www.dﬁ.comChapter 1 Introduction

AL9A3

COM Express Mini Module

User’s Manual

A44310830

www.dﬁ.comChapter 1 Introduction

This publication contains information that is protected by copyright. No part of it may be re-

produced in any form or by any means or used to make any transformation/adaptation without

the prior written permission from the copyright holders.

This publication is provided for informational purposes only. The manufacturer makes no

representations or warranties with respect to the contents or use of this manual and specifi-

cally disclaims any express or implied warranties of merchantability or fitness for any particular

purpose. The user will assume the entire risk of the use or the results of the use of this docu-

ment. Further, the manufacturer reserves the right to revise this publication and make changes

to its contents at any time, without obligation to notify any person or entity of such revisions

or changes.

Changes after the publication’s first release will be based on the product’s revision. The website

will always provide the most updated information.

Trademarks

Product names or trademarks appearing in this manual are for identification purpose only and

are the properties of the respective owners.

COM Express Specification Reference

PICMG®COM Express®Module Base Specification.

http://www.picmg.org/

FCC and DOC Statement on Class B

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reason-

able protection against harmful interference when the equipment is operated in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference

to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is encour-

aged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio TV technician for help.

Notice:

1. The changes or modifications not expressly approved by the party responsible for compli-

ance could void the user’s authority to operate the equipment.

2. Shielded interface cables must be used in order to comply with the emission limits.

www.dﬁ.comChapter 1 Introduction

Table of Contents

Trademarks........................................................................................................2

COM Express Specification Reference...................................................2

FCC and DOC Statement on Class B.....................................................2

Warranty..............................................................................................................4

Static Electricity Precautions......................................................................4

Safety Measures..............................................................................................4

About the Package.........................................................................................5

Optional Items..................................................................................................5

Before Using the System Board...............................................................5

Chapter 1 - Introduction.............................................................................6

Specifications ................................................................................................6

Features..........................................................................................................7

Chapter 2 - Concept.......................................................................8

COM Express Module Standards..............................................................8

Specification Comparison Table ...............................................................9

Chapter 3 - Hardware Installation...............................................10

Board Layout...............................................................................................10

Block Diagram.............................................................................................10

Mechanical Diagram..................................................................................11

System Memory..........................................................................................12

Connectors...................................................................................................13

COM Express Connector.............................................................................13

COM Express Connector Signal Discription.................................................. 16

Cooling Option............................................................................................22

Heat Sink...................................................................................................22

Installing AL9A3 onto a Carrier Board.................................................22

Installing the COM Express Debug Card.............................................23

Chapter 4 - BIOS Setup............................................................... 26

Overview.......................................................................................................26

AMI BIOS Setup Utility.............................................................................27

Main.........................................................................................................27

Advanced..................................................................................................27

Security ....................................................................................................34

Boot ......................................................................................................... 35

Save & Exit...............................................................................................36

Updating the BIOS....................................................................................37

Notice: BIOS SPI ROM.............................................................................37

Chapter 5 - Supported Software...........................................................38

Chapter 6 - GPIO Programming Guide...............................................45

Appendix A - Watchdog Sample Code................................................46

Appendix B - System Error Message...................................................47

Appendix C - Troubleshooting................................................................49

www.dﬁ.comChapter 1 Introduction

Warranty

1. Warranty does not cover damages or failures that arised from misuse of the product,

inability to use the product, unauthorized replacement or alteration of components and

product specifications.

2. The warranty is void if the product has been subjected to physical abuse, improper instal-

lation, modification, accidents or unauthorized repair of the product.

3. Unless otherwise instructed in this user’s manual, the user may not, under any circum-

stances, attempt to perform service, adjustments or repairs on the product, whether in or

out of warranty. It must be returned to the purchase point, factory or authorized service

agency for all such work.

4. We will not be liable for any indirect, special, incidental or consequencial damages to the

product that has been modified or altered.

Static Electricity Precautions

It is quite easy to inadvertently damage your PC, system board, components or devices even

before installing them in your system unit. Static electrical discharge can damage computer

components without causing any signs of physical damage. You must take extra care in han-

dling them to ensure against electrostatic build-up.

1. To prevent electrostatic build-up, leave the system board in its anti-static bag until you are

ready to install it.

