Portable CD Boombox with FM Radio
TC - 28
9
17
25
33
41
49
57
65
73
81
89
1
Safety information
Please read the safety instructions carefully before using the product for
the first time and keep the instructions for future reference.
1.This product is not a toy. Keep it out of reach of children.
2.Keep product out of the reach of children and pets to avoid chewing
and swallowing.
3.Never use old and new batteries or different types of batteries together.
Remove the batteries when you are not using the system for a longer period
of time. Check the polarity (+/-) of the batteries when inserting them in the
product. Wrong positioning can cause an explosion. Batteries are not included.
4.Product operating and storage temperature is from 0 degree Celsius to 40
degree Celsius. Under and over this temperature might affect the function.
5.Never open the product. Touching the inside electrics can cause electric shock.
Repairs or service should only be performed by qualified personnel.
6.Do not expose to heat, water, moisture, direct sunlight!
7.Please protect your ears against loud volume. Loud volume can damage your
ears and risk in hearing loss.
8.The unit is not waterproof. If water or foreign objects enter the unit, it may
result in fire or electric shock. If water or a foreign object enters the unit, stop
use immediately.
9.The direct plug-in cable is used as disconnect device, the disconnect device
shall remain readily operable. So, make sure there is space around the power
outlet for easy access.
10.Do not use non original accessories together with the product as this can
make the product functionality abnormal.
2
Instructions Manual
Product overview
1.
2. PROGRAM/REPEAT/PRESET button
3. Stop button
4. Previous/TUN- button
5. Volume +/Next button
6. Volume -/Back/CLOCK. ADJ button
7. Play/Pause/FM SCAN button
8. Next/TUN + button
9. LCD display
10. Carry handle
11. Telescopic antenna
12. AC power socket
13. Battery compartment
14. Headphone jack
15. AUX IN jack
16. CD compartment
/SOURCE button
3
4
Set clock
1. Once connecting to the power supply, the boom box enters standby.
“00:00” is displayed.
2. Press the CLOCK. ADJ button to enter clock setting mode.
3. Press the Previous/TUN- button to select “24 H” or “12 H”, then press the
CLOCK. ADJ button.
4. “Set time” is displayed and the hour digits flash. Press the Next/TUN+ or
Previous/TUN- button to adjust hour, then press the CLOCK. ADJ button.
5. The minute digits flash. Press the Next/TUN+ or Previous/TUN- button to
adjust minute, then press the CLOCK. ADJ button.
FM Radio mode
Check that your boom box is in FM radio mode. To enter FM radio mode, press
repeatedly the /SOURCEbutton until FM mode is displayed.
If you switch the boom box on again, the last selected radio station is
automatically selected.
5
Tuning to an FM station
1. In FM mode, press the FM SCAN button to initialize scan. When an
available radio station is tuned to, the scan stops.
2. Press the Next/TUN+ or Previous/TUN- button to fine tune each frequency
in 0.05 MHz steps, if necessary.
Storing an FM station
Your boom box can store up to 10 FM radio stations in its preset memories for
instant access to your favorite stations.
1. Tune the boom box to the FM radio station that you wish to preset.
2. Press and hold the PRESET button for approximately 2 seconds until ‘P01’
is displayed.
3. Press the PRESET button to select a preset number (1-10) you would like to
store the radio station to.
4. Press and hold the PRESET button. ‘P XX stored’ is displayed, where ‘X’ is
the number of the preset (1-10).
Note: If there is already an existing FM station stored under a preset, the
newly stored station overwrites the old one.
Selecting a preset FM station
1. In FM mode, press the PRESET button to select a preset station number (1-
10) you would like to listen to.
2. Press and hold the PRESET button to confirm selection. The preset station
begins to broadcast.
Note: If no FM station has been stored under a preset number, ‘Preset
Empty’ is displayed, and then the boombox reverts to the previously
selected radio station after a few seconds.
CD Mode
Check that your Boom box is in CD mode. To enter CD mode, press repeatedly
the /SOURCE button until CD mode is displayed. The display shows
6
flashing ‘_ _ _’, followed by ‘NO’ if no CD is loaded.
AUX mode
Check that your boom box is in AUX mode. To enter AUX mode, press repeatedly
the /SOURCE button until AUX mode is displayed. Through AUX
connection, you can listen to an external audio device through the speakers of the
boom box.
1. Using a 3.5mm audio cable (not included), connect the AUX IN jack on the
boom box to the headphone jack (or auxiliary output) on an external audio
device.
2. Start play on the connected audio device.
3. To adjust volume, you may use the volume controls on the boom box.
Other information
Technical specifications
AC input power
230V AC, 50Hz
Battery power
(optional)
6 x 1.5V C size (LR14) (not included)
Speaker output
2 x 1W RMS
FM frequency range
87.5 MHz to 108 MHz
Please notice - All products are subject to change without any notice.
We take reservations for errors and omissions in the manual.
7
Electric and electronic equipment contains materials, components and
substances that can be hazardous to your health and the environment,
if the waste material (discarded electric and electronic equipment) is
not handled correctly.
Electric and electronic equipment is marked with the crossed out trash
can symbol, seen above. This symbol signifies that electric and
electronic equipment should not be disposed of with other household
waste, but should be disposed of separately.
All cities have established collection points, where electric and
electronic equipment can either be submitted free of charge at
recycling stations and other collection sites, or be collected from the
households. Additional information is available at the technical
department of your city.
Hereby, Denver A/S declares that the radio equipment type
TC-28 is in compliance with Directive 2014/53/EU. The full text of
the EU declaration of conformity is available at the following
