Cube™

User Guide

Guide d’utilisation

WHAT`S IN THE BOX

CONTENU DE LA BOÎTE

Cube™

Users Guide

Guide d’utilisation

3.5mm analog

audio cable

Câble audio

analogique 3,5 mm

User guide

Guide d’utilisation

Power cord

Cordon d’alimentation

GETTING STARTED

GUIDE DE DÉMARRAGE

You don’t have to charge the battery, because

it works off of AC power. Just plug and play.

Fully charge your Cube

Plug the power cord into an AC outlet to fully charge the

battery. It takes about 3 hours to acquire a full charge.

Turn on your Cube

Press and hold the power button to turn on

your Cube.

Connect

Press and Hold the Bluetooth®button for 2 seconds

to enter pairing mode.

Enjoy!

Le Cube est prêt à utiliser sans charger la pile. Vous

n’avez qu’à le brancher dans une prise de courant CA.

Chargez le Cube à bloc

Branchez le cordon d’alimentation dans une prise CA

our charger la pile. Une charge complète prend environ

3 heures.

Allumez votre Cube

Appuyez le bouton d’alimentation et tenez enfoncé

pour allumer le Cube

Connexion

Lorsque l’appariement est réussi, la bague demeurera bleue.

Jouir de!

CONTROLS

CONTRÔLES FUNCTION

FONCTION

Power on/off

Press and hold to turn on

Press and hold to turn off

Allumer/éteindre

Appuyez et tenez enfoncé pour allumer

Volume +

Volume + one press, volume increases one increment.

Press and hold, volume increases until max volume is reached.

Volume +

Une simple pression sur + monte le volume d’un cran.

Une pression continue sur + monte le volume graduellement.

Volume --

Volume -- one press, volume decreases one increment.

Press and hold, volume increases until min volume is reached.

Volume --

Une simple pression sur – baisse le volume d’un cran.

Une pression continue sur – baisse le volume graduellement.

Bluetooth pairing

Press and hold for 2 seconds to pair

Appariement Bluetooth

Appuyez 2 secondes pour apparier

Play/pause

Press to play

Press to pause

Lecture/pause

Appuyez pour lecture

Appuyez pour pause

If your Bluetooth device is NFC

enabled, you can hold it close to

the Cube to pair and connect.

Si votre dispositif Bluetooth est doté

de la fonction NFC, tenez-le près

du Cube pour l’apparier.

CONNECT

CONNEXION

where to hold

your Bluetooth/

NFC device

1. Press and Hold the Bluetooth®button

for 2 seconds to enter pairing mode.

Appuyez sur le bouton Bluetooth pour

2 secondes pour lancer l’appariement.

2. Once pairing is successful the ring

will remain blue.

Lorsque l’appariement est réussi,

la bague demeurera bleue.

Connect directly using the

3.5mm stereo cable

3.5mm cable disables Bluetooth mode

Connexion du Cube utilisant

un câble stéréo 3,5 mm.

Le câble 3,5 mm désactive le mode Bluetooth

LED STATUS

ÉTAT DES DEL

Power On

Power button shines white to indicate power

is on. Blue LEDs turn on & fade in a sequential

circular pattern.

Allumé

Le bouton luit blanc lorsque le Cube est allumé.

Les DEL bleues pulsent en tournant.

Power Off

Blue LEDs turn off in a sequential circular pattern.

Éteint

Les DEL bleues s’éteignent en tournant.

Volume +/-

Single Press – Flashes once and is supplemented

by audible sound.

Press and hold – Flashes once per second until max/

min volume is reached; when max/min setting has

been reached, 3 ashes; the indicator is supplemented

by an audible sound.

Volume +/-

Simple pression: clignote une fois et émet

une tonalité.

Pression continue: clignote une fois par seconde

jusqu’à ce que le volume max./min. soit atteint

puis clignote 3 fois et émet une tonalité.

Battery Charging

Alternates between white and red when Cube is on.

Pulses red if Cube is off.

Recharge de la pile

Alterne blanc et rouge lorsque le Cube est allumé.

Pulse rouge lorsqu’il est éteint.

Low Battery

Flashes red.

Pile faible

Clignote rouge.

Full Charge

Power button LED returns to white if power is on.

Power button LED turns off when full charge

is reached if power is off.

Recharge complète

Le bouton

luit blanc si le Cube est allumé

Le bouton

s’éteint lorsque le Cube est chargé

à bloc et est éteint.

Bluetooth Pairing

PAIRING MODE

When in pairing mode, LEDs will turn on and fade out

until the Cube has paired with the Bluetooth device.

PAIRING SUCCESSFUL

Once paired the ring will be solid blue.

PAIRING FAILED

Flashes 5 times.

Appariement Bluetooth

MODE D’APPARIEMENT

En mode d’appariement, les DEL pulsent jusqu’à ce

que le Cube se soit apparié avec un dispositif Bluetooth.

APPARIEMENT RÉUSSI

La bague luit bleu continu.

