Data Video DAC-50 Manuel utilisateur

Table of Contents

Warnings and Precautions......................................................3

Disposal....................................................................................4

Warranty ................................................................................... 5

Packing List............................................................................6

Introduction..............................................................................6

Features....................................................................................6

Connections & Controls..........................................................7

Front Panel.............................................................................7

Mini Switch Function...............................................................7

Rear Panel.............................................................................8

Up Conversion .......................................................................9

Down Conversion.................................................................10

Standard / Format Conversion.............................................15

Specifications......................................................................... 18

Service and Support………………………………………….....20

Disclaimer of Product and Services

The information offered in this instruction manual is intended as a guide only. At all

times, Datavideo Technologies will try to give correct, complete and suitable

information. However, Datavideo Technologies cannot exclude that some

information in this manual, from time to time, may not be correct or may be

incomplete. This manual may contain typing errors, omissions or incorrect

information. Datavideo Technologies always recommend that you double check the

information in this document for accuracy before making any purchase decision or

using the product. Datavideo Technologies is not responsible for any omissions or

errors, or for any subsequent loss or damage caused by using the information

contained within this manual. Further advice on the content of this manual or on the

product can be obtained by contacting your local Datavideo Office or dealer.

Warnings and Precautions

1. Read all of these warnings and save them for later reference.

2. Follow all warnings and instructions marked on this unit.

3. Unplug this unit from the wall outlet before cleaning. Do not use

liquid or aerosol cleaners. Use a damp cloth for cleaning.

4. Do not use this unit in or near water.

5. Do not place this unit on an unstable cart, stand, or table. The

unit may fall, causing serious damage.

6. Slots and openings on the cabinet top, back, and bottom are

provided for ventilation. To ensure safe and reliable operation of

this unit, and to protect it from overheating, do not block or cover

these openings. Do not place this unit on a bed, sofa, rug, or

similar surface, as the ventilation openings on the bottom of the

cabinet will be blocked. This unit should never be placed near or

over a heat register or radiator. This unit should not be placed in

a built-in installation unless proper ventilation is provided.

7. This product should only be operated from the type of power

source indicated on the marking label of the AC adapter. If you

are not sure of the type of power available, consult your

Datavideo dealer or your local power company.

8. Do not allow anything to rest on the power cord. Do not locate

this unit where the power cord will be walked on, rolled over, or

otherwise stressed.

9. If an extension cord must be used with this unit, make sure that

the total of the ampere ratings on the products plugged into the

extension cord do not exceed the extension cord’s rating.

10. Make sure that the total amperes of all the units that are plugged

into a single wall outlet do not exceed 15 amperes.

11. Never push objects of any kind into this unit through the cabinet

ventilation slots, as they may touch dangerous voltage points or

short out parts that could result in risk of fire or electric shock.

Never spill liquid of any kind onto or into this unit.

12. Except as specifically explained elsewhere in this manual, do not

attempt to service this product yourself. Opening or removing

covers that are marked “Do Not Remove” may expose you to

dangerous voltage points or other risks, and will void your

warranty. Refer all service issues to qualified service personnel.

13. Unplug this product from the wall outlet and refer to qualified

service personnel under the following conditions:

a. When the power cord is damaged or frayed;

b. When liquid has spilled into the unit;

c. When the product has been exposed to rain or water;

d. When the product does not operate normally under

normal operating conditions. Adjust only those

controls that are covered by the operating

instructions in this manual; improper adjustment of

other controls may result in damage to the unit and

may often require extensive work by a qualified

technician to restore the unit to normal operation;

e. When the product has been dropped or the cabinet

has been damaged;

f. When the product exhibits a distinct change in

performance, indicating a need for service.

Disposal For EU Customers only - WEEE Marking

office.

This symbol on the product indicates that it should not

be treated as household waste. It must be handed

over to the applicable take-back scheme for the

recycling of Waste Electrical and Electronic

Equipment. For more detailed information about the recycling of this

product, please contact your local Datavideo

Warranty

Standard Warranty

•Datavideo equipment is guaranteed against any manufacturing

defects for one year from the date of purchase.

•The original purchase invoice or other documentary evidence

should be supplied at the time of any request for repair under

warranty.

•Damage caused by accident, misuse, unauthorized repairs, sand,

grit or water is not covered by this warranty.

•All mail or transportation costs including insurance are at the

expense of the owner.

•All other claims of any nature are not covered.

•Cables & batteries are not covered under warranty.

•Warranty only valid within the country or region of purchase.

•Your statutory rights are not affected.



Two Year Warranty

All Datavideo products purchased after 01-Oct.-2008 qualify for a free

one year extension to the standard Warranty, providing the product is

registered with Datavideo within 30 days of purchase. For information

on how to register please visit www.datavideo.com or contact your

local Datavideo office or authorized Distributors

Certain parts with limited lifetime expectancy such as LCD Panels,

DVD Drives and Hard Drives are only covered for the first 10,000

hours, or 1 year (whichever comes first).

