Operating Instructions
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
2DEHC.PS.300.D1.02
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
3
DEHC.PS.300.D1.02
1. Introduction
1.1 General description ....................................................................................................4
1.2 Important to know......................................................................................................4
1.3 Contents of the package...........................................................................................4
2. Starting and charging the gateway
2.1 View of Danfoss Bluetooth® Gateway ..................................................................5
2.2 Switching on .................................................................................................................5
2.3 Charging the battery..................................................................................................6
2.4 Recommendations......................................................................................................6
3. Pairing the gateway
3.1 Windows XP...................................................................................................................7
3.2 Windows Vista ...........................................................................................................10
4. Configuring Tool4Cool®...............................................................................................14
5. Technical data overview..............................................................................................17
6. Gateway status ................................................................................................................18
7. Safety notes ......................................................................................................................19
8. Troubleshooting
8.1 Error message............................................................................................................20
8.2 LED2 is flashing red..................................................................................................20
2.3 Top causes of errors.................................................................................................20
8.4 There is no connection between the computer
and the device served by the gateway ............................................................21
Contents
1. Introduction
1.1 General
description
1.3 Contents of
the package
The Danfoss Bluetooth® gateway is used in the connection between a controller and a computer when
running Tool4Cool® software.
The gateway is equipped with a high-performance rechargeable battery, so an external power source
is not required. This makes the gateway particularly suitable in mobile applications.
Under normal circumstances no driver installation is required and the gateway functions fully inde-
pendently of the operating system platform in use. However if problems arise, please refer to
section 8.
Please read the instructions in this handbook before using the gateway for the first time.
Bluetooth® RS485 gateway with male DSUB-9 plug connector
USB power supply
Operating Instructions
1.2 Important to
know
1. The Bluetooth® gateway is battery driven. It is not fully charged upon new delivery.
Charging the gateway may take up to 2 hours. The gateway may be used while charging.
2. When fully charged the gateway will run continuously 8 – 12 hours without power supply.
3. The maximum range is ~10 meters.
4. The Bluetooth® gateway may be permanently installed in an application.
In permanent applications the charger enclosed upon delivery is used as a power supply.
5. If no serial communication occurs over a period of 60 seconds then the Bluetooth® gateway will
shut down to conserve the battery. If the finding and pairing of the Bluetooth® device takes more
than 60 seconds then the gateway will shut down. In the event that the gateway shuts down in the
middle of an operation simply turn it on again and repeat the operation.
6. Requirements for Bluetooth® adapters:
- PC or adapter has to be a class 1 or class 2 Bluetooth® transmitter. The Danfoss Bluetooth®
gateway is a class 2 transmitter.
- Dedicated software has to support Bluetooth® serial ports.
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
4DEHC.PS.300.D1.02
2. Starting and charging
the gateway
2.1 View of Danfoss
Bluetooth®
Gateway
On/Off push button
switch
LED1 (battery status)
LED2 (operating status)
Antenna
USB port for
charging battery
2.2 Switching on To switch on the gateway:
1. Plug the Danfoss Bluetooth® gateway into the RS485 communication interface of the controller.
2. Switch on the Danfoss Bluetooth® gateway.
3. The gateway enters operating mode. LED2 flashes green rapidly for approx. 3 seconds and then
slowly green. (For LED sequences, please see the overview in section 6.)
DC power jack
6 -24V DC supply
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
5
DEHC.PS.300.D1.02
2.3 Charging the
battery
The Danfoss Bluetooth® gateway is equipped with a high-performance rechargeable battery, so an
external power source is not required. This makes the gateway particularly suitable in mobile applica-
tions.
We recommend charging the battery before using the device for the first time.
To avoid overcharging and faulty operation, always use the battery charger supplied with the gateway.
The time required for full charging is approximately 2 hours.
To charge the battery:
1. Connect the charger to the USB port at the rear of the Bluetooth® gateway
2. Then connect the charger to the wall socket.
3. The status of the charging process is indicated by LED1 (“Charging”) on the gateway, as follows:
Battery status, during charging with the USB power supply:
LED1 Meaning
RED Battery is charging - charge duration to full capacity for empty battery approx. 2 hours
OFF RS485 Danfoss Bluetooth® gateway is not connected to the charger or the battery is fully charged.
2.4 Recommendations 1. Keep the gateway fully charged, so it is ready for field work.
2. Keep an USB-cable/charger as a backup in the car just for the case someone forgets to charge the
gateway battery
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
6DEHC.PS.300.D1.02
3. Pairing the gateway
In order to communicate, Bluetooth® devices must first be paired. Pairing is performed before using
the device for the first time. Pairing does not need to be repeated for subsequent use.
Please choose the operating system installed on your computer.
3.1 Windows XP 1. Attach or turn on the Bluetooth® radio adapter (transceiver) for your Windows XP computer.
2. Turn on the Danfoss Bluetooth® gateway by pressing briefly on the push button.
The LED will blink green.
Please note!:
The gateway runs for 60 seconds before shutting down automatically.
At each step of the pairing process, check that the LED is still blinking.
If one stage of the pairing fails, turn the gateway on again, and try again.
3. Open Bluetooth® Devices in Control Panel/Printers and Other Hardware (Category view)
or Control Panel (Classic view).
Control Panel Category View:
Control Panel Classic View:
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
7
DEHC.PS.300.D1.02
4. On the Devices tab, click Add.
5. Select the My device is set up and ready to be found check box, and then click Next.
6. Click on the Danfoss Bluetooth® gateway shown in the dialog, and then click Next.
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
8DEHC.PS.300.D1.02
7. Click Use the passkey found in the documentation, and then type the passkey: 1234.
8. Note the outgoing COM port, in this example COM 9. Then click Finish to complete pairing.
9. The COM port can also be viewed in the COM ports tab of the Bluetooth® devices dialog.
Make a note of the Outgoing COM port (in this example, COM9):
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
9
DEHC.PS.300.D1.02
3.2 Windows Vista 1. Attach or turn on the Bluetooth® radio adapter (transceiver) for your Windows Vista computer.
2. Turn the Danfoss Bluetooth® gateway on by pressing briefly on the push button.
The LED will blink green.
Please note!:
The gateway runs for 60 seconds before shutting down automatically.
At each step of the pairing process, check that the LED is still blinking .
If one stage of the pairing fails, turn the gateway on again, and try again.
3. Open Bluetooth® Devices in Control Panel/Hardware and Sound.
4. Select Add then OK.
The wizard will open:
5. Check the Bluetooth® gateway is turned on.
Click the box My device is set up and ready to be found.
Select Next.
The wizard will search…
Operating Instructions Danfoss Bluetooth® Gateway with Tool4Cool® LabEdition
10 DEHC.PS.300.D1.02
