DELL™C 5100
TONER CARTRIDGE REMANUFACTURING INSTRUCTIONS
DELL C 5100
LASER PRINTER
TONER CARTRIDGE
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •[email protected]
DELL C 5100 TONER CARTRIDGE REMOVING THE GEARLESS END CAP
1. Remove the gearless end cap (shown) to access the toner
fill cap. Using a small flathead screwdriver, carefully push out
one side of the end cap (shown) to unlock it from the first set
of tabs.
2. Rotate the cartridge and disengage the third tab (shown) in
the same manner.
3. Disengage the fourth tab as shown.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •[email protected]
4. Carefully slide out the gearless end cap. NOTE: Note the
original positioning (shown) for reassembly.
REMOVING THE TONER FILL PLUG
5. Carefully insert a small flathead screwdriver between the
base of the toner fill plug and its housing as shown.
6. Carefully lift the toner fill plug out as shown. Be careful not
to damage the plastic housing.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
7. Toner fill plug removed. Note the original positioning of the
plug for reassembly.
SEPARATING THE TONER CARTRIDGE
8. Locate the gear side of the cartridge shown. Holding the
gear end cap, remove the outer jacket (highlighted) of the car-
tridge by sliding it out as shown.
9. Cartridge separated. Note the original positioning of the
outer container. Clean thoroughly using compressed air.
ALTERNATE CLEARSEAL™ASSEMBLY
10. First, using a pair of pliers, gently peel off the worn sealant
(shown) from the toner cartridge.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
OUTER CONTAINER
(SLIDES OUT)
GEARSIDE
END CAP
11. Wipe the seal opening and surroundings clean using iso-
propyl alcohol and a lint free cloth.
INSTALLING THE CLEARSEAL™ADHESIVE
12. Make sure that the new seal is being placed in its proper
position (shown) before applying.
NOTE: Optional UniNet Clear Seal™universal adhesive for use
in Dell C 5100 OEM BK/C/M/Y toner cartridges (UniNet part
#10353).
13. Remove the adhesive backing of the Clearseal™and care-
fully place over the opening as shown. Apply pressure using
your fingers to ensure a tight seal.
14. gently wrap the seal flap around the toner fill opening (as
shown) while you prepare to insert the cartridge. This will
ensure that the seal flap properly exits the opposite end of the
container.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
INSTALLING THE CARTRIDGE
15. Slide the cartridge into the container as indicated.
16. Continue until it is completely inserted.
17. Final result. You are now ready to fill the cartridge. REFILLING THE TONER CARTRIDGE
18. Place the cartridge in a vertical position and refill with the
appropriate amount of toner and install the fill plug.
NOTE: Additional carrier may be required for this cartridge.
Consult your afermarket reseller for more details.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
INSTALLING THE GEARLESS END CAP 19. First, wrap the remaining seal around the toner fill plug as
shown.
20. Place the gearless end cap, in its original positioning, over
the seal and toner fill plug as shown.
Make sure that the remaining seal flap is showing through as
shown.
21. Push the end cap inward until it latches onto the four lock-
ing tab mechanisms. Make sure all four tabs are properly
secured.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
REPLACING THE OEM CHIP
22. Locate the OEM chip housing near the gearless side of the
cartridge.
23. Using a small flathead screwdriver, press down on the tabs
(shown on either side) to release the chip housing.
24. Always wear latex gloves when handing chips. 25. Unlock the actual chip from its housing by pressing the
tabs (shown) using an angled hook tool.
UNINET IMAGING INC. •BROTHER 1240/1650 •ASSEMBLING THE TONER CARTRIDGEUNINET IMAGING INC. •BROTHER 1240/1650 •DISASSEMBLING THE TONER CARTRIDGE
UNINET IMAGING INC. •DELL C 5100 CARTRIDGE REMANUFACTURING INSTRUCTIONS
© 2008 UniNet Imaging Inc. All Trademark names are property of their respective owners. Product brand names mentioned are intended to show compatibility only.
UniNet Imaging does not warrant downloaded information. Summit Technologies is a division of UniNet Imaging Inc.
www.uninetimaging.com
USA •UK •EUROPE •AFRICA •JAPAN •CHINA •BRAZIL •MEXICO •COLOMBIA •ARGENTINA •VENEZUELA
11124 Washington Blvd., Culver City, CA, U.S.A. 90232 •Ph +1 310 280 9620 •Fx +1 310 838 7294 •techsuppor[email protected]
26. Carefully lift the chip from its housing. INSTALLING THE NEW CHIP
27. Place the new contact chip on the cartridge in the manner
shown.
28. Place the housing over the chip as shown. 29. Press down until the tabs lock it into place.
