Digicom Tiziano 56 Memory Manuel utilisateur

rev. 1.0 del 03/99

TIZIANO 56

MEMORY

http://www.digicom.it

User's Manual

TIZIANO 56 MEMORY

Index

INDEX

PREFACE III

1. GENERALITY 1.1

1.1. PRODUCT PACKAGE CONTENTS 1.2

1.2. PRODUCT FEATURES 1.2

2. INSTALLATION 2.1

2.1. HARDWARE INSTALLATION 2.1

Picture 2.1.Desktop version rear panel 2.2

2.2. SOFTWARE INSTALLATION 2.2

2.2.1. WINDOWS® 95/98/NT4.0 2.3

2.2.2. MACINTOSH® - MODEM INSTALLATION FORARAOPENTRANSPORT 2.6

3. MODEM AT COMMAND SET 3.1

3.1. AT COMMAND SET DESCRIPTION 3.1

3.1.1. MNP10 COMMAND 3.9

3.1.2. CELLULAR MODE COMMAND 3.9

3.2. VOICE AT COMMANDS 3.10

3.3. SPEAKERPHONE AT COMMANDS 3.12

3.4. S REGISTERS 3.13

3.4.1. SPECIAL S REGISTER DESCRIPTION 3.13

3.5. CONNECTION MESSAGES 3.14

4. PERFORMANCES WHEN COMPUTER IS OFF 4.1

4.1. MAIN FEATURES 4.1

4.2. DESCRIPTION OF PWR LED FOR THE MEMORY FUNCTION 4.2

4.3. RECORD THE WELCOME MESSAGE 4.2

4.4. DOWNLOAD OF VOICE MESSAGES AND FAX 4.4

4.5. AT COMMANDS FOR MEMORY FUNCTION 4.4

DECLARATION CE OF CONFORMITY V

TIZIANO 56 MEMORY

Preface

III

PREFACE

system, or trasmitted in any form or by any means, electronic, otherwise, without the prior

written permission of DIgicom S.p.A..

The contents of this booklet may be modified without prior permission.

Every possible care has been taken in testing and putting together all the documentation

containedinthisbooklet,however Digicom cannot take anyresponsability brought bythe

use of this booklet.

The following installation rules should be respected in order to have the best working

order of the equipment and for the user’s safety.

ENVIROMENTAL CONDITIONS

For all devices:

ENVIROMENTAL TEMPERATURE RELATIVE HUMIDITY

from 0 to + 45°C from 20 to 80% n.c.

Rapid changes of temperature or humidity should be avoided (0,03°C/min).

This equipment, including cables, should be installed in an area free from:

lDust, humidity, heat from direct sun light.

lObjects which irradiate heat. These could cause damage to the container or other

problems.

lObjects which produce a strong electtromagnetic field (loudspeakers, etc.)

lLiquids or chemical corrosive substances.

GENERAL WARNINGS

For all equipment powered directly from mains power

POWER SUPPLY 220-240 Volt single phase 50 Hz

ISOLATION CLASSIFICATIONS only those indicated on the equipment label

NOMINAL CURRENTS only those indicated on the equipment label

To avoid electric shock, the equipment should never be opened.Ask qualified personnel

help.

Disconnect the power cable from the wall outlet when the equipment is not to be used for

a long period. To disconnect the cable pull it by the plug, never pull it by the cable itself.

If there should be liquid or object penetration in the equipment, disconnect the power

cable and call a qualified personl for testing.

CLEANING THE TERMINAL

Use a clean and soft cloth. Wet the cloth with water or natural detergent if it is necessary

to remove any stains. Never use chemical products such as petrol or solvents.

VIBRATIONS OR DROPPING

Caution against vibrations and dropping

WARNING

This is a class A product.

In a domestic environment this product may cause radio interference

in which case the user may be required to take adequate measures.

TIZIANO 56 MEMORY

Generality

1.1

1. GENERALITY

This operating manual describes the installation procedures and the main

features of Tiziano 56 Memory.

Tiziano 56 Memory is a

multistandard fax/modem

suitable for applications

requiring ultra high speed

over the PSTN line.

Itcomplieswith ETS 300-001

European regulation and it is

homologated by the P.T.

Ministery to be connected to the

national telephone line (RTN).

The homologation number is shown on the label under the modem.

DEAR CUSTOMER,

Your Tiziano 56 Memory complies with the 56Kbps standard

accordingtotheITU-TV.90regulationfordatacommunication

up to 56000 bps.

The V.90 standard, like the K56Flex, has an unbalanced connection speed.

Itmeansthat you have a connection wheredataare received at the maximum

speed of 56000 bps and sent at the maximum speed of 33.600 bps.

The unbalance, due to the technical limitations of the analog telephone lines,

allows to carry out connections with top performances in applications of

Internet access or remote access.

