Digi-tech BP200 Manuel utilisateur

MODELING

BASS

PROCESSOR

User’s

Guide

BP200 Manual 9/26/01 3:21 PM Page 1

These symbols are internationally accepted symbols that warn of potential

hazards with electrical products.The lightning flash means that there are

dangerous voltages present within the unit.The exclamation point indicates

that it is necessary for the user to refer to the owners manual.

These symbols warn that there are no user serviceable parts inside the unit.

Do not open the unit.Do not attempt to service the unit yourself.Refer all

servicing to qualified personnel.Opening the chassis for any reason will void

the manufacturer’s warranty. Do not get the unit wet.If liquid is spilled on

the unit,shut it off immediately and take it to a dealer for service.

Disconnect the unit during storms to prevent damage.

Warning

For your protection, please read the following:

Water and Moisture:Appliances should not be used near water

(e.g. near a bathtub, washbowl,kitchen sink,laundry tub,in a wet

basement,or near a swimming pool,etc.) Care should be taken so

that objects do not fall and liquids are not spilled into the enclosure

through openings.

Power Sources:The appliance should be connected to a power

supply only of the type described in the operating instructions or as

marked on the appliance.

Grounding or Polarization: Precautions should be taken so that

the grounding or polarization means of an appliance is not defeated.

Power Cord Protection: Power supply cords should be routed so

that they are not likely to be walked on or pinched by items placed

upon or against them,paying particular attention to cords at plugs,

convenience receptacles,and the point where they exit from the

appliance.

Servicing:To reduce the risk of fire or electrical shock,the user

should not attempt to service the appliance beyond that described in

the operating instructions.All other servicing should be referred to

qualified service personnel.

For units equipped with externally accessible fuse recepta-

cle: Replace fuse with same type and rating only.

Electromagnetic Compatibility

Operation is subject to the following conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interfer-

ence that may cause undesired operation.

•Use only shielded interconnecting cables.

•Operation of this unit within significant electromagnetic fields should

be avoided.

BP200 Manual 9/26/01 3:21 PM Page 2

DECLARATION OF CONFORMITY

Manufacturer’s Name: DigiTech

Manufacturer’s Address: 8760 S.Sandy Parkway

Sandy,Utah 84070,USA

declares that the product:

Product name: BP200

Note:Product name may be suffixed by the letters EU,JA,NP and UK.

Product option: all (requires Class II power adapter that conforms

to the requirements of EN60065,EN60742, or equivalent.)

conforms to the following Product Specifications:

Safety: IEC 60065 (1998)

EMC: EN 55013 (1990)

EN 55020 (1991)

Supplementary Information:

The product herewith complies with the requirements of the LowVoltage Directive 72/23/EEC and the EMC Directive

89/336/EEC as amended by Directive 93/68/EEC.

DigiTech / Johnson

President of Harman Music Group

8760 S.Sandy Parkway

Sandy,Utah 84070,USA

Date:September 14,2001

European Contact: Your local DigiTech / Johnson Sales and Service Office or

Harman Music Group

8760 South Sandy Parkway

Sandy,Utah 84070 USA

Ph:(801) 566-8800

Fax:(801) 568-7573

BP200 Manual 9/26/01 3:21 PM Page 3

Warranty

We at DigiTech are very proud of our products and back-up each one we sell with the following warranty:

1.The warranty registration card must be mailed within ten days after purchase date to validate this warranty.

2.DigiTech warrants this product,when used solely within the U.S.,to be free from defects in materials and workmanship

under normal use and service.

3.DigiTech liability under this warranty is limited to repairing or replacing defective materials that show evidence of defect,

provided the product is returned to DigiTechWITH RETURNAUTHORIZATION,where all parts and labor will be covered

up to a period of one year.A ReturnAuthorization number may be obtained from DigiTech by telephone.The company shall

not be liable for any consequential damage as a result of the product's use in any circuit or assembly.

4.Proof-of-purchase is considered to be the burden of the consumer.

