Dell Wyse E class

Dell Wyse E class:

Aordable computing for education

Wyse

ContactStart Technical PrintModels Features

Introducing the Dell Wyse E class

Affordable computing for classrooms.

Everywhere.

Dell Wyse E class entry-level zero clients have been specifically created to

help schools and teaching professionals increase the ratio of efficient, flexible

and accessible Windows 7 desktops to pupils by maximizing the potential

of shared computing with Windows Multipoint Server 2011.

The result? A truly affordable alternative to the costly classroom PC. One

that’s easy to deploy, simple to set up and the only one in its class capable

of supporting USB peripherals such as webcams and flash drives.

The benefits for teaching professionals and their schools are dramatic, with

little or no management required; switch them on and they ‘just work’.

They’re cool running, compact and silent, and deliver rapid ‘pay-back’ on

pressured energy budgets with up to 90% reductions in energy consumption.

New Dell Wyse E02

Shared medium/large room

computing via Ethernet connections.

Dell Wyse E01

Shared table/small

room computing via

USB connections.

Meet the

family

ContactStart Technical PrintModels Features

Introducing the Dell Wyse C class zero clients cont.

All round benefits. For your students,

administrators and you.

• More desktops, for more students: Up to 20 students are able to access

a single host server running Windows Multipoint Server 2011 with no

drop in their learning experience

• Easy to use and add students: As a teacher you’ll appreciate the simple

plug-n-play nature of Dell Wyse E class zero clients. For additional

desktops all you do is plug one into the server, and your students can

• Lower operational costs: Schools only need to service and support

one host server per 20-seat workgroup*

. And, combined with the easy

set-up and management that’s built into Windows MultiPoint Server

2011, student desktop down-time and support issues are all significantly

reduced too

• Energy-efficient desktops: As Dell Wyse E class zero clients draw a

fraction of the power required to power full PC desktops, they’ll have a

dramatic effect on your energy budget as well helping to reduce your

carbon footprint too

* 20-seat workgroup is dependant on the configuration of the server.

 One Windows Multipoint server shares its operating system and

applications with up to 20 users at a time

 Features Dell Wyse E class zero clients, one per desktop and each

one linked by a USB or Ethernet cable

 Low cost, fast and simple to set up delivery of Windows desktops

ContactStart Technical PrintModels Features

Introducing

Windows MultiPoint Server 2011 & Dell Wyse E class

Quick conﬁguration guide

8 ~ 20 users

Intel CPU i5/i7

8 GB

500 GB

4 ~ 6 users

Intel CPU i5/i7

4 GB

250 GB

CPU

Memory

Intel HD Graphics 2000 or similar

ATI Radeon™ HD 4600 / 4770 / 5750 nVidia GeForce 8x,

9x Series / GT220,GT240

Hard drive

Software Microsoft Windows Multipoint Server 2011

Dell Wyse E01 and E02 Zero Client

Microsoft MultiPoint Server License

Microsoft MultiPoint CAL License per device

Zero client

Licenses

(Microsoft

Academic VL)

On board

PCI-Express

Card

Graphics

The Dell Wyse E class is packed with features that would put a classroom PC to shame.

Every Dell Wyse E class zero client boasts class-leading connectivity and functionality

within a compact, energy ecient footprint.

Just click on the icons below to discover more.

GreenConnectivity

ContactStart Technical PrintModels Features

Features Dell Wyse E class zero clients

Take a tour of the

Dell Wyse E class

Dell Wyse E01

Three External

USB 2.0 ports

Audio out: 1/8-inch

mini jack, 16 bit stereo

Audio in: 1/8-inch

mini jack, 8 bit stereo

microphone

External USB 2.0 port

VGA Video outputInput USB port

from server

10/100/1000 Base-T

Ethernet port

External USB 2.0 port

Audio out: 1/8-inch mini jack,

16 bit stereo

Audio in: 1/8-inch mini jack,

8 bit stereo microphone

External USB 2.0 port

Dell New Wyse E02

VGA Video output

ContactStart Technical PrintModels Features

Connectivity Dell Wyse E class zero clients

Continue tour

ContactStart Technical PrintModels Features

Desktop computing Without compromise

Start the tour again

That’s Dell Wyse

EarthSmart™computing

Through our EarthSmart Computing initiative

we are committed to helping organizations

implement a greener computing strategy – one

that delivers a more ecient and productive

computing experience for your users with a

positive eect on energy wastage, heat and

carbon emissions.

Green power

The Dell Wyse Xenith family packs a considerable

punch with their green credentials. From reduced

manufacturing impact and end-of-life recycling

waste, to as little as 7 watts energy consumption,

deploying Dell Wyse Xenith zero clients will

enable your organization to achieve a lighter

carbon footprint.

More information

Download carbon calculators, fact sheets

and white papers from here:

www.wyse.com/green

ContactStart PrintModels Features

Technical Dell Wyse E class zero clients

Technical

Find all you need about the new Dell Wyse E class technical speciﬁcations here.

If you have any further questions about your deployment, simply contact your

Dell Wyse representative.

Simply click the icons below.

E02 Technical

speciﬁcations

E01 Technical

speciﬁcations

ContactStart PrintModels Features

Technical specifications Dell Wyse E01

Technical

Server OS Windows MultiPoint Server 2011

I/O peripheral support One VGA (DB-15)

Four USB 2.0 ports (1 on left side, 3 on right side)

One Mic In / One Line Out

USB keyboard (not included)

USB mouse (not included)

Networking One USB in to connect to host computer (cable included)

Maximum distance between each Wyse E01 zero client and the host computer

is 5 meters (16 feet 5 inches)

Display Up to 1680 x 1050 @ 60Hz / 32bits or 1600 x 1200 @ 60Hz / 32bits

Audio Output: 1/8-inch mini jack, full 16 bit stereo

Input: 1/8-inch mini jack, 8 bit microphone

Physical characteristics Height: 21.5mm (0.85 inches)

Width: 132mm (5.20 inches)

Depth: 87mm (3.43 inches)

Shipping Weight 145g (0.32 lbs)

Audio Output: 1/8-inch mini jack, full 16 bit stereo

Input: 1/8-inch mini jack, 8 bit microphone

Physical characteristics Height: 1.38 inches (34mm)

Width: 6.94 inches (177mm)

Depth: 4.75 inches (121mm)

Shipping Weight 145g (0.32 lbs)

Power Worldwide auto-sensing 100-240 VAC, 50/60 Hz. power supply

Average power usage with device connected to 1 keyboard with 1 mouse

and 1 monitor: less than 3 Watts

Temperature Range Vertical position: 50° to 104° F (10° to 40° C)

Humidity 20% to 80% condensing

10% to 95% non-condensing

Safety certiﬁcations German EKI-ITB 2000, ISO 9241-3/-8

cULus 60950, TÜV-GS, EN 60950

FCC Class B, CE, C-Tick

WEEE, RoHS Compliant

Warranty 3 years limited hardware warranty

ContactStart PrintModels Features

Technical specifications Dell Wyse E02

Technical

Server OS Windows MultiPoint Server 2011

I/O peripheral support One VGA (DB-15)

Two USB 2.0 ports

One Mic In / One Line Out

USB keyboard (not included)

USB mouse (not included)

Networking 10/100/1000 Base-T Ethernet

Display Up to 1680 x 1050 @ 60Hz / 32bits or 1600 x 1200 @ 60Hz / 32bits

Audio Output: 1/8-inch mini jack, full 16 bit stereo

Input: 1/8-inch mini jack, 8 bit microphone

Physical characteristics Height: 98mm (3.86 inches)

Width: 98mm (3.86 inches)

Depth: 20mm (0.79 inches)

Shipping Weight 128g (0.28 lbs)

Audio Output: 1/8-inch mini jack, full 16 bit stereo

Input: 1/8-inch mini jack, 8 bit microphone

Physical characteristics Height: 98mm (3.86 inches)

Width: 98mm (3.86 inches)

Depth: 20mm (0.79 inches)

Shipping Weight 128g (0.28 lbs)

Power Worldwide auto-sensing 100-240 VAC, 50/60 Hz. power supply

Average power usage with device connected to 1 keyboard with 1 mouse

and 1 monitor: less than 3 Watts

Temperature Range Vertical position: 50° to 104° F (10° to 40° C)

Humidity 20% to 80% condensing

10% to 95% non-condensing

Safety certiﬁcations German EKI-ITB 2000, ISO 9241-3/-8

cULus 60950, TÜV-GS, EN 60950

FCC Class B, CE, C-Tick

WEEE, RoHS Compliant

Warranty 3 years limited hardware warranty
