Denver SEL-10510F Manuel utilisateur

Original instructions

SEL-10510F

facebook.com/denver.eu

Before operating this vehicle, read all the instructions for safe assembly and operations. User’s manual can guide

you through the functions and usage of Electric scooter. Before using this Electric scooter, familiarize yourself with

how to operate, so that you can keep the Electric scooter in the best condition possible.

This appliance can be used by children aged from 14 years and above and persons with reduced physical, sensory

or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

The appliance is only to be used with the power supply unit provided with the appliance.

This appliance contains batteries that are not replaceable.

Version 1.0

Table of Contents

1 Product and Accessories......................................................................................................................3

2 Unfolding and folding the scooter........................................................................................................ 5

3 Assembling the device.......................................................................................................................... 6

4 Charging the scooter.............................................................................................................................7

5 Intended Use........................................................................................................................................ 8

6 Safety Instruction..................................................................................................................................8

7 Maintenance.........................................................................................................................................9

8 Operational control......................................................................................................................... 11

9 Electric scooter riding......................................................................................................................... 12

10 List of parameters............................................................................................................................... 14

11 Electric scooter safe parking............................................................................................................... 15

12 Safe transportation............................................................................................................................. 15

13 Warnings............................................................................................................................................. 15

1Product and Accessories

Important!

This electric scooter must be charged and stored in a safe way.

For safety reason and protect battery life, never charge the electric scooter in temperatures below 5 °C

or above 45 °C. Equally, always disconnect the electric scooter with the power cable once fully charged.

Always use the supplied power adapter to charge the electric scooter.

Make sure that all screws are properly tightened to avoid unsafe situations.

WARNING

●Please make sure to check that the steering system is correctly adjusted and that all

connection components are firmly secured and not broken before riding, refer to

handlebar assembly and safety instruction.

●Please read operation guide and warnings of correct techniques for use and braking

●Always wear shoes.

●When self-locking nuts and other self- locking fixings may lose their effectiveness.

●All parts and materials of electric scooter cannot be changed, modifications are not

allowed.

1. Product and Accessories

Front LED light

Disc brake

Back reflector

Disc Brake

Throttle

Foldable

Rear LED light

Bell

Display

Electric brake

White reflector

10”wheel size

Front shock absorption

Valve extension for air

tube

Screw for handlebar

attachment x 4

Allen key x 2

charger

2Unfolding and folding the scooter

Unfolding the scooter

1）Place the electric scooter on its wheels like below. Unlock the hook on the handlebar.

2) Pull up the handle in a gentle way. Raise the handle slowly.

Close the lock lever located on the lower part of the handlebar support tube.

3) The electric scooter is unfolded as soon as you hear the rod clicks into place.

Folding the scooter

1. Release the release lever located on the lower part of the support tube

of the handlebars.

2. Fully open the release lever.

3. Open the scooter by accompanying the handlebar tube downwards.

4. Hook the folded tube onto the appropriate support.

3Assembling the device

Before using the scooter it is necessary to install the handlebar on the frame

main vehicle.

1). Insert the handlebar into the vehicle frame.

2). After matching the holes in the handlebar with those of the frame,

insert the screws and tighten them well; repeat the operation also in the side

opposite of the handlebar inserting a total of 4 screws.

4Charging the scooter

Connect the supplied power adapter to the charging port of the electric scooter.

Charging port

5Intended Use

The Electric scooter is neither a means of transport nor sports equipment, but a device for personal

entertainment. The Electric scooter for domestic use only and only by a person aged at least 14 with a

maximum weight of 120 kg. The other parameters for the permissible operation of the Electric scooter are

defined in the section (“10. List of parameters”) . Importantly, the Electric scooter may only be operated in

good visibility conditions and only if the physical conditions for stability on the Electric scooter are met (for

example, not on one leg/not under the influence of drugs or alcohol). When operating the electric scooter,

the operator must wear personal protective equipment specified in the section (“13. Warnings” > 13.2

Preparation”).

6Safety Instruction

We recommend always wearing helmet and protective gear like elbow, knee and wrist protectors to ensure

your personal safety.

Also make sure you have read the user manual carefully, to ensure you know how to ride it in a safe and

fun way.

The Electric scooter is for domestic use only.

It is your responsibility to be aware of and comply with all regulations. If there are no regulations for this

Electric scooter in your country, please take care of your own safety and the safety of others.

Also pay attention to other people. Always ride safely and only at a speed that allows you to brake safely

at any time. A common thing for such products is that there is a risk that you may fall off the product

and injure yourself. Always ride as safely as possible.

If lending the electric scooter to friends and family, please make sure they use proper protective gear

and know how to ride it.

Before riding the electric scooter, please check that all parts are working as supposed to. If any loose

parts, abnormal noise, reduced battery life etc. are detected, please contact your retailer for product

service and warranty. Do not repair the electric scooter yourself.