Any second year warranty claims must be made to your local

Datavideo office or one of its authorized Distributors before the

extended warranty expires.

Packing List

Items Description Q’ty

1 DAC-50 1

2 Switching Adaptor 12V / 0.5A 1

3 DAC-50 Instruction Manual 1

Introduction

The Datavideo DAC-50 is standalone SDI or HD-SDI to YUV or HD-

YUV video converter. The format of the component output is chosen

based on the supplied SDI input and a combination of Mini switch

choices. This unit allows conversion from HD to SD, SD to HD,

Aspect Ratio change from 4:3 to 16:9 and even standard conversion

from PAL to NTSC or vice versa.

Features

6 Mode Resolutions

DC 12V input

1x HD/SD-SDI Video Input (BNC x1)

1x HD/SD YUV component output (BNC x3)

Accepted HD/SD-SDI Input Resolutions:

720x480 Interlace

720x576 Interlace

1280x720 / 59.94Hz Progressive

1280x720 / 50Hz Progressive

1920x1080 / 59.94Hz Interlace

1920x1080 / 50Hz Interlace

HD/SD YUV Output Resolutions:

720x480 Interlace

720x576 Interlace

1280x720 / 59.94Hz Progressive

1280x720 / 50Hz Progressive

1920x1080 / 59.94Hz Interlace

1920x1080 / 50Hz Interlace

Connections & Controls

Front Panel

HD/SD - SDI Input

4:2:2 SDI Video data supports SMPTE 292M

standard at 1.5G Mbps.

SDI delivers professional level video signals over

long distances when using the correct cabling and

repeaters.

Mini Switch

Uses the mini switch to select the required output

format.

Mini Switch Function

Mini Switches setting for video output

ON-SD output Mode

OFF - HD output Mode

ON OFF ON OFF

D2 50Hz 59.94Hz 50Hz 59.94Hz

D3 0 IRE 7.5 IRE 1080i 720p

D4 16:9 4:3 16:9 4:3

D5 CVBS YUV YUV YUV

D6 On: Aspect ratio conversion is disabled

Off: Aspect ratio conversion is enabled

Rear Panel

DC In Socket

Connects the supplied 12V 0.5A PSU to this socket.

The connection can be secured by screwing the

outer fastening ring of the DC In plug to this socket.

Power Switch

Switches the power On / Off.

HD/SD YUV

HD/SD YUV component analogue output connectors

Alternatively the Y BNC connector can be used as a

Composite (CV) output connector when Mini

switches 1 and 5 are moved to the ON position.

