

■690 Horizontal TV Lines

■3.3 ~ 12mm Varifocal Auto Iris Lens

■TDN (True Day and Night/IR Cut Filter)

■3D-DNR (3D Digital Noise Reduction)

■Powerful Wide Dynamic Range

■Smear Canceling Circuit

■AGC / BLC / AWB

■DIS (Digital Image Stabilizer)

■HME (Highlight Masking Exposure)

■AGC / BLC / AWB

■Programmable Privacy Zone (6) & Motion Detection

■Easy Icon Driven OSD Menu with Built-in Joystick

■Low Power Consumption

■Auto Sensing 12VDC/24VAC with Line Lock

■Secondary Video-BNC Output

DIMENSION (mm)*

109.6

103.1

41.3

6.5



145

117.0

125.0



5.0



4.5

91.0

85.0

L= 300mm

VIDEO(yellow)

BNC JACK

DC 12V or AC24V

5mm TWIST SOLDERING

RED

BLACK

1110

INSTALLATION*

A. Loosen the Fixing Screw (D), using a screw

driver.

B. Separate the Upper Case (A) and the Base (E).

C. Detach the Gimbal (C) from the Base (E).

D. Cut a hole in the ceiling for routing the cables.

E. Place the Base (E) horizontally against the

ceiling and drill the screw holes at the two

marked positions.

F. Pass the Power Cable (F) and Video Cable (G)

from the camera unit through the cable hole in

the ceiling.

G. Align the screw holes of the camera unit with

the holes in the ceiling. Secure

the camera to the ceiling with the two screws.

H. Fix Gimbal (C) to the Base (E).

I. Install and adjust the camera unit.

J. Adjust the dome liner to show the lens through

the camera window, and then x it to the Base (E).

11. Attach the Upper Case (A) with the Base (E) and

tighten Loosen the Fixing Screw (D).

CONNECTION*

DC12V

CAUTION : Chec k for polarit polarit y when using a DC12V power power suppl y.

300.0

DC12V / AC24V

1312

CAMERA SETTING*

■LENS ADJUSTMENT

1. Focus Lever

2. Zoom Lever

1. Set the zoom level to the desired position by moving the Zoom Lever.

2. Set the focus, using the Focus Lever.

: V1362DIR, V1363TIR, V1382TIR, V1382TIRH, V1365T

AMERA SETTING FOR SIDE OSD CONTROL BOARD*

LEFT

UP DOWN

RIGHT

CON2

CON1

FUNCTIONAL OF CONTROL BOARD

[1] SW

[2] CON1

[3] CON2

Functional control of O.S.D(On Screen Display)

Second Video output connector

RS-485 connector

1514

REMOTE CONTROL*-

V1382TIR, V1382TIRH

NOTE: PRESS [KEY+ID]

(DEFAULT IS “001”FOR ID=1)

PRESS [ENT] TO ACCESS THE MENU

NOTE : THE CAMERA ID IS A 3-DIGIT NUMBER.

Set the Camera iD in the OSD menu.The default

setting is 001. NOTE : If the Camera ID is modied,

you must reset the power for the new settings to

apply. Once you reset the power, the camera will

recognize the new Camera ID.

If you press the KEY Button, the camera display

will turn into the standby image. NOTE : The LED

icker for approximately 20 seconds.

Input the same number used as the Camera ID to

the Remote Controller. After the number has been

input, the LED light will turn on, and the remote

controller will be ready to use. NOTE : The ID

number is 3 digits.

The ZOOM In (+) and ZOOM Out (-) Keys are used

to control the zoom of your camera lens and to

select the zoom area of alarm function. Select the

area where you wish to observe the movement of

objects.

Select the zoom range by pressing the WIDE (7)

Key. Save the zoom range by pressing theTELE (8)

Key. NOTE: If the zoom range is smaller than the

alarm standby range, the zoom range setting will

not be saved.

■REMOTE CONTROL Instructions

MODULE OSD MENU*-

V1362DIR

EXPOSURE COLOR DAY&NIGHT

BRIGHTNESS

SHUTTER

BLC

AGC

WB MODE D&N MODE

FUNCTION MOTION PRIVACY

MIRROR

SHARPNESS

GAMMA

SLC

HME

DRC

ALARM MASK 1

MASK 2

MASK 3

MASK 4

COLOR SET

SYNC SETUP EXIT

SYNC CAMERA ID

TITLE EDIT

TITLE RESET

TITLE POSITION

DPC SET

LANGUAGE

PC CONT.

