VACUUM CLEANER
RC-8O5
READ AND KEEP THIS
• Thank you for purchasing this vacuum cleaner.
• For proper operation, please read this manual before using.
OWNER'S
MANUAL
1. ASSEMBLY
DESCRIPTION AND USING
2
A. DUST METER • How to check the DUST METER
Operate the cleaner with MAX power and keep the wide suction
brush apart from the floor.
• If the red indicator of the DUST METER appears,
– Empty the cloth filter or change the paper filter bag.
– In case the hose is blocked with a large object, remove it.
• When cleaning with the crevice tool or the dusting brush, the red
indicator may apear. In this case, continue cleaning.
B. HOSE HANDLE • AIR CONTROL VALVE (MODEL : RC-805)
C. CORD REWIND
BUTTON
D. POWER CORD • Connect to the same voltage as shown on the rating label.
• To plug or unplug, grasp the plug body. Do not hold or pull the
cord.
E. ON/OFF BUTTON
F. CLEANING TOOLS • Crevice tool
• Dusting brush
G. HOSE ADAPTER • When the separating the hose from the body, pull the hose
adapter as pressing the button.
H. KEEPING • HOSE HANGER, PIPE HOLDER (MODEL : RC-805)
2. USING MODEL RC-805
3
MAX
HIGH
POWER CONTROL
MID
MIN
STOP
B
H
C D
E
F
A
G
DUST
COVER
HOSE
WIDE SUCTION
BRUSH HANDLE
GROOVE BUTTON
PIPE HOLDER
HOSE HANGER
CREVICE
TOOL
DUSTING
BRUSH
ROTATE
This vacuum cleaner should only be used for normal dry houshold dust and dirt.
The manufacturer cannot be held responsible for any damage caused by use or operation of the
cleaner contrary to these instructions.
If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability
can be accepted for any possible damage.
PRECAUTIONS FOR SAFE USE
4
RED MARK
HOSE
• Do not vacuum areas which contain
moisture or water and inflammable matter,
needles, pins, razor blades, matches,
cigarette-ends, etc., since they may damage
the cleaner or filter bag or make fire.
• When rewinding the power cord, hold the
plug body before pressing the cord rewind
button to prevent whipping.
• Do not pull the power cord out beyond the
specified length.
• Make sure a filter bag and a motor protection
filter are always inserted. • This product provided with a cable which, if
damaged, must be replaced by a repair shop
auhorized by the manufacturer since special
tools are required.
• This hose (Model RC-805H) contains
electrical connections.
– Do not use to suck up water.
– Do not immerse in water for cleaning.
– The hose should be checked regularly and
must not be used if damaged.
• Do not pull the dust cover back excessively.
In case the dust cover is taken out of the
body. Fit it in place.
REPLACING THE FILTER
5
Gitter
Filter
• Open the grille and take the filter out of the grille.
• Replace the soiled filter by the new one.
REPLACING THE FILTER BAG
Staubbeute-
lhalterung
Führung-
sschiene
Haken Kartonseite
Deckel
• Open the dust cover and push the filter bag holder in the direction of the arrow mark, and then
take out the filter bag.
• When inserting the filter bag, place the board of the filter bag between the two guides and
insert the lower part of it into the bottom hooks and fix the upper part of it with the filter bag
holder.
• The dust cover can not be closed completely when the filter bag is set wrong.
• If DAEWOO filter bag is not reserved. PHILIPS paper filter bag (OSLO series) may be used.
Please check each item below if you have trouble with your cleaner.
Before checking, ensure the the cleaner is unpluged from the power supply.
BEFORE ASKING FOR SERVICE
6
PROBLEM CHECK POINT MEASURE
• Suction power is weak. • Filter bag
• Hose
• If it is filled with dust,
change it.
• If clogged or blocked,
remove the object.
• The cleaner does not work. • Is the hose adapter inserted
into the suction opening of
the cleaner completely?
• When the filter bag is full or
blocked or any of the
accessories are blocked,
the overheating protection
for the motor is activated
automatically.
• Insert it completly.
• Switch off and unplug the
cleaner and check the dust
bag and accessories and
remove any blockages.
The cleaner can be
switched on again after
about 30 minutes.
• Power cord does not rewind.
• Power cord is not pulled out
of the cleaner
• Power cord
• Power cord
• Pull the power cord out a
little and press the cord
rewind button.
• Do not pull it by force
Rewind it a little by
pressing the cord rowind
button and pull it out.
SPECIFICATIONS
7
Model RC-805H
Rating 230V/50Hz
Input watt Max 1300 W, CEE 1100 W
Weight (Body) 5.2 kg
Dimension (L x H x D) 474 x 221 x 283 mm
Cord Length 6 m
