DeLonghi DFH550R Manuel utilisateur

FAN HEATER

TERMOVENTILADOR

INSTRUCTIONS FOR USE

INSTRUCCIONES DE USO

DFH550R

Electronic thermostat

Power selection

Infrared receiver

for remote control

Oscillating body and

adjustable base

Foot switch

IMPORTANT SAFEGUARDS

When using electrical appliances, basic precautions should always be followed to reduce

risk of fire, electric shock, and injury to persons, including the following:

1. Read all instructions before using the appliance.

2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot sur-

faces. Use handle when moving this heater. Keep combustible materials, such as furni-

ture, pillows, bedding, papers, clothes and curtains at least 3 feet (0,9 m) from the

front and top of the heater and keep them away from the sides and rear.

3. Extreme caution is necessary when any appliance is used by or near children or

invalids and whenever the heater is left operating and unattended.

4. Always unplug appliance when not in use.

5. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, has been dropped or damaged in any manner.

Return heater to authorized service facility for examination, electrical or

mechanical adjustment, or repair.

6. Do not use outdoors.

7. Do not use this heater in the immediate proximity of bathrooms, laundry areas and simi-

lar indoor locations. Never place appliance where it may fall into a bathtub or other

water container.

8. Do not run cord under carpeting. Do not cover cord with throw rugs, run-

ners, or the like. Arrange cord away from traffic area and where it will

not be tripped over.

9. To disconnect the appliance, turn controls to off, then remove plug from outlet.

10. Connect to properly polarized outlets only.

11. Do not insert or allow foreign objects to enter any ventilation opening as this may

cause an electric shock, fire or damage the appliance.

12. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not

use on soft surfaces, like a bed, where openings may become blocked.

13. A fan heater has hot or arcing or sparking parts inside. Do not use it in

areas where gasoline, paint, or flammable liquids are used or stored.

14. Use this appliance only as described in this manual. Any other use not recommended

by the manufacturer may cause fire, electric shock, or injury to persons.

15. To prevent overload and blown fuses, be sure that no other appliance is plugged into

the same outlet (receptacle) or into another outlet (receptacle) wired into the same circuit.

16. It is normal for the heater’s plug and cord to feel warm to the touch. A plug or cord

which becomes hot to the touch or becomes distorted in shape may be a result of a

worn electrical outlet (receptacle). Worn outlets or receptacles should be replaced prior

to further use of the heater. Plugging heater into a worn outlet/receptacle/ may result

in overheating of the power cord or fire.

17. Do not use an extension cord because the extension cord may overheat

and cause a risk of fire. However, if you have to use an extension cord, the

cable cord be no. 14 AWG minimum size and rated not less than 1875

watts, and has to be used only for supplying power to this appliance.

18. Be sure that the plug is fully inserted into an appropriate outlet. Please remember that

outlets also deteriorate due to aging and continuous use: check periodically if signs of

overheating or deformations are evidenced by the plug. Do not use the outlet and CALL

your electrician.

19. Check that neither the appliance nor the power cord have been damaged in any way

during transportation.

20. CAUTION: to prevent electric shock match wide blade of plug to wide slot, fully insert.

21. Do not cover the appliance while it is functioning in order to avoid overheating with the

attendant risk of fire.

SAVE THESE INSTRUCTIONS

Your product is equipped with a polarized alternating current line plug (a plug having one

blade wider than the other). This plug will fit into the power outlet only one way. This is a

safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If

the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not

defeat the safety purpose of the polarized plug.

CAUTION

- Always use the heater in an upright position.

- Do not use the heater to dry your laundry. Never obstruct the intake and outlet grilles

(danger of overheating).

- The appliance must be installed so that the switches and other controls cannot be rea-

ched from a person standing in a bathtub or a shower.

- The electrical feed cord must be replaced only by officially authorised personnel.

ELECTRIC POWER CONNECTION

The fan heater must be connected to a properly polarized A/C 110/120 V household out-

let in perfect working condition.

Keep loose clothing or bedding, furniture and flammable material away from the wall outlet

where the heater is plugged in.

INSTALLATION

The fan heater can be easily positioned on any horizontal support surface in an upright position.

