Digi ConnectPort LTS 8 Manuel d'installation

ConnectPort® LTS

Command Reference

Revision history—90001099

Revision Date Description

B August

2010

Minor updates.

C June 2012 Added command descriptions.

D January

2017

Rebranding and fix to set time command parameters and example.

E September

2017

Updated the customflow option description and the Set custom flow control

example in the Set serial Command.

Trademarks and copyright

Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the

property of their respective owners.

Disclaimers

Information in this document is subject to change without notice and does not represent a

commitment on the part of Digi International. Digi provides this document “as is,” without warranty of

any kind, expressed or implied, including, but not limited to, the implied warranties of fitness or

merchantability for a particular purpose. Digi may make improvements and/or changes in this manual

or in the product(s) and/or the program(s) described in this manual at any time.

Warranty

To view product warranty information, go to the following website:

www.digi.com/howtobuy/terms

Send comments

Documentation feedback: To provide feedback on this document, send your comments to

techcomm@digi.com.

Customer support

Digi Technical Support: Digi offers multiple technical support plans and service packages to help our

customers get the most out of their Digi product. For information on Technical Support plans and

pricing, contact us at +1 952.912.3444 or visit us at www.digi.com/support.

ConnectPort® LTS Command Reference 2

Contents

Introduction

Products to which this book applies 5

Quick reference for configuring features 6

Access the command line 8

Configure an IP address 9

Basic command information

Navigation and editing keys 11

Displaying online help 11

Abbreviating commands 11

Syntax conventions 11

Entering special characters in string values 12

Verifying device support for commands 12

User permissions in ConnectPort LTS products

Multi-user model 14

Increasing security for device users 14

Command descriptions

backup 17

bash 18

boot 19

close 21

connect 23

display 24

display buffers 27

exit 29

help and ? 30

info 31

kill 37

newpass 38

ping 39

python 40

quit 41

reconnect 42

revert 44

ConnectPort® LTS Command Reference 3

ConnectPort® LTS Command Reference 4

rlogin 48

set alarm 49

set autoconnect 52

set buffer 56

set esc 59

set ethernet 60

set group 62

set host 64

set ippool 65

set lcd 66

set modem 68

set network 70

set nfs 75

set permissions 78

set pmodem 84

set portauth 86

set portgroup 90

set ppp 92

set profile 96

set python 99

set realport 100

set rtstoggle 102

set samba 104

set sdmemory 107

set serial 109

set service 112

set smtp 118

set snmp 120

set socket_tunnel 126

set switches 128

set sysauth 131

set syslog 135

set system 137

set tcpserial 138

set time 141

set trace 143

set udpserial 146

set usb 150

set user 153

set web 158

set xbee 159

show 162

status 166

telnet 167

wan 168

who 169

Introduction

This book describes the commands in the command-line interface for several Digi product families,

listed below. This chapter provides the following:

nA quick reference showing the commands used to configure features or perform configuration

tasks from the command line.

nBasic information that applies to all commands, including navigation and editing keys,

displaying online help, abbreviating commands, syntax conventions, and entering special

characters in string values.

nHow to access the command line.

nHow to configure an IP address for a ConnectPort LTS product from the command line, if an

address has not already been assigned.

nInformation about user models and user permissions in ConnectPort LTS products, and how

they affect the commands you can issue.

Products to which this book applies 5

Quick reference for configuring features 6

Access the command line 8

Configure an IP address 9

Products to which this book applies

This manual documents the command-line interface for the ConnectPort LTS Family, which includes

these products:

nConnectPort LTS 8

nConnectPort LTS 8 MEI

nConnectPort LTS 8 W

nConnectPort LTS 8 MEI W

nConnectPort LTS 16

nConnectPort LTS 16 MEI

nConnectPort LTS 16 W

nConnectPort LTS 16 MEI W

nConnectPort LTS 16 MEI 2AC

ConnectPort® LTS Command Reference 5

Introduction Quick reference for configuring features

ConnectPort® LTS Command Reference 6

nConnectPort LTS 32

nConnectPort LTS 32 MEI

nConnectPort LTS 32 W

nConnectPort LTS 32 MEI W

Quick reference for configuring features

The following table shows common features that can be configured from the command line, and the

commands used to configure each feature. If you are viewing the PDF file of this document, click the

commands in the “Commands” column to go to the command descriptions.

Feature/Task Commands

Alarms set alarm

Autoconnection

(automatically connect a

user to a server or network

device)

set autoconnect

set serial

set tcpserial

Configuration

management/administration

Backup/restore a configuration from a TFTP server on the network:

backup

Update firmware: boot

Reset configuration to factory defaults: revert or boot

action=factory” (see boot)

Reboot the device: boot

Display current configuration

settings in a device

show

Ethernet settings set ethernet

Help on device commands help and ?

Host name for a device

(Specify a name for the

device)

set host

IP address settings set network

Multiple Electrical Interface

(MEI)

set switches

Point to Point Protocol (PPP) set ppp

Port buffering display buffers

set buffer

Port profiles: sets of

preconfigured serial-port

settings for a particular use

set profile

Introduction Quick reference for configuring features

ConnectPort® LTS Command Reference 7

Feature/Task Commands

Python program storage and

execution on ConnectPort

LTS products

To learn about the Python programming language and

writing programs: see the Digi Python Programming

Guide.

