DCS UR624 Manuel utilisateur

OUTDOOR REFRIGERATOR AND

BEER DISPENSER

Use and Care Guide

MODELS:

UT624

UR624

Thank you for selecting this DCS Outdoor Refrigerator/Beer Dispenser. Because of these appliances’ unique

features we have developed this Use and Care Guide. It contains valuable information on how to properly install,

operate and maintain your new appliance for years of safe and enjoyable operation.

To help serve you better, please fill out and submit your Ownership Registration by visiting our website at

www.dcsappliances.com and selecting “Customer Service” on the home page and then select “Ownership

Registration” or submit the enclosed Ownership Registration Card to the address below. In addition, keep this

guide handy, as it will help answer questions that may arise as you use your new appliance.

For your convenience, product questions can be answered by a DCS Customer Care Representative at

1-888-281-5698, email: [email protected], or by mail:

Fisher & Paykel Appliances, Inc.

Attention: DCS Customer Care

5900 Skylab Road

Huntington Beach, CA 92647

Note to Customer:

This merchandise was carefully packed and thoroughly inspected before leaving our plant. Responsibility for its safe

delivery was assumed by the carrier upon acceptance of the shipment. As directed on the side of your packing carton,

claims for loss or damage sustained in transit must be made on the carrier as follows:

A) Exterior Damage: Make thorough damage notation on your delivery receipt and have driver acknowledge by signa-

ture and date. Send a written request asking for an inspection report from carrier. Include the name of carrier repre-

sentative and the date the inspection was requested. Retain inspection report and receipt for filing of a claim.

B) Concealed Damage: This must be reported to carrier within fifteen days. Obtain inspection report from the carrier.

Retain the inspection report for filing of the claim. DO NOT RETURN DAMAGED MERCHANDISE TO MANUFACTURER --

FILE THE CLAIM WITH THE CARRIER.

PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.

A MESSAGE TO OUR CUSTOMERS

TABLE OF CONTENTS

SAFETY PRACTICES AND PRECAUTIONS 3-4

INSTALLATION 4-5

USING THE FRIDGE/BEER DISPENSER 6

CARE AND MAINTENANCE

Replace interior light bulb 7

Things to remember 7

Energy saving tips 7

How to clean and maintain your cabinet 8

TROUBLESHOOTING 9

SERVICE 10

WARRANTY 11-12

SAFETY PRACTICES & PRECAUTIONS

To reduce the risk of fire, electric shock, or injury to persons read the IMPORTANT SAFETY INSTRUCTIONS before

operating this appliance.

Use this appliance only for its intended purpose as described in this User Guide.

WARNING

When using this appliance always exercise basic safety precautions including the following:

Danger!

■

Risk of child entrapment. Before you throw away your old refrigerator or freezer:

- Take off the doors.

- Leave the shelves in place so that children may not easily climb inside.

Electrical

■

This appliance must be properly installed in accordance with the installation instruction before it is used.

■

Never unplug your refrigerator by pulling on the power cord.

■

Always grip the plug firmly and pull straight out from the outlet.

■

Repair or replace immediately all electric service cords that have become frayed or otherwise damaged. Do not

use a cord that shows cracks or abrasion along its length or at either the plug or appliance end.

If the power supply cord is damaged, it must only be replaced by your Fisher & Paykel Appliances Authorized

Service Center because special purpose tools are required.

■

Unplug your refrigerator before cleaning or replacing the light bulb.

Storing

■

Never store volatile or flammable materials in your refrigerator as they may explode.

Cleaning

■

Many commercially available cleaning products contain solvents which may attack plastic components of your

refrigerator or freezer and cause them to crack. Please refer to the cleaning care section of this booklet for

further advice (see pages 6-8).

SELECT LOCATION:

The proper location will ensure peak performance of your appliance. Choose a location where the unit will be

out of direct sunlight, away from heat sources and moisture. Units with fan cooled condensers can be built in.

Unit should be operated in a properly ventilated area with ambient temperatures above 40 degrees and

below 100 degrees Fahrenheit.

Installation should be such that the cabinet can be moved for servicing if necessary.

CABINET CLEARANCE:

Ventilation is required from the bottom front section of the unit. Keep this area open and clear of any

obstructions.

The adjacent cabinets and counter top can be built around the unit as long as no top trim or counter top is

installed lower than the top of the hinge.

INSTALLATION

HOW TO INSTALL YOUR OUTDOOR REFRIGERATOR/BEER DISPENSER

24” Outdoor Refrigerator

Dimensions

Island Preparation

24” Outdoor Beer Dispenser

Dimensions

Island Preparation

INSTALLATION

HOW TO INSTALL YOUR OUTDOOR REFRIGERATOR/BEER DISPENSER

24” Outdoor Beer Dispenser

• 120V 60Hz • UL approved

• 1800 watt • Available freestanding or built-in

• 3 wire • Drip tray

• 15 amp circuit

24” Outdoor Refrigerator

• 120V 60Hz • UL approved

• 1800 watt • Interior space 6.1 cu ft

• 3 wire • Available freestanding or built-in

• 15 amp circuit • Auto defrost

AC Interface AC Interface

ELECTRICAL CONNECTION:

Check serial plate for correct power supply. Use only electrical power supply as specified on your appliance

serial nameplate. Do not use an extension cord!

WARNING!

Do not splash or spray water from a hose onto the refrigerator! Doing so may cause an electrical shock, which may

result in severe injury or death.

