Datalogic FireScan D141 Manuel utilisateur

DATALOGIC S.p.A.,

Via Candini, 2

40012 - Lippo di Calderara

Bologna - Italy

dichiara che

declares that the

déclare que le

bescheinigt, daß das Gerät

declare que el

FireScan D1XX

e tutti i suoi modelli

and all its models

et tous ses modèles

und seine modelle

y todos sus modelos

sono conformi alle Direttive del Consiglio Europeo sottoelencate:

are in conformity with the requirements of the European Council Directives listed below:

sont conformes aux spécifications des Directives de l'Union Européenne ci-dessous:

den nachstehenden angeführten Direktiven des Europäischen Rats:

cumple con los requisitos de las Directivas del Consejo Europeo, según la lista

89/336/EEC EMC Directive e 92/31/EEC, 93/68/EEC emendamenti successivi

and further amendments

et ses successifs amendements

und späteren Abänderungen

y succesivas enmiendas

Basate sulle legislazioni degli Stati membri in relazione alla compatibilità

elettromagnetica ed alla sicurezza dei prodotti.

On the approximation of the laws of Member States relating to electromagnetic

compatibility and product safety.

Basée sur la législation des Etates membres relative à la compatibilité

électromagnétique et à la sécurité des produits.

Über die Annäherung der Gesetze der Mitgliedsstaaten in bezug auf

elektromagnetische Verträglichkeit und Produktsicherheit entsprechen.

Basado en la aproximación de las leyes de los Países Miembros respecto a la

compatibilidad electromagnética y las Medidas de seguridad relativas al producto.

Questa dichiarazione è basata sulla conformità dei prodotti alle norme seguenti:

This declaration is based upon compliance of the products to the following standards:

Cette déclaration repose sur la conformité des produits aux normes suivantes:

Diese Erklärung basiert darauf, daß das Produkt den folgenden Normen entspricht:

Esta declaración se basa en el cumplimiento de los productos con la siguientes normas:

EN 55022, August 1994: L

IMITS AND METHODS OF MEASUREMENTS OF

RADIO DISTURBANCE OF INFORMATION

TECHNOLOGY EQUIPMENT

(ITE)

EN 55024, September 1998: I

NFORMATION

ECHNOLOGY

QUIPMENT

MMUNITY CHARACTERISTICS

. L

IMITS AND

METHODS OF MEASUREMENTS

Lippo di Calderara, 23/02/2004 Ruggero Cacioppo

Quality Assurance Laboratory Manager

FireScan™

D141 READERS

QUICK REFERENCE

INSTALLAZIONE RAPIDA

INSTALLATION RAPIDE

SCHNELLINSTALLATION

INSTALACIÓN RÁPIDA

820001300

USING FIRESCAN™ SERIES READERS

FireScanguns automatically scan barcodes at a distance.

Simply aim and pull the trigger. Code scanning is performed

along the scan line emitted from the reading window. This line

must cross the entire code.

Successful scanning is obtained by tilting the scanner with

respect to the barcode to avoid direct reflections which impair

the reading performance, see the figure.

Con le pistole FireScanla lettura dei codici a barre avviene a

distanza: è sufficiente mirare sul codice e premere il grilletto.

La lettura avviene sulla linea laser che deve attraversare

interamente il codice da leggere.

Le condizioni ottimali per la lettura si ottengono inclinando lo

scanner rispetto al codice, così da evitare riflessioni dirette, che

potrebbero compromettere le prestazioni di lettura (vedere la

figura).

Avec les pistolets FireScan, la lecture des codes s'effectue

automatiquement et à distance. Il suffit de viser le code et

d’appuyer sur la gâchette. Le code est lit sur la ligne sortant de

la fenêtre de lecture de l'appareil. Cette ligne doit traverser le

code à barres à lire de part en part.

Pour des prestations optimales inclinez la douchette par

rapport au code à lire, afin d'éviter des réflexions directes qui

pourraient compromettre la performance de lecture (voir la

figure).

SERVICES AND SUPPORT

Datalogic provides several services as well as

technical support through its website. Log on to

www.datalogic.com/services/support and click on

the links indicated for further information including:

Datalogic fornisce servizi e supporto tecnico tramite

il suo sito web. Connettersi al sito

www.datalogic.com/services/support e cliccare

sui link indicati per avere ulteriori informazioni, come

elencato di seguito:

Datalogic fournit différents services et une aide

technique en ligne. Connectez-vous sur

www.datalogic.com/services/support et cliquez

sur le lien indiqué pour obtenir des informations

complémentaires sur:

Datalogic bietet unterschiedliche Service-

Leistungen, wie auch technische Unterstützung über

Internetseiten. Gehen Sie auf die Seite

www.datalogic.com/services/support und klicken

Sie auf die Links die Sie über folgende Punkte

informieren::

Datalogic proporciona servicios y soporte técnico a

través su página web. Para ello Usted debe

conectarse a

www.datalogic.com/services/support y hacer clic

en los enlaces indicados a continuación para recibir

más información:

•

Services – Warranty Extensions and Maintenance

Agreements

•

Support – Software Driver Downloads

•

Quality Partners

•

Authorised Repair Centres

WARRANTY

Datalogic warranties this product against defects in

workmanship and materials, for a period of 5 years

from the date of shipment, provided that the product

is operated under normal and proper conditions.

Datalogic has the faculty to repair or replace the

product, these provisions do not prolong the original

warranty term.

The warranty does not apply to any product that has

been subject to misuse, accidental damage,

unauthorized repair or tampering.

Datalogic garantisce questo prodotto contro difetti di

fabbricazione e di materiali per 5 anni dalla data di

consegna, a condizione che il prodotto sia utilizzato

come previsto.

Datalogic si riserva la facoltà di riparare o sostituire il

prodotto. Quanto sopra non prolunga la garanzia

originale.

La garanzia non si applica a prodotti utilizzati in modo

non corretto, danneggiati accidentalmente, sottoposti

a riparazioni non autorizzate o manomessi.

Datalogic garantit ce produit de tout défaut de

fabrication ou des matériaux pendant 5 ans à compter

de la date de livraison, à condition que le produit soit

utilisé correctement.

Datalogic a la faculté de réparer ou de remplacer ce

produit. Ces mesures ne prolongeront pas l’échéance

de la garantie.

La garantie ne s’applique pas aux produits qui ont été

utilisés de façon incorrecte, accidentellement

endommagés, soumis à des réparations non

autorisées ou bien altérés.

Datalogic gibt für dieses Produkt eine Garantie von 5

Jahren auf Herstellungs- und Materialfehler ab

Versandsdatum, falls das Produkt unter normalen und

angemessenen Bedingungen verwendet wurde.

Datalogic behält sich vor, das Produkt entweder zu

reparieren oder zu ersetzen, was aber den originalen

Garantietermin nicht verlängert.

Die Garantie erlischt bei unsachgemäßer Verwendung

und unberechtigter Veränderungen am Produkt.

Datalogic garantiza este producto contra todos los

defectos de fabricación y materiales por un periodo

de 5 años desde la fecha de envío, a condición de

que el producto sea utilizado en condiciones

normales y correctas.

Datalogic tiene el derecho de reparar o reemplazar el

producto sin que esto suponga una prolongación de

la garantía original.

La garantía no será valida si el producto ha sufrido

abusos, daños accidentales, reparaciones no

autorizadas o ha sido falsificado.

Die FireScanLesepistolen lesen Strichcodes automatisch

und berührungslos. Es genügt auf den Code zu zielen und die

Taste zu drücken. Der Code wird mittels einer Lichtlinie

gelesen, die das Gerät durch das Lesefenster verlässt und den

gesamten Code durchqueren muß.

Eine optimale Lesung ist gewährleistet, wenn der Benutzer die

Pistole bzgl. den Code etwas neigt, um eine direkte Reflexion

zu vermeiden, wie im Bild oben gezeigt wird.

Los lectores FireScan™ capturan automáticamente códigos de

barras a distancia: sólo hay que encuadrar el código y apretar

el gatillo. La lectura se realiza sobre el rayo láser emitido por la

ventana de lectura que debe atravesar el código de parte a

parte.

Las condiciones óptimas para la lectura se obtienen inclinando

el escáner respecto al código de barras para evitar reflexiones

directas de luz que podrían perjudicar el rendimiento de lectura

(ver figura).

CONNECTIONS

DISCONNECTING THE CABLE

READING DIAGRAM

100 200 400

200

100

-100

-200

300 500 600

Reading Zones (10° skew angle)

700 800 mm

-300

300

1.00

0.12

0.19

0.25

EAN

0.33 mm

0.38

0.50

FCC COMPLIANCE

This device complies with PART 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference which

may cause undesired operation.

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own

expense.

TECHNICAL FEATURES

FireScan™ D141

Electrical Features

Power supply 4.75 - 14 Vdc

Consumption

Operating

Stand by

180 mA @ 5 Vdc

5 mA @ 5 Vdc

Scan Rate 35 ±5 scans/sec

Reading Indicators

Laser On (red) LED / Good Read

(green LED), Beeper (available

for suitable decoders)

Optical Features

Light Source VLD 630 ~ 680 nm

Power (peak) 0.9 mW

Scan Angle 42° ±2°

Laser Safety Class

EN 60825-1 / CDRH 2

Reading Field see reading diagram

Max. Resolution 0.12 mm (5 mils)

PCS min. 15% (Datalogic Test Chart)

Environmental Features

Working Temperature 0 °C to + 50 °C

Storage Temperature -20 °C to + 70 °C

Humidity 90% non condensing

Drop resistance

(on concrete)

IEC 68-2-32 Test ED

1.5 m

ESD Protection 16 KV

Protection Class IP30

Mechanical Features

Weight (without cable) about 210 g (7.4 oz.)

Cable length

(CAB 397 – fully extended)

(CAB 396 – fully extended)

2.60 m (8 ft. 5 in.)

3.00 m (9 ft. 9 in.)

CABLE CLAMP

An adhesive cable clamp is provided to fix the cable

to a surface.

Il fermacavo adesivo fornito consente di fissare il

cavo ad una superficie.

Le serre-fil adhésive fourni permis de fixer le câble

sur la surface voulue.

Die klebende Kabelverschraubung erlaubt das Kabel

auf die Tischoberfläche zu verschrauben.

La brida adhesiva de pared permite fijar el cable en

una superficie.

ELECTRICAL CONNECTIONS

The FireScan™ D141 scanner can be used with CAB 397

(coiled cable and 9-pin male connector) for direct connection to

the DATAPLUS and DLD series decoders.

CAB 397

1 - Not connected 5 - TRIGGER

2 - SCAN 6 - BEEPER/LED

3 - Not connected 7 - VIDEO

6789

12345

4 - GND 8 – LASER ON

9 - +VCC

9-pin male connector

The FireScan™ D141 scanner can be used with CAB 396

(coiled cable and 8-pin modular connector) for direct

connection to PSC Inc. flat bed scanners.

CAB 396

1 - TRIGGER 5 - BEEPER/LED

2 – LASER ON 6 - Not connected

3 - Not connected 7 - +VCC

4 - VIDEO 8 - GND

8-pin modular connector

A definition of the terms used to identify the pins is as follows:

SCAN This scanner “open collector” output signal is

used to synchronize the decoding logic with

the scanner. Each transition of this signal

from low-to-high or high-to-low corresponds

to the start of a scan. The signal is a TTL

level 57 ms period square wave (see the

following figure Video and Scan signals).

GND Supply ground and signal reference.

TRIGGER This output is connected to GND when the

trigger is pressed and is left floating when the

trigger is released.

BEEPER/LED This scanner input drives the green decoding

LED, and the beeper in the scanner. The

LED turns on when a positive current is

applied to the pin. The beeper sound is

obtained pulsating this current at a frequency

of about 2 kHz. The maximum voltage that

can be applied to this input is 5 Vdc.

VIDEO This “open collector” scanner output is

electrically identical to the barcode. It

supplies a series of pulses the length of

which are proportional to the width of the

elements within the barcode read. A low

output level corresponds to a bar. The

frequency of the pulses depends on the

density of the code, the distance from code

and the programmed output scan frequency

(see the following figure Video and Scan

signals).

LASER ON A positive voltage between 4.75 and 5 Vdc is

applied to this input by the decoder when the

decoding logic senses the trigger is pressed;

this causes the laser to start scanning and

the red LED to turn on.

+VCC This input must be connected to the positive

pin of the supply voltage (4.75 - 14 Vdc).

When the LASER ON pin is positive, all the

current necessary to power the scanner flows

through +VCC.

Video and Scan Signals

CODE

VIDEO

SCAN

ELECTRICAL CONNECTIONS

The FireScan™ D141 scanner can be used with CAB 397

(coiled cable and 9-pin male connector) for direct connection to

the DATAPLUS and DLD series decoders.

CAB 397

1 - Not connected 5 - TRIGGER

2 - SCAN 6 - BEEPER/LED

3 - Not connected 7 - VIDEO

6789

12345

4 - GND 8 – LASER ON

9 - +VCC

9-pin male connector

The FireScan™ D141 scanner can be used with CAB 396

(coiled cable and 8-pin modular connector) for direct

connection to PSC Inc. flat bed scanners.

CAB 396

1 - TRIGGER 5 - BEEPER/LED

2 – LASER ON 6 - Not connected

3 - Not connected 7 - +VCC

4 - VIDEO 8 - GND

8-pin modular connector

A definition of the terms used to identify the pins is as follows:

SCAN This scanner “open collector” output signal is

used to synchronize the decoding logic with

the scanner. Each transition of this signal

from low-to-high or high-to-low corresponds

to the start of a scan. The signal is a TTL

level 57 ms period square wave (see the

following figure Video and Scan signals).

GND Supply ground and signal reference.

TRIGGER This output is connected to GND when the

trigger is pressed and is left floating when the

trigger is released.

BEEPER/LED This scanner input drives the green decoding

LED, and the beeper in the scanner. The

LED turns on when a positive current is

applied to the pin. The beeper sound is

obtained pulsating this current at a frequency

of about 2 kHz. The maximum voltage that

can be applied to this input is 5 Vdc.

VIDEO This “open collector” scanner output is

electrically identical to the barcode. It

supplies a series of pulses the length of

which are proportional to the width of the

elements within the barcode read. A low

output level corresponds to a bar. The

frequency of the pulses depends on the

density of the code, the distance from code

and the programmed output scan frequency

(see the following figure Video and Scan

signals).

LASER ON A positive voltage between 4.75 and 5 Vdc is

applied to this input by the decoder when the

decoding logic senses the trigger is pressed;

this causes the laser to start scanning and

the red LED to turn on.

+VCC This input must be connected to the positive

pin of the supply voltage (4.75 - 14 Vdc).

When the LASER ON pin is positive, all the

current necessary to power the scanner flows

through +VCC.

Video and Scan Signals

CODE

VIDEO

SCAN

TECHNICAL FEATURES

FireScan™ D141

Electrical Features

Power supply 4.75 - 14 Vdc

Consumption

Operating

Stand by

180 mA @ 5 Vdc

5 mA @ 5 Vdc

Scan Rate 35 ±5 scans/sec

Reading Indicators

Laser On (red) LED / Good Read

(green LED), Beeper (available

for suitable decoders)

Optical Features

Light Source VLD 630 ~ 680 nm

Power (peak) 0.9 mW

Scan Angle 42° ±2°

Laser Safety Class

EN 60825-1 / CDRH 2

Reading Field see reading diagram

Max. Resolution 0.12 mm (5 mils)

PCS min. 15% (Datalogic Test Chart)

Environmental Features

Working Temperature 0 °C to + 50 °C

Storage Temperature -20 °C to + 70 °C

Humidity 90% non condensing

Drop resistance

(on concrete)

IEC 68-2-32 Test ED

1.5 m

ESD Protection 16 KV

Protection Class IP30

Mechanical Features

Weight (without cable) about 210 g (7.4 oz.)

Cable length

(CAB 397 – fully extended)

(CAB 396 – fully extended)

2.60 m (8 ft. 5 in.)

3.00 m (9 ft. 9 in.)

CABLE CLAMP

An adhesive cable clamp is provided to fix the cable

to a surface.

Il fermacavo adesivo fornito consente di fissare il

cavo ad una superficie.

Le serre-fil adhésive fourni permis de fixer le câble

sur la surface voulue.

Die klebende Kabelverschraubung erlaubt das Kabel

auf die Tischoberfläche zu verschrauben.

La brida adhesiva de pared permite fijar el cable en

una superficie.

CONNECTIONS

DISCONNECTING THE CABLE

READING DIAGRAM

100 200 400

200

100

-100

-200

300 500 600

Reading Zones (10° skew angle)

700 800 mm

-300

300

1.00

0.12

0.19

0.25

EAN

0.33 mm

0.38

0.50

FCC COMPLIANCE

This device complies with PART 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference which

may cause undesired operation.

This equipment has been tested and found to comply with the

limits for a Class A digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential

area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own

expense.

WARRANTY

Datalogic warranties this product against defects in

workmanship and materials, for a period of 5 years

from the date of shipment, provided that the product

is operated under normal and proper conditions.

Datalogic has the faculty to repair or replace the

product, these provisions do not prolong the original

warranty term.

The warranty does not apply to any product that has

been subject to misuse, accidental damage,

unauthorized repair or tampering.

Datalogic garantisce questo prodotto contro difetti di

fabbricazione e di materiali per 5 anni dalla data di

consegna, a condizione che il prodotto sia utilizzato

come previsto.

Datalogic si riserva la facoltà di riparare o sostituire il

prodotto. Quanto sopra non prolunga la garanzia

originale.

La garanzia non si applica a prodotti utilizzati in modo

non corretto, danneggiati accidentalmente, sottoposti

a riparazioni non autorizzate o manomessi.

Datalogic garantit ce produit de tout défaut de

fabrication ou des matériaux pendant 5 ans à compter

de la date de livraison, à condition que le produit soit

utilisé correctement.

Datalogic a la faculté de réparer ou de remplacer ce

produit. Ces mesures ne prolongeront pas l’échéance

de la garantie.

La garantie ne s’applique pas aux produits qui ont été

utilisés de façon incorrecte, accidentellement

endommagés, soumis à des réparations non

autorisées ou bien altérés.

Datalogic gibt für dieses Produkt eine Garantie von 5

Jahren auf Herstellungs- und Materialfehler ab

Versandsdatum, falls das Produkt unter normalen und

angemessenen Bedingungen verwendet wurde.

Datalogic behält sich vor, das Produkt entweder zu

reparieren oder zu ersetzen, was aber den originalen

Garantietermin nicht verlängert.

Die Garantie erlischt bei unsachgemäßer Verwendung

und unberechtigter Veränderungen am Produkt.

Datalogic garantiza este producto contra todos los

defectos de fabricación y materiales por un periodo

de 5 años desde la fecha de envío, a condición de

que el producto sea utilizado en condiciones

normales y correctas.

Datalogic tiene el derecho de reparar o reemplazar el

producto sin que esto suponga una prolongación de

la garantía original.

La garantía no será valida si el producto ha sufrido

abusos, daños accidentales, reparaciones no

autorizadas o ha sido falsificado.

Die FireScanLesepistolen lesen Strichcodes automatisch

und berührungslos. Es genügt auf den Code zu zielen und die

Taste zu drücken. Der Code wird mittels einer Lichtlinie

gelesen, die das Gerät durch das Lesefenster verlässt und den

gesamten Code durchqueren muß.

Eine optimale Lesung ist gewährleistet, wenn der Benutzer die

Pistole bzgl. den Code etwas neigt, um eine direkte Reflexion

zu vermeiden, wie im Bild oben gezeigt wird.

Los lectores FireScan™ capturan automáticamente códigos de

barras a distancia: sólo hay que encuadrar el código y apretar

el gatillo. La lectura se realiza sobre el rayo láser emitido por la

ventana de lectura que debe atravesar el código de parte a

parte.

Las condiciones óptimas para la lectura se obtienen inclinando

el escáner respecto al código de barras para evitar reflexiones

directas de luz que podrían perjudicar el rendimiento de lectura

(ver figura).

Autres manuels pour FireScan D141

Table des matières

Autres manuels Datalogic Lecteur de codes-barres

Datalogic

Datalogic PowerScan PD9531-AR Manuel utilisateur

Datalogic

Datalogic QuickScan QS6500BT Manuel utilisateur

Datalogic

Datalogic Gryphon L GD4300 Manuel utilisateur

Datalogic

Datalogic QuickScan QS6500 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon D130 Manuel utilisateur

Datalogic

Datalogic Magellan 9800i Manuel d'installation et d'exploitation

Datalogic

Datalogic DS6300 Manuel utilisateur

Datalogic

Datalogic Gryphon GM44XX Manuel utilisateur

Datalogic

Datalogic PowerScan BC96 Series Manuel utilisateur

Datalogic

Datalogic QuickScan i QD2100 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GM4100 guide Manuel utilisateur

Datalogic

Datalogic MAGELLAN 8500? Manuel d'installation et d'exploitation

Datalogic

Datalogic GRYPHON D Series Manuel utilisateur

Datalogic

Datalogic Gryphon I GD4100 Manuel d'installation et d'exploitation

Datalogic

Datalogic Gryphon I GBT4400 Manuel utilisateur

Datalogic

Datalogic QuickScan BC2030 Manuel utilisateur

Datalogic

Datalogic DSE0420 Guide de configuration rapide

Datalogic

Datalogic PowerScan Area Imager Manuel utilisateur

Datalogic

Datalogic QUICKSCAN 6000 PLUS Mode d'emploi

Datalogic

Datalogic MAGELLAN 3200VSI Manuel utilisateur

Datalogic

Datalogic GRYPHON BT SH3500 Manuel utilisateur

Datalogic

Datalogic GRYPHON BT Manuel utilisateur

Datalogic

Datalogic MAGELLAN 8200 Manuel d'installation et d'exploitation

Datalogic

Datalogic DS5100-X200 Manuel utilisateur

Manuels Lecteur de codes-barres populaires d'autres marques

POSMicro

POSMicro Datalogic PowerScan D7100 Manuel utilisateur

Marson

Marson MT780 Guide de configuration rapide

NCR

NCR RealPOS Manuel utilisateur

Motorola

Motorola SE3300 Guide de configuration rapide

Element

Element P130BT Manuel utilisateur

Motorola

Motorola Symbol LS3008 Manuel d'installation et d'exploitation

Meec tools

Meec tools OBD-II / VAG Manuel utilisateur

SICK

SICK CLP 100 Manuel utilisateur

Royal Tag SA

Royal Tag SA I-Read Manuel utilisateur

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuel utilisateur

Meteor

Meteor 8310 Manuel utilisateur

Denso

Denso BHT-500B Manuel utilisateur

Motorola

Motorola MP6000 Instructions de montage

Newland

Newland NLS-HR15-BT Manuel utilisateur

ARTDEV

ARTDEV AS-1310 Manuel utilisateur

Aopos

Aopos AS290 Manuel utilisateur

ENS

ENS 367-5455 Manuel utilisateur

Atid

Atid AT188N Plus Manuel utilisateur
