optipLEx™330

tEchnicaL guiDEbook

insiDE thE optipLEx 330

VERSION 1.0

ovErviEw 3

Mini Tower Computer (MT) View 5

Desktop Computer (DT) View 6

MarkEting systEM configurations

Operating System, Chipset 7

Processor 8

Advanced System Manageability Modes, Deployment Mode Options 8

Memory 9

Drives and Removable Storage 10

System Board Connectors, Graphics/Video Controller 11

External Ports/Connectors 12

Communications – Network Adapter (NIC) 12

Communications – Modem 12

Audio and Speakers, Keyboard and Mouse, Security 13

Service and Support, Software 14

DEtaiLED EnginEEring spEcifications

System Dimensions (Physical) 15

System Board Connector Maximum Allowable Dimensions 15

System Level Environmental and Operating Conditions 16

Power 16

Audio 17

Communications – Network Adapter (NIC) 18

Graphics/Video Controller 20

Hard Drives 23

Optical Drives 27

BIOS Defaults 31

chassis EncLosurE anD vEntiLation rEquirEMEnts 32

rEguLatory coMpLiancE anD EnvironMEntaL

Acoustic Noise Emission Information 33

TABLE OF CONTENTS

VERSION 1.0 3

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

DELL

™optipLEx™330

The Dell OptiPlex 330 raises the bar in the entry-level desktop category by providing advanced features to suit

the needs of growing businesses. Conﬁguration options include two form factor choices, blazing-fast Intel Core™

2 Duo processors, an optional energy-ecient 80PLUS®power supply, and RAID 1 support. The OptiPlex 330 delivers

essential networking capabilities and enhanced performance. Simplify desktop computing with the OptiPlex 330.

powEr EfficiEncy

Productivity and power savings in a proven, reliable design. Dell Energy Smart is a unique

approach to energy-ecient computing which includes hardware and software, tools,

and partnerships.

•Dell factory-enabled Energy Smart software settings put your system into a low-energy sleep state after 15

minutes of inactivity. Remote power policy management software delivers even greater energy savings

• Ecient hardware includes Intel Core™ 2 Duo, 80PLUS®power supplies, ENERGY STAR®4.0 and EPEAT™

Gold conﬁgurations

• Ecient Dell BTX design and HyperCool™ thermal-management technology help save energy and boost reliability

• Dell’s online Energy Calculator is a unique tool which allows you to compare systems, features, and usage models

to optimize energy savings across Dell commercial client products

• Dell is working alongside industry leaders and standards organizations worldwide to help drive revolutionary change

sMart sEcurity

Strategic, comprehensive endpoint solutions for all types of businesses.

• Simple deterrents such as physical locks help prevent theft

• RAID 1 support helps keep data intact and accessible via real-time redundancy

• CompuTrace® tracking capability incorporated into the BIOS can help reduce data loss from theft

VERSION 1.0 4

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

SIMPLY PUT: DELL

™OPTIPLEX™330

Easy to ManagE.

EfficiEnt to own.

EssEntiaL rEMotE ManagEMEnt

Run your IT better and have greater control with ﬂexible hardware options and management

software. Dell Client Manager brings it all together in one management console, available as a

free download. Built-in, standards-based management helps ensure simplicity and interoperability.

• Widely installed ASF (Alert Standard Format) standards-based technology, which supports basic in- and out-of-band

hardware inventory, alerting, and power control

• Dell Client Manager Standard, available at no cost, integrates all components of Dell™ OpenManage™ into a single

remote console

DELL DEpLoyMEnt sErvicEs

Get IT Faster with custom image management, in-factory conﬁguration, and deployment made

simple. Dell's direct, steppingstone approach to customization helps ensure the best ﬁt for

your needs.

• Dell ImageDirect allows you to dynamically create, manage, and load your custom images to Dell client systems

• Advanced Conguration Services enable easy customization, at the point of sale

• Microsoft® Windows Vista® Assessment and Migration options help streamline and optimize your deployment processes

VERSION 1.0 5

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

Mini towEr coMputEr (Mt) viEw

SYSTEM BOARD COMPONENTS

1speaker connector (INT_SPKR)

2processor connector (CPU)

3processor power connector (12VPOWER)

4memory module connectors (DIMM_1, DIMM_2)

5SATA drive connectors (SATA0, SATA1)

6front-panel connector (FRONTPANEL)

7power connector (POWER)

8SATA drive connectors (SATA2, SATA3)

9RTC reset jumper (RTCRST)

10 password jumper (PSWD)

11 battery socket (BATTERY)

12 PCI Express x16 card connector (SLOT1)

13 PCI card connectors (SLOT2 and SLOT3)

14 internal buzzer (SPKR)

15 serial/PS/2 connector (PS2/SER2)

16 fan connector (FAN_CPU)

17 oppy drive connector (FLOPPY)