APPARIEMENT ÉCHOUÉ

5 clignotements

SPECIFICATIONS

Battery Life: up to 8 hours

Varies with system volume

Autonomie de la pile : jusqu’à 8 heures

Peut varier selon le volume du système

Dimensions: 7.7” H x 7.5” W x 7.5” D

Dimensions: 19.7cm H x 19.1cm W x 19.1cm D

Drivers: (5) 1-1/4” mid/high frequency drivers, (1) 5-1/4” woofer

Transducteurs : (5) méd/aigus 3.175 cm, (1) graves 13.34 cm

Frequency response: 50Hz-20kHz

Résponse en fréquence: 50 Hz à 20 kHz

Bluetooth range: 10m (33')

Portée bluetooth: 10m (33 pi)

FOR MORE INFORMATION

POUR PLUS DE RENSEIGNEMENTS

Limited Warranty

2-Years for Drivers and Cabinets, 2-Years for Electronic

Components DEI Sales Co., dba Denitive Technology

(herein “Denitive”), warrants to the original retail

purchaser only that this Denitive loudspeaker product

(the “Product”) will be free from defects in material and

workmanship for a period of two (2) years covering the

drivers and cabinets, and two (2) years for the electronic

components from the date of the original purchase

from a Denitive Authorized Dealer. If the Product is

defective in material or workmanship, Denitive or its

Authorized Dealer will, at its option, repair or replace the

warranted product at no additional charge, except as set

forth below. All replaced parts and Product(s) become

the property of Denitive. Product that is repaired or

replaced under this warranty will be returned to you,

within a reasonable time, freight collect. This warranty is

non-transferable and is automatically void if the original

purchaser sells or otherwise transfers the Product to any

other party. This Warranty does not include service or

parts to repair damage caused by accident, misuse,

abuse, negligence, inadequate packing or shipping

procedures, commercial use, voltage in excess of the

rated maximum of the unit, cosmetic appearance of

cabinetry not directly attributable to defects in material

or workmanship. This warranty does not cover the

elimination of externally generated static or noise, or the

correction of antenna problems or weak reception. This

warranty does not cover labor costs or damage to the

Product caused by installation or removal of the Product.

Denitive Technology makes no warranty with respect to

its products purchased from dealers or outlets other than

Denitive Technology Authorized Dealer.

The warranty is automatically void if:

1) The product has been damaged, altered in any way

mishandled during transportation or tampered with.

2) The product is damaged due to accident, re, ood,

unreasonable use, misuse, abuse, customer applied

cleaners, failure to observe manufacturers warnings,

neglect or related events.

3) Repair or modication of the Product has not been

made or authorized by Denitive Technology.

4) The product has been improperly installed or used.

Product must be returned (insured and prepaid),

together with the original dated proof of purchase

to the Authorized Dealer from whom the Product

was purchased, or to the nearest Denitive factory

service center. Product must be shipped in the original

shipping container or its equivalent. Denitive is not

responsible or liable for loss or damage to Product

in transit. This limited warranty is the only express

warranty that applies to your product. Denitive

neither assumes nor authorizes any person or entity

to assume for it any other obligation or liability in

connection with your product or this warranty. All

other warranties, including but not limited to express,

implied, warranty of merchantability or tness for

a particular purpose, are expressly excluded and

disclaimed to the maximum extent allowed by law.

All implied warranties on product are limited to the

duration of this expressed warranty. Denitive has no

liability for acts of third parties. Denitive’s liability,

whether based on contract, tort, strict liability, or

any other theory, shall not exceed the purchase

price of the product for which a claim has been

made. Under no circumstance will Denitive bear

any liability for incidental, consequential or special

damages. The consumer agrees and consents that all

disputes between the consumer and Denitive shall

be resolved in accordance with California laws in

San Diego County, California. Denitive reserves the

right to modify this warranty statement at any time.

Some states do not allow the exclusion or limitation

of consequential or incidental damages, or implied

warranties, so the above limitations may not apply to

you. This warranty gives you specic legal rights, and

you may also have other rights which vary from state

to state.

FEDERAL COMMUNICATION

COMMISSION INTERFERENCE STATEMENT

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful

interference in a residential installation.

Autres manuels pour cube

Table des matières

Autres manuels Definitive Technology Intervenants

Definitive Technology

Definitive Technology Mythos XTR-50 Manuel utilisateur

Definitive Technology

Definitive Technology Sound Cylinder Manuel utilisateur

Definitive Technology

Definitive Technology Mythos STS Manuel utilisateur

Definitive Technology

Definitive Technology SR9080 Manuel utilisateur

Definitive Technology

Definitive Technology DI 5.5BPS Manuel utilisateur

Definitive Technology

Definitive Technology 3.5R Manuel utilisateur

Definitive Technology

Definitive Technology Mythos Two Manuel utilisateur

Definitive Technology

Definitive Technology C/L/R 2500 Manuel utilisateur

Definitive Technology

Definitive Technology AW5500 Manuel utilisateur

Definitive Technology

Definitive Technology SuperTower BP7001SC Document technique

Definitive Technology

Definitive Technology Mythos Mythos STS Manuel utilisateur

Definitive Technology

Definitive Technology SR9080BP Manuel utilisateur

Definitive Technology

Definitive Technology DYMENSION DM40 Manuel utilisateur

Definitive Technology

Definitive Technology Mythos One Manuel

Definitive Technology

Definitive Technology CS-8040HD Manuel utilisateur

Definitive Technology

Definitive Technology DYMENSION DM10 Manuel utilisateur

Definitive Technology

Definitive Technology UIW RLS III Manuel utilisateur

Definitive Technology

Definitive Technology BP9000 SERIES Manuel utilisateur

Definitive Technology

Definitive Technology D7 Manuel utilisateur

Definitive Technology

Definitive Technology ProCenter 1000 Manuel utilisateur

Definitive Technology

Definitive Technology Mythos Mythos ST Manuel utilisateur

Definitive Technology

Definitive Technology Mythos ST Manuel utilisateur

Definitive Technology

Definitive Technology Mythos Mythos STS Manuel utilisateur

Definitive Technology

Definitive Technology MYTHOS XTR-SSA5 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur

Definitive Technology cube Manuel utilisateur

Manuels Intervenants populaires d'autres marques
