USER GUIDE

NDUSTRIAL

ATA

OMMUNICATIONS

It is essential that all instructions contained in the User Guide are followed precisely to ensure proper operation of equipment.

SRM6200E-SLC

Frequency Hopping Spread Spectrum

Ethernet Radio Modem

DATA-LINC GROUP

PN161-09990-002C

Product User Guide

FCC Notification

This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:

1) This devicemaynot causeharmfulinterference and

2) This devicemustaccept any interferencereceived,including interferencethat may

causeundesired operation.

The device must be operated as supplied by Data-Linc Group.Any changes or modifications made to the

devicewithout theexpress writtenapproval ofData-Linc Groupmay voidthe user’sauthorityto operatethe

device.

Caution: This device has a maximum transmitted output power of 955 mW. It is required that the

transmit antenna be kept at least 23 cm away from nearby persons to satisfy FCC RF exposure

requirements.

Note: This equipment has been tested and found to comply with the limits for a ClassAdigital device, pursuant

topart 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful

interferencein aindustrial installation.This equipmentgenerates, usesand canradiate radiofrequency energy

and, if not installed and used in accordance with the instructions, may cause harmful interference to radio

communications.However, thereis noguarantee thatinterference willnot occur in a particular installation.If

thisequipment doescause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the

followingmeasures:

Reorientor relocatethereceiving antenna.

Increasethe separation betweentheequipment andreceiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consultthe dealeror anexperienced radio/TVtechnician for help.

Note: Wheneverany Data-Linc Group SRM series modem is placed inside an enclosure a label must be

placed on the outside of that enclosure which includes the modem’s FCC ID.

Thefollowing antennasare approved for use withData-Linc Group’s900 MHz series modems.

NOTE: Per FCC Rules, the maximum power allowed at the antenna is 4 Watts E.I.R.P.

900MHz Directional Antenna

Gain Manufacturer Manufacture Model Number Data-Linc Model Number

8.2 dBi Larsen YA6-900W A-YB

12.2 dBi Larsen YA0006 A-Y10B

900MHz Omni-Directional Antenna

Gain Manufacturer Manufacture Model Number Data-Linc Model Number

5.2 dBi Maxrad MAX-9053 A-OB

7.2 dBi Maxrad BMEFC8985HD A-O5B

0 dBi Ying Hao YH920801/AD-725-A-1 A-06/ADJ

0 dBi Centurion EXC-902-BN A-06BH-3S / 10S (**)

(**) This part number refers to an antenna kit(s). The 0 dBi refers to the antenna portion of the kit.

Note: The antenna used for this device must be professionally installed on a fixed-mounted permanent

outdoor structure for satisfying RF exposure requirements, including antenna co-location requirements

of1.1307(b)(3).

DATA-LINC GROUP

SRM6200E-SLCUser’sGuide

PN161-09990-002C

rev 3/29/04

Table of Contents Page

Introduction 3

Quick Start 4

ModemConfiguration 6

Main Menu Option (0): Set Operation Mode 8

Main Menu Option (1): Set Baud Rate 10

Main Menu Option (2): Edit Call Book 10

Main Menu Option (3): Edit Radio Transmission Characteristics 12

Main Menu Option (4): Show Radio Statistics 16

Main Menu Option (5): Edit Multi-Point Parameters 18

Main Menu Option (8): Password 21

ModemLocation 22

UsinganExternalAntenna 22

Modem Front Panel LED’s 23

Sample Data Communication Links 25

Technical Specifications 27

Troubleshooting 28

Technical Support 29

ReturnMaterialAuthorization 29

Contact Information 29

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○

DATA-LINC GROUP

2PN161-09990-002C

rev 3/29/04

SRM6200E-SLCUser’sGuide

DATA-LINC GROUP

SRM6200E-SLCUser’sGuide

PN161-09990-002C

rev 3/29/04

Introduction

Data-LincGroup’sSRM6200E-SLC has beendesigned to mountin anAllen-Bradley SLC 500Slot Rack.The SRM6200E-

SLCtransceiver modem isahigh performance,wirelessradio modem designedforheavy-duty industrialdata

communicationsin the 902-928MHzlicense-free band.Itemploys advanced spreadspectrumfrequency hoppinganderror

detectiontechnology to achievevery reliable,noiseand interferenceimmuneoperation.Ahigh RFdatarateof 188kbpsand

superiorsensitivity provideultra reliable dataintegrity.TheSRM6200E-SLC hasa rated rangeof upto 25 miles(40 km)and

an installed range of up to 35 miles (56 km) in optimal conditions with line-of-sight and an omni directional antenna. This can

alsobe extended furtherwithrepeaters orhighergain antenna.