EXIT

SAVE & EXIT

FACTORY RESET

Menu Access and Control

Zoom Function Control

Key Button

ID Buttons

Motion Alarm

ON / OFF

1716

EXPOSURE

BRIGHTNESS MANUAL (ELC LEVEL : 0 ~ 100) / DC (DC LEVEL : 0 ~ 31)

SHUTTER 1/60, 1/100FLC, 1/120 ~ 1/100000

BLC OFF / ON

BLC (Back Light Compensation)

AGC OFF / 12dB ~ 36dB

AGC (Auto Gain Control)

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

COLOR

WB MODE AWC / ATW / MANuAL / PUSHLOCK (AWC is recommended.)

R-Y GAIN 0 ~ 255

B-Y GAIN 0 ~ 255

DAY & NIGHT

Day & Night Mode

AUTO / COLOR / BW

COLOR---->BW : Switching from COLOR to BW; If the number is higher, the camera will only

switch during a super low light condition.

BW ---->COLOR : Switching from BW to COLOR; This number should be always lower than

COLOR to BW

Read Time : time interval to switch from COLOR to BW

COLOR:

B&W BURST(OFF/ON) ; When the burst is OFF, the picture will have less noise.

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

OSD MENU*-

V1362DIR

FUNCTION

MIRROR OFF/ MIRROR

SHARPNESS 0 ~ 49

GAMMA USER / 0.45 / 0.6 / 1.00

SLC OFF / ON (0 ~ 50)

SLC (Side Light Compensation)

HME OFF / ON (0 ~ 55)

HME (Highlight Masking Exposure)

DIS OFF /ON

DIS (Digital Image Stabilizer)

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

MOTION (OMNI-Plus Cameras Only)

MOTION

OFF / ON

SET WINDOW

ALL SET (Set the Entire Screen)

ALL CLEAR (Clear the Entire Screen)

SENSITIVITY (0 ~ 55)

SHOW INDICATOR (OFF / ICON / TRACE)

DELAY OUT(1 ~ 15)

Motion Alarm Zoom-In Delay

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

1918

PRIVACY

MASK 1 OFF / ON

MASK 2 OFF / ON

MASK 3 OFF / ON

MASK 4 OFF / ON

COLOR SET BLACK / GRAY / COLOR 1~ 6

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

SYNC

SYNC MODE INTERNAL / AUTO

V-PHASE 0 ~ 199

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

SETUP

CAMERA ID 0 ~ 255

TITLE EDIT

TITLE RESET

TITLE POS.

DPC OFF / ON

DPC ( Dead Pixel Cancellation)

LANGUAGE English / Chinese

PC CONT. OFF / ON

EXIT JUMP EXIT / SAVE&EXIT / FACTORY SET

EXIT

EXIT Exit the menu

SAVE&EXIT Exit the menu and save the setting

FACTORY SET Reset the menu setting to factory default

MODUEL OSD MENU*-

V1363TIR

EXPOSURE COLOR DAY&NIGHT

BRIGHTNESS

AE PREFERENCE

BLC / HME

AGC

STARLIGHT

NIGHT-UP

WB MODE

R-Y GAIN

B-Y GAIN

D&N MODE

C_SUP

A_SUP

FUNCTION MOTION PRIVACY

MIRROR

SHARPNESS

GAMMA

FREEZE

NEGATIVE

D-ZOOM

3D DNR

DRC

MOTION PRIVACY

SYNC SETUP EXIT

SYNC TITLE EDIT

PC CONTROL

LANGUAGE

MONITOR

OSD COLOR

OMNI LENS

EXIT

SAVE & EXIT

FACTORY RESET

Autres manuels pour V1362DIR

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Digital Watchdog Caméra de sécurité

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-MC553WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-D4583WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus HD over Coax... Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MD421TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-VA853WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-D3263WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog MegaPix Pano DWC-PZ21M69T Manuel utilisateur

Digital Watchdog

Digital Watchdog INFINITY 960H SNAP-IT DWC-D4567WD Manuel utilisateur

Digital Watchdog

Digital Watchdog STAR-LIGHT DWC-V4283WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MVA5Wi28T Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-B7553TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-light Plus DWC-B6883WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog STAR-LIGHT Universal HD over Coax... Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-MC753WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-B5661TIR Manuel utilisateur

Digital Watchdog

Digital Watchdog Snapit DWC-V4367WD Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light Plus DWC-V6563WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog D4252 Series Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGApix DWC-MPVA5WiAT Manuel utilisateur

Digital Watchdog

Digital Watchdog MEGAPIX DWC-MV45WiATW Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-MV72Wi4 Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-D3263WTIR Manuel utilisateur

Digital Watchdog

Digital Watchdog DWC-V1CMW Manuel utilisateur

Digital Watchdog

Digital Watchdog Star-Light 960H DWC-B6563DIR Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