To configure Python programs to execute when the Digi

device boots: set python

To manually execute a Python program from the command

line: python

RealPort (COM port

redirection) configuration

set realport

See also the RealPort Installation Guide.

Remote login (rlogin) rlogin

Reverting configuration

settings

revert

RTS Toggle set rtstoggle

Serial port configuration Serial port communication options: set serial

Port profiles: set profile

RTS Toggle: set rtstoggle

TCP serial connections: set tcpserial

UDP serial characteristics: set udpserial

Security, users, user access

permissions, and

user groups

See User permissions in ConnectPort LTS products for a discussion

of how users and access permissions are implemented in Digi

Connect products. To create users and change user names: set user

To control access to inbound ports:set service

To issue new password to user: newpass

To set permissions associated with various services and

commands: set permissions

To add or remove user groups, change group configuration

attributes, or display group configuration attributes: set group

Simple Network

Management Protocol

(SNMP)

To configure SNMP: set snmp

To enable/disable SNMP service: set service

Simple Mail Transfer

Protocol (SMTP) settings

To configure SMTP settings: set smtp

Set system information:

assign system-

identifying information to a

device

set system

Socket tunnel setting set socket_tunnel

Statistics for your

ConnectPort LTS product

info

Introduction Access the command line

ConnectPort® LTS Command Reference 8

Feature/Task Commands

Status of your ConnectPort

LTS product

display

status

who

Telnet to network devices telnet

LCD set lcd

NFS set nfs

Samba set samba

SD memory set sdmemory

Syslog set syslog

Trace set trace

USB set usb

Web set web

XBee set xbee

Access the command line

To configure devices using commands, you must first access the command line, and then log on as

needed.

This procedure assumes that you have already configured the ConnectPort LTS product with an IP

address.

1. To access the command-line interface for the ConnectPort LTS product, enter the following

command from a command prompt on another networked device, such as a server:

telnet

ip address

ssh

user@ ip address

Where:

ip address is the ConnectPort LTS product’s IP address.

user is the username on ConnectPort LTS product.

For example:

telnet 192.3.23.5

ssh root@192.2.23.5

Or connect to the serial console port with a terminal emulator.

Introduction Configure an IP address

ConnectPort® LTS Command Reference 9

2. A login prompt is displayed. If you do not know the user name and password for the device,

contact the system administrator who configured the device. The default username is “root”

and the default password is “dbps.”

3. If the system interface access option of the user is set as “Shell”, the bash-shell can be

accessed after authentication is passed. To access configuration-shell from the bash-shell,

enter following command on the bash-shell.

configshell

If the system interface access option of the user is set as “CLI menu”, the configuration-shell

can be accessed directly after authentication is passed. For details on configuring the system

interface access option, see the Digi product’s User’s Guide or the “set user” command.

Configure an IP address

If the device to which you will be issuing commands has not already been assigned an IP address, or if

the IP address needs to be modified from its initial configuration, see the Digi product’s User’s Guide

for details on configuring an IP address.

Basic command information

Navigation and editing keys 11

Displaying online help 11

Abbreviating commands 11

Syntax conventions 11

Entering special characters in string values 12

Verifying device support for commands 12

ConnectPort® LTS Command Reference 10

Autres manuels pour ConnectPort LTS 8

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Digi Serveur

Digi

Digi Connect IT Mini Manuel utilisateur

Digi

Digi DC-ES-4SB Manuel utilisateur

Digi

Digi opengear CONSOLE MANAGER 8100 Manuel utilisateur

Digi

Digi Connect EZ Mini Manuel utilisateur

Digi

Digi Connect IT 16 Manuel utilisateur

Digi

Digi PortServer CM Manuel utilisateur

Digi

Digi ConnectPort TS 8 MEI Manuel utilisateur

Digi

Digi PortServer TS 1 M MEI Manuel utilisateur

Digi

Digi DIGI CONNECT ES Manuel d'exploitation

Digi

Digi Connect IT 4 Manuel utilisateur

Digi

Digi PortServer TS Series Manuel utilisateur

Digi

Digi ConnectPort LTS Series Manuel utilisateur

Digi

Digi Passport 48 Manuel utilisateur

Digi

Digi One SP Manuel utilisateur

Digi

Digi PortServer/8 Manuel utilisateur

Digi

Digi ConnectPort LTS 8 Manuel utilisateur

Digi

Digi Connect IT 16 Manuel utilisateur

Digi

Digi TS 8 MEI Manuel utilisateur

Digi

Digi DIGI CONNECT ES Manuel utilisateur

Digi

Digi ConnectPort LTS 8 Manuel utilisateur

Digi

Digi PortServer TS M MEI Manuel utilisateur

Digi

Digi Connect IT Mini Manuel utilisateur

Digi

Digi PortServer TS 8 Manuel utilisateur

Digi

Digi One IAP Haz Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