5.DigiTech reserves the right to make changes in design,or make additions to,or improvements upon this product without

incurring any obligation to install the same on products previously manufactured.

6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tampered with by anyone

other than a certified DigiTech technician or,if the product is used withAC voltages outside of the range suggested by the

manufacturer.

7.The foregoing is in lieu of all other warranties,expressed or implied,and DigiTech neither assumes nor authorizes any per-

son to assume any obligation or liability in connection with the sale of this product.In no event shall DigiTech or its dealers

be liable for special or consequential damages or from any delay in the performance of this warranty due to causes beyond

their control.

NOTE:The information contained in this manual is subject to change at any time without notification.Some information con-

tained in this manual may also be inaccurate due to undocumented changes in the product or operating system since this

version of the manual was completed.The information contained in this version of the owner's manual supersedes all previ-

ous versions.

BP200 Manual 9/26/01 3:21 PM Page 4

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . .1

Included Items . . . . . . . . . . . . . . . . . . . . . . . . .1

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Connecting the BP200 . . . . . . . . . . . . . . . . . . .5

Mono Operation . . . . . . . . . . . . . . . . . . . . . . .5

Stereo Operation . . . . . . . . . . . . . . . . . . . . . . .6

Modes and Functions . . . . . . . . . . . . . . . . . .8

Performance Mode . . . . . . . . . . . . . . . . . . . . . .8

Edit Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Store Mode . . . . . . . . . . . . . . . . . . . . . . . . . .10

Bypass Mode . . . . . . . . . . . . . . . . . . . . . . . . .12

Tuner Mode . . . . . . . . . . . . . . . . . . . . . . . . . .12

RhythmTrainer . . . . . . . . . . . . . . . . . . . . . . . .14

Expression Pedal . . . . . . . . . . . . . . . . . . . . . . .14

AssigningA Parameter . . . . . . . . . . . . . . . . . .14

Expression Pedal Calibration . . . . . . . . . . . . .15

Factory Reset . . . . . . . . . . . . . . . . . . . . . . . . .16

Effects and Parameters . . . . . . . . . . . . . . .17

Signal Path . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Fretless /Wah . . . . . . . . . . . . . . . . . . . . . . . .17

Compressor . . . . . . . . . . . . . . . . . . . . . . . . . .18

Amp/Stompbox Models . . . . . . . . . . . . . . . . .18

EQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Cabinet - Gate . . . . . . . . . . . . . . . . . . . . . . . .20

Effects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Chorus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Flanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Phaser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Envelope Filter . . . . . . . . . . . . . . . . . . . . . . . .22

Vibrato . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Octavider . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

SynthTalk™ . . . . . . . . . . . . . . . . . . . . . . . . . .23

Pitch Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Detune . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Whammy™ . . . . . . . . . . . . . . . . . . . . . . . . . .24

Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Reverb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Specifications: . . . . . . . . . . . . . . . . . . . . . . . . .26

Preset List . . . . . . . . . . . . . . . . . . . . . . . . . . .27

BP200 Manual 9/26/01 3:21 PM Page 5

Introduction

The BP200 gives you the flexibility and power to produce sonic creations never before thought

possible. To become better acquainted with the BP200, we recommend you go through this

User’s Guide with your BP200 in front of you.

Included Items

Before you get started, please make sure that the following items have been included:

• BP200

• PS0913B Power Supply

• User’s Guide

•Warranty Card

The utmost care was taken while your BP200 was being manufactured. Everything should

be included and in perfect working order. If anything is missing,contact the factory at once.

Please help us become acquainted with you and your needs by completing your warranty

card. Thank you!

BP200 Manual 9/26/01 3:21 PM Page 1

Front Panel

SLApin

BP200 Manual 9/26/01 3:21 PM Page 2

1.FOOT SWITCHES - Navigate through all 80 presets. When pressed together,they bypass

the current preset. When pressed together and held,Tuner mode is entered.

2.AMPTYPE, GAIN, MASTER LEVEL Knobs - Adjusts the effect parameters in Edit Mode

and adjustAmpType, Gain,and Master Level in Performance Mode, and select Pattern,Tempo,

and Rhythm Level in Rhythm mode.

3.SELECT button - Enters and exits Edit Mode. Successive presses will navigate through all

the effect rows.

4. RHYTHM button -Turns on and off the RhythmTrainer function.

5. EFFECTS MATRIX - Lists all effect parameters available for editing. The LEDs next to

each effect will light when the effect is on in a preset. The LEDs also serve as a reference

when using the BP200’sTuner.

6.DISPLAY - Provides information for all the BP200’s different functions.

7. EXPRESSION PEDAL - Controls the BP200's parameters in real time.

8.STORE button - Stores or copies presets to User preset locations.

BP200 Manual 9/26/01 3:21 PM Page 3

Rear Panel

1.INPUT - Connect your instrument to this jack.

2.JAM-A-LONG - Connect the headphone output of your CD, tape,or MP3 player to this

1/8” stereo jack to practice along with you favorite music.

3.OUTPUT -The BP200’s output is aTRS (tip,ring,sleeve) Stereo output that is used for

both mono and stereo applications. Connect one end of a single mono instrument cable,or

aTRS stereo“Y” cord to this jack,and the other end to an amplifier,mixer,or recording

device’s input(s).

4.HEADPHONE - Connect a pair of stereo headphones to this jack.

5.POWER - Connect only the DigiTech PS0913B power supply to this jack.

BP200 Manual 9/26/01 3:21 PM Page 4

Connecting the BP200

The BP200 can be connected in several different ways.The following diagrams show a few possi-

ble options.Before connecting the BP200,make sure the power to your amplifier is turned off.

The BP200 should also be powered off or unplugged.

Mono Operation

1.Connect your bass to the BP200’s Input.

2.Connect a single mono instrument cable from the BP200’s Output to the amplifier’s

instrument input,or a power amp’s line input.

SLApin

BassAmp Input/Effect Return Output Input

BP200 Manual 9/26/01 3:21 PM Page 5

Table des matières

Autres manuels digi-tech Matériel informatique

digi-tech

digi-tech RP355 Manuel utilisateur

digi-tech

digi-tech STUDIOQUAD Manuel utilisateur

digi-tech

digi-tech VOCALISTPERF Manuel utilisateur

digi-tech

digi-tech VOCALISTVR Manuel utilisateur

digi-tech

digi-tech STUDIOVOCALISTEX Manuel utilisateur

digi-tech

digi-tech STUDIO QUAD V2 Manuel utilisateur

digi-tech

digi-tech RP90 Manuel utilisateur

digi-tech

digi-tech RPX400 Manuel de programmation

digi-tech

digi-tech RP55 Manuel utilisateur

digi-tech

digi-tech MIDIVOCALIST Manuel utilisateur

digi-tech

digi-tech RP355_E - REV 18-6412V-D Manuel utilisateur

digi-tech

digi-tech VOCALIST II Manuel utilisateur

digi-tech

digi-tech ACCESS Manuel utilisateur

digi-tech

digi-tech VOCALISTWEX Manuel utilisateur

digi-tech

digi-tech BP80 Manuel utilisateur

digi-tech

digi-tech STUDIO 400 Manuel utilisateur

digi-tech

digi-tech AR-1924 Manuel utilisateur

digi-tech

digi-tech VCS1 Manuel utilisateur

digi-tech

digi-tech RP255 Manuel utilisateur

digi-tech

digi-tech RP70 Manuel utilisateur

digi-tech

digi-tech VALVEFX Manuel utilisateur

digi-tech

digi-tech VOCALIST LIVE 4 Manuel utilisateur

digi-tech

digi-tech VOCALIST LIVE PRO Manuel utilisateur

digi-tech

digi-tech VOCALIST VL3D - Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

digi-tech BP200 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques
