CONSIDERATIONS ABOUT THESE INSTRUCTIONS
●
The instruments of the HS-7000 Series are fully programmable processors, so that, all the
function provided in its Function Blocks can be enabled or disabled by key pad or by software,
to fit the application requirements. The Function Blocks of the HS-7000 can be linked to each
other, allowing infinity of control structures to fit almost every application.
●
This feature makes the menu in the HS-7000 Series to be non-linear one, so that it is
impossible to explain how it operates following the pre-established structure of menu.
●
Moreover, these functions represented as symbols on the display, can be assigned to any
of the three loops or to any Password level available in the instrument, so that it can be
located, in the menu, in different positions according to the programmer and the application’s
requirements.
●
This is why the display of the HS-7000 is different from other displays, since it can display
between 6 and 15 different values by multiplexing the screens on the display. These screens
are identified and presented as Meauring or Control Loops L1, L2 and L3, to which, can be
assigned any measured or calculated signal. Every loop can be selected by using the key
from any position of the MAIN MENU.
●
Thus, in the HS-7000, one display may shows the one input signal, the other one the Total
of a flow measurement and the third one may displays a hold value, or one setpoint, or the
control output value, etc.
●
Those instruments, because of its versatility, performances, accuracy and fast response are
considered as high range instruments of its segment.
The operation instructions are organized in different sections to ease the operation of
Parameterization, Configuration and Specific Applications, as follows:
STRUCTURE OF THESE INSTRUCTIONS
These instructions are structured in different sections:
INSTRUCTIONS FOR WIRING, MOUNTING AND CONTROL KEYPAD
●
Inputs, Outputs, Displays and Keypad.
OPERATION OF FUNCTIONS OF MAIN MENU
●
SP, A/M, Alarms, Auxiliary Setpoints, Integrator, Counter, Hold, PID, Communications, etc.
SPECIFIC APPLICATIONS OF SOME OF MAIN FUNCTIONS
●
Indicator types, Counter, Frequency, Type of Controllers, Special models, etc.
BASIC CONFIGURATION BY KEYPAD OF MAIN FUNCTIONS
●
Allows, without using the LoopWin software, using the keypad to modify the most common
functions of the HS-7000 Series such as: Input, Output, Hold, Integrator, Derivator, Timers,
Linearizers, Alarms, PID, Setpoint SP, Password
COMPLETE MENU OF MODELS WITH DISPLAY
For any model of HS-7000 with display, with all its functions enabled, and indistinctly of the
assignation to the dispaly, or in which Loop or Password the function is located, when the key