FAN HEATER CONTROLS:The thermostat will adjust the set temperature automatically and

keep it constant.

Voltage Wattage See rating label

thermostat dial

Fig. 1

These two LEDs indicate

the selected power level As the appliance cycles

between the different power

levels when it is in use, these

two LEDs indicate the level

currently in use

ON/OFF button

ventilation only

OPERATION AND USE

By pressing the “ON/OFF” button (Fig. 1) one or more times (a beep will confirm each

selection), the appliance will select the operating heating power, as follow:

P max (maximum power)

P med (medium power)

P min (minimum power)

Fan only (summer operation)

off

If “P max” maximum appliance operating power has been selected, adjust the thermostat

dial (Fig. 1) to the desired comfort temperature, from 42°F and 95°F (5°C and 35°C).

If the selected temperature is higher than the actual room temperature, the appliance will start

automatically and rapidly heating the room until it reaches the selected temperature. The unit will

automatically mantain the temperature at a constant level, by cycling between “max” (fig. 2),

“med” and “min”, as it approaches the selected comfort temperature.

If the room temperature exceeds the selected temperature level, the appliance will turn itself

off.

room temperature

°C °F

541

10 50

15 59

20 68

25 77

30 86

35 95

The appliance will turn on automatically again when the room temperature falls below the

selected temperature level.

If a power level below “P max” has been selected using the “ON/OFF” button, the appli-

ance will modulate between the selected level and the lower power levels.

ANTIFREEZE FUNCTION

Press the “ON/OFF” button to select the “P max” power level.

Set the thermostat dial to the “*” position (Fig. 1).

When set in this way, the appliance will turn on automatically only if the room temperature

falls below 42°F (5°C), to prevent it from freezing at minimum energy consumption.

This function is not guaranteed in the event of black outs, even if lasting just a few seconds.

MODELS WITH ROTATING BODY

This appliance is fitted with a motorized base and a rotating body.

To distribute the air flow over a larger area, push the foot switch (Fig. 3).

When activated, the appliance will oscillate from right to left over an angle.

To stop the appliance in the desired position, simply push the foot switch again (a beep will

confirm the selection)

MODELS WITH REMOTE CONTROL

Some models are equipped with a remote control to provide ease of operation.

The appliance can be completely controlled with the remote control.

Two AAA 1,5V batteries are required (not included):

•remove the cover located on the back side of the remote control;

•insert the two AAA 1,5V batteires positioning them correctly (see the instructions in the

batteries compartment);

•replace the cover.

MAX

MED

MAX

MIN

MAX

OFF

Selected power

Power used

fig. 2

Fig. 3

REMOTE CONTROL OPERATION

-When you press the “ON power selection” push button, the appliace operates at the

maximum power. Each further pression of the “power selection” push button, the power

will change from MAX to MED/MIN/MAX.

-If you desire to operate with the fan only, press the “Fan Only” pushbutton.

-Only when a function is selected it is possible to activate the rotation of the appliance,

by pushing the “ON/OFF oscillating base” push button.

-The “Off” push button switches off the appliance.

Every time you press a button, the appliance will confirm the selection with a “beep” and

the pilot light on the remote control will illuminate.

FLOW DIRECTION (Tilting Body)

The appliance inclines or declines manually so that air is flowing in the desired direction.

IMPORTANT

In the event of a blackout , the appliance settings will be reset.

To turn the appliance back on, repeat the procedure described above.

MAINTENANCE AND SERVICE

Always remove the plug from the power outlet and allow the heater to cool. After the heater has

cooled, clean it with a soft damp cloth, do not use detergents or abrasives. Periodically clean

the air intake and outlet grilles during the period in which the heater is in use with a vacuum

cleaner.

Should the heater not be in use over a certain length of time, store it in a dry place.

This appliance has been built to provide many years of trouble free service.

In case of malfunction, do not try to repair the heater yourself: it may result in fire hazard or

electric shock. Call the nearest Service Center (see attached list of Service Centers).

