Dell™E1911 monitor User's Guide

Notes,Cautions,Warnings



Information in this document is subject to change without notice.

©2010DellInc.Allrightsreserved.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo aretrademarksofDellInc;Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in

theUnitedStatesand/orothercountries;Adobe is a trademark of Adobe Systems Incorporated, which may be registered in certain jurisdictions.ENERGYSTAR is a registered

trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR partner, Dell Inc. has determined that this product meets the ENERGY STAR guidelines for energy

efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any

proprietary interest in trademarks and trade names other than its own.

Model E1911f/E1911c

August 2010 Rev.A00

About Your Monitor

Setting Up Your Monitor

Operating Your Monitor

Troubleshooting

Appendix



NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Great user manuals database on UserManuals.info

Back to Contents Page



About Your Monitor

Dell™E1911 monitor User's Guide

Package Contents

Your monitor ships with the components shown below. Ensure that you have received all the components and contact Dell if something is missing.



Package Contents

Product Features

Identifying Parts and Controls

Monitor Specifications

Plug and Play Capability

LCD Monitor Quality and Pixel Policy

Maintenance Guidelines

NOTE: Some items may be optional and may not ship with your Monitor. Some features or media may not

be available in certain countries.



lMonitor

lStand base

lPower Cable

lVGA Cable

Great user manuals database on UserManuals.info



Product Features

The Dell™ E1911 display has an active matrix, thin-film transistor (TFT), liquid crystal display (LCD). The monitor features include:

■48.26 cm (19 inches) viewable area display.

■1440x900 resolution, plus full-screen support for lower resolutions.

■Wide viewing angle to allow viewing from a sitting or standing position, or while moving from side-to-side.

■Tilt adjustment capabilities.

■Removable pedestal and Video Electronics Standards Association (VESA®) 100 mm mounting holes for flexible mounting solutions.

■Plug and play capability if supported by your system.

■On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.

■Software and documentation media which includes an information file (INF), Image Color Matching file (ICM), and product documentation.

■Energy Saver feature for Energy Star®compliance.

■Security lock slot.

■EPEAT™GOLDcompliant.

■Halogen reduced.

■Asset Management Capability.

■PowerNap Software included (comes in the CD attached with the monitor).

Identifying Parts and Controls

Front View

lDVI Cable

lDrivers and Documentation media

lQuick Setup Guide

lSafety Information

Front View

Front Panel Controls

Great user manuals database on UserManuals.info

Back View



Side View





Bottom View

Label

Description

Function buttons (For more information, see

Operating the Monitor)

Power On/Off button (with LED indicator)

Back View

Back View with Monitor Stand

Label

Description

Use

Barcode serial number label

To contact Dell for technical support.

Security lock slot

To help secure your monitor.

Dell Soundbar mounting brackets

To attach the optional Dell Soundbar.

Regulatory rating label

Lists the regulatory approvals.

VESA mounting holes (100mm)

(Behind attached base plate)

To mount the monitor.

LeftView

Great user manuals database on UserManuals.info



Bottom View

Label

Description

AC power cord connector

DVI connector

VGA connector

Monitor Specifications

Flat Panel Specifications

*[E1911] color gamut (typical) is based on CIE1976 (80%) and CIE1931 (72%) test standards.

Model

Dell E1911 monitor

Screen type

Active matrix -TFT LCD

Panel type

Screen dimensions

19 inches (19-inch viewable image size)

Preset display area

408.24 (H) X 255.15 (V)

Horizontal

408.24 mm (16.08 inches)

Vertical

255.15 mm (10.05 inches)

Pixel pitch

0.2835 mm

Viewing angle

160°(vertical)typical,160°(horizontal)

typical

Luminance output

250 cd/m²(typical)

Contrast ratio

1000 to 1 (typical)

Faceplate coating

Antiglare with hard-coating 3H

Backlight

CCFL (2) edgelight system

Response Time

5 ms typical

Color depth

16.7 millions colors

Color Gamut

80% CIE1976 (typical)*

Great user manuals database on UserManuals.info

Resolution Specifications

Supported Video Modes

Model

Dell E1911 monitor

Horizontal scan range

30 kHz to 83 kHz (automatic)

Vertical scan range

56Hzto75Hz(automatic)

Maximum preset resolution

1440 X 900 at 60 Hz

Video display

capabilities (DVI

playback)

480i/480p/576i/576p/720p/1080i/1080P (Supports

HDCP)

Preset Display Modes

Display Mode

Horizontal Frequency

(kHz)

Vertical Frequency

(Hz)

Pixel Clock (MHz)

Sync Polarity

(Horizontal/Vertical)

