DVP02TK-S / DVP02TU-S

Temperature Control

Module Manual

2017-12-06

Industrial Automation Headquarters

Delta Electronics, Inc.

Taoyuan Technology Center

18 Xinglong Road, Taoyuan District,

Taoyuan City 33068, Taiwan (R.O.C.)

TEL: 886-3-362-6301 / FAX: 886-3-371-6301

Asia

Delta Electronics (Jiangsu) Ltd.

Wujiang Plant 3

1688 Jiangxing East Road,

Wujiang Economic Development Zone

Wujiang City, Jiang Su Province, P.R.C. 215200

TEL: 86-512-6340-3008 / FAX: 86-769-6340-7290

Delta Greentech (China) Co., Ltd.

238 Min-Xia Road, Pudong District,

ShangHai, P.R.C. 201209

TEL: 86-21-58635678 / FAX: 86-21-58630003

Delta Electronics (Japan), Inc.

Tokyo Ofce

2-1-14 Minato-ku Shibadaimon,

Tokyo 105-0012, Japan

TEL: 81-3-5733-1111 / FAX: 81-3-5733-1211

Delta Electronics (Korea), Inc.

1511, Byucksan Digital Valley 6-cha, Gasan-dong,

Geumcheon-gu, Seoul, Korea, 153-704

TEL: 82-2-515-5303 / FAX: 82-2-515-5302

Delta Electronics Int’l (S) Pte Ltd.

4 Kaki Bukit Ave 1, #05-05, Singapore 417939

TEL: 65-6747-5155 / FAX: 65-6744-9228

Delta Electronics (India) Pvt. Ltd.

Plot No 43 Sector 35, HSIIDC

Gurgaon, PIN 122001, Haryana, India

TEL : 91-124-4874900 / FAX : 91-124-4874945

Americas

Delta Products Corporation (USA)

Raleigh Ofce

P.O. Box 12173, 5101 Davis Drive,

Research Triangle Park, NC 27709, U.S.A.

TEL: 1-919-767-3800 / FAX: 1-919-767-8080

Delta Greentech (Brasil) S.A.

Sao Paulo Ofce

Rua Itapeva, 26 - 3° andar Edicio Itapeva One-Bela Vista

01332-000-São Paulo-SP-Brazil

TEL: 55 11 3568-3855 / FAX: 55 11 3568-3865

Europe

Delta Electronics (Netherlands) B.V.

Eindhoven Ofce

De Witbogt 20, 5652 AG Eindhoven, The Netherlands

TEL: +31 (0)40-8003800 / FAX: +31 (0)40-8003898

DVP-0002220-02

*We reserve the right to change the information in this catalogue without prior notice.

DVP02TK-S / DVP02TU-S

Temperature Control Module Manual

Chapter 1 Introduction

1.1 Specification......................................................................................1-3

1.2 Dimensions (mm)..............................................................................1-7

1.2.1 DVP02TU-S.................................................................................. 1-7

1.2.2 DVP02TK-S.................................................................................. 1-8

1.3 Installation........................................................................................1-9

1.4 Terminal arrangement.......................................................................1-9

1.5 Wiring Diagram ...............................................................................1-10

1.6 LED Indicator Description................................................................1-13

1.7 RS-485 Communication for DVP02TK-S Series ................................1-13

Chapter 2 Control Register

2.1 Control Registers...............................................................................2-2

2.1.1 List of the Control Registers ........................................................... 2-2

2.1.2 Basic Setup Page.......................................................................... 2-3

2.1.3 PID Setup Page ............................................................................ 2-6

2.1.4 Program Control Setup Page........................................................... 2-8

2.1.5 Pattern0, 1 Setup Page.................................................................. 2-8

2.1.6 Pattern2, 3 Setup Page.................................................................. 2-9

2.1.7 Pattern4, 5 Setup Page................................................................ 2-10

2.1.8 Pattern6, 7 Setup Page................................................................ 2-11

2.2 Analog Input Description.................................................................2-12

2.3 Outputs ...........................................................................................2-13

2.3.1 The output value varies with the PV value. ..................................... 2-13

2.3.2 Alarm Outputs............................................................................ 2-13

2.4 ON/OFF Control Mode......................................................................2-15

2.5 PID Control Mode ............................................................................2-16

2.6 Programmable SV Control Mode ......................................................2-20

2.7 ERROR LED Indicator.......................................................................2-20

1-1

Chapter 1 Introduction

Table of Contents

1.1 Specification......................................................................................1-3

1.2 Dimensions (mm)..............................................................................1-7

1.2.1 DVP02TU-S..................................................................................1-7

1.2.2 DVP02TK-S.................................................................................. 1-8

1.3 Installation........................................................................................1-9

1.4 Terminal arrangement.......................................................................1-9

1.5 Wiring Diagram ...............................................................................1-10

1.6 LED Indicator Description................................................................1-13

1.7 RS-485 Communication for DVP02TK-S Series ................................1-13

DVP02TK-S/DVP02TU-S Temperature Control Module Manual

1-2

Thank you for using Delta DVP02TK-S/DVP02TU-S Temperature Control Module. To ensure a successful installation and

for safety reasons, please read this manual carefully before operating.

