Daikin ARC423A17 Manuel utilisateur

ARC423 Series Si10-416A

108 Remote Controllers

ARC423A17, A18

Open

the

cover.

AMPM

TEMP

ON/OFF

MODE

OFF

TIMER

FAN

SWING

CANCEL

POWERFULL

Si10-416A ARC423 Series

Remote Controllers 109

1. Transmitter

It sends signals to the indoor unit.

2. Display

It displays the current settings. (In this illustration,

each section is shown with all its displays ON for the

purpose of explanation. Some models may not show

all its indications.)

3. TEMPERATURE adjustment buttons

It changes the temperature setting.

4. ON/OFF button

Press it once to start operation.

To stop it, press it once again.

5. POWERFULL button

6. MODE selector button

It selects the operation mode.

7. FAN setting button

It selects the air flow rate setting.

8. SWING button

9. ON TIMER button

10. OFF TIMER button

11. TIMER CANCEL button

It changes the temperature setting.

12. TIMER Setting button

It changes the time setting.

13. CLOCK button

: DRY

: COOL

: FAN

: AUTO

: DRY

: COOL

: HEAT

Unit operation panel and display panel

OFF

Operation lamp (green)

TIMER lamp (orange)

ON/OFF button

ARC423 Series Si10-416A

238 Operation

4. ARC423 Series

4.1 Preparation Before Operation

Setting the batteries

+–

–+

Position + and

– correctly!

Remote controller

Press with a finger and slide the front

cover to take it off.

Set two dry batteries (AAA).

Set the front cover as before.

!This will cause the figures on the display

to flash. Set the clock at this point.

Si10-416A ARC423 Series

Operation 239

O N

OFF

Receiver

Operating the remote controller

To use the remote controller, aim the transmitter at

the indoor unit. If there is anything to block signals

between the unit and the remote controller, such as

a curtain, the unit will not operate.

Do not drop the remote controller. Do not get it wet.

The maximum distance for communication is about

7 m.

!To remove, pull it upwards.

Remote

controller

holder

Set.

To fix the remote controller

holder on the wall

Choose a place from where the signals reach

the unit.

Fix the holder to a wall, a pillar, etc. with the

screws supplied with the holder.

Place the remote control in the remote control

holder.

ARC423 Series Si10-416A

240 Operation

Si10-416A ARC423 Series

Operation 241

ARC423 Series Si10-416A

242 Operation

Si10-416A ARC423 Series

Operation 243

4.2 AUTO • DRY • COOL • HEAT • FAN

Operation

The air conditioner operates with the settings of

your choice.

From the next time on, the air conditioner will

operate with the same settings.

Press

MODE

and select a mode.

!Each pressing of the button advances the

mode setting in sequence.

Display

<FLK>

<FLX>

Press

ON/OFF

Then OPERATION

lamp lights up.

"""" To stop:

Press

ON/OFF

once again.

Then OPERATION lamp goes off.

ARC423 Series Si10-416A

244 Operation

""""

To change the temperature setting:

AUTO or HEAT or COOL mode

Press to raise the temperature and

press to lower the temperature.

Set to the temperature you like.

DRY or FAN mode

The temperature

setting is not

variable.

Display

!At smaller air flow rates, the cooling effect is

also smaller.

""""

To change the air flow rate setting:

AUTO or HEAT or COOL or FAN mode

Five levels of air flow rate setting from

“ ” to “ ”plus “ ” are

available.

DRY mode

The air flow

rate setting

is not

variable.

Press

FAN

Display

Si10-416A ARC423 Series

Operation 245

NOTE

!Since this air conditioner heats the room by

taking heat from outdoor air to indoors, the

heating capacity becomes smaller in lower

outdoor temperatures. If the heating effect is

insufficient, it is recommended to use another

heating appliance in combination with the air

conditioner.

!The heat pump system heats the room by

circulating hot air around all parts of the room.

After the start of heating operation, it takes

some time before the room gets warmer.

!In heating operation, frost may occur on the

outdoor unit and lower the heating capacity. In

that case, the system switches into defrosting

operation to take away the frost.

!During defrosting operation, hot air does not

flow out of indoor unit.

!This operation dehumidifies the indoor air when

it is humid.

!In AUTO operation, the system selects a

temperature setting and an appropriate mode

(COOL or HEAT) based on the room

temperature at the start of the operation.

!The system automatically reselects setting at a

regular interval to bring the room temperature

to user-seetting level.

!If you do not like AUTO operation, you can

select manually, you like the mode and setting.
