Daewoo RC-320F Manuel utilisateur
;;;;;;
;;;;;;
;;;;;;
VACUUM CLEANER
RC-320F
READ AND KEEP THIS
• Thank you for purchasing this vacuum cleaner.
• For correct operation, please read this manual before use.
OWNER’S MANUAL
CONTENTS
•Description and operation...................2,3
•Cleaning the filter and
•Changing the dustbag.............................4
•Precautions for safe use..........................5
•Before asking for service.........................6
•Specifications .........................................6
2
DESCRIPTION AND OPERATION
HOSE CONNECTION
PIPE CONNECTION
• To connect the nozzle, hold
the tubes and the handle:
insert the narrowed section
into the wide section.
CREVICE NOZZLE
• Connecting the hose : insert the
hose firmly into the hose inlet.
(“Click”)
• Disconnecting the hose: press
the button and pull the hose out
of the vacuum cleaner.
CLICK
Crevice nozzle
(Back Board Tool)
SUCTION CONTROL
• The suction power control at
the hand grib enables you to
control suction power.
WIDE SUCTION NOZZLE
• Use this nozzle for cleaning
both carpeted and uncarpeted
floors.
3
ON/OFF SWITCH
• Press the on/off switch.
CORD REWIND BUTTON
• Rewind the power cord by
pressing the cord rewind button.
DUST METER
• When the colour of the dust
meter is changed to RED for
long time, change the dust
bag.(Page 4)
STORAGE
• When storing the vacuum
cleaner pipe and nozzle can be
attached as shown in the
picture.
PRACTICAL PARKING
• If you want to stop vacuum
cleaning for a while, you can
place the brush clip into the
rest.
VICE NOZZLE
rest
brush clip
4
CLEANING THE FILTER
CHANGING THE DUSTBAG
• Switch off • Open the cover.
• Switch off and open the cover. • Hold the cover while
separating the dustbag from
the dustbag holder.
• Shake the dust out of the filter. • Insert the filter and close the
cover. • Close the cover.
• Empty the dustbag.
• Insert the new dust bag into
the dust bag holder properly
as shown in picture.
Note: If no dustbag has been placed into the
dustbag holder, the cover cannot be closed.
EXHAUST
FILTER
MOTOR
PROTECTION FILTER
231
231
564
5
• Do not vacuum areas which contain moisture
or water and inflammable matter, needles,
pins, razor blades, matches, cigarette-ends,
etc., since they may damage the cleaner or
dust bag or cause a fire.
• Make sure a dust bag and a motor protection
filter are always inserted.
• When rewinding the power cord, hold the plug
body before pressing the cord rewind button to
prevent whipping.
• Do not pull the power cord beyond the specified
length.
• This product provided with a cable which, if
damaged, must be replaced by a repair shop
authorized by the manufacturer since special
tools are required.
This vacuum cleaner should only be used for normal dry household dust and dirt.
The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner
contrary to these instructions.
If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can be
accepted for any possible damage.
PRECAUTIONS FOR SAFE USE
6
■ Before Asking for Service, please check each item below if you have trouble with your cleaner.
BEFORE ASKING FOR SERVICE
Problem
Suction power is weak.
The cleaner does not work.
Power cord does not rewind.
Check Point
• Dust bag
• Pipe or hose
• Power cord
• on/off switch
• Power cord
Measure
If dust bag is dirty, replace it.
If clogged or blocked, remove the object.
Check if power cord is plugged.
Check if the power switch is turned on.
Pull the power cord out a little and press
the cordrewind button.
Model
Rating
Watts
Noise level
Weights(Net)
Dimension (L X W X H)
Cord Length
RC-320F
230V/50Hz
1300W
81 dB
3.8kg
446 X 284 X 217mm
5m
SPECIFICATIONS
• Specifications can be changed for improvement without notice.
