DeDietrich Oven Manuel utilisateur

FR GUIDE D'UTILISATION

EN USER GUIDE

ES MANUAL DE UTILIZACIÓN

PT MANUAL DE UTILIZAÇÃO

DE BETRIEBSANLEITUNG

Four

Oven

Horno

Forno

Backofen

Dear Customer.

You have just purchased a DE DIETRICH oven and we would like to thank you.

Our research teams have designed this new generation of appliances for you. Their

quality, aesthetics, functions and technological developments make them exceptional

products and proof of our ability and know-how.

Your new DE DIETRICH oven will fit harmoniously into your kitchen, combining top

cooking performance with ease of use. We want you to enjoy a product of excellence.

In the DE DIETRICH range of products, you will also find a wide selection of cookers,

hobs, extraction hoods, dishwashers and built-in refrigerators, which can be

coordinated with your new DE DIETRICH oven.

Of course, with a view to meeting your requirements as closely as possible, our

customer service department is available to answer any questions or listen to your

suggestions (details at the end of this booklet).

You can also connect to our web site:

www.dedietrich-electromenager.com where you will find our latest innovations, as well

as useful and additional information.

DDEEDDIIEETTRRIICCHH

NNeewwoobbjjeeccttssooffvvaalluuee

As part of our commitment to constantly improving our products, we reserve the right to make

changes to them based on advances in their technical and functional features and appearance.

Warning:

Before installing and using your appliance, please read this Installation and Use Guide

carefully, which will allow you to quickly familiarise yourself with the appliance’s operation.

CONTENTS EN

1/ DESCRIPTION OF YOUR APPLIANCE

• Presentation of your oven ___________________________________ 4

• Presentation of control panel_________________________________ 5

2/ USING YOUR APPLIANCE

• Cooking __________________________________________________ 6

• Settings when switching on for the first time ____________________ 7

• Resetting the time__________________________________________ 7

• Using the drawer ___________________________________________ 8

• Standby mode _____________________________________________ 10

• “EXPERT” function _________________________________________ 10

º Guide to “Expert” cooking _______________________________ 11

º Grill+ option ___________________________________________ 14

º Starting cooking _______________________________________ 15

• “Steamer RECIPES” function_________________________________ 16

º Advice and tips ________________________________________ 17

• “SETTINGS” function _______________________________________ 19

º Time _________________________________________________ 19

º Sound ________________________________________________ 19

º Display _______________________________________________ 19

º Consumption __________________________________________ 20

º Language _____________________________________________ 20

º Services ______________________________________________ 21

• “CLEANING” function_______________________________________ 22

• Control panel locking (child safety device) ______________________ 26

5 / TROUBLESHOOTING PROBLEMS _______________________________ 27

6 / FUNCTION SUITABILITY TESTS _________________________________ 28

1/ DESCRIPTION OF YOUR APPLIANCEEN

INTRODUCTION TO YOUR OVEN

•

Programmer

Control buttons

Lamp

Wire shelf supports

1/ DESCRIPTION OF YOUR APPLIANCE EN

List of symbols:

Programming in progress

Door locked

Keypad locked

Cleaning recommended

Selector buttons

Turn off oven or your cooking programme

Back to the previous level

Information display

Drawer opening button

Validation button

“Wake up” button (come out of standby)

Using for the first time: before using your

oven for the first time, heat it up while empty

with the door closed for approximately

15 minutes using the maximum setting in

order to “cure” the appliance. The rock wool

that surrounds the oven cavity may initially

release a particular odour caused by its

composition. Similarly, you may notice the

release of some smoke. All of this is normal.

BCEF

DESCRIPTION OF CONTROLS

•

2/ USING YOUR APPLIANCEEN

COOKING

•

- The oven offers several modes

combined steam:

- Expert mode

With three combined steam functions, the user can

manage all aspects of cooking.

- Cooking guide

The user chooses from 17 pre-programmed recipes

(roasts, poultry, bread, cakes, cooked dishes, thawing).

- Multifunction Plus,

- 10 cooking functions,

- Reservoir capacity, 1 litre,

- Water level visible in the reservoir with blue

backlight,

- Touch sensitive water drawer opening

- De-scaling recommendation.