FRONT VIEW

1service tag

2optical drive

3ﬂoppy drive

4drive activity light

5USB 2.0 connectors (2)

6diagnostic lights

7power button

8headphone connector

9microphone connector

10 LAN indicator light

BACK VIEW

1cover-release latch

2padlock ring

3power connector

4voltage selector switch

5back panel connectors

6card slots

16 17

VERSION 1.0 6

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

DEsktop coMputEr (Dt) viEw

FRONT VIEW

1USB 2.0 connectors (2) 7LAN indicator light

2drive activity light 8headphone and microphone

connectors

3power button 9ﬂoppy drive

4Dell badge 10 optical drive

5power light 11 service tag

6diagnostic lights

BACK VIEW

1card slots

2back panel connectors

3power connector

4voltage selection switch

5padlock ring

6cover-release latch

92356

SYSTEM BOARD COMPONENTS

1speaker connector (INT_SPKR)

2processor connector (CPU)

3processor power connector (12VPOWER)

4memory module connectors (DIMM_1, DIMM_2)

5SATA drive connectors (SATA0, SATA1)

6front-panel connector (FRONTPANEL)

7power connector (POWER)

8SATA drive connectors (SATA2, SATA3)

9RTC reset jumper (RTCRST)

10 password jumper (PSWD)

11 battery socket (BATTERY)

12 PCI Express x16 card connector (SLOT1)

13 PCI card connectors (SLOT2 and SLOT3)

14 internal buzzer (SPKR)

15 serial/PS/2 connector (PS2/SER2)

16 fan connector (FAN_CPU)

17 oppy drive connector (FLOPPY)

VERSION 1.0 7

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

MT DT

Windows VistaOperating System Windows Vista® Ultimate, Windows Vista® Business,

Windows Vista® Home Basic

Windows XPOperating System Windows® XP Professional, Windows® XP Home Edition

Other FreeDOS (for n-series), Red Flag Linux (China only)

OS Media Support ✓ ✓

MarkEting systEM configurations

Oerings may vary by region. For more information regarding the conﬁguration of your computer, click "Start Help"

and "Support" and select the option to view information about your computer.

opErating systEM

One of the following Operating Systems will be preinstalled.

chipsEt

MT DT

Chipset Intel® G31 Express Chipset (ICH7R)

Non-volatile Memory on Chipset

BIOS Conguration FWH (rmware hub) 8 MB located at SP1_FLASH on chipset

TPM 1.2 Security Device (Trusted Platform Module)

NIC EEPROM 1 MB located at LOM_FLASH on chipset

VERSION 1.0 8

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

procEssor

Processor numbers are not a measure of performance.

PROCESSOR (SPEED, CACHE, FSB) MT DT

IntelCore™2 Duo with Intel, Enhanced Intel SpeedStep Technology, and Execute Disable Bit

Intel Core 2 Duo E7200 Processor (2.53GHz, 3MB L2 cache, 1066MHz FSB) ✓ ✓

Intel Core 2 Duo E6850 Processor (3.0 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓

Intel Core 2 Duo E6750 Processor (2.66 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓

Intel Core 2 Duo E6550 Processor (2.33 GHz, 4 MB L2 cache, 1333 MHz FSB) ✓ ✓

Intel Core 2 Duo E4700 Processor (2.6 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓

Intel Core 2 Duo E4600 Processor (2.4 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓

Intel Core 2 Duo E4500 Processor (2.2 GHz, 2 MB L2 cache, 800 MHz FSB) ✓ ✓

Intel Core 2 Duo E2220 Processor (2.4Hz, 1MB L2 cache, 800MHz FSB) ✓ ✓

Intel Core 2 Duo E2200 Processor (1.8GHz, 1MB L2 cache, 800MHz FSB) ✓ ✓

Intel Core 2 Duo E2180 Processor (2.0 GHz, 1 MB L2 cache, 800 MHz FSB) ✓ ✓

Intel Core 2 Duo E2160 Processor (1.8 GHz, 1 MB L2 cache, 800 MHz FSB) ✓ ✓

IntelCeleronwith Execute Disable Bit

Intel Celeron 440 Processor (2.0 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓

Intel Celeron 430 Processor (1.8 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓

Intel Celeron 420 Processor (1.6 GHz, 512 K L2 cache, 800 MHz FSB) ✓ ✓

aDvancED systEM ManagEabiLity MoDEs

MT DT

Basic Client Systems Management (w/ ASF) ✓ ✓

VERSION 1.0 9

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

MEMory

Your computer supports a maximum of 4 GB of memory when you use two 2 GB DIMMs.

Memory modules should be installed in pairs of matched memory size, speed, and technology. If the memory modules

are not installed in matched pairs, the computer will continue to operate, but with a slight reduction in performance.

