Dell Inspiron 5680 Manuel d'exploitation et d'entretien

Inspiron Gaming Desktop

Setup and Specications

Computer Model: Inspiron 5680

Regulatory Model: D27M

Regulatory Type: D27M002

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make

better use of your product.

CAUTION: A CAUTION indicates either potential damage to hardware or

loss of data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be

trademarks of their respective owners.

2018 - 05

Rev. A01

Contents

Set up your computer................................................... 5

Create a USB recovery drive for Windows.....................9

Reinstall Windows using a USB recovery drive......................................... 9

Views............................................................................11

Front........................................................................................................11

Front (For computers shipped without optical drive).............................. 13

Back........................................................................................................15

Back panel...............................................................................................17

Specications.............................................................. 19

Computer model..................................................................................... 19

System information................................................................................. 19

Operating system....................................................................................19

Dimensions and weight........................................................................... 19

Memory..................................................................................................20

Intel Optane memory..............................................................................20

Ports and connectors..............................................................................21

Communications.....................................................................................22

Audio......................................................................................................22

Storage.................................................................................................. 22

Power ratings......................................................................................... 23

Video......................................................................................................23

Computer environment...........................................................................24

Intel Optane memory...................................................25

Enabling Intel Optane memory................................................................25

Disabling Intel Optane memory...............................................................25

Getting help and contacting Dell..................................27

Self-help resources................................................................................. 27

Contacting Dell.......................................................................................28

Set up your computer

1 Connect the keyboard and mouse.

NOTE: For setup instructions, see the documentation shipped with the

keyboard and mouse.

2 Connect the network cable—Optional.

3 Connect the display.

NOTE: Connect the display to the discrete graphics card shipped with

your computer.

4 Connect the power cable.

5 Press the power button.

6 Finish Windows setup.

Follow the on-screen instructions to complete the setup. When setting up, Dell

recommends that you:

– Connect to a network for Windows updates.

NOTE: If connecting to a secured wireless network, enter the

password for the wireless network access when prompted.

– If connected to the internet, sign-in with or create a Microsoft account. If

not connected to the internet, create an oine account.

– On the Support and Protection screen, enter your contact details.

7 Locate and use Dell apps from the Windows Start menu—Recommended

Table 1. Locate Dell apps

Dell Product Registration

Dell Help & Support

Access help and support for your computer.

SupportAssist

Proactively checks the health of your computer’s hardware and

software.

NOTE: Renew or upgrade your warranty by clicking the

warranty expiry date in SupportAssist.

Dell Update

Updates your computer with critical xes and important device

drivers as they become available.

Dell Digital Delivery

Download software applications including software that is

purchased but not pre-installed on your computer.

8 Create recovery drive for Windows.

NOTE: It is recommended to create a recovery drive to troubleshoot

and x problems that may occur with Windows.

For more information, see Create a USB recovery drive for Windows.

Create a USB recovery drive for

Windows

Create a recovery drive to troubleshoot and x problems that may occur with

Windows. An empty USB ash drive with a minimum capacity of 16 GB is required to

create the recovery drive.

NOTE: This process may take up to an hour to complete.

NOTE: The following steps may vary depending on the version of Windows

installed. Refer to the Microsoft support site for latest instructions.

1 Connect the USB ash drive to your computer.

2 In Windows search, type Recovery.

3 In the search results, click Create a recovery drive.

The User Account Control window is displayed.

4 Click Yes to continue.

The Recovery Drive window is displayed.

5 Select Back up system les to the recovery drive and click Next.

6 Select the USB ash drive and click Next.

A message appears, indicating that all data in the USB ash drive will be deleted.

7 Click Create.

8 Click Finish.

For more information about reinstalling Windows using the USB recovery drive,

see the Troubleshooting section of your product's Service Manual at

www.dell.com/support/manuals.

Reinstall Windows using a USB recovery drive

CAUTION: This process formats the hard drive and removes all data on your

computer. Ensure that you back up data on your computer before beginning

this task.

NOTE: Before reinstalling Windows, ensure your computer has more than 2

GB of memory and more than 32 GB of storage space.

NOTE: This process may take up to an hour to complete and your computer

will restart during the recovery process.

1 Connect the USB recovery drive to your computer.

2 Restart your computer.

3 Press F12 after the Dell logo is displayed on the screen to access the boot menu.

A Preparing one-time boot menu message appears.

4 After the boot menu loads, select the USB recovery device under UEFI BOOT.

The system reboots and a screen to Choose the keyboard layout is displayed.

5 Choose your keyboard layout.

6 In the Choose an option screen, click Troubleshoot.

7 Click Recover from a drive.

8 Choose one of the following options:

–Just remove my les to do a quick format.

–Fully clean the drive to do a complete format.

9 Click Recover to start the recovery process.
