DAPAudio CS-330 Manuel utilisateur

CS-330

Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands

Ordercode: D6562

MANUAL

ENGLISH

CS-330

Ordercode: D6562

Warning

Unpacking Instructions

Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure

that all parts are present, and have been received in good condition. Notify the dealer immediately and

retain packing material for inspection if any parts appear damaged from shipping or the carton itself

shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be

returned to the factory, it is important that the fixture be returned in the original factory box and packing.

Your shipment includes

DAP Audio CS-330 20 Watt 4x3” Column Speaker

Safety precaution

Keep this manual for future reference.

Clean only with dry cloth

Take care of your speaker wires, they should be free of damage. Damaged speaker wires might

result in poor sound quality and can damage amplifiers.

Make sure the ceiling/wall can support the speakers weight.

No main power shall be connected to the loudspeakers, doing so will damage the speaker.

This apparatus should only be serviced by qualified personnel. If not warranty might be void.

Use cable of the right gauge, certainly for long runs.

Use cables with clear color indication and maintain polarity throughout the whole system.

Avoid loud feedback from microphones, this can damage your speaker.

Please check the units condition after unpacking. If the outside of the carton box has been

damaged, inform your shipper immediately.

Take notice that this speaker is intended for indoor use only. Do not expose the speaker to rain or

moisture.

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY!

CAUTION! Be careful with your operations.

With a dangerous voltage you van suffer

a dangerous electric shock when touching the wires!

CS-330

Ordercode: D6562

Specifications

Power taps:

10/20W

Line Voltage:

100V

Frequency response:

170 –15kHz

Sensitivity:

91dB

Material:

Aluminium

Colour:

White

IP rating:

IP-40

Dimensions (LxWxH):

405 x 106 x 75mm

Weight:

2 Kg

Dimensions Mounting

CS-330

Ordercode: D6562

Troubleshooting

No Sound

Always check to see if all of the cables and cords are connected. Always turn off power to the area before

checking the wires to prevent electrical shock.

If everything checks out and there is still no sound, revisit the manufacturer’s instructions to make sure they

were followed during installation. If everything was installed correctly and there is still no sound, you may want

to consider bringing in a professional to take a look at your speakers.

Return Procedure

Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.

Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned

without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call

Highlite 0031-455667723 or mail [email protected] and request an RMA prior to shipping the fixture. Be

prepared to provide the model number, serial number and a brief description of the cause for the return. Be

sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the customer’s

responsibility. Highlite reserves the right to use its own discretion to repair or replace product(s). As a suggestion,

proper UPS packing or double-boxing is always a safe method to use.

Note: If you are given an RMA number, please include the following information on a piece of paper inside the

box:

1) Your name

2) Your address

3) Your phone number

4) A brief description of the symptoms

Claims

The client has the obligation to check the delivered goods immediately upon delivery for any short-comings

and/or visible defects, or perform this check after our announcement that the goods are at their disposal.

Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be reported to the

carrier upon receipt of merchandise. It is the customer's responsibility to notify and submit claims with the

shipper in the event that a fixture is damaged due to shipping. Transportation damage has to be reported to

us within one day after receipt of the delivery. Any return shipment has to be made post-paid at all times.

Return shipments must be accompanied with a letter defining the reason for return shipment. Non-prepaid

return shipments will be refused, unless otherwise agreed in writing. Complaints against us must be made

known in writing or by fax within 10 working days after receipt of the invoice. After this period complaints will

not be handled anymore. Complaints will only then be considered if the client has so far complied with all

parts of the agreement, regardless of the agreement of which the obligation is resulting.