TheSRM6200E-SLC can beoperated inanumber ofdifferentmodes tosatisfya broadrange of communications

requirements.It canbeconfigured forpoint-to-point or multi-pointoperation withanunlimited numberof remote siteson a

singlemaster dependingon data throughputrequirements. Repeaterscan beused in thesystem toextend range and

eliminate dead RF zones that are blocked by obstructions.

An external antenna can be used with up to two hundred feet of coax. This provides a boost in signal strength and decreases

induced noise levels. With an external antenna, radio modems can be located inside buildings or metallic enclosures.

Equippedwith a10 Base-T Ethernetport, theSRM6200E-SLC is easilyconnected viastandard 10 Base-TCategory 5patch

cord(provided) toanAllen-Bradley SLC5/05 CPU ENET port,hubor anyother device equippedwith a 10Base-Tnetwork

interface.

TheUser Guide coversthe operating modesand configurations thatare available tousers of theSRM6200E-SLC. Italso

providesthe userwith bench testinginstructions, technicalinformation andspecifications.

In most applications, the SRM6200E-SLC comes pre-configured for the application in which it is going to be used. In most

casesno otherconfigurationis required.If you areunsure if themodem needsfurtherconfiguration, pleasecontact Data-Linc

Group.

DATA-LINC GROUP

4PN161-09990-002C

rev 3/29/04

SRM6200E-SLCUser’sGuide

Quick Start

TheSRM6200E-SLC comes pre-configuredforyour application (unlessotherwiserequested). In mostcases,configuration

settingsare notrequired.

Although each modem is tested before shipment, it is recommended that a bench test be done before the modem is

installed in its application.

In all applications, there is a master modem and one or more remotes. Some applications may also have one or more

repeaters. This “Quick Start” will assume that there is a repeater in the system. If there is not, ignore the parts that talk

aboutrepeaters, asthe remote modems should operatethe samewith or withoutrepeaters.

TheSRM6200E-SLCisavailable in threedifferent powerconfigurations:

• SRM6200E-SLC is a 12VDC powered device that is designed to take 12VDC in on the barrel jack on the front

panel.

•SRM6200E-SLC/BPis a24VDCpowered devicethat receives powerdirectly fromthe backplane anddoes not

need a separate power supply. Be sure that your 1746 chassis has a large enough supply — Data-Linc Group

recommends the use of the P-4 power supply chassis (a wall transformer power supply has been included for

bench testing purposes).

• SRM6200E-SLC/24Vis a24VDC powered devicethat isdesigned totake 24VDC inon theremovable screw

terminal connector on the front panel (please note the polarity: positive side marked “+” on the top if you are

supplying your own power).

Locate the modem labeled “Master” and connect its power supply to an appropriate 120VAC power source, then connect it

to the modem. The “P” LED should come on and stay on

Note: on all modems, the “RF Link” LED will come on for the first few seconds after power up.

Next, locate the modem(s) labeled “Repeater” and connect to power. The LED “P” and “RF Link” should come on and stay

on. Now locate the modem(s) labeled “Remote” and connect to power. The LED “P” and “RF Link” should come on and stay

on.The modems are now ready to carry Ethernet data.

Connectthe “Master” and“Remote” (or“Repeater/Remote”if yournetworkhas one)to the Ethernetequipment that hasbeen

pretestedfor operation. Thedevicehas beendesignedwith a crossoverswitch.The crossoverfunctioninterchanges the

transmitand receivepairsremoving theneedfor acrossover cable incertain situations.