This manual contains important safety instructions.

Cette notice contient des instructions importantes concernant la sécurité.

Disconnect all sources of supply before servicing.

Couper toutes les sources d’alimentation avant de faire l’entretien et les réparations.

For use in a controlled environment. Refer to manual for environmental conditions.

Pour utilisation en atmosphère contrôlée. Consulter la notice technique.

Warning: proper ventilation is required to reduce the risk of hazardous or explosive gas buildup during indoor charging.

Avertissement : une ventilation adéquate est nécessaire afin de réduire les risques d’accumulation de gaz dangereux

ou explosifs durant la recharge à l’intérieur.

The analog input circuits shall not be connected to MAINS CIRCUIT for measuring or sensing and limited to SELV

circuit only.

The supply voltage and transistor (analog) outputs are SELV circuit and limited energy.

This is an OPEN TYPE module and therefore should be installed in an enclosure free of airborne dust, humidity, electric

shock and vibration. The enclosure should prevent non-maintenance staff from operating the device (e.g. key or

specific tools are required for operating the enclosure) in case danger and damage on the device may occur. Do not

touch any terminal when the power is on.

This manual provides you with the introductions on the specifications, installation, basic operations, setups and

temperature measurements.

Read this manual carefully and follow the instructions to avoid danger and damage to people and property.

DVP02TK-S series includes DVP02TKR-S, DVP02TKN-S and DVP02TKL-S. DVP02TU-S series includes

DVP02TUR-S, DVP02TUN-S and DVP02TUL-S.

Chapter 1 Introduction

1-3

1.1 Specification

DVP02TK-S/DVP02TU-S

Supply voltage 24VDC

Max. rated power

consumption 2.4W, supplied by external power source in compliance with UL61010-2-201 \ IEC61131-2

Connector Type European standard removable terminal block (Pin pitch: 3.5mm)

Operation/storage

temperature

Operation: 0°C ~ 55°C (temperature), 5 ~ 95% (humidity), Pollution degree: 2

Storage: -25°C ~ 70°C (temperature), 5 ~ 95% (humidity),Attitude: up to 2000m;

For use in dry location only

Vibration/Shock

resistance International standards: IEC 61131-2, IEC 68-2-6 (TEST Fc) / IEC 61131-2 & IEC 68-2-27 (TEST

Ea)

Connection to

DVP-PLC The modules are numbered from 0 to 7 automatically by their distance from DVP-PLC. Max. 8

modules are allowed to connect to DVP-PLC and will not occupy any digital I/O points.

I/O points 2 points of universals analog inputs (CH1, CH2), 2 analog outputs (OUT1, OUT2) or 4 digital

outputs (OUT1~OUT4)

General Analog Input

Input CH1,

CH2

Thermal resistance: Pt100, JPt100, Pt1000, Ni100, Ni1000, Cu50, Cu100, GNi1000

Thermocouple : J, K, R, S, T, E, N, B, U, L, TXK (L), C, PL II

Voltage input: 0~+50mV, 0~+5V, 0~+10V

Current input: 0mA~+20mA, 4~+20 mA

Hardware Resolution 16 bits

Distance 100 meters

Input disconnection

detection Supported by exceeded temperature input range

Analog / Digital Output

Analog OUT1~

OUT2 Analog output, 12-bit: 0~+10V, 0/4~+20mA

Digital OUT1~

OUT4

4 channels digital output, 250VAC, 60Hz/24VDC, 2A, Relay

4 channels digital output, Voltage pulse output, 24VDC, 300mA

A/D Function Specification

Analog / Digital Voltage Input

Maximum rated input 0V~10V 0V~5V

Overall accuracy

(normal temperature) 0.5%

Overall accuracy

(full temperature range) 1%

Hardware resolution 16 bits

DVP02TK-S/DVP02TU-S Temperature Control Module Manual

1-4

Input impedance 650KΩ

Analog / Digital Current Input

Maximum rated input 0mA~20mA 4mA~20mA

Overall accuracy

(normal temperature) 0.5%

Overall accuracy

(full temperature range) 1%

Hardware resolution 16 bits

Input impedance 249Ω

Analog / Digital Temperature Input

Maximum rated input Thermocouple Thermistor

Overall accuracy

(normal temperature) 0.4%

Overall accuracy

(full temperature range) 0.8%

Hardware resolution 24 bits

Input impedance 2MΩ

Analog sampling time (by channel)

Analog input type AI Thermocouple Thermistor Quick AI (0~10V)*2

Setting time (ms) 80 80 160 3

Conversion time (ms) 50 50 100 2

Response time (ms) 130 130 260 5

Response time = setting time + conversion time

*1. Compared to the response time of the thermocouple temperature, it needs two times of time for the thermistor

temperature to respond, since the thermistor channels require a temperature compensation.

*2. Since there is only one channel used, the time to stabilize the circuit is not required.