In order to reach the connection speed of 56000 bps, according to the 56K

technology, one of the two modems must be connected to a digital network

(usually ISDN or *64 in G703/G7047). In fact, the modems of the Services

Provider (Internet POP or access servers) are special ones, like "Central

Site Modem"(CSM).

Themaximum speed, when receivingdata, in users connectionsover analog

line is 33.600 bps.

1.2

TIZIANO 56 MEMORY

Generality

1.1. PRODUCT PACKAGE CONTENTS

lTiziano 56 Memory

lSerial cable

lDrivers for Windows® 98/95, NT4 (Windows® version only)

lDrivers for Mac OS (Macintosh® version only)

lVoice/Data/Fax software for Windows® 98/95, NT4(Windows® version

only)

lVoice/Data/Fax software for Macintosh® (Macintosh® version only)

lInstallation guide

1.2. PRODUCT FEATURES

lAsynchronous Tx: from 300 to 115200 bps.

lStandardmodulations for modem section:V.90,K56flex™,V.34 annex 12,

V.34, V.32bis, V.32, V.22bis, V.22, V.21, V.23 (1200/75).

lStandard modulations for fax section: V.27ter, V.29 Group 3 Class 1 for

fax Tx/Rx up to 14.400 bps (optional fax emulation software is required).

lAT command set with autobaud for the data mode up to 115.200 bps.

lNon volatile memory directory for user profiles.

lAuto dial and autoanswer.

lTone and pulse dialing.

lInternal telephone book

lMNP10-EC Enhanced Cellular (available on request)

lError Correction: MNP 4/10 and V.42

lData Compression: MNP 5 and V.42bis

lFax emulation

lDigital answering machine

lSpeakerphone

TIZIANO 56 MEMORY

Installation

2.1

2. INSTALLATION

2.1. HARDWARE INSTALLATION

Check the modem is OK after you removed it from the package.

Use the universal

cable in the

package to

connect the

modem to anyone

of the computer

serial ports.

Connect the modem to

the telephone line through the

cable supplied.

IfyouworkwithaMacintosh®connect the serial

cable to the "Modem port" or to the "Printer port".

After you carried out the serial ports and the

telephone line connections connect the modem to

theexternal power supply and switchON the power

switch on the rear panel.

Check that the LED PWR

indicator is on.

Go on with the installation reading the SOFTWARE INSTALLATION section.

2.2

TIZIANO 56 MEMORY

Installation

ON PWR RS232 JA JB JC JD LINE

On/Off

Switch Microphone

Headset

Input

Power

Supply Audio

Input

Audio

output Line

Picture 2.1. Desktop version rear panel

2.2. SOFTWARE INSTALLATION

lWINDOWS® 95/98/NT4.0 Drivers

Before starting with the software installation, please read the file Readme.txt

on the Floppy Disk or the CD ROM included with the modem package.

This file contains the complete installation procedure and more details about

the different versions of Windows® 95/98.

The following sections describe the standard installation of the software

driver for your modem using Windows® 98/95/NT4.0

lMACINTOSH® ARA/Open Transport Drivers

Copy your modem driver from the Floppy Disk or the CD ROM folder into the

"System Folder"-> Extensions ->Modem Script.

Your modem driver is now listed and available for any application that uses

ARA/Open Transport.

Remember to select the correct communication port in the application in

accordance with the hardware installation and disconnect the AppleTalk

protocol on the busy port.

TIZIANO 56 MEMORY

Installation

2.3

Follow this procedure to correctly disconnect the protocol:

1. Open the AppleTalk from the Control panel

2. Select "User Mode" from Edit Menu (or command-U)

3. Select "Advanced" and then click OK

4. Click "Options"

5. Select "Inactive" and then click OK

6. Close the AppleTalk

7. Save the new settings

Initialization string for FreePPP

If you are using FreePPP for connections to the Internet or to other access

systems,theinitialization string is the following: AT&FX3&C1&D2&K3\N3%C3

lOTHER DRIVERS

For other Operating Systems, see the installation procedures on the Floppy

Disk or the CD ROM included in the modem package.

2.2.1. WINDOWS® 95/98/NT4.0

1. Run Windows®95/98/NT4.0

2. Select from the START icon : Settings-Control Pannel- Modem- Add

2.4

TIZIANO 56 MEMORY

Installation

3. From the window "Install New Modem" put a tick in the box “Don’t detect my modem"

and click Next.

4. Click on Disk.

5. Inthewindow "Install from disk":InserttheFloppydiskortheCDROMintheappropriate

drive(A:or CD-Rom reader) and select the unit"Copy manufacturer's files from:"then

press OK.

TIZIANO 56 MEMORY

Installation

2.5

6. From the list select the driver to use (e.g. Digicom Tiziano 56 Memory) and click Next.

7. Select the COM port where your modem is connected, then clik Next and then Finish.

Your modem is now installed among the modems Windows® will use for the

connections. It will be possible to select it from the list in the Windows®

setup menus (Hyperterminal, Remote Access, etc.).