The SRM6200E-SLC crossover switch has been factory set in the crossover position. If the system is connected and the

LAN link LED is not lit, the crossover switch (SW3- Diagram 3, pg. 24) may need to be moved to the straight through

position.

DATA-LINC GROUP

SRM6200E-SLCUser’sGuide

PN161-09990-002C

rev 3/29/04

Tochange thecrossover switch removethe SRM6200E-SLC fromtheAllen-BradleySLC500 Slot Rack.Underthe edgeof

the enclosure is a black and silver slide switch (S3- Diagram 3, page 24). If connecting to an Ethernet hub, the crossover

switch should be set in the straight through (left) position. If connecting to a PC, PLC or most other Ethernet interface

equippeddevices, thecrossover switch shouldbe setinthe crossover(right) position.

Note: TheSRM6200E-SLC willnot support“Peer toPeer” communications. The equipment thatis attachedto the

SRM6200E-SLCmust becapableof operatingin a “Master(host) toRemote” network

It is recommended that a “Ping” test be done at this point. This can be done in either direction, but remember that only a

“Master to Remote” or “Remote to Master” connection can be established through the modems.Also note that because of

the MAC filtering done by the modems, if you take a piece of Ethernet equipment on one side of the SRM6200E-SLC

networkand move it to the other sideof saidnetwork, youmust power down both the “Master” and the effected“Remote” in

order to re-establish connectivity through the modems. If powering down the modem is not practical to the applications, the

modems will rebuild the MAC filter table in approximately six minutes and communications should return. Once a successful

“Ping” test has been done, the modems are ready for communication. If the “Ping” test was not successful, please refer to

the trouble shooting section of this manual or contact Data-Linc Group tech support for assistance.

DATA-LINC GROUP

6PN161-09990-002C

rev 3/29/04

SRM6200E-SLCUser’sGuide

Configuration

Inmost cases,the SRM6200E-SLCcomes pre-configured fromthe factory. However, itmay sometimes be necessary to

changethe configuration.Most parameters arechanged inthe radiosection of themodem althoughthere are a few settings

that are set using switches. If you are not sure if you need to change the configuration of the SRM6200E-SLC, you probably

don’t.Please contact Data-LincGroup for furtherinformation if youare unsure aboutyour configuration.

Switch Settings

To access the switches, remove the modem from the SLC Rack. The switch bank (SW1-Diagram 3, pg. 24) is located in the

center of the large PCB.

Note: Leave switch positions 4, 5 and 6 at factory setting of off unless otherwise directed by Data-Linc Group.

Changingthese switches requiresaradio parameterschange.

MAC Filtering Function

Alldevices capableof generating Ethernet traffichave aMAC (MediumAccess Control)address. This address is usedin the

communicationsof Ethernetdata.

The SRM6200E-SLC is factory set to perform MAC level filtering. This means that it learns all the MAC addresses from the

LAN it is connected to, and only forwards data packets across the radio links which are destined for addresses located

across the radio link. The MAC filtering function is enabled by setting switch (SW2-Diagram 3, pg.24) to the on position.

The MAC address table can store up to 10,000 addresses. Each entry to the table has a lifetime of six minutes after which

the address is deleted. This dynamic table building allows for the possibility of stations being removed from the LAN. The net

result of this filtering functionality is the reduction of unnecessary network traffic across the radio link.

Note: ManyEthernet networks have data packets that arenot coveredby theMAC filterfunction (broadcastpackets

forexample). These packetscan occupy tremendousamount of thenetwork’s bandwidth andoverwhelm the

SRM6200E-SLCsection ofthe network. Ifthe SRM6200E-SLC’sare goingto be installedwhere theyare linked to

anopen network(on officenetwork, etc.),a properlyconfigured routeror switchshould beinstalled toprotect the

modemsfrom excessivedata traffic. Ifyou areunsure aboutyour network, pleaseconsult withyour network

administrator.

DATA-LINC GROUP

SRM6200E-SLCUser’sGuide

PN161-09990-002C

rev 3/29/04

Radio Parameter Configuration

TheSRM6200E-SLC allowsyou to set several parameterstosuit yourparticularapplication.Alladjustmentsare done

throughthe SRM6200E-SLCsetup program, a user interfacethat eliminatesthe need for setup diskettesor customsoftware.

To access the configuration menu, connect the radio modem’s configuration port to any terminal program with port settings of

19.2Kbaud, 8 data bits, no parity and one stop bit. With the modem connected to the PC running the terminal program,

pressthe Configurebutton. While anyterminal programwill work, examplesfor thismanual were generatedusing the

MicrosoftWindows2000application “HyperTerminal.”

Note: Whenusing HyperTerminal, set Handshakingto noneand usea standard straight throughcable. Ifyou are

using something other than HyperTerminal, it may be necessary to use a cable that has pins 4 and 6 connected

togetheron themodemside ofthecable. ContactData-Linc for furtherinformation.

Table 1: Terminal Settings

Whenthe setup programis invokedtheRF “IN”LEDon theSRM6200E-SLC front panelwill flash oncewhen the Configure

button is pressed and the RF “Link” LED will remain on for the entire time the radio modem is in setup mode.

Themain menuprovides the radiomodem’s uniquecallbook numberand the setof choicesfor editing theoperational

parametersandviewingtheperformance data.

Figure 1: Main Menu

retemaraP gnitteS

etaRduaB00291

stiBataD8

ytiraPenoN

stiBpotS1

lortnoCwolFenoN

DATA-LINC GROUP

8PN161-09990-002C

rev 3/29/04

SRM6200E-SLCUser’sGuide

Main Menu Option (0): Set Operation Mode

When item (0) is selected, the Operation Mode Menu appears as shown in figure 2. The Operation Mode option is used to

designatethe methodin which theparticular SRM6200E-SLCwill be used.The SRM6200E-SLCoperates in amaster to

remote configuration; therefore, any radio modems that are intended to operate together must be set up as such. In a point-

to-point setup, either the Master or Remote may be used on either end of the communications link. One consideration when

setting up the radio modems is that a number of parameters are controlled by the settings in the Master; therefore, you may

wish to deploy the Master on the communications end where you will have easier access to the radio modem.

Figure 2: Mode Menu

Shownbelow are examplesettings. Pleasereferto suppliedconfigurationsheets foryour modem’s configuration.

(0) Point-to-point Master

TheSRM6200E-SLC operates ina master/remote configuration.When designatedasa masterinpoint-to-point mode,

the radio modem will call any or all remotes it is instructed to call in the call book. The Master determines the settings

usedfor allRadio Transmission Characteristics(except power),regardless ofthe settings inthe remotesand/or

repeaters.

(1) Point-to-Point Remote

When set up as a point-to-point remote, an SRM6200E-SLC will communicate with any master in its call book, either

directly or through one or two repeaters. When functioning as a remote, the Entry to Call feature in the radio modem’s

call book (Figure 3) is not operational. The remote will communicate with any master on the list that calls.

(2) Point-to-Multi-Point Master

The SRM6200E-SLC may be set to run in multi-point mode, which allows one master to simultaneously be in

communicationwith numerousremotes.Apoint-to-multi-point master willcommunicate onlywith other radiomodems

designatedaspoint-to-multi-point remotesorpoint-to-multi-point repeaters.

(3) Point-to-Multi-Point Remote

Setting (3) allows the radio modem to operate as a remote in a multi-point network.

Pleaserefer tothesection entitledmulti-point operation, formore information onrunning amulti-point network.

Table des matières

Autres manuels Data-Linc Group Modem

Data-Linc Group

Data-Linc Group FLC910E Manuel utilisateur

Data-Linc Group

Data-Linc Group MDL500/MR Manuel utilisateur

Data-Linc Group

Data-Linc Group PlantLinc PLR5000 Manuel utilisateur

Data-Linc Group

Data-Linc Group DLM4500 Manuel utilisateur

Data-Linc Group

Data-Linc Group FastLinc FLC820G Manuel utilisateur

Data-Linc Group

Data-Linc Group LCM100 Manuel utilisateur

Data-Linc Group

Data-Linc Group DLM4100 Manuel utilisateur

Data-Linc Group

Data-Linc Group DLM4000 Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
