Dell™ 2200MP Projector User's Guide
The information below is provided by the supplier of the referenced device without independent verification by Dell
and is subject to the restrictions and disclaimers.
Safety Instructions (Read before connecting the projector)
About Your Projector
Installation
Using Your Projector
Troubleshooting
Specifications
Regulatory Notices
Contacting Dell
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your projector.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to
avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
Information in this document is subject to change without notice.
©2003 Coretronic Corporation.
©2003 Dell Inc.. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP and Texas Instruments are
trademarks of Texas Instruments Corporation; Microsoft and Windows are registered trademarks of Microsoft
Corporation; Macintosh is a registered trademark of Apple Computer, Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names
other than its own.
Restrictions and Disclaimers
The information contained in this document, including all instructions, cautions, and regulatory approvals and
certifications, is based upon statements provided to Dell by the manufacturer and has not been independently
verified or tested by Dell. Dell disclaims all liability in connection with any deficiencies in such information.
All statements or claims regarding the properties, capabilities, speeds, or qualifications of the part referenced in
this document are made by the manufacturer and not by Dell. Dell specifically disclaims any knowledge of the
accuracy, completeness, or substantiation for any such statements.
October 2003 Rev. A00
Back to Contents Page
Safety Instructions: Dell™ 2200MP Projector
CAUTION
Use the following safety guidelines to help protect your projector from potential damage and to ensure your
own personal safety:
The surface beneath the projector might be hot with use. Be careful in handling the unit.
The lamp becomes very hot with use. Do not attempt to replace the lamp after use until the projector
has been allowed to cool down for at least 30 minutes, and follow all instructions in "Changing the
Lamp."
Do not touch the bulb or the lamp glass at any time. The bulb may explode due to improper handling,
including the touching of the bulb or the lamp glass.
Remove lens cap before turning on projector. Failure to do so may cause the lens cap to reach high
temperatures.
To avoid damaging the projector and lamp, allow the cooling fan to run for 2 minutes before turning
off the projector.
Do not block the ventilation slots and openings on the projector.
Disconnect the power cord from the electrical outlet if the projector is not used for a long period of
time.
Do not use the projector in an extremely hot, cold, or humid environment.
Do not use the projector in areas susceptible to excessive dust and dirt.
Do not use the projector near any appliance that generates a strong magnetic field.
Do not place the projector in direct sunlight.
Do not look into the lens while the projector is on; the bright light may hurt your eyes.
To reduce the risk of fire or electric shock, do not expose the projector to rain or moisture.
To prevent electric shock, do not open or disassemble the projector further than what is needed for
lamp replacement.
To avoid damaging the projector, ensure that the zoom lens and elevator foot are fully retracted
before moving the projector or placing the projector in its carrying case.
Turn off the projector and disconnect it from the electrical outlet before cleaning it. Use a soft cloth
moistened with mild detergent to clean the display housing. Do not use abrasive cleaners, waxes, or
solvents.
Back to Contents Page
Back to Contents Page
About Your Projector: Dell™ 2200MP Projector
Features
Equipment
Main Unit
Control Panel
Connection Ports
Remote Control
Features
Single chip 0.55" Texas Instruments DLP™ technology
High contrast, double data rate (DDR) digital micromirror device
True SVGA, 800 x 600 addressable pixels
4.7 lbs (2.14 kgs) lightweight compact design
1200 ANSI lumens brightness (Max)*
1700:1 full on / full off contrast ratio
1.2x manual zoom lens
Built in 2W speaker
Auto image re-sizing (Auto-Sync) to 800 x 600 full screen with scaling compression compatibility for
SXGA+,SXGA, XGA, SVGA, VGA, MAC
Preset and user defined video modes for optimum video and graphic settings
Self-diagnostic for video troubleshooting
State-of-the-art motion adaptive hardware deinterlacing with 3:2 and 2:2 pull down
200-watt, user-replaceable lamp
Compatibility with Macintosh® computers
Compatibility with NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, and HDTV (1080i, 720P, 576i/P,
480i/P)
Multi-function remote control
D-Sub 15-pin cable for analog video connectivity
High-definition TV compatibility
User-friendly, multi-language on-screen display (OSD)
Advanced electronic keystone correction
User-friendly control panel with backlight
Carrying case included
*Based on ANSI/NAPM IT7.228-1997 tests of 100 units, October 2003, with average ANSI Lumens 1152. Bulb
brightness degrades with usage. Dell recommends replacing your bulb after 2000 hours usage.
Equipment
Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell if
anything is missing.
Main unit 3.0m Power cord 1.8m VGA cable
(D-sub to D-sub)
2.0m S-video cable 1.8m USB cable
1.8m Composite Video cable
1.8m D-sub to YPbPr cable 1.8m RCA to Audio cable 1.8m mini pin to mini pin cable
Remote control
Dell 2200MP Projector
User's Guide Dell 2200MP Projector Quick Start
Card
Warranty Guide Owner's Manual Carrying case
Batteries (2)
Main Unit
1Control panel
2Zoom tab
3Focus ring
4 Lens
5Elevator button
6Remote control receiver
Control Panel
1Power button
2Four directional keys
3Keystone adjustment
4Temperature warning light
5Lamp warning light
6 Resync
7 Menu
8Keystone adjustment
9 Source
Connection Ports
1VGA in (D-sub) connector
2VGA out (monitor loop-through)
3IR receiver
4USB connector
5S-video connector
6Composite video connector
7Audio input connector
Remote Control
1Light
2Power button
3Previous Page button (page up)
4Four Direction buttons
5Source button
6Resync button
7Keystone Correction button
8Volume button
9Hide button
10 4:3/16:9 (aspect ratio) button
11 Menu button
12 Next Page button (page down)
13 Video Mode button
Battery Disposal: Your projector remote control uses zinc-manganese batteries. If you
need to replace the batteries, see your Dell 2200MP Projector Quick Start Card.
Do not dispose of used batteries along with household waste. Contact your local waste
disposal agency for the address of the nearest battery deposit site.
Back to Contents Page
Back to Contents Page
Installation: Dell™ 2200MP Projector
Connecting the Projector
Powering On/Off the Projector
Adjusting the Projected Image
Changing the Lamp
Connecting the Projector
A. To Computer
1Power cord
2D-sub to D-sub cable
3USB to USB cable
B. To DVD Player: There are three possible methods of connecting to a DVD player.
1. Connecting with component cable:
1Power cord
2D-sub to HDTV/Component cable
2. Connecting with S-video cable:
1Power cord
2S-video cable
3. Connecting with composite cable:
