Digi-tech WEAPON Manuel utilisateur

Warning

For your protection, please read the following:

Important Safety Instructions

1.Read these instructions.

2.Keep these instructions.

3.Heed all warnings.

4.Do not use this apparatus near water.

5.Clean only with dry cloth.

6.Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

7.Do not install near any heat sources such as radiators,

heat registers,stoves,or other apparatus (including

amplifiers) that produce heat.

8.Protect the power cord from being walked on or

pinched particularly at plugs, convenience receptacles,

and the point where they exit from the apparatus.

9.Unplug this apparatus during lightning storms or when

unused for long periods of time.

10.No user serviceable parts inside. Refer all servicing to

qualified service personnel. Servicing is required when

the apparatus has been damaged in any way,such as

power-supply cord or plug is damaged,liquid has been

spilled or objects have fallen into the apparatus,the

apparatus has been exposed to rain or moisture, does

not operate normally, or has been dropped.

11.WARNING:To reduce the risk of fire or electric shock,

do not expose this apparatus to rain or moisture.

12.Refer to labels on the unit,including bottom cover, or

other markings and pertinent information.

DECLARATION OF CONFORMITY

Manufacturer’s Name: DigiTech

Manufacturer’s Address: 8760 S.Sandy Parkway

Sandy, Utah 84070, USA

declares that the product:

Product name: TheWeapon

Product option: all (requires Class II power

adapter that conforms to the

requirements of EN60065,

EN60742,or equivalent.)

conforms to the following Product Specifications:

Safety: IEC 60065 (1998)

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the Low

Voltage Directive 72/23/EEC and the EMC Directive 89/336/EEC

as amended by Directive 93/68/EEC.

Vice-President of Engineering

8760 S.Sandy Parkway

Sandy, Utah 84070, USA

Date:December 5,2003

European Contact: Your local DigiTech Sales and

Service Office or

Harman Music Group

8760 South Sandy Parkway

Sandy, Utah 84070 USA

Ph:(801) 566-8800

Fax:(801) 568-7583

WARRANTY: We at DigiTech are proud of our products and back-up each one with the following warranty:

1.The warranty registration card must be mailed within ten days after purchase date to validate this

warranty.

2.DigiTech warrants this product,when used solely within the U.S.,to be free from defects in materials

and workmanship under normal use and service.

3.DigiTech liability under this warranty is limited to repairing or replacing defective materials that show

evidence of defect,provided the product is returned to DigiTechWITH RETURN AUTHORIZATION,

where all parts and labor will be covered up to a period of one year (this warranty is extended to a

period of six years when the product has been properly registered by mail or through our website).

A ReturnAuthorization number may be obtained from DigiTech by telephone. The company shall not

be liable for any consequential damage as a result of the product's use in any circuit or assembly.

4.Proof-of-purchase is considered to be the burden of the consumer.

5.DigiTech reserves the right to make changes in design, or make additions to, or improvements upon

this product without incurring any obligation to install the same on products previously manufactured.

6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and

tampered with by anyone other than a certified DigiTech technician or, if the product is used with AC

voltages outside of the range suggested by the manufacturer.

7.The foregoing is in lieu of all other warranties,expressed or implied,and DigiTech neither assumes nor

authorizes any person to assume any obligation or liability in connection with the sale of this product.

In no event shall DigiTech or its dealers be liable for special or consequential damages or from any

delay in the performance of this warranty due to causes beyond their control.

NOTE:The information contained in this manual is subject to change at any time without notification. Some

information contained in this manual may also be inaccurate due to undocumented changes in the product or

operating system since this version of the manual was completed. The information contained in this version

of the owner's manual supersedes all previous versions.

DigiTech®products have long been the effects processors of choice for

musicians around the world. Our philosophy for developing new

products always starts with the artist in mind and the desire to give

them the best-sounding,most creative tools possible. Along the way

we’ve built special relationships with numerous musicians and our

Artist Series is the result of that dedication and our commitment to

building the best stompboxes period. TheArtist Series pedals help you

sound just like your favorite artist.

TheWeapon™ is the product of our collaboration with Dan Donegan,

guitarist of the multi-platinum selling band Disturbed. It is an exciting

combination of seven of Dan’s signature sounds and tones including

distortion,phaser,wah,and sitar simulator. Dan is a longtime DigiTech

endorsee and prior to the release of this pedal, he needed numerous

effects devices to recreate some of the sounds and studio production

techniques you hear on his recordings.

