Dell PowerEdge 2410 Manuel utilisateur

Dell PowerEdge Rack

Enclosure

Installation Guide

Guide d’installation

Installationsanleitung

設置ガイド

Guía de instalación

Dell PowerEdge Rack

Enclosure

Installation Guide

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of

your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if

instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this publication is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.

is strictly forbidden

Trademarks used in this text: Dell™, the D LL logo, and Power dge™ are trademarks of Dell Inc.

Other trademarks and trade names may be used in this publication to refer to either the entities claiming

the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and

trade names other than its own.

July 2010 P/N JRY4T Rev. A00

Contents 3

Contents

Safety Instructions. . . . . . . . . . . . . . . . . . . . . 5

SAFETY: Rack Mounting of Systems . . . . . . . . . 5

Rack Installation Instructions . . . . . . . . . . . . . . . 5

Rack Specifications . . . . . . . . . . . . . . . . . 6

Before You Begin . . . . . . . . . . . . . . . . . . . 6

Installation Tasks . . . . . . . . . . . . . . . . . . . 7

Recommended Tools and Supplies . . . . . . . . . . 7

Removing and Replacing the Rack Doors . . . . . . 8

Removing and Replacing the Side Panels . . . . . 12

Reversing the Front Door (Optional) . . . . . . . . 16

Securing the Rack Leveling Feet . . . . . . . . . . 23

Installing the Rack Stabilizer Feet . . . . . . . . . 24

Adjusting the Rack Posts (Optional) . . . . . . . . 27

Routing Cables . . . . . . . . . . . . . . . . . . . 28

Coupling Two Racks . . . . . . . . . . . . . . . . . . . 32

4Contents

Installation Guide 5

Safety Instructions

Use the following safety guidelines to ensure your own personal safety and to

help protect your system and working environment from potential damage.

For complete safety and regulatory information, see the safety instructions

that shipped with your system. Warranty information might be included in

this document or as a separate document.

SAFETY: Rack Mounting of Systems

Observe the following precautions for rack stability and safety. Also refer to

the rack installation documentation accompanying the system and the rack

for specific caution statements and procedures.

Systems are considered to be components in a rack. "Component" refers to

any system as well as to various peripherals or supporting hardware.

CAUTION: Instructions for Rack-Mounted Systems:

• Your rack kit has been approved only for the rack cabinet provided.

It is your responsibility to ensure that installation of the equipment

into any other rack complies with all applicable standards. Dell disclaims

all liability and warranties with respect to combinations of equipment

with any other rack.

• Before installing your equipment in a rack, install all front and side

stabilizers. Failure to install stabilizers can allow the rack to tip over.

• Always load from the bottom up, and load the heaviest items first.

• Do not overload the AC power supply branch circuit that provides

power to the rack.

• Do not stand or step on any components in the rack.

Rack Installation Instructions

This installation guide provides instructions for trained service technicians

installing a rack enclosure. Information includes assembling the rack,

coupling two racks, and routing cables through the rack. The rack can be

installed using the recommended tools.

Before attempting this installation, you should read through this entire

procedure carefully.

6Installation Guide

Rack Specifications

CAUTION: The rack meets the specifications of American National Standards

Institute (ANSI), Consumer Electronics Association (CEA) Standard EIA/CEA-310-E,

International Electrotechnical Commission (IEC) 60297-3-100, and Deutsche Industrie

Norm (DIN) 41494.

Before You Begin

WARNING: Before you begin installing your rack, carefully read "Important

Safety Information," as well as the safety instructions that came with the rack.

WARNING: When installing multiple systems in a rack, complete all of the

procedures for the current system before attempting to install the next system.

WARNING: Rack cabinets can be extremely heavy and move easily on the

casters. The cabinet has no brakes. Use extreme caution while moving the rack

cabinet. Retract the leveling feet when relocating the rack cabinet. Avoid long or

steep inclines, rough surfaces, or ramps where loss of cabinet control may occur.

Extend the leveling feet for support and to prevent the cabinet from rolling.

WARNING: Avoid rolling the rack cabinet over rough surfaces. Hard impacts to

the casters could cause them to break, and the rack could become unstable and

may tip over.

WARNING: Do not attempt to move your rack with components installed.If you

move a fully loaded rack on a slightly uneven surface, the rack may become

unstable and may tip over.

Important Safety Information

Observe the safety precautions in the following subsections when installing

your system in the rack.

WARNING: You must strictly follow the procedures in this document to protect

yourself as well as others who may be involved. Your system may be very large

and heavy, and proper preparation and planning are important to prevent injury

to yourself and to others. This becomes increasingly important when systems

are installed high up in the rack.

Installation Guide 7

Rack Stabilizer Feet

WARNING: Before installing systems in a rack, install front and side stabilizers

on stand-alone racks or the front stabilizer on racks joined to other racks.

Failure to install stabilizers accordingly before installing systems in a rack

could cause the rack to tip over, potentially resulting in bodily injury under certain

circumstances. Therefore, always install the stabilizer(s) before installing

components in the rack.

WARNING: After installing systems in a rack, never pull more than one system

out of the rack on its slide assemblies at one time. The weight of more than one

extended system could cause the rack to tip over and cause injury.

The stabilizer feet help prevent the rack from tipping over when a system

or other component is pulled out of the rack with the slide assemblies

fully extended.

Installation Tasks

Installing a rack cabinet involves the following tasks:

Removing and replacing the rack doors

Removing and replacing the side panels

Reversing the front door and badge (optional)

Securing the leveling feet

Installing the stabilizer feet

Adjusting the rack posts (optional)

Routing cables through the rack

Coupling two racks (optional)

Recommended Tools and Supplies

You may need the following tools and supplies to install the rack:

• #2 Phillips screwdriver

• Flat head screwdriver

• 12-mm wrench

8Installation Guide

• Needle-nose pliers

• 4-mm Allen wrench (if you want to reverse the direction that

the front door opens)

• Keys to the rack doors and side panels

• 13-mm wrench (for rack removal from pallet)

• 17-mm wrench (for rack removal from pallet)

Removing and Replacing the Rack Doors

WARNING: Because of the size and weight of the rack cabinet doors,

never attempt to remove or install them by yourself.

WARNING: When storing the doors, lay the doors flat so they do not fall over

and accidentally injure someone.

Removing the Front Door

Pull the door latch and open the front door all the way (see Figure 1-1).

While holding the door, pull the hinge pin upward so that it clears the

door’s hinge-pin housing (see Figure 1-1).

The hinge pin’s retention clip prevents the hinge from being pulled out of

the hinge body.