2. Wear an antistatic wrist strap.

3. Do all preparation work on a static-free surface.

4. Hold the device only by its edges. Be careful not to touch any of the components, contacts

or connections.

5. Avoid touching the pins or contacts on all modules and connectors. Hold modules or con-

nectors by their ends.

Safety Measures

To avoid damage to the system:

• Use the correct AC input voltage range.

To reduce the risk of electric shock:

• Unplug the power cord before removing the system chassis cover for installation or servic-

ing. After installation or servicing, cover the system chassis before plugging the power

cord.

Important:

Electrostatic discharge (ESD) can damage your processor, disk drive and other com-

ponents. Perform the upgrade instruction procedures described at an ESD worksta-

tion only. If such a station is not available, you can provide some ESD protection by

wearing an antistatic wrist strap and attaching it to a metal part of the system chas-

sis. If a wrist strap is unavailable, establish and maintain contact with the system

chassis throughout any procedures requiring ESD protection.

www.dﬁ.comChapter 1 Introduction

About the Package

The package contains the following items. If any of these items are missing or damaged,

please contact your dealer or sales representative for assistance.

• 1 AL9A3 board

• 1 Heat sink

Optional Items

• COM100-B carrier board kit

• Heat spreader

The board and accessories in the package may not come similar to the information listed

above. This may differ in accordance with the sales region or models in which it was sold. For

more information about the standard package in your region, please contact your dealer or

sales representative.

Before Using the System Board

Before using the system board, prepare basic system components.

If you are installing the system board in a new system, you will need at least the following

internal components.

• Storage devices such as hard disk drive, etc.

You will also need external system peripherals you intend to use which will normally include at

least a keyboard, a mouse and a video display monitor.

www.dﬁ.comChapter 1 Introduction

Chapter 1 - Introduction

Specifications

Chapter 1

SYSTEM Processor

Intel Atom

Processor E3900 Series, BGA 1296

Intel Atom

x7-E3950 Processor, Quad Core, 2M Cache, 1.6GHz (2.0GHz), 12W

Intel Atom

x5-E3940 Processor, Quad Core, 2M Cache, 1.6GHz (1.8GHz), 9.5W

Intel Atom

x5-E3930 Processor, Dual Core, 2M Cache, 1.3GHz (1.8GHz), 6.5W

Intel

Pentium

Processor N4200, Quad Core, 2M Cache, 1.1GHz (2.5GHz), 6W

Intel

Celeron

Processor N3350, Dual Core, 2M Cache, 1.1GHz (2.4GHz), 6W

Memory 4GB/8GB Memory Down

Dual Channel DDR3L 1600MHz

BIOS AMI SPI 128Mbit (supports UEFI boot only)

GRAPHICS Controller Intel®HD Graphics

Feature OpenGL 5.0, DirectX 12, OpenCL 2.1

HW Decode: AVC/H.264, MPEG2, VC1, WMV9, JPEG/MJPEG, HEVC/H.265, VP8, VP9, MVC

HW Encode: AVC/H.264, JPEG/MJPEG, HEVC/H.265, VP8, VP9, MVC

Display 1 x DDI (HDMI/DVI/DP++)

1 x LVDS/eDP

LVDS: single channel 24-bit, resolution up to 1366x768 @ 60Hz

HDMI: resolution up to 3840x2160 @ 30Hz

DP++: resolution up to 4096x2160 @ 60Hz

eDP: resolution up to 3840x2160 @ 60Hz

Dual

Display

DDI + LVDS

DDI + eDP

EXPANSION Interface 4 x PCIe x1 (Gen 2)

1 x SDIO (available upon request)

1 x LPC

1 x I²C

1 x SMBus

1 x SPI

2 x UART (TX/RX)

AUDIO Interface HD Audio

ETHERNET Controller 1 x Intel®I210AT PCIe (10/100/1000Mbps) (0 to 60°C) or

1 x Intel®I210IT PCIe (10/100/1000Mbps) (-40 to 85°C)

I/O USB 2 x USB 3.0

8 x USB 2.0

SATA 2 x SATA 3.0 (up to 6Gb/s)

SSD 1 x 4GB/8GB/16GB/32GB/64GB Onboard SSD (available upon request)

(SM611GXC-BD/64GB Read: 161.5 MB/s, Write 11.01 MB/s)

GPIO 1 x 8-bit GPIO

WATCHDOG

TIMER Output &

Interval System Reset, Programmable via Software from 1 to 255 Seconds

POWER Type 4.75V~20V, 5VSB, VCC_RTC (ATX mode)

4.75V~20V, VCC_RTC (AT mode)

Consumption Typical: E3940: 12V @ 0.34A (4.08W)

Max.: E3940: 12V @ 1.62A (19.44W)

OS SUPPORT

(UEFI ONLY) Windows 10 IoT Enterprise 64-bit

Ubuntu 15.10 (Intel®graphic driver available)

ENVIRONMENT Temperature Operating: 0 to 60°C/-40 to 85°C

Storage: -40 to 85°C

Humidity Operating: 5 to 90% RH

Storage: 5 to 90% RH

MTBF 1,090,551 hrs @ 25°C; 509,776 hrs @ 45°C; 283,622 hrs @ 60°C

Calculation model: Telcordia Issue 2

Environment: GB, GC – Ground Benign, Controlled

MECHANICAL Dimensions COM Express®Mini

84mm (3.30") x 55mm (2.16")

Compliance PICMG COM Express®R2.1, Type 10

www.dﬁ.comChapter 1 Introduction

Features

• Watchdog Timer

The Watchdog Timer function allows your application to regularly “clear” the system at the set

time interval. If the system hangs or fails to function, it will reset at the set time interval so

that your system will continue to operate.

• DDR3L

DDR3L is a higher performance DDR3 SDRAM interface providing less voltage and higher

speed successor. DDR3L SDRAM modules support 1600MHz for DDR modules. DDR3L delivers

increased system bandwidth and improved performance to provide its higher bandwidth and its

increase in performance at a lower power.

• Graphics

The integrated Intel®HD graphics engine delivers an excellent blend of graphics performance

and features to meet business needs. It provides excellent video and 3D graphics with out-

standing graphics responsiveness. These enhancements deliver the performance and compat-

ibility needed for today’s and tomorrow’s business applications. Supports 1 x DDI (HDMI/DVI/

DP++) and 1 x LVDS/eDP interfaces for display outputs.

• Serial ATA

Serial ATA is a storage interface that is compliant with SATA 1.0a specification. With speed of

up to 6Gb/s (SATA 3.0), it improves hard drive performance faster than the standard parallel

ATA whose data transfer rate is 100MB/s.

• Gigabit LAN

The Intel®I210AT Gigabit LAN controller or the Intel®I210IT Gigabit LAN controller supports

up to 1Gbps data transmission.

• USB

The system board supports the new USB 3.0. It is capable of running at a maximum transmis-

sion speed of up to 5 Gbit/s (625 MB/s) and is faster than USB 2.0 (480 Mbit/s, or 60 MB/s)

and USB 1.1 (12Mb/s). USB 3.0 reduces the time required for data transmission, reduces

power consumption, and is backward compatible with USB 2.0. It is a marked improvement in

device transfer speeds between your computer and a wide range of simultaneously accessible

external Plug and Play peripherals.

Chapter 1

www.dﬁ.comChapter 2 Concept

Chapter 2

Chapter 2 - Concept

COM Express Module Standards

The figure below shows the dimensions of the different types of COM Express modules.

AL9A3 is a COM Express Mini. The dimension is 84mm x 55mm.

106.00

91.00

70.00

51.00

4.00

18.00

6.00

0.00

16.50

4.00

0.00

Extended

BasicCompact

Mini

74.20

80.00

91.00

121.00

151.00

Common for all Form Factors

Extended only

Basic only

Compact only

Compact and Basic only

Mini only

www.dﬁ.comChapter 2 Concept

Chapter 2

Specification Comparison Table

The table below shows the COM Express standard specifications and the corresponding specifications supported on the AL9A3 module.

Module Pin-out - Required and Optional Features C-D Connector. PICMG®COM Express®

Revision 2.1

Note:

• 5 Indicates 12V-tolerant features on former VCC_12V signals.

• 6 Cells in the connected columns spanning rows provide a rough approximation of

features sharing connector pins.

Connector Feature

COM Express Module Base

Specification Type 10

(Single Connector) Min / Max

DFI AL9A3

Type 10

A-B

A-B PCI Express Lanes 0 - 5 1 / 4 4

A-B LVDS Channel A 0 / 1 1

A-B LVDS Channel B NA NA

A-B eDP on LVDS CH A pins 0 / 1 1(option)

A-B VGA Port NA NA

A-B TV-Out NA NA

A-B DDI 0 0 / 1 1

A-B

Serial Ports 1 - 2 0 / 2 2

A-B CAN interface on SER1 0 / 1 1

A-B SATA / SAS Ports 1 / 2 2

A-B AC’97 / HDA Digital Interface 0 / 1 1

A-B USB 2.0 Ports 4 / 8 8

A-B USB Client 0 / 1 0

A-B USB 3.0 Ports 0 / 2 2

A-B LAN Port 0 1 / 1 1

A-B Express Card Support 0 / 2 2

A-B LPC Bus 1 / 1 1

A-B SPI 1 / 2 1

A-B SDIO (muxed on GPIO) 0 / 1 1(option)

General Purpose I/O 8 / 8 8

A-B SMBus 1 / 1 1

A-B I2C 1 / 1 1

A-B Watchdog Timer 0 / 1 1

A-B Speaker Out 1 / 1 1

A-B External BIOS ROM Support 0 / 2 1

A-B Reset Functions 1 / 1 1

System I/O

System Management

A-B

Connector Feature

COM Express Module Base

Specification Type 10

(Single Connector) Min / Max

DFI AL9A3

Type 10

A-B

A-B Thermal Protection 0 / 1 1

A-B Battery Low Alarm 0 / 1 1

A-B Suspend/Wake Signals 0 / 3 3

A-B Power Button Support 1 / 1 1

A-B Power Good 1 / 1 1

A-B VCC_5V_SBY Contacts 4 / 4 4

A-B

Sleep Input 0 / 1 1

A-B

Lid Input 0 / 1 1

A-B

Fan Control Signals 0 / 2 2

A-B Trusted Platform Modules 0 / 1 0

A-B

A-B VCC_12V Contacts 12 / 12 12

Power Management

Power

q p

Connector Feature

COM Express Module Base

Specification Type 10

(Single Connector) Min / Max

DFI AL9A3

Type 10

C-D PCI Express Lanes 16 - 31 NA NA

PCI Express Graphics (PEG) NA NA

Muxed SDVO Channels 1 - 2 NA NA

PCI Express Lanes 6 - 15 NA NA

PCI Bus - 32 Bit NA NA

PATA Port NA NA

LAN Ports 1 - 2 NA NA

DDIs 1 - 3 NA NA

USB 3.0 Ports NA NA

C-D

C-D VCC_12V Contacts NA NA

Power

System I/O

C-D

www.dﬁ.comChapter 3 Hardware Installation

Chapter 3

Chapter 3 - Hardware Installation

Board Layout

Top View

Bottom View

Block Diagram

EEPROM

USB 2.0 8x

SATA 3.0 2x

A / B

USB

SATA

Intel Atom®Processor

E3900 Series

Intel® I210

AT/IT

MDI

Channel A

DDI Port 0

DDI

Port

HD Audio

LPC Bus

Audio

LPC

Bus

WDT

I2C Bus 1, 2

Serial Port 1, 2

Fan PWM/

TACH IN

SLP/LID

WDT

USB 3.0 2x

USB

PCIe x1 4x

PCIe

4GB/8GB DDR3L

Memory Down

Channel B

4GB/8GB DDR3L

Memory Down

CB 1 2

Serial Port 1, 2

C Bus 1, 2

SMBus

8-bit GPIO TCA6408A

SSD Chip SATA Ports

eDP/DDI

(optional)

(p )

PTN3460

LVDS

(optional)

(p )

SPI Bus

SPI

Bus

SPI BIOS

Embedded

Controller

SDIO

MDI

PCIe x1

EEPROM

bit GPIO8

TCA6408A

SPI Flash BIOS NXP

PTN3460

Intel Atom

E3900 Series

DDR3L

DDR3L DDR3L

DDR3L

Intel

I210AT or

I210IT

DDR3L DDR3L DDR3L

DDR3L

iTE

IT8528VG

SSD

(optional)

B110 B1

A110 A1

COM Express connector

Table des matières

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