MT DT

Type: DDR2 Synch DRAM Non-ECC Memory 667 MHz or 800 MHz speeds

DIMM Slots 2 2

DIMM Capacities Up to 2 GB Up to 2 GB

Minimum Memory 512 MB 512 MB

Maximum Memory with 667 MHz Speed Memory 2 GB 2 GB

Maximum Memory with 800 MHz Speed Memory 4 GB14 GB1

Conﬁgurations:

800 MHz Memory Conﬁgurations

4 GB DDR2 Non-ECC SDRAM, 800 MHz (2 DIMM) ✓ ✓

2 GB DDR2 Non-ECC SDRAM, 800 MHz (1 DIMM) ✓ ✓

2 GB DDR2 Non-ECC SDRAM, 800 MHz (2 DIMM) ✓ ✓

1 GB DDR2 Non-ECC SDRAM, 800 MHz (1 DIMM) ✓ ✓

667 MHz Memory Conﬁgurations

2 GB DDR2 Non-ECC SDRAM, 667 MHz (2 DIMM) ✓ ✓

2 GB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓

1 GB DDR2 Non-ECC SDRAM, 667 MHz (2 DIMM) ✓ ✓

1 GB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓

512 MB DDR2 Non-ECC SDRAM, 667 MHz (1 DIMM) ✓ ✓

1The total amount of available memory will be less, depending on actual system conﬁguration.

VERSION 1.0 10

DELL™ OPTIPLEX™ 330 TECHNICAL GUIDE

DrivEs anD rEMovabLE storagE

MT DT

Bays:

3.5-inch Bay (External Floppy) 1 1

5.25-inch Bay (External Optical) 2 1

Hard Drives Supported (Internal) 2

1 (Normal)

2 (Second HDD support,

mutually exclusive with oppy)

Optical Drives Supported (External) 2 1

Interface:

SATA (number of connectors) 4 4

Floppy/Diskette 1 1

Hard Drive: size, type, speed, RPM

80 GB SATA 10 K RPM HDD2✓ ✓

250 GB SATA 7200 RPM HDD2✓ ✓

160 GB SATA 7200 RPM HDD2✓ ✓

80 GB SATA 7200 RPM HDD2✓ ✓

RAID 1 Data Protection: (includes two matching capacity/speed hard drives)

80 GB SATA 10 K RPM HDD2✓ ✓

250 GB SATA 7200 RPM HDD2✓ ✓

160 GB SATA 7200 RPM HDD2✓ ✓

80 GB SATA 7200 RPM HDD2✓ ✓

Optical Drive:

DVD +/- RW 16x SATA 16x SATA

DVD-ROM 16x SATA 16x SATA

Combo Drive CD-RW 48x/32x/16x SATA 48x/32x/16x SATA

CD-ROM 48x SATA 48x SATA

Floppy Diskette Drive: (SFF requires a slimline ﬂoppy drive)

Floppy Drive 1.44 MB 1.44 MB

2 For hard drives, GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.

Autres manuels pour OptiPlex 330

Table des matières

Autres manuels Dell Ordinateur de bureau

Dell

Dell Precision 7865 Tower Manuel utilisateur

Dell

Dell OptiPlex 3000 Tower Manuel utilisateur

Dell

Dell Alienware 0JYTRGA00 Manuel utilisateur

Dell

Dell Precision 9T217 Manuel utilisateur

Dell

Dell OptiPlex 3070 Microo Manuel utilisateur

Dell

Dell Dimension 4550 Series Manuel utilisateur

Dell

Dell OptiPlex 380 Mini-Tower Manuel utilisateur

Dell

Dell Dimension 5150 Manuel utilisateur

Dell

Dell Precision Tower 3630 Manuel utilisateur

Dell

Dell Dimension 8458P Manuel utilisateur

Dell

Dell Inspiron 5676 Manuel d'exploitation et d'entretien

Dell

Dell Precision T3912 Manuel utilisateur

Dell

Dell Dimension E510 Manuel utilisateur

Dell

Dell OptiPlex 7470 All-in-One Manuel utilisateur

Dell

Dell OptiPlex GX60 Manuel utilisateur

Dell

Dell Inspiron 22 3000 SERIES Manuel d'exploitation et d'entretien

Dell

Dell OptiPlex E1 Manuel de l'opérateur

Dell

Dell OptiPlex FX160 Manuel utilisateur

Dell

Dell Precision R7610 Manuel utilisateur

Dell

Dell bpcwcsn_5 - OptiPlex - 740 Manuel utilisateur

Dell

Dell Dimension 0C0921A01 Manuel utilisateur

Dell

Dell POWEREDGE 1900 Manuel utilisateur

Dell

Dell OptiPlex 7450 Manuel utilisateur

Dell

Dell Studio XPS 8100 Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

HP Z1 Manuel utilisateur

Everex

Everex eXplora Manuel utilisateur

Lenovo

Lenovo ThinkCentre M75e Manuel utilisateur

Compaq

Compaq iPAQ Internet Device Manuel utilisateur
