Data Video TLM-700HD Manuel utilisateur

7" TFT LCD Monitor

TLM-700HD

Quick Start Guide

www.datavideo-tek.com

Table of Contents

Warnings and Precautions.........................................................2

What's in the Box.......................................................................4

Introduction................................................................................4

Features ....................................................................................4

Connections & Control...............................................................5

Front Panel ................................................................................5

Rear Panel.................................................................................7

Menu Options ............................................................................8

Support Format........................................................................ 11

Specification ............................................................................12

Service & Support....................................................................13

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use

liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The unit

may fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are

provided for ventilation. To ensure safe and reliable operation of this

unit, and to protect it from overheating, do not block or cover these

openings. Do not place this unit on a bed, sofa, rug, or similar

surface, as the ventilation openings on the bottom of the cabinet will

be blocked. This unit should never be placed near or over a heat

installation unless proper ventilation is provided.

7. This product should only be operated from the type of power source

indicated on the marking label of the AC adapter. If you are not sure

of the type of power available, consult your Datavideo dealer or your

local power company.

8. Do not allow anything to rest on the power cord. Do not locate this

unit where the power cord will be walked on, rolled over, or

otherwise stressed.

9. If an extension cord must be used with this unit, make sure that the

total of the ampere ratings on the products plugged into the

extension cord do not exceed the extension cord’s rating.

10. Make sure that the total amperes of all the units that are plugged

into a single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or

short out parts that could result in risk of fire or electric shock. Never

spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not

attempt to service this product yourself. Opening or removing covers

that are marked “Do Not Remove” may expose you to dangerous

voltage points or other risks, and will void your warranty. Refer all

service issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified service

personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under normal

operating conditions. Adjust only those controls that are

covered by the operating instructions in this manual; improper

adjustment of other controls may result in damage to the unit

and may often require extensive work by a qualified technician

to restore the unit to normal operation;

e. When the product has been dropped or the cabinet has been

damaged;

f. When the product exhibits a distinct change in performance,

indicating a need for service.

What’s in the box?

Items Description Q’ty

1 TLM-700HD 1

2 Sunshield 1

3 Switching Adaptor DC 12V/1.5A 1

4 User’s Manual 1

Introduction

The Datavideo TLM-700HD is designed for outdoor field side for user; it

can be dust-proof, drop-proof, sunshade and carry easy, TLM-700HD is a

standard V-Mount enabling you to power the monitor using a universal

battery from a range of manufacturers, prefect for use in the field.

Features

z7” 16:9 Wide Screen Panel

zResolution: RGB 800X480 dots

zBrightness, Contrast, Colour, Tint Adjustable (Tint NTSC only)

zNTSC/PAL Auto Switching

z16:9 / 4:3 / 15:9 switchable

zCarry Case Included

zOSD Menu Control

zSupport Blue Only

zSupport Embedded Audio & Time Code

zBuilt in V-Mount kit

Connections & Control

Front Panel

Power Switch

Switches the power On / Off.

Stereo mini jack plug

For stereo headphones. The headphone volume is

controlled by the Audio Level Adjustments.

N.B. Audio source from HDMI or SDI audio embedded

audio.

Audio Level Adjustments

Allow you to adjust the headphones volume.

Source Button

Select Input source between SDI, YPbPr, CVBS, and HDMI.

Aspect Ratio Button

Sets the LCD aspect ratio to 15:9, 16:9 or 4:3

PATTERN

The PATTERN button can be generated a colour bar on

screen. Press the PATTERN button again to return normally

output.

BLUE

The BLUE button is set blue only enable, Press this button

to eliminate the red and green component of input signals.

Only the blue component of an input is displayed on the

screen. This facilitates adjustments of chroma and phase.

(Phase adjustment is effective only for NTSC signals).

Calls up the on-screen adjustment menu (See Menu

Options for more details).

UP / DOWN

Navigate the on-screen menu and set the functions & levels.

ENTER

Confirms the new settings or return to the default state.

Rear Panel

HD/SD - SDI input

BNC connector for SDI Input.

YUV input

BNC connectors for analog (Component) video inputs.

Composite video input

BNC connectors for analog (Composite) video inputs.

HDMI in interface

HDMI digital signal input connecter.

Support HDMI 1.1

Tally In

Send in red and yellow colour tally signal to tally LED. Red

means on-air, yellow means standby.

DC in socket

Connect the supplied 12V 1.5A PSU to this socket. The

connection can be secured by screwing the outer fastening

ring of the DC In plug to the socket.

Menu Options

1. Picture

- Press the MENU button into the system Picture setting mode.

- Press ENTER button into the Picture setting position.

- Press UP / DOWN button moving to the Brightness setting.

- Press ENTER button into the Brightness setting position.

- Press UP /DOWN button to setting the Brightness values from 0~100

- Press MENU button return to the Picture setting menu.

- Press SOURCE button exit the setting mode.

N.B. To select a different setting (Contrast, Saturation, Tint) use the UP /

DOWN buttons. Follow the same procedure to set the others values.

N.B. Brightness, Contrast and Saturation these three modes, the value all

the same as 0~100.

2. Audio

- Press the MENU button two times into the Audio setting mode.

- Press ENTER button into the Audio setting position.

- Press ENTER button to setting the audio volume indicator ON/OFF display on

the screen.

- Press SOURCE button exit the setting mode.

3. Func.

- Press the MENU button three times into the Func. setting mode.

- Press ENTER button into the Func. setting position.

- Press UP / DOWN button moving to the Center Mark setting.

- Press ENTER button to setting the center mark ON/OFF on the screen.

- Press UP / DOWN button moving to the Safety Zone setting.

- Press ENTER button to setting Safety Zone range (80, 90 or OFF).

- Press UP / DOWN button exit the setting mode.

N.B.To select a different setting (4:3 Screen, Cinema Zone) use the UP /

DOWN buttons. Follow the same procedure to set the others status.

4. Setup

- Press the MENU button four times into the Setup setting mode.

- Press ENTER button into the Setup setting position.

- Press UP / DOWN button moving to the OSD Timer setting.

- Press ENTER button into the OSD Timer setting position.

- Press UP / DOWN button to select the OSD display on screen time (value from

5~60 SEC).

- Press ENTER button to setting the OSD display on screen time.

- Press UP / DOWN button moving to the OSD Blending setting.

- Press ENTER button into the OSD Blending setting position.

- Press UP / DOWN button to select the OSD blending display on screen (value

from 0~7).

- Press ENTER button to setting the OSD blending display on screen

- Press UP / DOWN button moving to the Timer Code setting.

- Press ENTER button to setting the Time Code ON/OFF on the screen.

- Press UP / DOWN button moving to the TC Position setting.

- Press ENTER button to setting the Time Code Position on the screen (Left/Up,

Middle/Down, Right/Down, Right/Up)

- Press UP / DOWN button moving to the TC HD Line setting.

- Press ENTER button to setting the time code for HD line (8~20).

- Press UP / DOWN button moving to the TC SD Line setting.

- Press ENTER button to setting the time code for SD line (10~21).

- Press UP / DOWN button moving to the TC Font Size setting.

- Press ENTER button to setting the time code font size on the screen (Large or

Small).

- Press MENU button return to the Setup setting menu.

- Press SOURCE button exit the setting mode.