Inspect the rear tire, rear brake, and brake pad according to Section 7 of the maintenance specification

in this operating instructions. The electric scooter may become unstable if the rear brake is deformed or

loose. This is because the distance between the brake pad and the rear wheel becomes too small,

possibly leading to a blocked rear wheel.

Avoid applying too much force or stepping on the rear fender permanently. This may cause the fender to

loosen or damage the spring holding the fender.

As a result, the brake pad constantly touches the wheel and the motor temperature increases due to the

additional resistance. The rear tire can also get loose if the brake is in constant braking position.

Avoid constant braking. As a result, the tires will not only wear off, but also become hot. This will soften

the rubber and it will no longer have the same grip on the road as usual. Do not touch the tire after

braking.

If you hear unusual noises or notice friction when switching on the electric scooter, a bearing may be

damaged. A worn bearing may even be indicated by strong vibration of the handlebar. In this case,

please contact your retailer since the bearing needs to be replaced and/or the handlebar checked and

adjusted.

Ride the electric scooter only on a dry surface since otherwise the riding safety and braking performance

may be impaired and the motor or bearings may be damaged.

Please do not ride up or down long and steep slopes.

Stop riding when you receive the "Low Battery Warning". The electric scooter then moves only slowly

and does not have the same traction as normal and the electric brake does not work. In this case, please

use the rear brake to stop the electric scooter. Get off the Electric scooter as soon as the speed allows to

do that safely.

Do not use the electric brake and the throttle at the same time.

A normally working Electric scooter operates safely and quietly. If you hear noises or notice bumpy

operation, please check wheels, bearings, and brakes. Contact your customer service for repair and

maintenance, if necessary.

7Maintenance

●To ensure you get the best possible performance and experience from your electric scooter, it is

important to do regular maintenance for important parts of the product.

●Battery maintenance

●Bearings, Screws, Brakes and Wheels

●Storage and Cleaning

Your electric scooter will require some maintenance so please read and familiarize yourself with this guide.

●Battery maintenance

All batteries have a life cycle, and performance will decrease over time, however here are some advice to

maximize the life span of the battery.

Make sure that the battery is charged at regular intervals, even if you do not use the electric scooter for a long

time. This is to prevent damage to the battery, caused by low voltage over an extended period.

Avoid draining the battery completely. It is best to charge while there is still power on it. This will extend battery

life. If the battery is constantly depleted, it will damage the battery (damaged battery caused by wrong handling

are not covered by the warranty).

If riding the electric scooter in cold or very hot areas, the battery time can be lower than when riding in

temperatures from 15-25° Celsius. This is not a failure on the batteries, but normal behavior.

Please notice: Even a fully charged battery will run out of power if the electric scooter is not used for a period.

Expect a fully charged battery to keep power between 90 and 120 days in off mode, before it is fully discharged. If

only partially charged, this period is lower.

Please make sure the battery does not get above 50° Celsius, or below minus 10° Celsius for a longer period. (e.g.

don’t leave the electric scooter in a hot car in summer, do not put battery into fire etc.) Low temperature (e.g.

subzero temperature) can damage the battery cells.

Keep the Electric scooter away from open flame or other sources of heat to prevent the battery from getting too

hot. Also make sure not to leave the electric scooter at freezing temperatures. Both heat and excessive cold can

cause the battery to discharge.

Only use original charger or an official replacement, as different batteries may require specific charger, and if

using other chargers, this could cause damage to the product.

Do not overcharge and discharge the battery.

Please make sure to charge the battery before it is completely out of power, to avoid damaging the battery cells.

(damaged battery caused by wrong handling are not covered by the warranty)

It is forbidden to disassemble battery package. This is only to be handled by official service repair centers and

professionals.

●Bearings, Screws, brakes and Wheels

Your electric scooter is made up of moving parts, which in time, will be susceptible to wear and tear.

Bearings and screws:

The electric scooter has sealed and dustproof bearings so that no lubrication is required. Check the bearings for

wear at regular intervals to avoid unsafe riding. Do not jump on and off and do not apply excessive force

otherwise to avoid damage to the bearings. This is not a sports electric scooter.

Make sure that all screws are properly tightened to avoid unsafe situations.

Please check the screws regularly and tighten if they seem loose.

Brakes:

Check the brake for wear at regular intervals to avoid unsafe riding. Do not apply excessive force to avoid damage

to the brake.

Electric scooter with disc brake will require adjustment over time and in the end will need to be replaced, when

worm down. Avoid using electric scooter when brakes are worn down, as this is unsafe and will also damage the

brake.

Wheels:

Check the wheels for wear at regular intervals to avoid unsafe riding.

Electric scooters come with different wheels but can in general be separated into tires with inflatable inner tubes

and solid wheels.

For inflatable tires, please make sure to keep the right pressure, as hard tires will last longer.

If the wheel seems wobbly even after screws are tightened, the bearings might be worn

down and need replacement
