Definitive Technology Mythos ST Manuel utilisateur

eﬁnitive’s CES 2007 new

product introduction is one

of the most important in our history.

With a landmark new addition to

our Mythos line as well as a new

entry-level system which redeﬁnes

incredible sound and affordable

price, Deﬁnitive is poised for

another exciting year.

New Mythos

ST SuperTower

with Built-in Powered SuperCube Subwoofer

The Mythos ST SuperTower, which has already been awarded the coveted

2007 CES Innovations Award for Design and Engineering Excellence, begins

with a sleek and sexy polished black or silver aluminum monocoque cabinet

mounted on a beautiful polished granite base. It contains extremely advanced

Deﬁnitive components and technologies that have been engineered to deliver

sonic performance truly in a class by itself. The Mythos’ trend setting concept

of form and function has dramatically evolved and goes considerably further

in the ST through the incorporation of high power built-in SuperCube

subwoofers right into the sleek aluminum cabinets.

Each Mythos ST contains a D’Appolito array consisting of two high-

deﬁnition Deﬁnitive Balanced Dual Surround System (BDSS) 5

"drivers (patent pending)

surrounding a new generation Deﬁnitive pure aluminum dome tweeter, which

incorporates a new voice coil, new dome, new surround and new special acoustically

contoured faceplate.

The subwoofer is built around a newly

designed Deﬁnitive racetrack-shaped carbon

ﬁber coned driver, which has a Finite

Element Magnetic Analysis optimized

magnet structure. This long-excursion,

very fast active driver is pressure-coupled to

two racetrack-shaped planar medite infrason-

ic radiators. This amazing subwoofer driver

array is powered by a built-in 300-watt

digital ampliﬁer. Low frequency performance

is exceptional and is basically similar to

Deﬁnitive’s award-winning SuperCube I.

Overall sonic performance is in a class

by itself especially when taking into account

the svelte proﬁle and remarkably affordable

price. Imaging and depth retrieval is simply

stunning. The STs, whether used in stereo

or as part of a multi-channel music or home

theater system, are capable of recreating a

three dimensional soundstage which is

breathtaking in terms of its ability to make

musicians and action come alive in the

listening room. The resolution of the

D’Appolito arrays with their newly designed

drivers combines ultimate clarity with a natural silky smoothness. And the soul-stirring

bass, which is produced by the dual subwoofers, is capable of earthshaking dynamics

as well as the most subtle and detailed musical nuances.

The Mythos STscan be combined with their matching center channel speaker

(Mythos Eight) and surrounds (Mythos Gem XLs) for an exceptional surround

system that, although not inexpensive, offers unmatched value.

SPECIFICATIONS:

Mythos ST: Dimensions: 51

"Hx9

"Dx6

"W. Frequency Response: 14 Hz –

30 kHz. Efficiency: 93 dB. Nominal Impedance: 4 – 8 ohms. Driver Complement: Two

"high-deﬁnition cast-magnesium basket polymer upper midrange drivers. One 1"

pure aluminum dome tweeter. One 6" x 10" long-throw racetrack subwoofer coupled to

two 6" x 10" long-throw racetrack radiators. Rec. Assoc. Ampl.: 20 – 350 watts/channel.

Built-In Subwoofer Power Ampliﬁer: 300-watt digitally-coupled Class D ampliﬁer.

The Mythos ST comes with a

gorgeous polished granite base.

Deﬁnitive Redeﬁnes Mythos

State-of-the-Art Performance for Your Lifestyle

Mythos ST SuperTowers areavailable in

both polished silver and gloss black ﬁnishes.

New high-deﬁnition drivers incorporate

our Balanced Double Surround System

(BDSS) technology (patent pending).

Mythos ST’s new generation tweeter

incorporates a new voice coil, a new

annealed dome, a new surround and a

special acoustically contoured faceplate.

The ST’s built-in subwoofer incorporates

Deﬁnitive’s new racetrack-shaped carbon

ﬁber coned driver coupled to two planar

medite infrasonic radiators.

New ProCinema System is an Affordable Miracle!

New ProCinema 600 Sub/Sat System

Deﬁnitive’s new ProCinema 600 System is our new entry-level

6-piece home theater system. Its surprisingly affordable price

belies its remarkable sophistication. The ProCinema 600 System

incorporates the same new technologies and advancements, including

BDSS drivers, pure aluminum dome tweeters, planar medite passive

radiators and a 250-watt SuperCube technology powered subwoofer,

which have made the new ProCinema 800 and 1000 systems instant

mega hits.

The satellites and center channel are available

in high-gloss hand-rubbed piano gloss black (with

matching black subwoofer) or gloss white. The satel-

lites can be shelf-mounted with their unique

tri-lobed base, wall-mounted using the built-in

keyhole mount or optional pivot mount or stand-

mounted with their optional ﬂoor stands. The

center channels have an adjustable foot for shelf-

mounting or can be wall-mounted using their

built-in threaded inserts.

Sonically, the new ProCinema 600 System

isarevelation in terms of achieving incredible

sound at an affordable price. Their imaging

is absolutely boxless, spacious and three-

dimensional while delivering

pinpoint speciﬁcity and

localization when called

for. They are velvety

smooth with a you-are-

there presence which is

unique at any price and

unheard of in this price

range. The 600 system

is dynamic but capable

of great subtlety so it

excels equally with

music or movies.

SPECIFICATIONS:

ProMonitor 600: Dimensions: 7" H x 4

"Dx4" W. Frequency

Response: 65 Hz – 30 kHz. Driver Complement: One 3

"bass/

midrange driver coupled to one 3

"pressure-driven planar low-

frequency radiator.One 1" pure aluminum dome tweeter.Rec. Assoc.

Ampl.: 10 – 150 watts/channel. Frequency Response: 65 Hz – 30 kHz.

ProCenter 600: Dimensions: 4" H x 4

Dx10

"W.Frequency Response: 55 Hz –

30 kHz. Driver Complement: Two 3

bass/ midrange drivers coupled to two 3

pressure-driven planar low-frequency radia-

tor. One 1" pure aluminum dome tweeter.

ProSub 600: Dimensions: 13" H x

13" D x 10

"W. Frequency Response:

22 Hz – 150 Hz. Driver Complement:

One 8" woofer with polymer cone, one

8" infrasonic radiator.Ampliﬁer: 250 watts

RMS. Speaker Level High-Pass Filter:

6dB/octave (100 Hz). High-Level Low-

Pass Filter: 24 dB/ octave continuously

variable (40 Hz – 150 Hz).

ProCinema 600

Mythos ST SuperTower’s Advanced Driver Technology
