DA-LITE SCREEN COMPANY, INC.

3100 North Detroit Street

Post Office Box 137

Warsaw, Indiana 46581-0137

Phone: 574-267-8101

800-622-3737

Fax: 574-267-7804

Toll Free Fax: 877-325-4832

www.da-lite.com

e-mail: [email protected]

POWER

PRESENTATION PRODUCTS

The

Operating Instructions for

MODEL C

WALL MOUNTING

TO OPEN SCREEN

Pull down on pull bail until desired picture area is obtained. Lock into position as on a window shade. Be sure surface is

locked before releasing.

1. Select fasteners of proper type for wall or ceiling involved.

2. Insert fasteners through proper openings provided in back side of end caps.

3. Attach screen securely to studding or other solid surface - never to plaster only.

4. MAKE SURE SCREEN IS MOUNTED LEVEL.

YOU HAVE MADE A WISE SELECTION…

in choosing a Da-Lite projection screen, designed and engineered to produce the sharpest,

most pleasing pictures with maximum convenience.

CEILING MOUNTING

1. Heavy screw hooks may be installed into wood joists. Other types of hooks or chain may be used for other ceilings or

for stage installations.

2. Insert hooks or chain through proper openings provided in sides of end caps. Screen must hang so that flat back of

case is perpendicular to floor.

3. MAKE SURE SCREEN IS MOUNTED LEVEL.

TO RE-ROLL YOUR PICTURE SURFACE

The Model C operates on the same principle as a window shade. Pull down about 4 inches to disengage the locking dog

and start the fabric up firmly and quickly.

Large picture surfaces are heavy and will start up too slowly to prevent the locking dog from catching unless help is

provided, so keep picture surface moving briskly.

Should the locking dog catch, pull the picture surface down about 4 inches and start the surface up rapidly.

However, do not permit the picture surface to roll up uncontrolled, particularly the last few feet. Allowing the bottom slat

to strike the case uncontrolled may result in severe damage to your screen. Use the cord provided for control.

PROTECT YOUR SCREEN

Before re-rolling surface into case, examine both front and back of surface to be sure they are free of foreign matter.

SUGGESTED METHODS OF INSTALLATION

MODEL C EXCLUSIVE FEATURES

•Easily Installed

•Multi-Purpose End Caps Form Sturdy Brackets for Wall/Ceiling Installation

•Aluminum Slat Saddle Distributes Uniform Tension on Picture Surface

•Heavy Duty Grooved Metal Roller Assures Permanent Fastening of Picture Surface

•Nylon and Ball Bearing Roller Mounting

•Handsome, Rugged, Powder Coated Steel Case

•Floor Stand Accessory

Floating Mounting Brackets

Ceiling Trim Kit

(optional at extra cost)

FOR WALL

FOR

CEILING

WALL MOUNTED

PICTURE SURFACE

CEILING HANGING

PICTURE SURFACE

USE No. 6 BRACKETS TO HANG

BEHIND BEAM OR VALANCE


SURFACE

CONCEALED

(ALLOW ROOM FOR ACCESS)

TO USE WITH PORTABLE FLOOR STAND

NOTE: CAN ONLY BE USED WITH FLOOR MODEL C. WALL SCREENS WILL NOT OPERATE CORRECTLY.

1. Assemble stand according to instructions.

2. Lay screen in cradle of stand with pull bail up.

3. Lift surface by pull bail and hook pull bail over gooseneck of elevating support.

4. Raise upper handle of elevating support until it locks in top position.

5. Raise lower handle of elevating support until full picture area is obtained and locked in position. No stretching, no

straining.

6. Stand may be placed on table if extra height is needed.

HANGING BRACKETS

(Optional at extra cost)

MODEL C

FLOOR STAND

No. 11 Wall Bracket

Non-Adjustable permits

screen to extend 10" or

14" from wall.

No. 6 Wall Bracket

Non-Adjustable permits

screen to extend 6"

from wall.

DA-LITE IS MORE THAN PROJECTION SCREENS

Da-Lite Tripod, Wall and

Ceiling and Electric Screens

Da-Lite Lecterns

Da-Lite

Project-O-Stands

and Easels

Da-Lite

Mounting Systems

Printed in U.S.A. 46422 Rev. 11/08