Up Conversion

No SDI Input YUV Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

1 480i

4:3 720/59.94p

16:9 OFF OFF OFF ON OFF

D1 D2 D3 D4 D5

2 480i

4:3 720/59.94p

4:3 OFF OFF OFF OFF OFF

D1 D2 D3 D4 D5

3 480i

4:3 720/50p

16:9 OFF ON OFF ON OFF

D1 D2 D3 D4 D5

4 480i

4:3 720/50p

4:3 OFF ON OFF OFF OFF

D1 D2 D3 D4 D5

5 480i

4:3 1080/59.94i

16:9 OFF OFF ON ON OFF

D1 D2 D3 D4 D5

6 480i

4:3 1080/59.94i

4:3 OFF OFF ON OFF OFF

D1 D2 D3 D4 D5

7 480i

4:3 1080/50i

16:9 OFF ON ON ON OFF

D1 D2 D3 D4 D5

8 480i

4:3 1080/50i

4:3 OFF ON ON OFF OFF

No SDI Input YUV Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

9 576i

4:3 720/59.94p

16:9 OFF OFF OFF ON OFF

D1 D2 D3 D4 D5

10 576i

4:3 720/59.94p

4:3 OFF OFF OFF OFF OFF

D1 D2 D3 D4 D5

11 576i

4:3 720/50p

16:9 OFF ON OFF ON OFF

D1 D2 D3 D4 D5

12 576i

4:3 720/50p

4:3 OFF ON OFF OFF OFF

D1 D2 D3 D4 D5

13 576i

4:3 1080/59.94i

16:9 OFF OFF ON ON OFF

D1 D2 D3 D4 D5

14 576i

4:3 1080/59.94i

4:3 OFF OFF ON OFF OFF

D1 D2 D3 D4 D5

15 576i

4:3 1080/50i

16:9 OFF ON ON ON OFF

D1 D2 D3 D4 D5

16 576i

4:3 1080/50i

4:3 OFF ON ON OFF OFF

Up Conversion continued

No SDI Input YUV Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

17 720/59.94p

16:9 1080/59.94i

16:9 OFF OFF ON ON OFF

D1 D2 D3 D4 D5

18 720/59.94p

16:9 1080/59.94i

4:3 OFF OFF ON OFF OFF

D1 D2 D3 D4 D5

19 720/59.94p

16:9 1080/50i

16:9 OFF ON ON ON OFF

D1 D2 D3 D4 D5

20 720/59.94p

16:9 1080/50i

4:3 OFF ON ON OFF OFF

No SDI Input YUV Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

21 720/50p

16:9 1080/59.94i

16:9 OFF OFF ON ON OFF

D1 D2 D3 D4 D5

22 720/50p

16:9 1080/59.94i

4:3 OFF OFF ON OFF OFF

D1 D2 D3 D4 D5

23 720/50p

16:9 1080/50i

16:9 OFF ON ON ON OFF

D1 D2 D3 D4 D5

24 720/50p

16:9 1080/50i

4:3 OFF ON ON OFF OFF

Down Conversion

No SDI Input YUV Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

25 720/59.94p

16:9 480i

16:9 , 0 IRE ON OFF ON ON OFF

D1 D2 D3 D4 D5

26 720/59.94p

16:9 480

4:3 , 0 IRE ON OFF ON OFF OFF

D1 D2 D3 D4 D5

27 720/59.94p

16:9 576i

16:9 ON ON OFF ON OFF

D1 D2 D3 D4 D5

28 720/59.94p

16:9 576i

4:3 ON ON OFF OFF OFF

No SDI Input CVBS Output MINI Switch Setup (D6 OFF)

D1 D2 D3 D4 D5

29 720/59.94p

16:9 480i

16:9 , 0 IRE ON OFF ON ON ON

D1 D2 D3 D4 D5

30 720/59.94p

16:9 480

4:3 , 0 IRE ON OFF ON OFF ON

D1 D2 D3 D4 D5

31 720/59.94p

16:9 576i

16:9 ON ON OFF ON ON

D1 D2 D3 D4 D5

32 720/59.94p

16:9 576i

4:3 ON ON OFF OFF ON

Autres manuels pour DAC-50

Table des matières

Autres manuels Data Video Convertisseur de média

Data Video

Data Video DAC-8P 4K Manuel utilisateur

Data Video

Data Video DAC-6 Manuel utilisateur

Data Video

Data Video DVK-400 Manuel utilisateur

Data Video

Data Video DAC-50 Manuel utilisateur

Data Video

Data Video DAC-75T Manuel utilisateur

Data Video

Data Video NVS-40 Manuel utilisateur

Data Video

Data Video DAC-70 Manuel utilisateur

Data Video

Data Video DAC-15 Manuel utilisateur

Data Video

Data Video DAC-100 Manuel utilisateur

Data Video

Data Video NVS-40D Manuel utilisateur

Data Video

Data Video NVS-40 Manuel utilisateur

Data Video

Data Video DAC-9P Manuel utilisateur

Data Video

Data Video DAC-9 Manuel utilisateur

Data Video

Data Video BAC-03 Guide de référence

Data Video

Data Video BAC-03 Manuel utilisateur

Data Video

Data Video NVD-35 MARK II Manuel utilisateur

Data Video

Data Video DAC-60 Manuel utilisateur

Data Video

Data Video DAC-2 Manuel utilisateur

Data Video

Data Video PD-10 Manuel utilisateur

Data Video

Data Video DAC-100 Manuel utilisateur

Data Video

Data Video DDC-2512 Manuel utilisateur

Data Video

Data Video KMU-100 Manuel utilisateur

Data Video

Data Video DAC-60 Manuel utilisateur

Data Video

Data Video DAC-8P Manuel utilisateur

Manuels Convertisseur de média populaires d'autres marques

SoundTraxx

SoundTraxx Blunami BLU-2200 Manuel utilisateur

SPROLINK

SPROLINK VA1 Manuel utilisateur

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manuel utilisateur

Nikon

Nikon AF-S TC-20E III Manuel utilisateur

Axis

Axis AXIS Q7406 Manuel utilisateur

Omega

Omega TAC80B-J Manuel utilisateur

Zoom

Zoom Thunderbolt TAC-2R Manuel utilisateur

OST

OST iConverter 10/100M Manuel utilisateur

Vertiv

Vertiv Netsure Manuel utilisateur

birddog

birddog MINI Manuel utilisateur

Roland

Roland GI-10 Manuel utilisateur

Wallenstein

Wallenstein WX310 Manuel utilisateur

Pace

Pace MSS 200-1 Manuel utilisateur

Solar Converters

Solar Converters EQ 12/24-50 Manuel utilisateur

CYP

CYP EL-7400V Manuel utilisateur

TIE

TIE MIDI 1i1o Manuel utilisateur

DCS

DCS Vivaldi Upsampler Manuel utilisateur

Westermo

Westermo MCW-211 SERIES Manuel utilisateur