VESA, 720 x 400

31.5

70.1

28.3

-/+

VESA, 640 x 480

31.5

59.9

25.2

-/-

VESA, 640 x 480

37.5

75.0

31.5

-/-

VESA, 800 x 600

37.9

60.3

40.0

+/+

VESA, 800 x 600

46.9

75.0

49.5

+/+

VESA, 1024 x 768

48.4

60.0

65.0

-/-

VESA, 1024 x 768

60.0

75.0

78.8

+/+

VESA, 1152 x 864

67.5

75.0

108.0

+/+

VESA, 1280 x 800

49.7

59.8

83.5

-/+

VESA, 1280 x 1024

64.0

60.0

108.0

+/+

VESA, 1280 x 1024

80.0

75.0

135.0

+/+

Great user manuals database on UserManuals.info

VESA, 1440 x 900 -Analog

55.9

59.9

106.5

-/+

VESA,1440x900(CTV-R) -Digital

55.5

59.9

88.8

+/-

Electrical Specifications



Video input signals

Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance

Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input

impedance

Synchronization input signals

Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG

(Composite SYNC on green)

AC input

voltage/frequency/current

100 to 240 VAC/50 or 60 Hz +3 Hz/1.5A (Max.)

Inrush current

120 V: 30 A (Max.)

240 V: 60 A (Max.)

Physical Characteristics

Model

Dell E1911 monitor

Connector type

15-pin D-subminiature, blue connector; DVI-

D, white connector

Signal cable type

Digital: Detachable, DVI-D, Solid pins,

shipped detached from the monitor

Analog: Detachable, D-Sub, 15pins, shipped

attached to the monitor

Dimensions (with stand)

Height

363.75 mm (14.32 inches)

Width

442.95 mm (17.44 inches)

Depth

155.75 mm (6.13 inches)

Dimensions (without stand)

Height

289.45 mm (11.40 inches)

Width

442.95 mm (17.44 inches)

Depth

59.00 mm (2.32 inches)

Stand dimensions

Height

125.3 mm (4.93 inches)

Width

249.86 mm (9.84 inches)

Great user manuals database on UserManuals.info

Depth

155.75 mm (6.13 inches)

Weight

Weight with packaging

5.52 kg (12.17 lbs)

Weight with stand assembly and

cables

4.59 kg (10.12 lbs)

Weight without stand assembly

(For wall mount or VESA mount

considerations -no cables)

3.45 kg (7.60 lbs)

Weight of stand assembly

0.70 kg (1.54 lbs)

Environmental Characteristics

Temperature



Operating

0°to50°C(32°to122°F)

Non-operating

Storage: -20°to60°C(-4°to140°F)

Shipping: -20°to60°C(-4°to140°F)

Humidity



Operating

10% to 80% (non-condensing)

Non-operating

Storage: 5% to 90% (non-condensing)

Shipping: 5% to 90% (non-condensing)

Altitude



Operating

4,850 m (15,913 ft) max

Non-operating

12,192 m (40,000 ft) max

Thermal dissipation

85.3 BTU/hour (maximum)

58.0 BTU/hour (typical)

Great user manuals database on UserManuals.info

Power Management Modes

IfyouhaveVESA'sDPM™compliancedisplaycardorsoftwareinstalledinyourPC,themonitorcanautomaticallyreduceitspowerconsumptionwhennotinuse.Thisis

referred to as Power Save Mode

*. If the computer detects input from keyboard, mouse, or other input devices, the monitor automatically resumes functioning. The

following table shows the power consumption and signaling of this automatic power saving feature:

VESA Modes

Horizontal Sync

Vertical Sync

Video

Power Indicator

Power Consumption

Normal operation

Active

Blue

25 W (maximum)

Normal operation

Active

Blue

17 W (typical)

Great user manuals database on UserManuals.info

Back to Contents Page



Appendix

Dell™E1911 monitor User's Guide

Safety Instructions

FCC Notice (U.S. Only) and Other Regulatory Information

Contacting Dell





WARNING: Safety Instructions

For information on safety instructions, see the Product Information Guide.

FCC Notices (U.S. Only) and Other Regulatory Information

For FCC notices and other regulatory information, see the regulatory compliance website located at www.dell.com\regulatory_compliance.

Contacting Dell

For customers in the United States, call 800-WWW-DELL (800-999-3355).

Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be

available in your area. To contact Dell for sales, technical support, or customer service issues:



Back to Contents Page

WARNING: Use of controls, adjustments, or procedures other than those specified in this documentation may result in exposure to shock,

electrical hazards, and/or mechanical hazards.

NOTE: If you do not have an active Internet connection, you can find contact information on your purchase invoice, packing slip, bill, or

Dell product catalog.

Visit support.dell.com.

Verify your country or region in the Choose A Country/Region drop-downmenuatthebottomofthepage.

Click Contact Us on the left side of the page.

Select the appropriate service or support link based on your need.

Choose the method of contacting Dell that is convenient for you.
