DFI G586VPA Manuel utilisateur
G586VPB
Rev. 0
System Board
User’s Manual
-D26850410-
vCopyright1995byDFI,Inc.
All rights reserved.
No part of this document may be copied, reproduced in
any form or by any means or used to make any trans-
formation/adaptation without the prior written consent
of DFI, Inc.
DFI, Inc. makes no warranties with respect to this
documentation and disclaims any implied warranties of
merchantability, quality, or fitness for any particular
purpose. The information in this document is subject to
change without notice. DFI, Inc. reserves the right to
make revisions to this publication and to make changes
to any and/or all parts of its content, at any time,
without obligation to notify any person or entity of such
changes. Further, DFI, Inc. assumes no responsibility
for any errors that may appear in this document.
DFI is a registered trademark, and G586VPB is a
trademark of Diamond Flower, Inc. All other product
names mentioned are trademarks or registered trade-
marks of their respective companies.
vFCC Statement on Class B
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interfer-
ence when the equipment is operated in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
the receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio TV
technician for help.
Notice:
1. The changes or modifications not expressly
approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
2. Shielded interface cables must be used in order to
comply with the emission limits.
v Table of Contentsv
Introduction ................................................................................
Features and Specifications .................................................
Package Checklist .................................................................
Installation Overview .................................................................
Preparing the Area ................................................................
Handling the System Board ..................................................
Tips in Handling the System Board ...............................
Hardware Installation ............................................................
Memory Installation ........................................................
Installing the Modules .............................................
Board Configuration .......................................................
Jumper Settings ......................................................
Jumper Settings for PS/2 Mouse, Flash
EPROM and CMOS Clean ................................
Jumper Settings for VESA VL-Bus Add-On
Boards .................................................................
Jumper Settings for PCI Slots ...........................
Cache Configuration ...............................................
Jumper Settings for Cache Memory .................
CPU Installation ..............................................................
Jumper Settings for CPU ........................................
Installing Upgrade CPU's ........................................
Installing Expansion Cards ...................................................
Installing the PS/2 Mouse Port .............................................
Installing the System Board ..................................................
1-1
1-2
1-4
2-1
2-1
2-2
2-2
2-2
2-2
2-6
2-7
2-8
2-8
2-11
2-13
2-15
2-16
2-18
2-19
2-21
2-27
2-29
2-30
Initial Setup Program ................................................................
Award BIOS CMOS Setup Utilities ......................................
Standard CMOS Setup ..................................................
BIOS Features Setup ....................................................
Chipset Features Setup .................................................
Power Management Setup ............................................
PCI Configuration Setup ................................................
Load BIOS Defaults .......................................................
Load Setup Defaults ......................................................
Password Setting ...........................................................
IDE HDD Auto Detection ...............................................
Save and Exit Setup ......................................................
Exit Without Saving ........................................................
Troubleshooting Checklist ......................................................
Appendix A:Types of Modules ..............................................
Appendix B:System Error Report .........................................
Appendix C:Memory & I/O Maps ...........................................
Appendix D:PCI I/O Pin Assignments ..................................
Appendix E:VL-Bus I/O Pin Assignments ...........................
Appendix F:16-bit ISA I/O Pin Assignments .......................
Appendix G:Connector Pin Assignments ............................
Appendix H:Award BIOS Hard Disk Table ..........................
3-1
3-2
3-2
3-5
3-7
3-8
3-9
3-15
3-15
3-16
3-17
3-17
3-18
4-1
A-1
B-1
C-1
D-1
E-1
F-1
G-1
H-1
GreenPCI/ISASystemBoard
vIntroduction
The G586VPB is an Energy Star Compliant system
board that supports the Environmental Protection
Agency’s Green PC requirements. It reduces energy
consumption by automatically turning off peripherals, or
the entire system, when not in use.
The G586VPB system board offers several advanced
features integrated into the system board. Its design is
based on the Peripheral Component Interconnect (PCI)
and Industry Standard Architecture (ISA) standards.
The G586VPB supports a 320-pin Zero Insertion Force
(ZIF) CPU socket. The board supports Flash EPROM,
a memory chip for the storage of BIOS which can be
erased in bulk or modified using a software utility. The
ZIF socket allows users to easily upgrade the CPU.
The G586VPB is equipped with three dedicated PCI
slots, one shared PCI/ISA slot and three dedicated 16-bit
ISA slots.
The G586VPB can be configured to several different
sizes of memory up to 128MB using 256Kx36,
512Kx36, 1Mx36, 2Mx36, 4Mx36 and 8Mx36 SIM
modules.
1-1 uIntroduction
G586VPB
Features and Specifications
Introduction u1-2
Processor
•Intel Pentium™ (3.3V) 75/90/100/120MHz
Chipset
•VIA - VT82C575MV: system and cache
controller
VT82C576MV: PCI bus controller
VT82C416MV: integrated clock
generator, real time clock, keyboard
controller and PS/2 mouse
VT82C577MV: data buffer
Architecture
•PCI/ISA
Power Management
•Normal, Doze, Sleep and Suspend modes
•System event monitoring with two event classes
and two idle timers
•Predefined and user programmable I/O range
•Primary and secondary interrupt differentiation
for individual channels
•Two extended peripheral timers and one general
purpose timer
•Clock stretching, clock throttling and clock stop
control
•Multiple internal and external SMI sources for
flexible power management
•Microsoft APM 1.1 compliant
BIOS
•Award Plug & Play BIOS
•Flash EPROM for easy BIOS upgrades
GreenPCI/ISASystemBoard
1-3 uIntroduction
Enhanced PCI IDE Interface
•Supports fast Mode 3 and Mode 4 hard drivers
•Two IDE connectors to control four drives (e.g.
two HDDs, one tape drive and one CD-ROM
drive)
Super I/O Interface
•Two NS16C550A-compatible enhanced serial
ports
•One parallel port with ECP/EPP support
•Supports 360KB, 720KB, 1.2MB and 1.44MB
floppy drives
•Software configurable
•Uses UMC UM8663AF super-I/O controller
Cache Memory
•256KB, 512KB, 1MB or 2MB direct map
write-back cache
•Uses 32Kx8, 64Kx8 or 128Kx8 SRAM:
pure 3.3V or 3.3/5V mixed voltage SRAM
Memory
•Normal and EDO DRAM support
•Up to 128MB
•Four 72-pin SIMM sockets, two banks
•Supports single and/or double density SIMMs
•256Kx36, 512Kx36, 1Mx36, 2Mx36, 4Mx36 or
8Mx36 SIMMs
•Supports 60ns or 70ns page mode DRAM
Expansion Slots
•Three dedicated PCI slots
•One shared PCI/ISA slot
•Three dedicated 16-bit ISA slots
G586VPB
Introduction u1-4
ZIF Socket
•320-pin ZIF socket (Intel Socket 5)
Board Dimensions
•33cm (13") x 22cm (8.66")
GreenPCI/ISASystemBoard
Package Checklist
The G586VPB package contains the following items:
•The G586VPB system board
•The G586VPB user’s manual
•... driver diskette(s)
•One 34-pin floppy disk drive cable
•Two 40-pin IDE hard disk cables
•One 25-pin printer port cable for chasis mounting
•One card-edge bracket with serial and mouse port
cables
If any of these items are missing or damaged, please
contact your dealer or sales representative for assistance.
1-5 uIntroduction
