Dell™ OptiPlex™ 320

Quick Reference Guide

Models DCSM, DCNE

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your computer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the

problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

If you purchased a Dell™ n Series computer, any references in this document to Microsoft

Windows

operating systems are not applicable.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell, OptiPlex, and the DELL logo are trademarks of Dell Inc.; Microsoft and Windows are registered trademarks

of Microsoft Corporation; Intel and Pentium are registered trademarks of Intel Corporation.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Models DCSM, DCNE

September 2006 P/N GK385 Rev. A01

Contents 3

Contents

Finding Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setting Up Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

System Views . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Mini Tower Computer — Front View . . . . . . . . . . . . . . . . . . . . 11

Mini Tower Computer — Back View . . . . . . . . . . . . . . . . . . . . 13

Mini Tower Computer — Back-Panel Connectors . . . . . . . . . . . . . 14

Desktop Computer — Front View. . . . . . . . . . . . . . . . . . . . . . 16

Desktop Computer — Back View. . . . . . . . . . . . . . . . . . . . . . 17

Desktop Computer — Back-Panel Connectors . . . . . . . . . . . . . . 18

Removing the Computer Cover. . . . . . . . . . . . . . . . . . . . . . . . . . 20

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Mini Tower Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Desktop Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Inside Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Mini Tower Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Desktop Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Dell Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

System Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Diagnostic Lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Beep Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Resolving Software and Hardware Incompatibilities . . . . . . . . . . . 38

Using Microsoft Windows XP System Restore . . . . . . . . . . . . . . . 38

Reinstalling Microsoft Windows XP . . . . . . . . . . . . . . . . . . . . 39

Using the Drivers and Utilities CD. . . . . . . . . . . . . . . . . . . . . . . . 42

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

4Contents

Quick Reference Guide 5

Finding Information

NOTE: Some features or media may be optional and may not ship with your computer. Some features or media may

not be available in certain countries.

NOTE: Additional information may ship with your computer.

What Are You Looking For? Find It Here

• A diagnostic program for my computer

• Drivers for my computer

• My computer documentation

• My device documentation

• Desktop System Software (DSS)

Drivers and Utilities CD (also known as ResourceCD)

NOTE: The Drivers and Utilities CD may be optional and may

not ship with your computer.

Documentation and drivers are already installed on your

computer. You can use the CD to reinstall drivers (see

"Reinstalling Drivers and Utilities" in your online User’s

Guide), to run the Dell Diagnostics (see "Dell Diagnostics"

on page 30), or to access your documentation.

Readme files may be

included on your CD to

provide the most current

updates about technical

changes to your computer

or advanced technical-

reference material for

technicians or experienced

users.

NOTE: Drivers and documentation updates can be found at

support.dell.com.

• Warranty information

• Terms and Conditions (U.S. only)

• Safety instructions

• Regulatory information

• Ergonomics information

• End User License Agreement

Dell™ Product Information Guide

6Quick Reference Guide

• How to remove and replace parts

• Specifications

• How to configure system settings

• How to troubleshoot and solve problems

Dell™ OptiPlex™ User’s Guide

Microsoft Windows XP Help and Support Center

Click

Start

→

Help and Support

→

Dell User and System

Guides

→

System Guides

Click the

User’s Guide

for your computer.

The User’s Guide is also available on the optional Drivers

and Utilities CD.

• Service Tag and Express Service Code

• Microsoft Windows License Label

Service Tag and Microsoft

Windows

License

These labels are located on your computer.

• Use the Service Tag to

identify your computer

when you use

support.dell.com

contact support.

• Enter the Express

Service Code to direct

your call when

contacting support.

• How to reinstall my operating system

Operating System CD

NOTE: The Operating System CD may be optional and may

not ship with your computer.

The operating system is already installed on your computer.

To reinstall your operating system, use the Operating

System CD. See "Reinstalling Microsoft Windows XP" on

page 39.

After you reinstall your

operating system, you can

use the optional Drivers

and Utilities CD

(ResourceCD)to reinstall

drivers for the devices that

came with your computer.

Your operating system

product key label is located

on your computer.

NOTE: The color of your CD varies based on the operating

system you ordered.

What Are You Looking For? Find It Here

Quick Reference Guide 7

• Solutions — Troubleshooting hints and tips, articles from

technicians, frequently asked questions, and online

courses

• Community — Online discussion with other Dell

customers

• Upgrades — Upgrade information for components, such

as memory, the hard drive, and the operating system

• Customer Care — Contact information, service call and

order status, warranty, and repair information

• Service and support — Service call status and support

history, service contract, online discussions with technical

support

• Reference — Computer documentation, details on my

computer configuration, product specifications, and white

papers

• Downloads — Certified drivers, patches, and software

updates

• Desktop System Software (DSS) — If you reinstall the

operating system for your computer, you should also

reinstall the DSS utility. DSS provides critical updates for

your operating system and support for Dell™ 3.5-inch

USB floppy drives, Intel

processors, optical drives, and

USB devices. DSS is necessary for correct operation of

your Dell computer. The software automatically detects

your computer and operating system and installs the

updates appropriate for your configuration.

Dell Support Website — support.dell.com

NOTE: Select your region or business segment to view the

appropriate support site.

To download Desktop System Software:

Go to

support.dell.com

, select your region or business

segment, and enter your Service Tag.

Select

Drivers & Downloads

and click

Click your operating system and search for the keyword

Desktop System Software

NOTE: The support.dell.com user interface may vary

dependent upon your selections.

• How to use Windows XP

• How to work with programs and files

• How to personalize my desktop

Windows Help and Support Center

Click

Start

→

Help and Support

Type a word or phrase that describes your problem and

click the arrow icon.

Click the topic that describes your problem.

Follow the instructions on the screen.

What Are You Looking For? Find It Here

8Quick Reference Guide

Setting Up Your Computer

CAUTION: Before performing any of the procedures in this section, follow the safety instructions in Product

Information Guide.

NOTICE: If your computer has an expansion card installed (such as a modem card), connect the appropriate cable

to the card, not to the connector on the back panel.

NOTICE: To help allow the computer to maintain proper operating temperature, ensure that you do not place the

computer too close to a wall or other storage compartment that might prevent air circulation around the chassis.

NOTE: Before you install any devices or software that did not ship with your computer, read the documentation

that came with the device or software, or contact the vendor to verify that the device or software is compatible

with your computer and operating system.

You must complete all the steps to properly set up your computer. See the appropriate figures that follow

the instructions.

NOTICE: Do not attempt to operate a PS/2 mouse and a USB mouse simultaneously.

Connect the keyboard and mouse.

NOTICE: Do not connect a modem cable to the network adapter connector. Voltage from telephone

communications can cause damage to the network adapter.

Set Up Your Keyboard and Mouse

Connect the modem or network cable.

Insert the network cable, not the telephone line, into the network connector. If you have an optional

modem, connect the telephone line to the modem.

Quick Reference Guide 9

Connect the monitor using

either

the white DVI cable

the blue VGA cable (

do not

connect both

cables).

Align and gently insert the monitor cable to avoid bending connector pins. Tighten the thumbscrews

on the cable connectors.

NOTE: Some monitors have the video connector underneath the back of the screen. See the documentation

that came with your monitor for its connector locations.

Set Up Your Monitor

Connect the speakers.

Connect power cables to the computer, monitor, and devices and connect the other ends of the power

cables to electrical outlets.

10 Quick Reference Guide

Power Connections

NOTICE: To avoid damaging a computer with a manual voltage-selection switch, set the switch for the voltage that

most closely matches the AC power available in your location.

NOTICE: In Japan, the voltage selection switch must be set to the 115-V position even though the AC power

available in Japan is 100 V.

Verify that the voltage selection switch is set correctly for your location.

Your computer has a manual voltage-selection switch. Computers with a voltage selection switch on

the back panel must be manually set to operate at the correct operating voltage.

Autres manuels pour OptiPlex 320

Table des matières

Langues :

Autres manuels Dell Enceinte

Dell

Dell Dell OptiPlex Micro Manuel utilisateur

Dell

Dell PowerEdge C6400 Manuel

Dell

Dell PowerEdge FX2 Manuel utilisateur

Dell

Dell DAE2-ATA Guide d'application

Dell

Dell PowerVault E04J Series Manuel utilisateur

Dell

Dell EMC PowerEdge MX7000 Guide de démarrage rapide

Dell

Dell PowerVault MD3200 Series Manuel utilisateur

Dell

Dell PowerVault MD3060e Series Manuel utilisateur

Dell

Dell PowerVault MD1200 Instructions d'utilisation

Dell

Dell PowerVault MD3060e Series Manuel de service

Dell

Dell PowerVault MD1000 Manuel technique

Dell

Dell External M1000e t Manuel utilisateur

Dell

Dell PowerVault MD1200 Manuel utilisateur

Dell

Dell PowerVault MD3060e Series Manuel de service

Dell

Dell PowerVault 114T Manuel du propriétaire

Dell

Dell PowerVault E03J Series Manuel utilisateur

Dell

Dell PowerVault 114x Manuel utilisateur

Dell

Dell PowerVault DL2000 Manuel

Dell

Dell SC400 Manuel utilisateur

Dell

Dell PowerVault MD3000 Guide rapide

Dell

Dell SC420F Manuel utilisateur

Dell

Dell EMC PowerEdge MX7000 Manuel utilisateur

Dell

Dell PowerVault MD3000 Manuel utilisateur

Dell

Dell PowerVault MD1120 Manuel utilisateur

Manuels Enceinte populaires d'autres marques

SilentiumPC

SilentiumPC Armis AR5 Manuel

Pulsar

Pulsar 17/TRP80/DSPR Manuel utilisateur

Thermaltake

Thermaltake V150 TG Manuel utilisateur

MSI

MSI MPG SEKIRA 500X Manuel utilisateur

Antec

Antec Dark fleet DF-10 Manuel utilisateur

Nexans

Nexans WTC05 Manuel utilisateur

Peavey

Peavey DS 1502 Manuel utilisateur

D-Link

D-Link ShareCenter Pro DNS-1550-04 Manuel utilisateur

Rosewill

Rosewill RX82-U(JBOD) Manuel utilisateur

QNAP

QNAP SAS JBOD CLI 1.0 Manuel utilisateur

GAMDIAS

GAMDIAS Talos P1 Manuel utilisateur

Auvs

Auvs KR615 Manuel utilisateur

Digitus

Digitus DA-71114 Manuel utilisateur

CommScope

CommScope FDH 3000 Manuel utilisateur

FS FHD-FWME4 Manuel utilisateur

JBL

JBL CS1215T Manuel utilisateur

Pulsar

Pulsar ARAD-S4 Manuel utilisateur

Pulsar

Pulsar AWO454 Manuel utilisateur
