Digi DC-ES-4SB Manuel utilisateur

Hardware setup guide

Digi Connect® ES

Device Server

Digi Connect ES Device Server Hardware setup guide 2

Digi Connect ES Device Server Hardware setup guide

90001925

Disclaimers

Information in this document is subject to change without notice and does not represent a commitment on

the part of Digi International. Digi provides this document “as is,” without warranty of any kind, expressed

or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular

purpose. Digi may make improvements and/or changes in this manual or in the product(s) and/or the

program(s) described in this manual at any time.

Trademarks and copyright

Digi, Digi International, Digi Connect, and the Digi logo are trademarks or registered trademarks in the United

States and other countries worldwide. All other trademarks mentioned in this document are the property of

their respective owners.

Customer support

If you need assistance, contact technical support:

Telephone (8:00 am - 5:00 pm—U.S. Mountain Time):

866.765.9885 toll-free U.S.A. & Canada

801.765.9885 Worldwide

Fax: 952.912.4952

Online: www.digi.com/support

Email: [email protected]

Mail:

Digi International

11001 Bren Road East

Minnetonka, MN 55343

USA

Revision Date Description

A June 2014 Revised and replaced document 90000715-88_D to comply with IEC

60601-1 documentation requirements.

Digi Connect ES Device Server Hardware setup guide 3

Contents

About Digi Connect ES Device Server

Technical description 5

Digi Connect ES Device Server models 5

Additional information 6

Recycling and disposal 6

Environmental information 6

Symbol definitions 7

Cautions and warnings 8

Connectors, LEDs, and controls 9

Setting up Digi Connect ES Device Server hardware

Before setting up the hardware 11

EMC specification 11

Setting up Digi Connect ES hardware 12

Digi Connect ES Device Server Hardware setup guide 4

Digi Connect ES Device Server Hardware setup guide 5

About Digi Connect ES Device Server

Digi Connect ES Device Server is a high performance, high-reliability serial-to-Ethernet

concentrator with extended safety characteristics.

Technical description

Digi Connect ES provides serial-over-Ethernet connectivity to connect sensitive RS-232-enabled

devices to the network. Both serial and Ethernet ports are galvanically isolated, and Ethernet

ports offer 10/100 Mbps network interface with an optional Ethernet switch.

Digi Connect ES is intended for data collection and information management, either directly or

through networks with independent devices. Digi Connect ES does not provide alarm or safety

notification capabilities and is not to be used in the critical path between any device and any

alarm or safety notification system.

Digi Connect ES Device Server models

This guide pertains to all Digi Connect ES Device Server models:

Digi Connect ES products are compliant with IEC 60601-1 3rd edition.

Digi Connect ES is intended for use as an ITE device for data transmission only. No data

modification takes place within the device.

Base model

Regional

model variants Description

DC-ES-4SB DC-ES-4SB-?? Digi Connect ES 4SB (4 ports)

DC-ES-8SB DC-ES-8SB-?? Digi Connect ES 8SB (8 ports)

DC-ES-4SB-SW DC-ES-4SB-SW-?? Digi Connect ES 4SB with Switch (4 ports)

DC-ES-8SB-SW DC-ES-8SB-SW-?? Digi Connect ES 8SB with Switch (8 ports)

Technical description

Digi Connect ES Device Server Hardware setup guide 6

This is a Class I Electrical Device.

Additional information

Recycling and disposal

Environmental information

Alternating

current

100-240V, 50-60 Hz

0.2A max

Fuse 250V F1A

All Digi Connect ES Device Server models include software in the form of firmware

described in the Digi Connect Family User Guide. Go to www.digi.com/products/

serialservers/digiconnectes to get the latest version of the guide, as well as a

detailed product datasheet for the Digi Connect ES family of products.

Improper disposal of IT equipment can have a negative impact on health and the

environment. Dispose of equipment and accessories at an appropriate facility to

enable recovery and recycling.

Recycle packaging and guides according to your local recycling regulators.

Operating temperature

Storage temperature

0° C to 55° C (32° F to 130° F)

-30° C to +85° C (-22° F to +185° F)

Relative humidity 5 to 95% (non-condensing)

Altitude 6560 feet (2000 meters)

Symbol definitions

Digi Connect ES Device Server Hardware setup guide 7

Symbol definitions

Symbol Definition

Alternating current

Atmospheric pressure limitation

Batch code

Catalog number

Caution

Conforms to the European Medical Device Directive 93/42/EEC; self certified

Consult instructions for use

YYYY Date of manufacture

ETH Ethernet connection

Functional earth terminal

Fuse

High voltage

Humidity limitation

Manufacturer

Cautions and warnings

Digi Connect ES Device Server Hardware setup guide 8

Cautions and warnings

CAUTION!

• Do not rely on the validity of the data from this device server without validating the integrity of

the entire information collection system.

• This product uses Double Pole/Neutral fusing. For continued protection against risk of fire,

return the unit to the factory for fuse replacement.

• The facility staff where this equipment is installed is responsible to ensure that this equipment

and the equipment it is connected to are safe, functional, and properly configured for their

environment and intended use. Devices and equipment must be installed, inspected, and

maintained in accordance with this guide.

• It is the responsibility of the system integrator or facility staff to verify data stream integrity

periodically.

• Connect ES should be periodically cleaned.

• When cleaning or disinfecting the device, power to the device must be turned off and the

power disconnected.

• Clean and disinfect the device periodically by wiping the outer case with a lint-free cloth,

lightly moistened with warm water and a mild, non-abrasive cleaning solution or 70%

isopropyl alcohol.

• Do not use excessive pressure when wiping.

• Do not sterilize the device server.

Package recycling information

QTY Quantity

REV Revision number

Serial number

Temperature limitation

Warning

WEEE

Device was put on the market after 13 August 2005. Conforms to the

Directive 2003/108/EC on waste electrical and electronic equipment (WEEE)

of the European Parliament.

Symbol Definition

Connectors, LEDs, and controls

Digi Connect ES Device Server Hardware setup guide 9

WARNING! This device contains no user-serviceable parts. No modification of this equipment is

allowed.

WARNING! In case of smoke, disconnect mains power from the device and discontinue use.

WARNING! Do not use this device in areas with high magnetic fields.

Connectors, LEDs, and controls

Callout Symbol Description

1Fuse

2Off/On

100-240V

50 - 60 Hz, 0.2A MAX

Mains power connector/Power input

4Grounding stud

5Ethernet uplink port

6Reset switch

7Ethernet switch ports

8lEthernet uplink LED

250V F1A

Off On

Connectors, LEDs, and controls

Digi Connect ES Device Server Hardware setup guide 10

9lEthernet switch LED

10 lSerial LED

11 Find me locater LED

12 Power LED

13 Serial ports (4 or 8)

Callout Symbol Description