Chapter 1 Introduction

1-5

DVP02TKL-S/DVP02TUL-S D/A Function Specification

Analog / Digital Voltage Output

Maximum rated input 0V~10V

Overall accuracy

(normal temperature) 0.5%

Overall accuracy

(full temperature range) 1%

Hardware resolution 12 bits

Allowable load impedance 1kΩ~ 2MΩat 0V~10V

Analog / Digital Current Output

Maximum rated output 0mA~20mA 4mA~20mA

Overall accuracy

(normal temperature) 0.5%

Overall accuracy

(full temperature range)

(average number of 100

times)

1%

Hardware resolution 12 bits

Allowable load impedance ≦550Ω

Analog setup time (by channel)

Analog output type Voltage Current

Setting time (µs) 100 250

Conversion time (µs) 500 500

Response time (µs) 600 750

Response time = setting time + conversion time

DVP02TK-S/DVP02TU-S Temperature Control Module Manual

1-6

DVP02TKR-S/DVP02TUR-S/DVP02TKN-S/DVP02TUN-S DO Function Specification

Model

Item

DVP02TKR-S

DVP02TUR-S

DVP02TKN-S

DVP02TUN-S

Output points 4 4

Connector Type Removable terminal block

Output point type Relay-R Transistor-T (NPN)

Voltage specification Below 250VAC, 30VDC 12~30VDC

Maximum load Resistive 2A/1point

(3A/COM)*1

0.3A/1 point

(0.6A/COM)*1

Inductive Life curves*2, 4 7.2W (24VDC)*3

Maximum output

frequency

Resistive 1Hz 100Hz

Inductive 0.5Hz 0.5Hz

Lamp 1Hz 10Hz

Maximum

response time

OFF→ON 10ms 0.5ms

ON→OFF

*1. Complied with UL61010-2-201 & IEC61131-2(AC or DC resistance)

*2. Complied with UL61010-2-201 & IEC61131-2 (AC/DC general-use or AC pilot duty)

Rated making capacity: 7.5A; rated breaking capacity: 0.75A; 2.5A thermal continuous at 240VAC

DC pilot duty; rated making capacity: 0.22A; rated breaking capacity: 0.22A; 1A thermal continuous at 30VDC

*3. Complied with IEC/UL61010-2-201 (DC general-use)

*4. Life curves

Disconnect power before servicing to avoid the risk of electric shock.

Utilisez relay est sous tension. Risque de choc électrique, couper le courant avant l’entretien.

Contact Current(A)

0.5

0.1 0.2

0.3 0.7 1 2

200

300

500

100

1000

2000

3000

Operation(X10)

120VAC Resistive

30VDC Inductive(t=7ms)

240VAC Inductive(cos 0.4)

120VAC Inductive(cos =0.4)

30VDC

Inductive

(t=40ms)

Chapter 1 Introduction

1-7

1.2 Dimensions (mm)

1.2.1DVP02TU-S

DVP-02TU

3.40

60.00

90.00

25.20 60.00 3.00

3.00

Description

1 Run/Error indicator

2 Model name

3 Removable terminal block

4 I/O terminal layout

5 I/O module clip

6 I/O module connection port

7 Label

8 DIN rail clip

DVP02TK-S/DVP02TU-S Temperature Control Module Manual

1-8

1.2.2DVP02TK-S

3.40

60.00

90.00

25.20 60.00 3.00

3.00

10 11

Description

1 Run/Error indicator

2 Model name

3 Removable terminal block

4 I/O terminal layout

5 Run/Stop switch

6 I/O module clip

7 I/O module connection port

8 Label

9 DIN rail clip

10 Power connection port

11 RS-485 communication port

Autres manuels pour DVP02TK-S

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Delta Unité de contrôle

Delta

Delta DVPDT02-H2 Manuel utilisateur

Delta

Delta 160 T6 Series Manuel utilisateur

Delta

Delta TECK 81T2 -WHSHWA Series Manuel utilisateur

Delta

Delta DRU-24V40ABN Guide de démarrage rapide

Delta

Delta MultiChoice T24876 Manuel utilisateur

Delta

Delta IFD9503 Instructions d'utilisation

Delta

Delta DVP series Manuel utilisateur

Delta

Delta DVP01LC-SL Manuel utilisateur

Delta

Delta TECK II 81T201BTA-MMO Manuel utilisateur

Delta

Delta ASRTU-EC16AP Manuel utilisateur

Delta

Delta TECK II Manuel d'instructions

Delta

Delta JA-190X Manuel utilisateur

Delta

Delta SEG-48100-02I Manuel utilisateur

Delta

Delta MultiChoice T27 Series Manuel utilisateur

Delta

Delta DVP04AD-SL Manuel utilisateur

Delta

Delta 112962C Manuel utilisateur

Delta

Delta TECK II 81T201BT Manuel utilisateur

Delta

Delta CANopen DVPCOPM-SL Manuel utilisateur

Delta

Delta R1-EC5614 Manuel utilisateur

Delta

Delta TECK COMMERCIAL R2570-MIXLFBOX Guide de démarrage rapide

Delta

Delta DVP04DA-H Manuel utilisateur

Delta

Delta FlushIQ RP76681 Manuel utilisateur

Delta

Delta EnviroStation EMS2000 Manuel utilisateur

Delta

Delta MultiChoice T27976-CZLHP Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