"DigiTech helped me recreate some of the effects I used in the studio and

then put them all into one pedal. It’s now easier to pull off live!”

Included Items

Before you get started,please make sure that the following items have

been included:

• DigiTech®’sArtist Series Dan Donegan Pedal -TheWeapon™

•Artist Series Pedal Gig Bag

• PS200R Power Supply

•Artist Series Dan Donegan Guitar Pick

•This Owner’s Manual

2 3 4

1. Level Knob

Controls the output level of the effect. Turn this knob clockwise to

increase the output level, and counter-clockwise to decrease the

output level.

2. Cntrl 1

Controls different functions depending on whichWeapon™Type is

selected. See the Knob Function Descriptions section on

following pages for a more detailed explanation of the Cntrl 1 knob’s

functions.

3. AC Adapter Jack

Connect only the included DigiTech®PS200R (9V DC) power supply

to this jack.

4. Cntrl 2

Controls different functions depending on whichWeaponType is

selected. See the Knob Function Descriptions section on

following pages for a more detailed explanation of the Cntrl 2 knob’s

functions.

5.Type Knob

Selects one of the seven different signature Dan Donegan tones.

1.“Stupify” Rhythm Guitar - Distortion

2.“Mistress” Rhythm Guitar - Medium Distortion

3.“Voices” Intro Phaser/Ramp to Full Distortion

4.“Bound” Intro -Wah w/Distortion

5.“Rise” and “Intoxication” Octave Pitch Shift Effect

6.“Stupify” Bridge - Sitar Effect

7.“Mistress” Radio-Style Guitar Break - Distortion

Please refer to the Knob Function Descriptions section for

detailed information regarding each type.

6. Input Jack

Connect your instrument to this jack. Connecting a guitar cable to

this jack supplies battery power even though the Indicator LED may

not be lit. To prolong battery life,disconnect all cables when not in

use.

7. Pedal Release Pins

These two pins are spring-loaded hinges that hold the pedal in place.

Push these pins in to release the pedal from the pedal chassis

exposing the battery compartment. (See the Battery Replacement

Diagram at the end of this Owner’s Manual.)

8. Pedal

Press the pedal to turn the effect on and off.

9. Out 1(Amp) Jack

Connect this output to your guitar amplifier.

10.Indicator LED

This LED indicates when the effect is turned on. If the LED

becomes dim or does not light when using battery power (with the

cables connected),the battery needs to be replaced.

11.Out 2 (Mixer) Jack

The Out 2 (Mixer) output has been specifically designed for use with

a full range audio system. This means that it is to be plugged directly

into a mixer or recording device connected to full range speakers

for optimal performance.

Knob Function Descriptions

Type 1.“Stupify” Rhythm Guitar - Distortion -This is Dan’s high

gain rhythm guitar sound for the song“Stupify”. Set the Cntrl

1and Cntrl 2 knobs to the twelve o’clock position to produce

this sound.

Type 2.“Mistress” Rhythm Guitar - Moderate Distortion - To

get the moderate distortion sound heard in the bridge section

of the song“Mistress” (studio version),Dan rolled back the

volume on his guitar. Type 2 emulates that same tone without

having to touch the volume knob. Set the Cntrl 1 and Cntrl 2

knobs to the twelve o’clock position to produce this sound.

TYPE

1- "Stupify" Rhythm Guitar - Distortion

2- "Mistress" Rhythm Guitar - Moderate Distortion

3- "Voices" Intro - Phaser/Ramp to Full Distortion

4- "Bound" Intro - Wah with Distortion

5- "Rise" and "Intoxication" Octave Pitch Shift Effect

6- "Stupify" Bridge - Sitar Simulator

7- "Mistress" Radio Style Guitar Break - Distortion

CNTRL 2

Output Level Low Freq. EQ Boost/Cut High Freq. EQ Boost/Cut

Output Level Phase Amount Ramp Time

Output Level Wah Sensitivity Wah Attack

Output Level Wet/Dry Mix Shift Amount +/- Octave

Output Level Fret Buzz Amount Reverb Level

Output Level Low Freq. EQ Boost/Cut High Freq. EQ Boost/Cut

LEVEL CNTRL 1