ATTENTION

A safety device turns the fan heater off if it accidentally overheats. An audible signal warns of

that overheating has occurred. To reset the unit to normal operation, remove the plug from the

outlet for a few minutes, eliminate the cause of overheating (e.g. obstructed air intake or outlet

grilles) and then plug the fan heater back in again. Contact your nearest Service Center if the

fan heater does not resume normal operation again.

ON power selection

pushbutton

Fan Only pushbutton

ON/OFF oscillating base

pushbutton

Off

Pilot light

LIMITED WARRANTY

What DoesThis Warranty Cover? We warrant each appliance to be free from defects in material and workman-

ship. Our obligation under this warranty is limited to replacement or repair, free of charge at our factory or authorized

service centers, of any defective part or parts thereof other than parts damaged in transit, which shall be returned to us,

transportation prepaid. This warranty shall apply only if the appliance is used in accordance with the factory directions

which accompany it, and on an Alternating Current (AC) circuit.

How Long Does The Coverage Last? This warranty runs for one year from the date of delivery and applies only to

the original purchaser for use.

What Does This Warranty Not Cover? This warranty does not cover defects or damage of the appliance which

result from repairs or alterations to the appliance outside our factory or authorized service centers, nor shall it apply to

any appliance which has been subject to abuse, misuse, negligence or accidents. Also, consequential and incidental

damages resulting from the use of this product or arising out of any breach of contract or breach of this warranty are not

recoverable under this warranty. Some states do not allow the exclusion or limitation of incidental or consequential dam-

ages, so the above limitation may not apply to you.

How Do You Get Service? If repairs become necessary or spare parts are needed, please write to:

DE’ LONGHI AMERICA INC.

Park 80 West Plaza One, 4th floor

Saddle Brook, NJ 07663

or call Service Tel. No. 1-800-322-3848

or visit our internet site www.delonghi.com

The above warranty is in lieu of all other express warranties and representations. All implied warranties are limited to

the applicable warranty period set forth above. This limitation does apply if you enter into an extended warranty with

De’ Longhi. Some states do not allow limitations on how long an implied warranty lasts, so the above exclusions may

not apply to you. De’ Longhi does not authorize any other person or company to assume for it any liability in connection

with the sale or use of its appliance.

How Does State Law Apply? This warranty gives you specific legal rights, and you may also have other rights which

vary from state to state.

Table des matières

Autres manuels DeLonghi Chauffage

DeLonghi

DeLonghi FAN HEATER Manuel utilisateur

DeLonghi

DeLonghi Mod. B Manuel utilisateur

DeLonghi

DeLonghi TRRS0715E Manuel utilisateur

DeLonghi

DeLonghi HFX12 Series Manuel utilisateur

DeLonghi

DeLonghi Electric oil Filled Radiator Manuel utilisateur

DeLonghi

DeLonghi Professional FDL3-i SLIM Mode d'emploi

DeLonghi

DeLonghi TCH8093ER Manuel utilisateur

DeLonghi

DeLonghi Dragon 4 Pro Manuel utilisateur

DeLonghi

DeLonghi TRRS2715EBK Manuel utilisateur

DeLonghi

DeLonghi EW7707CB Manuel utilisateur

DeLonghi

DeLonghi HFX30 Series Manuel utilisateur

DeLonghi

DeLonghi TRD40615EBKCA Manuel utilisateur

DeLonghi

DeLonghi RCH100 Manuel utilisateur

DeLonghi

DeLonghi FAN HEATER Manuel utilisateur

DeLonghi

DeLonghi TRRS0920E.G Manuel utilisateur

DeLonghi

DeLonghi TCH7690ER Manuel utilisateur

DeLonghi

DeLonghi HTN Series Manuel utilisateur

DeLonghi

DeLonghi TRRS2715EBKCA Manuel utilisateur

DeLonghi

DeLonghi DCH7093ERBCA Manuel utilisateur

DeLonghi

DeLonghi DCH7993ER.BC Manuel utilisateur

DeLonghi

DeLonghi HSX3320 Series Manuel utilisateur

DeLonghi

DeLonghi DR18TQP Manuel d'instructions d'installation

DeLonghi

DeLonghi HTM023C Manuel utilisateur

DeLonghi

DeLonghi Electric oil filled radiator Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur
