dallmeier MDF5400HD-DN Manuel utilisateur
006834 | Rev. 1.0.1 | 2018-12-19
English
MDF5400HD-DN
Commissioning
Copyright © 2018 Dallmeier electronic GmbH & Co.KG
The reproducon, distribuon and ulizaon of this document as well as the communicaon of its contents to others without express authorizaon is prohibited.
Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor defects of the product or documentaon, e.g. print or spelling errors,
and for those not caused by intenon or gross negligence of the manufacturer.
Figures in this document may dier from the actual product.
We reserve the right to make technical modicaons.
All trademarks idened by ® are registered trademarks of Dallmeier electronic.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
HDMI of HDMI Licensing, LLC headquartered in Sunnyvale, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
microSDXC of SD-3C, LLC headquartered in North Hollywood, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in Redmond, Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA;
Phillips of Phillips Screw Company headquartered in Burlington, Massachuses, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the complete idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the respecve trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit (hp://www.openssl.org) and cryptographic soware wrien by Eric Young (eay@cryptso.com).
Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 3
Commissioning MDF5400HD-DN
Contents
1 Validity 4
2 Documents 4
This Document 4
Other Applicable Documents 5
3 TypographicalConvenons 6
4 SafetyInstrucons 8
5 General Notes 11
Scope of Delivery 11
Transportaon and Packaging 11
Warranty 11
Appropriate Use 12
Operaon 13
Approvals/Cercaons 13
6 Requirements 14
Ambient Condions 14
Power Supply 15
7 Maintenance 17
8 InstallaonandCommissioning 18
9 Interfaces 38
10 InserngaMemoryCard 40
11 Pin Assignment 42
12 ConneconandLogin 44
Connecon 45
Login 46
13 TechnicalProductSpecicaon(BasicData) 47
14 Dimensions 50
4Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
MDF5400HD-DN Commissioning
1 Validity
This document applies to the following device:
• MDF5400HD-DN
For reasons of simplicaon, the term “device” or “camera” is used in the following.
Figures in this document may dier from the actual product.
2 Documents
The product documentaon for the device contains several documents which are included in the scope of delivery in a printed form and/or on a digital
medium. Addional informaon, if available, is provided exclusively on the website www.dallmeier.com.
Read the complete product documentaon for the device carefully and thoroughly before using the device. Always observe and follow the contained
instrucons, notes and warnings as well as the technical data in the currently valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for future reference.
Regularly check the website www.dallmeier.com for the latest product documentaon updates.
This Document
Commissioning
The document entled “Commissioning” (this document) contains detailed informaon concerning the installaon, connecon and commissioning of
the device as well as safety instrucons and general notes.
The target audience of this document is trained system integrators (video security/surveillance systems installaon contractors).
Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 5
Commissioning MDF5400HD-DN
Other Applicable Documents
ProductSpecicaon
The product specicaon contains detailed technical data, features and characteriscs of the device.
The target audience of the document is trained system integrators (video security/surveillance systems installaon contractors).
Conguraon
The document entled “Conguraon” contains detailed informaon concerning the conguraon of the device.
The target audience of the document is trained system integrators (video security/surveillance systems installaon contractors).
6Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
MDF5400HD-DN Commissioning
3 TypographicalConvenons
This document may contain various warning words and symbols that indicate potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided, could result in minor or moderate injury.
NOTICE
NOTICE addresses pracces not related to physical injury and indicates measures to prevent device and/or property damage due to
improper installaon, assembly, wiring, operaon, conguraon or maintenance of the device.
Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 7
Commissioning MDF5400HD-DN
For reasons of clarity and readability, various text formang elements and types of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence described.
“Expressions” in quotaon marks usually refer to individual components of the device (housing parts, mounng elements, connecons/interfaces, etc.)
or to control elements of the device’s web-based graphical user interface (menu items, buons, etc.).
Paragraphs in italics provide informaon on basic principles, special features and ecient procedure as well as general recommendaons.
8Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
MDF5400HD-DN Commissioning
4 SafetyInstrucons
Only use the device if it is in technically perfect condion, according to the intended purpose, in a safety and hazard conscious manner and in compliance
with the following safety instrucons:
• QualiedPersonnel
The assembly, installaon, connecon, commissioning and conguraon of the device may only be carried out by qualied personnel.
This also applies to the maintenance, inspecon and repair of the device in complying with the regulaons of the DIN VDE 0701-0702 series
of standards (VDE 0701-0702: “Inspecon aer repair, modicaon of electrical appliances – Periodic inspecon on electrical appliances –
General requirements for electrical safety”).
• Regulaons
The use of video and audio security/surveillance systems is, in general, strictly regulated.
Before using the device, inform yourself about the currently valid laws and regulaons regarding data, worker and environmental protecon and
ensure compliance with them.
• System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfuncons, damage and data loss and may result in the loss of warranty.
• ModicaonstotheDevice
Do not make any modicaons to the hardware or soware of the device that have not been tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damage and data loss and may result in the loss of warranty.
Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 9
Commissioning MDF5400HD-DN
• ProductDocumentaon
The product documentaon for the device contains several documents which are included in the scope of delivery in a printed form and/or on a
digital medium. Addional informaon, if available, is provided exclusively on the website www.dallmeier.com.
Read the complete product documentaon for the device carefully and thoroughly before using the device. Always observe and follow the contained
instrucons, notes and warnings as well as the technical data in the currently valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for future reference.
Regularly check the website www.dallmeier.com for the latest product documentaon updates.
• Condensaon
If the device is brought from a cold to a warm environment, resulng condensaon may cause malfuncons and damage. In this case, wait unl the
device has reached room temperature (up to 8 hours) before commissioning.
• Earthing&EquipotenalBonding
For the safety of persons (protecon against dangerous contact voltages) and devices (protecon against over-voltages) as well as for the immunity
of informaon and communicaon technology equipment to electromagnec interferences (EMI), all protecve measures, which are specied by the
currently applicable DIN, VDE and ISO standards and which provide for a standard-compliant grounding/earthing and a correct equipotenal bonding
of electrical and electronic devices, are mandatory and must be fullled by all means.
• LightningStorms
To avoid damage to the device by electrical surge during lightning storms, all protecve measures, which are specied by the currently applicable DIN,
VDE and ISO standards and which provide for a standard-compliant lightning protecon equipotenal bonding, are mandatory and must be fullled
by all means.
10 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
MDF5400HD-DN Commissioning
• OperangCondions
Unfavorable operang condions may shorten the lifeme of the device, may cause malfuncons, damage and data loss and may result in the loss of
warranty.
Observe the specicaons given in the technical data, the operang condion requirements and the maintenance instrucons.
• ForeignBodiesintheDevice
If objects or liquids get into the device, immediately disconnect it from the power supply (pull out the power plug or disconnect the device from the
PoE enabled PSE port).
Contact the sales partner responsible for your area.
• BurntSmellfromtheDevice
If you noce burnt smell or a formaon of smoke coming from the device, immediately disconnect it from the power supply (pull out the power plug
or disconnect the device from the PoE enabled PSE port).
Contact the sales partner responsible for your area.
• Opening the Device
The device may only be opened by qualied personnel for commissioning, inspecon, maintenance and repair.
• Disposal of the Device
Do not dispose waste electrical and electronic equipment into the household trash.
Disconnect the device from the power supply.
Remove all connected peripherals.
Return the device to the sales partner responsible for your area.