- 2 pyrolysis levels

• More succulent cooking

• Food that keeps its crispness

• Food that is not dried out

• Beautiful presentation, food retains the texture it had before cooking

• More gentle cooking that preserves flavour

COMBI STEAM OVEN

An efficient and economical oven

2/ USING YOUR APPLIANCE EN

•Language

The oven automatically displays the following

screen.

It allows you to select your language by

pressing the < and > buttons.

Confirm by pressing OK.

•Time

A second screen then appears, to allow you

to set the time.

Set the time using the < and > buttons and

then press OK.

The hour display flashes, you can adjust it

using the < and > buttons and confirm by

pressing OK.

Do the same for the minutes (1).

You can choose a 12-hour (am/pm) or

24-hour display (2).

Select using the < and > buttons and then

confirm by pressing OK.

Digital display

SETTINGS WHEN SWITCHING ON FOR THE FIRST TIME

•

O K

(1)

(2)

Deutsch

English

Francais

•Resetting the time

- Press the OK button.

The oven displays the following screen by

default (“Expert”) function.

- Press the < and > buttons until the “Settings”

screen appears, confirm with OK. The “time”

screen is displayed; press OK again to access

the time data screen and then proceed as for

switching on for the first time.

EXPERT

Clock

2/ USING YOUR APPLIANCEEN

USING THE DRAWER

•

•Filling the reservoir

— Always fill the reservoir with water before

you cook.

The reservoir capacity is as follows:

- a maximum of 1 litre.

- Only use tap water. Do not use softened

or demineralised water.

Press the button, the filling drawer pops

outs (fig.1).

- Fill the reservoir.

Make sure that the reservoir is filled to its

maximum capacity.

Use the maximum level mark visible on the

front face of the drawer (fig.2).

Then, close the drawer by pushing it shut

(fig. 3).

Your oven is now ready for Combi-steam

cooking.

MAXI

MINI

fig.1

fig.2

Note

The reservoir capacity is a maximum

of 1 litre.

Do not use softened or demineralised

water.

Tip

When filling the reservoir, leave the

water level for a couple of seconds so

that it can settle.

Readjust the level if necessary.

fig.3

MIN

MAX

2/ USING YOUR APPLIANCE EN

USING THE DRAWER

•

Note

The emptying cycle must be carried out

after every Combi-steam Cooking. The automatic emptying cycle lasts for about 3 minutes/

•Emptying the reservoir

— Manual emptying

- Open your oven door so that it is easier to

empty the reservoir.

Press the button, the filling drawer pops

outs.

- Place a container under the drawer to collect

any water (fig.1).

- Keep your finger on the button for the

entire emptying cycle (fig.3), about 3 minutes

for 1 litre.

- The pump is continuously activated and the

water escapes through an opening located

under the drawer (fig.1).

— Automatic emptying

- Empty the reservoir after cooking with the

Combi-steam oven.

- The display, the drawer and the flashing

light indicate that you may proceed with the

emptying cycle (fig.2)

Press the button, the filling drawer pops

outs.

- Place a container under the drawer to collect

any water (fig.1).

- Keep your finger on the button for

3 seconds (fig.3),

- The automatic emptying cycle begins.

The display indicates the time needed for

emptying e.g. 2 minutes 20s. The emptying is

finished when the display indicates 00

minutes. You may remove the container.Then,

close the drawer by pushing it shut.

2/ USING YOUR APPLIANCEEN

EXPERT

Chal. tournante

Example

•The “Expert” function

The Expert function lets you set the cooking

parameters yourself: temperature, cooking

type, cooking time.

-Press the OK button. You access the

“Expert” screen.

-Press OK again to choose the type of

cooking from the following list by pressing

the < and > buttons (to make a selection,

refer to the cooking guide on the next page):

· Circulating heat

· Combined heat

· Traditional Eco

· Turbo grill

· High grill

· Medium grill

· Keep warm

· Defrost

- Traditional + steam

- Pulsed grill + steam

- Circulating heat + steam

Confirm your selection by pressing OK.

THE “EXPERT” FUNCTION

•

STANDBY MODE

•

After 4 minutes with no action by the user, the

display switches off to save energy (except for

a delayed start) and the button starts

flashing. The screen is then

in standby mode.

To activate the oven and restore the display to

full brightness, press the “wake up”

button.

The screen shows the time again.

CCiirrccuullaattiinngghheeaatt