GROUNDING METHOD

This product is factory equipped with a power supply cord that has a three-pronged grounded plug. It must be

plugged into a mating grounding type receptacle in accordance with the National Electrical Code and

applicable local codes and ordinances. If the circuit does not have a grounding type receptacle, it is the

responsibility and obligation of the customer to exchange the existing receptacle in accordance with the

National Electrical Code and applicable local codes and ordinances. The third ground prong should not, under

any circumstances, be cut or removed. All UL listed refrigerated products are equipped with this type of plug.

A ground fault circuit interrupter electrical receptacle is to be used to supply electrical power to the refrig-

erator for outdoor applications. Contact an electrician if you need to install one to supply electrical power to

your outdoor refrigerator.

POWER REQUIREMENTS:

Note:

The plug shown is for 115V units. The

prongs on your model may be different

than the one shown if your unit is other

than 115 volts.

Grounding Type

Wall Receptacle

Power Supply Cord

with 3-Prong

Grounding

Plug

USING THE FRIDGE/BEER DISPENSER

TEMPERATURE CONTROL

Initially set the cold control knob midway between the numbers.

After at least 2 hours, adjust to the temperature that suits you. The

higher the number you select, the cooler the temperature (Fig. 02).

The temperature control knob is located at the bottom, front of the

cabinet, just behind the square opening near the middle of the

venting grill.

DEFROSTING INSTRUCTIONS

Never use a scraper or any tool that might scratch or pierce the

cooling plate. Follow these steps whenever 1/4 inch or more of

frost accumulates;

1. Disconnect the power cord and set the cold control knob to “OFF”

position.

2. Remove contents.

3. Place pans of hot water on the shelf under cooling plate if you wish to speed up defrosting.

Note:

Place a clean cloth under the hot pan of water to protect the glass shelf from breaking.

4. Wipe out the interior and replace contents.

5. Connect power cord to outlet.

6. Set temperature control to desired level.

HELP PREVENT TRAGEDIES. . .

Each year children die because they climb inside a discarded refrigeration product, get trapped inside and

suffocate. Take precautions to prevent such tragedies by removing the door, taping or chaining it shut before

discarding.

ALL REFRIGERATOR MODELS

All refrigerator models automatically defrost their cooling plate during each compressor off cycle. No

manual defrosting is required.

Dial setting established

at the top of the knob

Fig. 02

CARE AND MAINTENANCE

REPLACE INTERIOR LIGHT BULB

When supplied with an interior light, your refrigerator uses a 15 Watt appliance light bulb. To replace the light

bulb, proceed as follows:

1. Unplug the power cord from the power supply.

2. Open the cabinet door and remove the glass shelves.

3. Remove the 3 screws on the front face of the light lens using a Phillips screwdriver.

4. Remove the lens.

5. Unscrew the existing bulb and replace with an equivalent 15 Watt, threaded, intermediate base appliance bulb.

Do not replace with a bulb higher than 15 Watts.

6. Reassemble.

To clean the light assembly, disconnect the power cord and let the light cool. Wipe the assembly with a mildly

damp cloth. Dry the unit completely before connecting the power cord. Make sure you disconnect the refrig-

erator’s power cord plug from the electrical receptacle BEFORE you clean the light assembly.

NOTE:

The rocker switch located on the right side of grill con-

trols the interior light and overrides the door plunger

switch allowing the light to stay on even with the door

closed. To have the interior light go out after the door

is shut, make sure the rocker switch is pushed into the

“OFF” position (Fig. 01).

THINGS TO REMEMBER. . .

1. Allow 24 hours for your refrigerator to reach a new temperature setting.

2. The motor will start and stop often. It must do this to maintain the temperature you select.

3. Keep your refrigerator reasonably level.

4. Unplug the refrigerator before working on anything with the electrical system.

5. Exercise caution when sweeping, vacuuming, or mopping near the front of the unit. Damage to the grill and/or

the light fixture switch can occur.

6. For all cleaning of the refrigerator interior, mix 2 tablespoons baking soda with 1 quart warm water or use mild

soap. Do not use strong cleaners or scouring powder or pads.

7. Keep your refrigerator out of direct sunlight.

8. Do not splash or spray water on or under the refrigerator.

9. Clean your refrigerator’s condenser periodically to maintain proper cooling performance.

ENERGY SAVING TIPS

1. Reduce door openings.

2. Close the door as soon as you can.

3. Keep the coils on bottom of the refrigerator clean.

4. Adjust the temperature control to a warmer setting when practical.

5. Don’t put hot foods in the refrigerator.

6. Keep unit away from the stove or other heat sources.

OFF

Fig. 01

ROCKER SWITCH

(optional features)

CARE AND MAINTENANCE

HOW TO CLEAN AND MAINTAIN YOUR UNIT

Condenser

The condenser coil under the cabinet for forced air units does not require frequent cleaning; however,

satisfactory cooling depends on adequate ventilation over the condenser coil. Be sure that nothing obstructs

the air flow openings in the lower front of the cabinet. At least once or twice a year brush or vacuum lint and

dirt from the condenser coil for efficient performance by unscrewing the grill on the bottom front of the cabinet.

Cabinet

The stainless steel cabinet can be washed with mild soap and water and thoroughly rinsed with clear water.

Never use abrasive scouring powders.

Interior and Door Gasket

Wash interior compartment with mild soap and water. Mix 2 tablespoons of baking soda with one quart of warm

water. Do not use an abrasive powder, solvent, polish cleaner or undiluted detergent.
